Milnor PulseFlow 76028 G3 Manual

Published Manual Number/ECN: MPI39G3PAE/2019416A
• Publishing System: TPAS2
• Access date: 10/22/2019
• Document ECNs: NOT latest
Installation and Service
76028 & 76039 G3
PulseFlow® Continuous
Batch Washers
PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.

Table of Contents
MPI39G3PAE/19416A
Page Description Document
1 Limited Standard Warranty BMP720097/2019036
2 How to Get the Necessary Repair Components BIUUUD19/20081231
3 Trademarks BNUUUU02/2017285A
5 1. Safety and Maintenance
6 Safety—Continuous Batch Washer BIUUUS27PC/20051111
11 Safety Placard Use and Placement 76028,76039G3 CBW
& 9248G4 CBW BMP040038/2004313V
13 Safety Placard Use and Placement ISO 76028,76039 G3
CBW & 9248 G4 CBW BMP040039/2004313V
15 Safety Placard Use and Placement Mentor Controller for
CBW BMP040040/2004313V
17 Safety Placard Use and Placement ISO Mentor Controller
for CBW BMP040041/2004313V
19 Safety Placard Use and Placement Inverter Box for CBW BMP040042/2004313V
21 Safety Placard Use and Placement ISO Inverter Box for
CBW BMP040043/2004313V
23 Safety Placard Use and Placement Typical All CBW
Auxiliary Tanks BMP040046/2004313V
25 Safety Placard Use and Placement ISO Typical All CBW
Auxiliary Tanks BMP040047/2004313V
27 Proximity Safeguarding for Automatic Shuttle Conveyors BISUUI01/20171205
31 Connecting Ancillary Equipment and Services BIPCUI02/20160113
35 Tag Guidelines BIUUUI02PL/20170824
40 Prevent Damage from Chemical Supplies and Chemical
Systems BIWUUI03/2019296A
45 Torque Requirements for Fasteners BIUUUM04/20180109
53 2. Installation
54 Attention Installers! Press, Tunnel Installation B2T2010023/2019193A
55 Tips for Connectiong Tunnel Units on Site BIPCLI02/20140226
57 3. Parts and Assemblies
59 3.1. Covers and Shipping Brackets
60 Cover Installation BMP000075/2001444V
61 Tunnel Feet & Shipping Brackets BMP000078/2018224A
63 3.2. Drive Assemblies
64 Drive Chart BMP000026/2008184B
66 Chain Tensioner BMP000027/2008184B
68 Chain Oiler BMP110071/2013102A
70 Support Roller Assembly - 76028 & 76039G3; 92048G4
Tunnels BMP000030/2011474B

