Milwaukee HEAVY DUTY M12 BHCS3L User manual

M12 BHCS3L
Original instructions

2 3
4
6
24
5
16
10
9
8
22
7
14
START
STOP
1312
Text section with Technical Data,
important Safety and Working Hints
and description of Symbols
26

4 5
1
1
2
2
Remove the battery pack
before starting any work on the
machine.
click
100% 75% 50% 25%

6 7
1
2

8 9
1ON
2OFF
l/min l/min
1 0,38 0,38
2 0,76 0,76
3 1,14 1,14
click

10 11
START
STOP
click
click

12 13
Remove nozzle (1) counterclockwise by hand.
Clean nozzle (1) and filter (2) after each use.
Insert filter (2) and mount nozzle clockwise by hand.
Remove nozzle attachment (1) counterclockwise by hand.
Nozzle attachments are available as spare parts.
See www.milwaukeetool.eu.
Mount nozzle attachment (1) clockwise by hand.
2
1
11
1

14 15
1
2
7
5
6
2
1
8
4
3
2
1
Max
3,7 l

16 17
1
2
3
4
5
2
1
1
2
Only fill residual liquid in an original
container or a designated container.
National and local regulations must be
observed.
Write content here!
CHEMICAL

18 19
8
6
7
3
Clean filter (1), filter (2) and tank (3) after each use.
Filters are available as spare parts.
See www.milwaukeetool.eu.
1
2

20 21
11
12
9
10
2
1
1
2
13

22 23
1 3
2
click

24 25

26 27
M12 BHCS3L
4914 65 01 XXXXXX MJJJJ
12 V
3,7 l
0,38 / 0,76 / 1,14 l/min
5,2 m
5,51 bar / 551 kPA
40 ml
Ø 1,7 mm x 248
Ø 0,3 mm x 460
2,87 kg
3,3 ... 3,5 kg
7,0 kg
0...+51 °C
M12B...
C12C; M12-18...; M12C4; M12TC
57 dB(A) / 3 dB(A)
68 dB(A) / 3 dB(A)
0,289 m/s2/ 1,5 m/s2
ENGLISH
TECHNICAL DATA
Type
Production code
Battery voltage
Tank capacity
Flow rate 1 / 2 / 3
Spray distance
Max working pressure
Residual tank
Mesh size filler filter
Mesh size suction filter
Weight base unit
Empty weight (including baseunit, tank, battery 2.0 ... 6.0 Ah)
Operation weight (including 3,7 l fluid at 20 °C with battery 2.0)
Recommended ambient operating temperature
Recommended battery types
Recommended charger
Noise Information:
Measured values determined according to EN 62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level / Uncertainty K
Sound power level / Uncertainty K
Wear ear protectors.
Vibration Information:
Total vibration values (vector sum in the three axes) determined
according to EN 62841.
Vibration emission value ah/ Uncertainty K
WARNING! Read all safety warnings, instructions,
illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
HANDHELD CHEMICAL SPRAYER SAFETY WARNINGS
Do not spray flammable liquids, such as gasoline, to reduce the risk
of fire or explosion.
Always follow the chemical manufacturer’s instructions printed on their
product labeling for use, cleaning, and storage. Chemicals should be
stored out of the reach of children.
Do not spray any material where the hazard is not known.
To reduce exposure to spray materials, wear approved safety
equipment, such as face mask designed for spraying, gloves, and
other appropriate protective equipment.
Do not use flammable solvents or abrasive cleaning agents to clean
the product.
Keep spray materials away from eyes. If spray materials come in
contact with the eyes, wash them immediately with clean water. If
irritation is still present, immediately seek medical help.
During filling and emptying power unit needs to be removed from the
tank.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Be aware of any hazards presented by the material being sprayed
and instruction to consult the markings on the container or the
information supplied by the manufacturer of the material to be
sprayed.
Keep the area clear of all bystanders, children, and pets while
spraying.
Ensure that the spray wand is securely connected to the spray wand
handle before using the product. If necessary, use pliers to attach the
spray wand to the spray wand handle.
Remember to properly replace and tighten the spray tank cover after
pouring liquid into the spray tank.
Use only consumer-grade water-based lawn and garden chemicals.
Do not use commercial-grade chemicals or chemicals for commercial
or industrial purposes.
Do not use caustic (alkali) self-heating or corrosive (acid) liquids with
the product. These can corrode metal parts or weaken the tank and
hose.
Handheld Chemical Sprayer
ENGLISH
Do not leave residue or spray material in the spray tank after using
the product. Clean after each use.
Do not pour hot or boiling liquids into the spray tank. These can
weaken or damage the hose or spray tank.
Do not overfill the tank.
Always check for leaks. If any are found, correct them before using
the product.
The spray area must be well ventilated.
Always inspect both the inside and outside of the product before each
use.
Liquids to be sprayed must be as thin as water. Thicker liquids will not
spray properly.
Spray materials may be premixed and poured into the spray tank
using a funnel.
Do not spray where spark, flame, or other source of ignition is
present.
Do not spray in the direction of people or animals. Always spray
downwind.
Do not smoke, eat, or drink while using the product.
Do not discharge directly against skin.
Do not let the spray materials come in contact with skin. If contact
does occur, wash immediately with soap and plenty of water.
Aim the nozzle directly at the plants or objects you intend to spray.
Ensure that the spray materials are directed at an area that will not be
damaged by the spray materials.
Avoid spraying on windy days. The spray materials can be
accidentally blown onto plants or objects that should not be sprayed.
The product may be operated with the spray wand handle resting in
the cradle, or may be rem oved from the cradle and be held by the
operator.
Electric shock hazard. Do not spray towards electrical outlets.
After every use, thoroughly wash your hands and any area where skin
has been exposed to the spray.
Maintain the product. Thoroughly inspect both the inside and outside
of the product and examine the components before each use. Check
for cracked and deteriorated hoses, leaks, clogged nozzles, and
missing or damaged parts. If damaged, have the product repaired
before use. Many accidents are caused by poorly maintained
products.
Wear personal protective equipment (PPE) according to the chemical
manufacturers instructions.
Remove the battery from the product before draining, cleaning, or
storing to avoid accidental starting.
Mix the chemicals strictly in accordance with the manufacturer’s
instructions. Incorrect mixtures may produce toxic fumes or explosive
solutions.
Never allow children, persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge or people
unfamiliar with these instructions to use the machine, local regulations
may restrict the age of the operator.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by
burning them. Milwaukee Distributors offer to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short circuit
risk).
Use only System M12 chargers for charging System M12 battery
packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it offimmediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
Warning! To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
or charger in fluid or allow a fluid to flow inside them. Corrosive or
conductive fluids, such as seawater, certain industrial chemicals, and
bleach or bleach containing products, etc., can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The handheld chemical sprayer is intended for outdoor use in a well-
ventilated area.
The sprayer is designed for spraying consumer-grade home and
garden chemicals such as:
• Pesticides
• Selective Herbicides
• Non-Selective Herbicides
• Insecticides
• Fungicides
• Fertilizers
• Plant Protection Treatments
This sprayer shall be used only with plant protection products
approved by local/national regulatory authorities for plant protection
products.
Do not use the sprayer with flammable liquids.
Use only substances approved for use with portable sprayers.
Do not use this product in any other way as stated for normal use.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise and the operator should pay special attention to
avoid the following:
Electric shock. Never spray liquid towards electrical sockets, cables,
or appliances.
Contact with hazardous substances. Spray materials may be harmful
if inhaled, ingested, or comes in contact with skin or eyes. Follow
instructions carefully and wear appropriate protective equipment as
prescribed in this manual.
WARNING
The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test given in EN
62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for different applications,
with different accessories or poorly maintained, the vibration and noise emission may differ. This may significantly increase the exposure level
over the total working period.
An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched offor when it is
running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration and/or noise such as: maintain the tool and the
accessories, keep the hands warm, organization of work patterns.

