Milwaukee M18 User manual

OPERATOR'S MANUAL
Cat. no.
M18 BPFPCSA
Cat. no.
M18 BPFPWSA
Cat. No.
M18 BPFPCSA, M18 BPFPWSA, 491628PSA, 491628WSA
M18TM SWITCH TANK CHEMICAL SPRAYER AND WATER SUPPLY
WARNING
To reduce the risk of injury, user must read and understand operator's manual.

2
WARNING
WORK AREA SAFETY
PERSONAL SAFETY
•
IMPORTANT SAFETY INSTRUCTIONS
Read all safety warnings,
instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
•
•
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Outdoor use. Do not expose to rain; store
indoors.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk
of electric shock.
If operating a power tool in a damp location is
unavoidable, use a residual current device
(RCD) protected supply. Use of a RCD reduces
the risk of electric shock.
•
•
•
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influrence of drugs, alchohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising power
tools that have the switch on invites accidents.
Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
•
•
•
•
•
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures
reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool’s operation.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.
Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for
safe handling and control of the tool in unexpected
situations.
•
•
•
•
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may
cause irritation or burns.
Do not use a battery pack or tool that is
damaged or modfied. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
•
•
•
•
•
•
•
•
•
Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a
second.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce
dust-related hazards.
•
•
•
•
•
•
•

3
•
WARNING
Risk of fire or explosion. Do
•
SPECIFIC SAFETY RULES FOR
BACKPACK SPRAYER
•
•
•
•
•
•
•
•
WARNING
Some dust created by power
SAVE THESE INSTRUCTIONS
sanding, sawing, grinding,
drilling, and other construction activities contains
chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these
chemicals are:
SERVICE
•
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause
explosion.
•
•
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
not spray flammable liquids
such as gasoline. Do not use tool around
spark, flame, or smoke. Chemical may ignite.
Chemical sprayers shall be used only with
plant protection products approved by
local/national regulatory authorities for plant
protection products for use with backpack
sprayers.
To reduce the risk of fire, personal injury, and
product damage due to a short circuit, never
immerse your tool, battery pack or charger in
fluid or allow a fluid to flow inside them. Do
not place or store tool where it can fall or be
pulled into a tub or sink. Corrosive or conduc-
tive fluids, such as seawater, certain industrial
chemicals, and bleach or bleach containing
products, etc., can cause a short circuit.
Electric shock hazard. Never spray toward
electrical outlets.
Spray area must be well ventilated to avoid
hazardous fumes build-up.
Avoid spraying on windy days. Spray can be
blown onto people, plants, or objects that
should not be sprayed.
Do not store chemicals in the tank. Chemicals
can degrade seals and hoses. Drain and clean
after each use.
Remove gloves before handling battery packs.
Chemicals are harmful to plastics.
Maintain your power tool. Thoroughly inspect
inside and outside and examine all
•
•
•
•
•
ADDITIONAL BATTERY SAFETY RULES
WARNING
To
personal injury,
reduce the risk of fire,
and product
damage due to short circuit, never immerse your
tool, battery pack or charger in fluid or allow a fluid
to flow i nside them. Corrosive or conductive fluids,
such as seawater, certain industrial chemicals, and
bleach or bleach-containing products, etc., can
cause a short circuit.
•
• Iead from lead-based paint
• crystalline silica from bricks and cement and
other masonry products, and
• arsenic and chromium from chemically-treated
lumber.
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a
well-ventilated area, and work with approved
safety equipment, such as those dust masks that
are specially designed to filter out microscopic
particles.
When transporting and handling sprayers always
secure the sprayer during transportation to
prevent loss, damage or injury.
components before each use. Check for
cracked and deteriorated hoses, leaks,
clogged nozzles, and missing or damaged
parts. If damaged, have the power tool
repaired before use. Many accidents are
caused by poorly maintained power tools.