Table of Contents, continued
MPI39G3PAE/19416A
Page Description Document
72 Guide Roller Assembly - 76028 & 76039G3; 92048G4
Tunnels BMP000031/2011474B
74 Unit to Unit Drive Coupling BMP000036/2001225V
76 Gear Reducer with Chain Coupling - 76028 & 76039 G3
Tunnels BMP000033/2010052B
78 Replacing G3 Drive Chain Couplings BIPCLM01/2000162N
82 Drive Train Service BIPCLM02/20020430
87 Proximity Switch & Target Installation BMP000034/2001015V
90 Setting Rotation Limit Switch Positions on 76028 and
76039 Tunnel Washers MSSMD446AE/199637AV
93 3.3. Load Chute and Seals
94 Load Chute and Seal Installation - 76028 & 76039G3;
92048G4 Tunnel BMP110060/2011483B
98 Water Collectors - 76028G3, 76039G3, & 92048G4 BMP000035/2011444B
100 Unit to Unit Transition Seal Installation BMP940101/2014096B
101 Tension Seal Assembly - 76028 & 76039G2 & G3;
92048G4 Tunnels BMP840026/2011474B
103 3.4. Water, Steam and Peristaltic
104 Pulse Flow® Water Options: Schematic and Piping 76028,
76039, 92048 Tunnels BMP170012/2019416A
117 Standard Large Split PulseFlow® Tank BMP180011/2018224A
124 Pulse Flow Tank Fresh Water Piping 76028G3, 76039G3,
92048G4 BMP110063/2017302A
127 Steam to PulseFlow® Tank BPTPUS01/2017302A
128 Level Box Drain Options 76028 & 76039 G3 Tunnels BMP000077/2017455B
131 Level Box & Flow Options 92048G4 PulseFlow® Tunnels
and 76039G3 PulseFlow® II (EXD) Tunne BMP110073/2018224A
134 Level Box Lid & Latches BMP180013/2018224A
136 Level Switch BMP180012/2018224A
137 Drain Stops - 76028 & 76039G3; 92048G4 Tunnel BMP100024/2011494B
138 Drain Stop Bonnet, 4” Double Acting - 76028G3, 76039G3,
& 9248G4 BMP100025/2010203B
139 Dump Valve Installation 76032, 76028, 76039, 92048
Tunnels BMP000072/2018013A
141 Dump Valve Bonnet - 76028 & 76039G3; 92048G4 Tunnel BMP000073/2011494B
143 Dump Valve Bonnet - Normally Closed BMP970067/2001444V
145 Steam Componenets with No-Air Sparger BMP180015/2018224A
149 Peristaltic Chemical Inlets 76028G3, 76039G3, 92048G4
Tunnels BMP180016/2019416A

Table of Contents, continued
MPI39G3PAE/19416A
Page Description Document
151 Magmeter BMP110014/2011085B
152 Optional De-linting Tank BMP180014/2018224A
155 3.5. Pneumatics
156 Pneumatic Shuttle Valve BMP080032/2008462B
157 4. Dimensional Drawings
159 Dimensional Drawing - 76028G3 PF Tunnel 3 Module BDPF28G3M3DDE/2018125D
160 Dimensional Drawing - 76028G3 PF Tunnel 4 Module BDPF28G3M4DDE/2018125D
161 Dimensional Drawing - 76028G3 PF Tunnel 5 Module BDPF28G3M5DDE/2018125D
162 Dimensional Drawing - 76028G3 PF 5 Module Standalone BDPF28G3M5SDDE/2018125D
163 Dimensional Drawing - 76028G3 PF Tunnel Options BDPF28G3OPDDE/2018125D
165 Dimensional Drawing - 76028G3 PF Venting BDPF28G3VTDDE/2018125D
167 Dimensional Drawing - Foundation 76028G3 PF Tunnels BDPF28G3FBDDE/2018125D
169 Dimensional Drawing - 76028G3 PF Shipping Brackets BDPF28G3SBDDE/2018125D
171 Dimensional Drawing - 76028G3 PF & MP2501 BDPF28G3INDDA/2018125D
172 Dimensional Drawing - 76028G3 PF & MP2601 BDPF28G3INDDB/2018125D
173 Dimensional Drawing - 76028G3 PF & MMT42032,
MXT42032 BDPF28G3INDDE/2018125D
174 Dimensional Drawing - 76028G3 PF & MP1540, MP1556,
MP1640, MP1656 BDPF28G3INDGC/2018125D
175 Dimensional Drawing - 76039G3 PF Tunnel, 3 Module BDPF39G3M3DDE/2019064D
176 Dimensional Drawing - 76039 PF Tunnel , 4 Module BDPF39G3M4DDE/2019064D
177 Dimensional Drawing - 76039G3 PF Options BDPF39G3OPDDE/2018125D
179 Dimensional Drawing - 76039G3 PF Venting BDPF39G3VTDDE/2018125D
181 Dimensional Drawing - 76039G3 PF Tunnel Foundation BDPF39G3FBDDE/2018125D
183 Dimensional Drawing - 76039G3 PF Shipping Brackets BDPF39G3SBDDE/2018125D
185 Dimensional Drawing -76028/76039G3 PF Tunnels Drain
Trough BDPF39G3DTDDE/2018125D
187 Dimensional Drawing - 76039G3 PF & MP2501 BDPF39G3INDDA/2018125D
188 Dimensional Drawing - 76039G3 PF & MP2601 BDPF39G3INDDB/2018125D
189 Dimensional Drawing - 76039G3 PF & MMT42032,
MXT42032 BDPF39G3INDDE/2018125D
190 Dimensional Drawing - 76039G3 PF & M7T4840, M9T4840 BDPF39G3INDDF/2018125D
191 Dimensional Drawing - 76039G3 PF & MP1540, MP1556,
MP1640, MP1656 BDPF39G3INDGC/2018125D
193 Dimensional Drawing - Module Recirculation Lint Tank BDMRLTNKAE/2011473D