28 29ENGLISH
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Low pressure Not enough battery
charge
Charge the battery
No pressure Not enough battery
charge
Charge the battery
Leaky Connections are not
connected properly,
gaskets porous
Retighten connecting
elements, replace sealing
elements
Motor is not
running
Battery empty or
defective
Recharge or replace the
battery
No spray Spray nozzles are
blocked
Clean with compressed
air or a suitable solvent. If
screens or spray heads are
damaged, they should be
replaced.
SYMBOLS
Please read the instructions carefully before starting
the machine.
CAUTION! WARNING! DANGER!
Remove the battery pack before starting any work on
the machine.
Always wear eye protection!
Wear a suitable dust protection mask.
Use protective clothing
Wear gloves!
Wear sturdy non-slip shoes!
Do not expose battery to rain. Do not use battery in
damp or wet locations.
Do not spray flammable liquids
Do not spray at people or animals!
Do not spray at a wall!
Do not spray against the wind!
Do not point the nozzle upwards! Only spray
downwards!
Store cleaned components dry and frost-free.
Keep bystanders a safe distance away from work
area!
Hazardous chemicals
Note the current tank content
Applicable chemical substances
Do not dispose of waste batteries, waste electrical
and electronic equipment as unsorted municipal
waste. Waste batteries and waste electrical and
electronic equipment must be collected separately.
Waste batteries, waste accumulators and light
sources have to be removed from equipment.
Check with your local authority or retailer for
recycling advice and collection point. According to
local regulations retailers may have an obligation
to take back waste batteries and Waste electrical
and electronic equipment free of charge. Your
contribution to re-use and recycling of waste batteries
and waste electrical and electronic equipment helps
to reduce the demand of raw materials. Waste
batteries, in particular containing lithium and waste
Electrical and electronic equipment contain valuable,
recyclable materials, which can adversely impact the
environment and the human health, if not disposed
of in an environmentally compatible manner. Delete
personnel data from waste equipment, if any.
VVoltage
Direct Current
European Conformity Mark
British Confomity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
ENGLISH
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and
away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
Battery protection for Li-Ion Akkus
In extremely high torque, binding, stalling and short circuit situations
that cause high current draw, the tool will vibrate for about 5 seconds,
the fuel gauge will flash,and then the tool will turn OFF. To reset,
release the trigger.
Under extreme circumstances, the internal temperature of the battery
pack could raise too much. If this happens, the fuel gauge will flash
until the battery pack cooled down. After the lights go off, the work
may continue.
Transport of Lithium Batteries
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
• The user can transport the batteries by road without further requi-
rements.
• Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation and
transport are exclusively to be carried out by appropriately trained
persons and the process has to be accompanied by corresponding
experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated to
prevent short circuit.
• Ensure that battery pack is secured against movement within
packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice.
TRANSPORTATION AND STORAGE
• Remove the battery pack.
• Ensure that all parts are clean and dry.
• Clean all foreign materials from the product.
• Drain all spray materials from the spray tank before storage and
transportation.
• After each use, check all parts of the product for leaks. Return the
product to an authorised service center for repair, if it has any.
• The spray wand can be stored in the cradle.
• For transportation, secure the product against movement or falling
to prevent injury to persons or damage to the product.
• Store the product in a cool, dry and well-ventilated place that is
inaccessible to children. Keep away from corrosive agents such as
garden chemicals and de-icing salts. Do not store outdoors.
CLEANING THE TANK
1. Ensure the battery is removed
2. Remove the tank from the base and set on a level surface away
from the base to prevent exposing the base to harsh chemicals.
3. Fill the tank about one-third full with clean water
4. Install the tank and spray the water until the tank has been
emptied. Make sure to direct the spray toward an area that will not
be damaged by residue chemicals in the tank.
5. Repeat the procedure with clean water until the tank is thoroughly
clean. Wash outside of nozzles and dry with cloth.
6. Wipe the outside of the tank with a clean, dry cloth.
7. Allow all pieces to completely dry before reinstalling parts and
storing the unit. Always reinsert strainer before replacing tank cap.
MAINTENANCE
Servicing requires extreme care and knowledge and should be
performed only be a qualified service technician. For service we
suggest you return the product to an authorized service center for
repair. When servicing, use only identical replacement parts.
Only make adjustments or repairs described in this manual. For other
repairs, contact an authorised service centre.
After each use, clean the product as prescribed in this manual.
Drain and empty the spray tank before cleaning.
Drain the spray materials through the fill area.
Drain all of the spray materials from the spray tank into a container
approved for chemicals. Do not store chemicals in the spray tank.
Use clean water to clean and rinse the spray tank. A small amount of
mild household detergent may be added.
Wipe the product with a clean, dry cloth.
It may be necessary to rinse the spray tank more than once.
Never dispose residual chemicals or contaminated rinsing solutions in
waterways, drains, sewers, street gutters, or manholes.
Dispose residual chemicals and used containers in accordance with
local waste disposal regulations.
ACCESSORIES
Use only Milwaukee accessories and spare parts. Should
components need to be replaced which have not been described,
please contact one of our Milwaukee service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the machine type printed as well as the six-digit No. on the label and
order the drawing at your local service agents or directly at: Techtronic
Industries GmbH, Max-Eyth-Straße 10, 71364 Winnenden, Germany.
BLOCKED NOZZLES
If the nozzles are blocked, immediately turn offthe sprayer.
Ensure the battery is removed.
Wear protective clothing such as gloves and eye protection.
Disassemble the nozzles and clean with clear water. Replace
defective filters.