Always unplug the charger and remove the
battery pack from the charger or tool before
performing any maintenance, storing, or
draining the tool. Never disassemble the tool,
battery pack or charger. Contact a
MILWAUKEE®service facility for ALL repairs.
Do not eat or smoke while handling or
operating the tool. After use, wash with hot,
soapy water to help reduce the risk of health
hazards due to exposure to chemicals.
Always use common sense and be cautious
when using tools. It is not possible to anticipate
every situation that could result in a dangerous
outcome. Do not use this tool if you do not
understand these operating instructions or you
feel the work is beyond your capability; contact
MILWAUKEE®Tool or a trained professional for
additional information or training.
Do not use the battery compartment for
storage.
Maintain labels and nameplates. These carry
important information. If unreadable or missing,
contact a MILWAUKEE®service facility for a
replacement.
Use the correct tank for your application.
These products are suitable for pesticide
applications (such as insecticides, fungicides,
or herbicides, fertilisers) and water supply
applications, when used in accordance with
these instructions and those applicable to the
chemicals.
Do not use bleach, caustic (alkali) self-heating
or corrosive (acidic) liquids in this sprayer. Do
not pour hot or boiling liquids into the tank.
These can corrode metal parts or weaken the
tank and hose.

FUNCTIONAL DESCRIPTION
Cat. no.
M18BPFPCSA
Cat. no.
M18BPFPWSA
4
ASSEMBLY
WARNING
Recharge only with the
12.
13.
10.
11.
14.
15.
Hose
Tank hook
receptacle
Waist strap
Adjustable nozzle ^
Nozzle holder
Battery
compartment accessories
WARNING
Only use
specifically recommended
for this tool. Others may be hazardous.
1. Tank
2. Tank cap
3. Wand storage
location
4. Carry handle
5. Spray wand
6. Trigger lock-on ^
7. Trigger handle ^
8. Trigger lock-off ^
9. Shoulder straps
16. Battery
compartment latch
17. Tank latch
18. Flow rate dial
19. On/Off switch
20. Power LED
21. Water nozzle *
22. Adjustable
nozzle ^
23. Fan nozzle ^
24. Strainer
25. Tank hooks
26. Gallon markings
27. Litre markings
WARNING
before
Always
orchanging
remove battery
removing
pack
accessories.
charger specified for the
battery. For specific charging instructions,
read the operator's manual supplied with
your charger and battery.
Inserting/ Removing the Battery
To remove the battery, push in the release buttons
and pull the battery pack away from the tool.
Cat. No.............. M18 BPFPCSA, M18 BPFPWSA
SPECIFICATIONS
Volts.......................................................... 18V DC
*the weight is based on M18B4 4.0Ah battery
Flow Rate
Tank Only (Chemical)........................
Tank Only (Water)............................
Operating Temperature................ 0°C to 51°C
Tank Capacity................................................ 15 L
Dry Weight:
M18 BPFPCSA......................................... 7.75 kg
M18 BPFPWSA........................................ 7.85 kg
M18 BPFPWSA........................................ 23.7 kg
Full Weight*
M18 BPFPCSA......................................... 23.6 kg
M18 BPFPCSA.............................. 0.4 - 1.9 L/min
M18 BPFPWSA............................. 0.6 - 4.2 L/min
* 491628WSA only
^ 491628PSA only
Battery Type................................................
............................... M18TM Charger Ty
Recommended Ambient
pe ...............
M18TM
491628PSA
491628WSA
To insert the battery, slide the pack into the body
of the tool. Make sure it latches securely into
place.
SYMBOLOGY
Volts
Direct Current
Read operator's manual
Wear eye protection.
Wear gloves.
Wear dust mask.
Wear protective clothing.
Do not spray flammable liquids.
Regulatory Compliance mark (RCM).
This product meets applicable regulatory
requirements.
V
Do not dispose of electric tools together
with household waste material. Electric
tools and electronic equipment that have
reached the end of their life must be
collected separately and returned to an
environmentally compatible recycling
facility.