BMP720097/19036
PELLERIN MILNOR CORPORATION
LIMITED STANDARD WARRANTY
We warrant to the original purchaser that MILNOR machines including electronic hardware/software
(hereafter referred to as “equipment”), will be free from defects in material and workmanship for a
period of one year from the date of shipment (unless the time period is specifically extended for
certain parts pursuant to a specific MILNOR published extended warranty) from our factory with no
operating hour limitation. This warranty is contingent upon the equipment being installed, operated
and serviced as specified in the operating manual supplied with the equipment, and operated under
normal conditions by competent operators.
Providing we receive written notification of a warranted defect within 30 days of its discovery, we
will—at our option—repair or replace the defective part or parts, EX Factory (labor and freight
specifically NOT included). We retain the right to require inspection of the parts claimed defective in
our factory prior to repairing or replacing same. We will not be responsible, or in any way liable, for
unauthorized repairs or service to our equipment, and this warranty shall be void if the equipment is
tampered with, modified, or abused, used for purposes not intended in the design and construction
of the machine, or is repaired or altered in any way without MILNOR's written consent.
Parts damaged by exposure to weather, to aggressive water, or to chemical attack are not covered
by this warranty. For parts which require routine replacement due to normal wear—such as gaskets,
contact points, brake and clutch linings, belts, hoses, and similar parts—the warranty time period is
90 days.
We reserve the right to make changes in the design and/or construction of our equipment (including
purchased components) without obligation to change any equipment previously supplied.
ANY SALE OR FURNISHING OF ANY EQUIPMENT BY MILNOR IS MADE ONLY UPON THE EXPRESS
UNDERSTANDING THAT MILNOR MAKES NO EXPRESSED OR IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR USE OR PURPOSE OR ANY OTHER
WARRANTY IMPLIED BY LAW INCLUDING BUT NOT LIMITED TO REDHIBITION. MILNOR WILL NOT
BE RESPONSIBLE FOR ANY COSTS OR DAMAGES ACTUALLY INCURRED OR REQUIRED AS A RESULT
OF: THE FAILURE OF ANY OTHER PERSON OR ENTITY TO PERFORM ITS RESPONSIBILITIES, FIRE
OR OTHER HAZARD, ACCIDENT, IMPROPER STORAGE, MIS-USE, NEGLECT, POWER OR
ENVIRONMENTAL CONTROL MALFUNCTIONS, DAMAGE FROM LIQUIDS, OR ANY OTHER CAUSE
BEYOND THE NORMAL RANGE OF USE. REGARDLESS OF HOW CAUSED, IN NO EVENT SHALL
MILNOR BE LIABLE FOR SPECIAL, INDIRECT, PUNITIVE, LIQUIDATED, OR CONSEQUENTIAL COSTS
OR DAMAGES, OR ANY COSTS OR DAMAGES WHATSOEVER WHICH EXCEED THE PRICE PAID TO
MILNOR FOR THE EQUIPMENT IT SELLS OR FURNISHES.
THE PROVISIONS ON THIS PAGE REPRESENT THE ONLY WARRANTY FROM MILNOR AND NO OTHER
WARRANTY OR CONDITIONS, STATUTORY OR OTHERWISE, SHALL BE IMPLIED.
WE NEITHER ASSUME, NOR AUTHORIZE ANY EMPLOYEE OR OTHER PERSON TO ASSUME FOR US,
ANY OTHER RESPONSIBILITY AND/OR LIABILITY IN CONNECTION WITH THE SALE OR FURNISHING
OF OUR EQUIPMENT TO ANY BUYER.
1