30 31
EC DECLARATION OF CONFORMITY
We declare as the manufacturer under our sole responsibility that
the product described under “Technical Data” fulfills all the relevant
regulations and directives listed below and that the following
harmonized standards have been used.
2011/65/EU (RoHS)
2009/127/EC
2006/42/EC
EN 62841-1:2015+A11:2022
EN ISO 19932-1:2013
EN ISO 12100:2010
EN IEC 55014-1:2021
EN IEC 55014-2:2021
EN IEC 63000:2018
Winnenden, 2022-11-25
Alexander Krug
Managing Director
Authorized to compile the technical file
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
GB-DECLARATION OF CONFORMITY
We declare as the manufacturer under our sole responsibility
that the product described under “Technical Data” fulfills all the
listed below relevant regulations and that the following designated
standards have been used.
S.I. 2008/1597 (as amended)
S.I. 2009/127 (as amended)
S.I. 2012/3032 (as amended)
BS EN 62841-1:2015+A11:2022
BS EN ISO 19932-1:2013
BS EN ISO 12100:2010
BS EN IEC 55014-1:2021
BS EN IEC 55014-2:2021
BS EN IEC 63000:2018
Winnenden, 2022-11-25
Alexander Krug
Managing Director
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
Authorized to compile the technical file:
Techtronic Industries (UK) Ltd
Parkway
Marlow SL7 1YL
UK

(11.22)
4100 4706 84
Copyright 2022
Techtronic Industries GmbH
Max-Eyth-Str. 10
71364 Winnenden
Germany
[phone]
www.milwaukeetool.eu
Techtronic Industries (UK) Ltd
Parkway
Marlow SL7 1YL
UK
