Milwaukee M18 ONEBLHPT User manual

Original instructions
Originalbetriebsanleitung
Notice originale
Istruzioni originali
Manual original
Manual original
Oorspronkelijke
gebruiksaanwijzing
Original brugsanvisning
Original bruksanvisning
Bruksanvisning i original
Alkuperäiset ohjeet

Orijinal iş
Pů


Eredeti használati utasítás
Izvirna navodila
Originalne pogonske upute
Instrukcijâm oriěinâlvalodâ
Originali instrukcija
Algupärane kasutusjuhend




Instrucţiuni de folosire originale




M18 ONEBLHPT

Technical Data,Safety Instructions, Specied Conditions of Use,
Declaration of Conformity, Batteries, Maintenance, Symbols Please read and save these instructions!
English
1515
Technische Daten, Sicherheitshinweise, Bestimmungsgemäße Verwendung,
CE-Konformitätserklärung, Akkus, Wartung, Symbole Bitte lesen und aufbewahren!
Deutsch
1818
Caractéristiques techniques, Instructions de sécurité, Utilisation conforme aux
prescriptions, Déclaration CE de Conformité, Accus, Entretien, Symboles A lire et à conserver soigneusement
Français
2121
Dati tecnici,Norme di sicurezza,Utilizzo conforme, Dicharazione di Conformità CE,
Batterie, Manutenzione, Simboli Si prega di leggere e conservare le istruzioni!
Italiano
2424
Datos técnicos, Instrucciones de seguridad, Aplicación de acuerdo a la nalidad,
Declaracion de Conformidad CE, Bateria, Mantenimiento, Símbolos Lea y conserve estas instrucciones por favor!
Español
2727
Características técnicas, Instruções de segurança, Utilização autorizada,
Declaração de Conformidade CE, Acumulador, Manutenção, Symbole Por favor leia e conserve em seu poder!
Português
3030
Technische gegevens, Veiligheidsadviezen, Voorgeschreven gebruik van het
systeem,EC-Konformiteitsverklaring,Akku, Onderhoud, Symbolen Lees en let goed op deze adviezen!
Nederlands
3333
Tekniske data, Sikkerhedshenvisninger, Tiltænkt formål,
CE-Konformitetserklæring, Batteri, Vedligeholdelse, Symboler Vær venlig at læse og opbevare!
Dansk
3636
Tekniske data, Spesielle sikkerhetshenvisninger, Formålsmessig bruk,
CE-Samsvarserklæring, Batterier, Vedlikehold, Symboler Vennligst les og oppbevar!
Norsk
3939
Tekniska data, Säkerhetsutrustning, Använd maskinen Enligt anvisningarna,
CEFörsäkran, Batterier, Skötsel, Symboler Läs igenom och spara!
Svenska
4242
Tekniset arvot, Turvallisuusohjeet, Tarkoituksenmukainen käyttö,
Todistus CE-standardinmukaisuudesta, Akku, Huolto, Symbolit Lue ja säilytä!
Suomi
4545
Τεχνικά στοιχεία, Ειδικές υποδείξεις ασφάλειας, Χρήση σύμφωνα με το σκοπό
προορισμού, Δήλωση πιστότητας ΕΚ, Μπαταρίες, Συντήρηση, Σύμβολα. Παρακαλούμε να τις διαβάσετε και να τις φυλάξετε!
Ελληνικά
4848
Teknik veriler, Güvenliğiniz için talimatlar, Kullanim, CE uygunluk beyanice,
Akü, Bakim, Semboller Lütfen okuyun ve saklayın
Türkçe
5151
Technická data, Speciální bezpečnostní upozornění, Oblast využití,
Ce-prohlášení o shodě, Akumulátory, Údržba, Symboly Po přečtení uschovejte
Česky
5454
Technické údaje, Špeciálne bezpčènostné pokyny, Použitie podl’a predpisov,
CE-Vyhlásenie konformity, Akumulátory, Údrzba, Symboly Prosím prečítať a uschovať!
Slovensky
5757
Danetechniczne,Specjalnezaleceniadotyczącebezpieczeństwa, Użytkowanie zgodne z
przeznaczeniem, Świadectwo zgodności ce, Baterie Akumulatorowe,Utrzymanie,Symbole Należy uważnie przeczytać i zachować do wglądu!
Polski
6060
Műszaki adatok, Különleges biztonsági tudnivalók, Rendeltetésszerű használat,
Ce-azonossági nyilatkozat, Akuk, Karbantartás, Szimbólumok Olvassa el és őrizze meg
Magyar
6363
Tehnični podatki, Specialni varnostni napotki, Uporaba v skladu z namembnostjo,
Ce-izjava o konformnosti, Akumulatorji, Vzdrževanje, Simboli Prosimo preberite in shranite!
Slovenščina
6666
Tehnički podaci, Specijalne sigurnosne upute, Propisna upotreba,
CE-Izjava konformnosti, Baterije, Održavanje, Simboli Molimo pročitati i sačuvati
Hrvatski
6969
Tehniskie dati, Speciālie drošības noteikumi, Noteikumiem atbilstošs izmantojums,
Atbilstība CE normām, Akumulātori, Apkope, Simboli Lūdzu, izlasīt un uzglabāt!
Latviski
7272
Techniniai duomenys, Ypatingos saugumo nuorodos, Naudojimas pagal paskirti,
CE Atitikties pareiškimas, Akumuliatoriai, Techninis aptarnavimas, Simboliai Prašome perskaityti ir neišmesti!
Lietuviškai
7575
Tehnilised andmed, Spetsiaalsed turvajuhised, Kasutamine vastavalt otstarbele,
EÜ Vastavusavaldus, Akud, Hooldus, Sümbolid Palunlugege läbi ja hoidkealal!
Eesti
7878
Технические данные, Указания по безопасности, Использование,
Декларация о соответствии стандартам EC, Аккумулятор, Обслуживание, Символы Пожалуйста прочтите и сохранитеэтуинструкцию.
Pусский
8181
Технически данни, Специални указанияза безопасност,Използване попредназначение,
СЕ - Декларация за съответствие, Акумулатори, Поддръжка, Символи Моля прочетете и запазете!
Български
8484
Date tehnice, Instrucţiuni de securitate, Condiţii de utilizare specifcate,
Declaraţie de conformitate, Acumulatori, Intreţinere, Simboluri Va rugăm citiţi şi păstraţi aceste instrucţiuni
Română
8787
Технички податоци, Упатства за употреба, Специфицирани услови на употреба,
ЕУ- декларација за Сообразност, Батерии, Одржување, Симболи Ве мoлиме прочитаjте го и чувајте го ова упатство!
Македонски
9090
Технічні характеристики, Вказівки З Техніки Безпеки, Використання за призначенням,
СертифікатВідповідностіВимогам Єс, Акумуляторнібатареї, Обслуговування, Символи Прочитайте та збережіть цю інструкцію.
Українська
9393
   