How to Get the Necessary Repair Components
PELLERIN MILNOR CORPORATION
BIUUUD19 (Published) Book specs- Dates: 20081231 / 20081231 / 20081231 Lang: ENG01 Applic: UUU
How to Get the Necessary Repair Components
This document uses Simplified Technical English.
Learn more at http://www.asd-ste100.org.
You can get components to repair your machine from the approved supplier where you got this
machine. Your supplier will usually have the necessary components in stock. You can also get
components from the Milnor®factory.
Tell the supplier the machine model and serial number and this data for each necessary component:
• The component number from this manual
• The component name if known
• The necessary quantity
• The necessary transportation requirements
• If the component is an electrical component, give the schematic number if known.
• If the component is a motor or an electrical control, give the nameplate data from the used
component.
To write to the Milnor factory:
Pellerin Milnor Corporation
Post Office Box 400
Kenner, LA 70063-0400
UNITED STATES
Telephone: [phone]
Fax: [phone]
Email: [email protected]
— End of BIUUUD19 —
2

Pellerin Milnor Corporation
Trademarks BNUUUU02.R01 0000158093 A.2 7/13/17 1:11 PM Released
These words are trademarks of Pellerin Milnor Corporation and other entities:
Table 1 Trademarks
AutoSpot™ GreenTurn™ Milnor® PulseFlow®
CBW® GreenFlex™ MilMetrix® PurePulse®
Drynet™ Hydro-cushion™ MilTouch™ Ram Command™
E-P Express® Linear Costa Master™ MilTouch-EX™ RecircONE®
E-P OneTouch® Linear Costo™ Miltrac™ RinSave®
E-P Plus® Mentor® MultiTrac™ SmoothCoil™
Gear Guardian® Mildata® PBW™ Staph Guard®
End of document: BNUUUU02
BNUUUU02 / 2017285A BNUUUU02 0000158094 A.3 7/13/17 1:53 PM Released
3

Safety and Maintenance 1
5

Safety—Continuous Batch Washer
PELLERIN MILNOR CORPORATION
BIUUUS27 (Published) Book specs- Dates: 20051111 / 20051111 / 20060323 Lang: ENG01 Applic: PCU
Safety—Continuous Batch Washer
1. General Safety Requirements—Vital Information for
Management Personnel[Document BIUUUS04]
Incorrect installation, neglected preventive maintenance, abuse, and/or improper repairs, or
changes to the machine can cause unsafe operation and personal injuries, such as multiple
fractures, amputations, or death. The owner or his selected representative (owner/user) is
responsible for understanding and ensuring the proper operation and maintenance of the machine.
The owner/user must familiarize himself with the contents of all machine instruction manuals.
The owner/user should direct any questions about these instructions to a Milnor® dealer or the
Milnor® Service department.
Most regulatory authorities (including OSHA in the USA and CE in Europe) hold the owner/user
ultimately responsible for maintaining a safe working environment. Therefore, the owner/user
must do or ensure the following:
• recognize all foreseeable safety hazards within his facility and take actions to protect his
personnel, equipment, and facility;
• work equipment is suitable, properly adapted, can be used without risks to health or safety,
and is adequately maintained;
• where specific hazards are likely to be involved, access to the equipment is restricted to those
employees given the task of using it;
• only specifically designated workers carry out repairs, modifications, maintenance, or
servicing;
• information, instruction, and training is provided;
• workers and/or their representatives are consulted.
Work equipment must comply with the requirements listed below. The owner/user must verify
that installation and maintenance of equipment is performed in such a way as to support these
requirements:
• control devices must be visible, identifiable, and marked; be located outside dangerous zones;
and not give rise to a hazard due to unintentional operation;
• control systems must be safe and breakdown/damage must not result in danger;
• work equipment is to be stabilized;
• protection against rupture or disintegration of work equipment;
• guarding, to prevent access to danger zones or to stop movements of dangerous parts before
the danger zones are reached. Guards to be robust; not give rise to any additional hazards; not
be easily removed or rendered inoperative; situated at a sufficient distance from the danger
zone; not restrict view of operating cycle; allow fitting, replacing, or maintenance by
restricting access to relevant area and without removal of guard/protection device;
• suitable lighting for working and maintenance areas;
• maintenance to be possible when work equipment is shut down. If not possible, then
protection measures to be carried out outside danger zones;
• work equipment must be appropriate for preventing the risk of fire or overheating; discharges
of gas, dust, liquid, vapor, other substances; explosion of the equipment or substances in it.
6