5
Ensure battery door is closed
whenever
WARNING
and latched
chemicals are present.
Filling the Tank
WARNING
Before filling the tank, remove
not overfill). Use the litre markings
on the side of the tank as a guide.
5. Reinstall the tank cap.
6. Reinstall the tank.
the tank from the base.
Ensure battery door is closed and latched
whenever chemicals are present.
Mix chemicals per manufacturer's instructions.
Failure to follow instructions may cause harsh
chemicals to injure user or damage tool.
A removable strainer prevents debris that can clog
or damage the pump from entering the tank. Label
tank contents accordingly during each use. Only
put recommended liquids in tank. Only use water in
water supply tank.
1. Ensure the battery door is
closed securely.
2. Remove the tank from the base
and set on a level surface away
from the base to prevent exposing
the base to harsh chemicals.
3. Unscrew and remove the tank
cap; ensure strainer is in place.
4. Fill the tank (up to 15 litres; do
Installing the Tank
WARNING
When filled, the sprayer will be
1. Ensure the battery door is closed securely.
2. Slide tank hooks into base and seat tank into
tank reservoir in the base.
3. Secure tank to base with front and rear tank
latches; ensuring the tank is level, firmly seated,
and all seals are aligned.
heavy, take care when putting
on the backpack to avoid strain.
Putting on the Backpack
1. Ensure tank is securely attached to base with
front and rear tank latches, tank cap is installed,
and battery door is latched.
3. With the sprayer on your back, tighten the
shoulder and waist straps until they fit snugly and
securely, high on your back. Connect chest strap.
4. Be sure the shoulder, chest, and waist straps are
tight but comfortable; if they are too loose, the
sprayer may slide around on your back, making it
uncomfortable to wear.
5. Be aware tank contents may shift during use and
movement, such as twisting or bending over.
Ensure trigger handle lock-on is not engaged
before turning ON tool.
Turning the Sprayer ON/OFF
1. Install the battery pack. Close and latch the
battery compartment.
2. To turn the sprayer ON, press the ON/OFF
switch to "I". The Power LED will light green.
3. To start the flow of liquid at the spray wand, pull
the trigger.
4. To stop the flow of liquid at the spray wand,
release the trigger.
5. To turn the sprayer OFF, press the ON/OFF
switch to "0".
NOTE: Be aware some spray material may remain
inside the spray wand and drip out. To drain, turn
off the tool, then pull the trigger and point the tool
down until dripping stops.
Trigger Lock-On
(Cat. No. 491628PSA)
Use trigger lock-on when spraying for an extended
period of time or when covering a large area.
1. To lock-on, pull the trigger and push in the
lock-on button.
2. To release the lock-on, pull and release the
trigger.
NOTE: Ensure the trigger is not locked on before
turning the sprayer off to avoid accidental spraying
when the sprayer is restarted.
1
2
Trigger Lock-On
Trigger Lock-Off
(Cat. no. 491628PSA)
To avoid accidental spraying, lock-off the trigger.
1. Press the lock-off toggle at the end of the trigger
(1).
2. Hook the lock-off tab onto the hook under the
trigger (2).
3. To release, push the tab back into the trigger.
WARNING
T
always wear
o reduce the risk of injury
, personal
protective equipment (PPE) according to the
chemical manufacturer's instructions. Always
wear eye protection. Always ensure battery
compartment latch is securely closed before
use.
OPERATION
Adjusting the Flow Rate
Select the desired flow rate from Low (1) to High
(5), depending on the job and the chemical
manufacturer's instructions.
Flow
Rate
M18 BPFPCSA
(Stream Nozzle)
0.4 L/min
0.5 L/min
1
2
3
4
5
0.9 L/min
1.3 L/min
1.9 L/min
M18 BPFPWSA
(Open Flow)
0.6 L/min
0.8 L/min
1.3 L/min
2.0 L/min
4.2 L/min
2. Pick up the backpack by one of the shoulder
straps, slide your arms through each shoulder
strap.