Safety—Continuous Batch Washer
PELLERIN MILNOR CORPORATION
1.1. Laundr
y
Facilit
y
—Provide a supporting floor that is strong and rigid enough to support–with
a reasonable safety factor and without undue or objectionable deflection–the weight of the fully
loaded machine and the forces transmitted by it during operation. Provide sufficient clearance fo
r
machine movement. Provide any safety guards, fences, restraints, devices, and verbal and/or
posted restrictions necessary to prevent personnel, machines, or other moving machinery from
accessing the machine or its path. Provide adequate ventilation to carry away heat and vapors.
Ensure service connections to installed machines meet local and national safety standards,
especially regarding the electrical disconnect (see the National Electric Code). Prominently post
safety information, including signs showing the source of electrical disconnect.
1.2. Personnel—Inform personnel about hazard avoidance and the importance of care and
common sense. Provide personnel with the safety and operating instructions that apply to them.
Verify that personnel use proper safety and operating procedures. Verify that personnel
understand and abide by the warnings on the machine and precautions in the instruction manuals.
1.3. Safety Devices—Ensure that no one eliminates or disables any safety device on the machine
or in the facility. Do not allow machine to be used with any missing guard, cover, panel or door.
Service any failing or malfunctioning device before operating the machine.
1.4. Hazard Information—Important information on hazards is provided on the machine safety
placards, in the Safety Guide, and throughout the other machine manuals. Placards must be kept
clean so that the information is not obscured. They must be replaced immediately if lost or
damaged. The Safety Guide and other machine manuals must be available at all times to
the appropriate personnel. See the machine service manual for safety placard part numbers.
Contact the Milnor Parts department for replacement placards or manuals.
1.5. Maintenance—Ensure the machine is inspected and serviced in accordance with the norms of
good practice and with the preventive maintenance schedule. Replace belts, pulleys, brake
shoes/disks, clutch plates/tires, rollers, seals, alignment guides, etc. before they are severely
worn. Immediately investigate any evidence of impending failure and make needed repairs (e.g.,
cylinder, shell, or frame cracks; drive components such as motors, gear boxes, bearings, etc.,
whining, grinding, smoking, or becoming abnormally hot; bending or cracking of cylinder, shell,
frame, etc.; leaking seals, hoses, valves, etc.) Do not permit service or maintenance by
unqualified personnel.
2. Safety Alert Messages—Internal Electrical and Mechanical
Hazards[Document BIUUUS11]
The following are instructions about hazards inside the machine and in electrical enclosures.
WARNING 1 : Electrocution and Electrical Burn Hazards—Contact with electric powe
r
can kill or seriously injure you. Electric power is present inside the cabinetry unless the main
machine power disconnect is off.
• Do not unlock or open electric box doors.
• Do not remove guards, covers, or panels.
• Do not reach into the machine housing or frame.
• Keep yourself and others off of machine.
• Know the location of the main machine disconnect and use it in an emergency to remove
all electric power from the machine.
7