Connecting the Spray Wand to the Trigger
Handle
(Cat. no. 491628PSA)
1. Insert the spray wand into the trigger
handle (1) until firmly seated.
2. Slide the nut onto the threaded
coupling and hand tighten securely (2).
3. Pull on the spray wand to be certain it is
properly secured.
4. Place the assembled trigger handle
and wand into one of the wand storage
locations.
Connecting the Nozzles
(Cat. no. 491628PSA)
Connecting Water Supply or Water Nozzle
(Cat. no. 491628WSA)
To attach water supply hose to the tool or
nozzle, push the quick connect fitting and
tool/nozzle together (1). Pull on the
connection to be certain it is properly
secured. To remove, pull the collar back
to release (2). When using the nozzle,
adjust spray pattern as desired by
tightening/loosening the nozzle.
Select and screw on the desired nozzle to the
wand end. When using the adjustable nozzle,
adjust spray pattern as desired by
tightening/loosening the nozzle.

APPLICATIONS
away from people, always
angle the wand and hose downward and avoid
direct contact with skin.
Maintaining Tool
WARNING
Before using any chemicals
Supplying Water
(Cat. No. 491628WSA)
and/ or solutions, read and
follow all original manufacturer instructions.
Read all Safety Data Sheets (SDS) and
container labels provided with the chemical.
Chemicals can cause serious bodily injury,
property damage, and/or damage the tool.
Wear personal protective equipment (PPE)
according to the chemical manufacturer's
instructions. Always wear eye protection.
Spraying
(Cat. No. 491628PSA)
1. Fill the tank with clean water and then install
onto the base.
3.
4.
2.
MAINTENANCE
1. Fill the tank and then install onto the base.
2.
4. Turn on the tool.
5.
6. If desired, lock-on the trigger for extended use.
7.
6
WARNING
To reduce the risk of personal
5. To start water flow, turn on the tool.
6.
7.
injury and damage, never
immerse your tool, battery pack or charger in
liquid or allow a liquid to flow inside them. Do
not use bleach as a cleaning agent.
Cleaning
Clean dust and debris from vents. Keep handles
clean, dry and free of oil or grease. Use only mild
soap and a damp cloth to clean, since certain
cleaning agents and solvents are harmful to
plastics and other insulated parts. Some of these
include gasoline, turpentine, lacquer thinner, paint
thinner, chlorinated cleaning solvents, ammonia
and household detergents containing ammonia.
Never use flammable or combustible solvents
around tools.
Cleaning Electrical Contacts
Keep electrical contact posts between bottom of
tank and base clean.
WARNING
before cleaning electrical
Remove battery pack from tool
contacts. Clean contacts with a dry, clean cloth
only.
Base
Contacts
Tank
WARNING
To
always wear
reduce the risk of injury
, personal
protective equipment (PPE) according to the
chemical manufacturer's instructions. Always
wear eye protection.
WARNING
Keep wand and hose pointed
Slide the pack into the body of the tool to insert
the battery. Make sure it latches securely into
place.
Pull the trigger and begin sweeping the nozzle
from side to side, coating the desired surface
evenly in accordance with chemical
manufacturer's instructions.
When done, release the trigger, turn off the tool,
remove the backpack, remove the battery, drain,
and clean the tank.
Attach water supply hose with the quick connect
fitting. Pull on the connection to be certain it is
properly secured.
Monitor water level in tank. When empty, turn off
tool, disconnect the hose, and refill tank. Don't
run tool when tank is empty.
When done, turn off the tool, remove battery,
disconnect hose, drain, and clean the tank.
Slide the pack into the body of the tool to insert
the battery. Make sure it latches securely into
place.
Place tool near the job within range of water
supply hose.
Put on the backpack and properly adjust the
straps.
3.
Keep your tool, battery pack and charger in good
repair by adopting a regular maintenance program.