Safety—Continuous Batch Washer
PELLERIN MILNOR CORPORATION
WARNING 2 : Entangle and Crush Hazards—Contact with moving components normally
isolated by guards, covers, and panels, can entangle and crush your limbs. These components
move automatically.
• Do not remove guards, covers, or panels.
• Do not reach into the machine housing or frame.
• Keep yourself and others off of machine.
• Know the location of all emergency stop switches, pull cords, and/or kick plates and use
them in an emergency to stop machine motion. These may not stop certain devices such
as pumps on some machines.
CAUTION 3 : Burn Hazards—Contact with hot goods or machine components can burn you.
• Do not remove guards, covers, or panels.
• Do not reach into the machine housing or frame.
3. Safety Alert Messages—External Mechanical Hazards[Document
BIUUUS12]
The following are instructions about hazards around the front, sides, rear or top of the machine.
4. Safety Alert Messages—Cylinder and Processing Hazards
[Document BIUUUS13]
The following are instructions about hazards related to the cylinder and laundering process.
WARNING 4 : Confined Space Hazards—Confinement in the cylinder can kill or injure
you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration,
biological contamination, electrocution, and crushing.
• Do not attempt unauthorized servicing, repairs, or modification.
WARNING 5 : Explosion and Fire Hazards—Flammable substances can explode or ignite
in the cylinder, drain trough, or sewer. The machine is designed for washing with water, not any
other solvent. Processing can cause solvent-containing goods to give off flammable vapors.
• Do not use flammable solvents in processing.
• Do not process goods containing flammable substances. Consult with your local fire
department/public safety office and all insurance providers.
5. Safety Alert Messages—Unsafe Conditions[Document BIUUUS14]
5.1. Damage and Malfunction Hazards
5.1.1. Hazards Resulting from Inoperative Safety Devices
WARNING 6 : Multiple Hazards—Operating the machine with an inoperative safety device
can kill or injure personnel, damage or destroy the machine, damage property, and/or void the
warranty.
• Do not tamper with or disable any safety device or operate the machine with a
malfunctioning safety device. Request authorized service.
8

Safety—Continuous Batch Washer
PELLERIN MILNOR CORPORATION
WARNING 7 : Electrocution and Electrical Burn Hazards—Electric box doors—
Operating the machine with any electric box door unlocked can expose high voltage conductors
inside the box.
• Do not unlock or open electric box doors.
WARNING 8 : Entangle and Crush Hazards—Guards, covers, and panels—Operating the
machine with any guard, cover, or panel removed exposes moving components.
• Do not remove guards, covers, or panels.
5.1.2. Hazards Resulting from Damaged Mechanical Devices
WARNING 9 : Multiple Hazards—Operating a damaged machine can kill or injure
personnel, further damage or destroy the machine, damage property, and/or void the warranty.
• Do not operate a damaged or malfunctioning machine. Request authorized service.
CAUTION 10 : Machine Damage Hazards—Drive shaft and drive motors—Although the
tunnel may operate with drive shafts disconnected between modules or units, or with a motor not
functioning, the added stress on drive components will quickly damage the machine.
• Do not operate the machine with any evidence of damage or malfunction.
5.2. Careless Use Hazards
5.2.1. Careless Operation Hazards—Vital Information for Operator Personnel
(
see also
operator hazards throughout manual)
WARNING 11 : Multiple Hazards—Careless operator actions can kill or injure personnel,
damage or destroy the machine, damage property, and/or void the warranty.
• Do not tamper with or disable any safety device or operate the machine with a
malfunctioning safety device. Request authorized service.
• Do not operate a damaged or malfunctioning machine. Request authorized service.
• Do not attempt unauthorized servicing, repairs, or modification.
• Do not use the machine in any manner contrary to the factory instructions.
• Use the machine only for its customary and intended purpose.
• Understand the consequences of operating manually.
CAUTION 12 : Goods Damage and Wasted Resources—Entering incorrect cake data
causes improper processing, routing, and accounting of batches.
• Understand the consequences of entering cake data.
5.2.2. Careless Servicing Hazards—Vital Information for Service Personnel (see also
service hazards throughout manuals)
WARNING 13 : Electrocution and Electrical Burn Hazards—Contact with electric
power can kill or seriously injure you. Electric power is present inside the cabinetry unless the
main machine power disconnect is off.
• Do not service the machine unless qualified and authorized. You must clearly understand
the hazards and how to avoid them.
• Abide by the current OSHA lockout/tagout standard when lockout/tagout is called for in
the service instructions. Outside the USA, abide by the OSHA standard in the absence of
9

Safety—Continuous Batch Washer
PELLERIN MILNOR CORPORATION
any other overriding standard.
WARNING 14 : Entangle and Crush Hazards—Contact with moving components
normally isolated by guards, covers, and panels, can entangle and crush your limbs. These
components move automatically.
• Do not service the machine unless qualified and authorized. You must clearly understand
the hazards and how to avoid them.
• Abide by the current OSHA lockout/tagout standard when lockout/tagout is called for in
the service instructions. Outside the USA, abide by the OSHA standard in the absence of
any other overriding standard.
WARNING 15 : Confined Space Hazards—Confinement in the cylinder can kill or injure
you. Hazards include but are not limited to panic, burns, poisoning, suffocation, heat prostration,
biological contamination, electrocution, and crushing.
• Do not enter the cylinder until it has been thoroughly purged, flushed, drained, cooled,
and immobilized.
• Abide by the confined space entry procedures in the reference manual.
— End of BIUUUS27 —
10

RPellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400 Litho in U.S.A.
BMP040038/2004313V
(Sheet 1 of 2)
Safety Placard Use and Placement 76028,76039 G3 CBW & 92048 G4 CBW
Notes: 1
. Approximate locations of placards are shown.
Mounting holes are provided on machine. If aluminum placard use #8 self-tapping screws.
. Replace placard immediately, if removed or
unreadable.
2
FRONT VIEW
REAR VIEW
LOAD END
DISCHARGE END
LEFT VIEW
RIGHT VIEW
1ST SECTION
1ST SECTION
LAST SECTION
LAST SECTION
*
10
10
10
20
20
30
11

RPellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400 Litho in U.S.A.
Item
Part Number Description Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers(1,2,3,etc.)assignedtocomponentsrelatethepartslisttotheillustration.
Parts List—Safety Placard Placement
BMP040038/2004313V
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
none
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 10 01 10511A NPLT:CBW END HAZARD-TCATA
all 20 01 10377A NPLT:ELEC HAZARD LG-TCATA
all 30 01 10699B NPLT:SERV HZRD-ALUM-TCATA
12

RPellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400 Litho in U.S.A.
BMP040039/2004313V
(Sheet 1 of 2)
Safety Placard Use and Placement ISO 76028,76039 G3 CBW & 92048 G4 CBW
ISO Placards shown on this page
10
Notes: 1
. Approximate locations of placards are shown.
Mounting holes are provided on machine. If aluminum placard use #8 self-tapping screws.
. Replace placard immediately, if removed or
unreadable.
2
FRONT VIEW
REAR VIEW
LOAD END
DISCHARGE END
LEFT VIEW
RIGHT VIEW
1ST SECTION
1ST SECTION
LAST SECTION
LAST SECTION
*
10
20
20
13

RPellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400 Litho in U.S.A.
Item
Part Number Description Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers(1,2,3,etc.)assignedtocomponentsrelatethepartslisttotheillustration.
Parts List—Safety Placard Placement
BMP040039/2004313V
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
none
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 10 01 10511X NPLT:CBW WARNINGS
all 20 01 10377 NPLTE:"WARNING" 4X4
14