Inspect your tool for issues such as undue noise,
misalignment or binding of moving parts, breakage
of parts, or any other condition that may affect the
tool operation. Return the tool, battery pack, and
charger to a MILWAUKEE®service facility for
repair. After six months to one year, depending on
use, return the tool, battery pack and charger to a
MILWAUKEE®service facility for inspection.
If the tool does not start or operate at full power
with a fully charged battery pack, clean the
contacts on the battery pack. If the tool still does
not work properly, return the tool, charger and
battery pack, to a MILWAUKEE®service facility for
repairs.

7
To Clean:
In the event the sprayer becomes blocked, return
to a service agent for repair. Do not operate the
unit and avoid direct contact with the unit.
Storage
Store indoors. Store spray wand securely in wand
storage area. Store the sprayer in a secure,
well-ventilated indoor space with the tank empty.
Repairs
For repairs, return the tool, battery pack and
charger to the nearest service centre.
ACCESSORIES
WARNING
Use only recommended accesso-
ries. Others may be hazardous.
For a complete listing of accessories, go online to
milwaukeetool.com.au / milwaukeetool.co.nz or
contact a distributor.
1. Ensure the battery door is closed securely.
2
3.
4.
5.
6.
8.
Always
protective equipment (PPE)
wear personal
1.
2.
3.
according to the chemical manufacturer's
instructions. Always wear eye protection.
Draining and Cleaning the Tank, Hose, and
Spray Wand
If there is any liquid left in the tank after spraying,
the tank should be drained before cleaning. Do not
store chemicals in the tank. Tank must be cleaned
before using another liquid. Do not mix liquids.
Follow the chemical manufacturer's instructions for
proper cleaning, storage and/or disposal of excess
liquid. To Drain:
Ensure the battery door has been removed from
the base and securely stored away from any
liquids.
Remove battery from the base and securely
store away from any liquids.
7. Wipe the outside of the tank with a clean, dry
cloth.
Allow all pieces to completely dry before
reinstalling parts and storing the unit. Always
reinsert strainer before replacing tank cap.
Remove the tank from the base and set on a
level surface away from the base to prevent
exposing the base to harsh chemicals.
Empty the tank into a suitable container through
the fill area.
Remove the tank from the base.
Install the tank and spray the water until the tank
has been emptied. Make sure to direct the spray
toward an area that will not be damaged by
residue chemicals in the tank.
Repeat the procedure with clean water until the
tank is thoroughly clean. Wash outside of
nozzles and dry with a cloth.
Remove the tank and fill it about one-third full
with clean water. A small amount of mild
household detergent may be added. Replace
the cap and gently slosh the water around the
tank.
WARNING

01610605301Q-04(A)
WARRANTY - AUSTRALIA and NEW ZEALAND
SERVICE - AUSTRALIA and NEW ZEALAND
Please refer to Australian and New Zealand warranty supplied with tool. This warranty applies only to
product sold by authorised dealers in Australia and New Zealand.
26 - 40 Nina Link, Dandenong South,
Victoria, 3175, Australia
Milwaukee Electric Tool Corporation
13135 West Lisbon Road, Brookfield, Wisconsin U.S.A. 53005
Milwaukee Tool (Australia)
DESIGNED BY MILWAUKEE ELECTRIC TOOL CORP.
PROFESSIONALLY MADE IN CHINA
PRINTED IN CHINA
MILWAUKEE®prides itself in producing a premium quality product that is Nothing But Heavy DutyTM.
Your satisfaction with our products is very important to us! If you encounter any problems with the
operation of this tool, please contact your authorised MILWAUKEE®dealer.
For a list of MILWAUKEE®dealers, guarantee or service agents please contact MILWAUKEE®
Customer Service or visit our website.
(Australia Toll Free Telephone Number 1300 645 928)
(New Zealand Toll Free Telephone Number 0800 645 928)
or visit milwaukeetool.com.au/milwaukeetool.co.nz.
Milwaukee Tool (New Zealand)
274 Church Street, Penrose,
Auckland, 1061, New Zealand