 9898

Originalinstructions
Originalbetriebsanleitung
Noticeoriginale
Istruzionioriginali
Manualoriginal
Manualoriginal
Oorspronkelijke
gebruiksaanwijzing
Originalbrugsanvisning
Originalbruksanvisning
Bruksanvisningi original
Alkuperäisetohjeet
Πρωτότυπο οδηγιών χρήσης
Orijinalişletme tal imatı
Původním návodem k používání
Pôvodný návod na použitie
Instrukcją oryginalną
Eredetihasználati utasítás
Izvirnanavodila
Originalnepogonske upute
Instrukcijâmoriěinâlvalodâ
Originaliinstrukcija
Algupäranekasutusjuhend
Оригинальное руководство
по эксплуатации
Оригинално ръковод ство за
експлоатация
Instrucţiunide folosire originale
Оригинален прирачник за
работа
Оригінал інструкц ії з
експлуатації
M18 ONEBLHPT
Service
2020
Jan Feb Mar Apr May June
July Aug Sept Oct Nov Dec
20

ONE KEY
VIII IX
III
VVI
VII
IV

Zubehör
Accessoires
Accessorio
Accessorio Acessório
Toebehoren Tilbehør
Tilbehør Tillbehör
Lisälaite 
Aksesuar Příslušenství
Príslušenstv 
Azokat a tartozékokat
Oprema Piederumi
Priedas Tarvikud
Äîïîëíèòåëü

Accesoriu 
 

III

22
I
TIP
78-100 %
33-54 %
55-77 %
10-32 %
<10 %
1
1
2

33
II
33
1.
3.
2.
GREASE

44
III
> + 50° C < - 10° C
Service
Service

55
IV
Stop
3 sec Auto Start Auto Stop
15 sec
1
2
LEDOn

66
IV
30 sec LED
LEDOn

77
V
2.1.
Ømm
3. 4.
3 sec Auto Start Auto Stop

88
V
5.

99
VI
1. 2.
3.
Ømm

1010
VI
3 sec Auto Start Auto Stop
4. 5.

1111
VI
7.
6.

1212
VII

1313
REPORT
ONE KEY
ONE KEY
VIII

1414
ONE KEY
VIII
1.
3.
ONE KEY
1
2
2
1
2. 3V CR2032
3V CR2032
+ +
1
2
+
+
2

Deutsch
1515
GB
English
TECHNICAL DATA
Press device M18 ONEBLHPT
Production code 4777 60 02 ...
... 000001-999999
Frequency band(s) of Bluetooth 2402 - 2480 MHz
Radio-frequency power 1,8 dBm
Bluetooth version 4.2 BT signal mode
Battery voltage 18 V
Power consumption 450 W
Nominal force 32 kN
Compression range:
Ø Plastics & Composite pipes
Ø Metal until 63 mm (110 mm) 54 mm (108 mm)
dep. on system
Weight according EPTA-Procedure 01/2014
(Li-lon 2,0 Ah ... 12,0 Ah) 2,9 ... 3,9 kg
Weight
(M18 ONEBLHPT / Li-Ion 2.0 Ah / J18-Th14) 4,7 kg
Noise information
Measured values determined according to EN60745.Typically, the
A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty
K=3dB(A)) 75 dB (A)
Sound power level (Uncertainty K=3dB(A)) 86 dB (A)
Wear ear protectors!
Vibration information
Vibration total values (triaxial vector sum) determined according
to EN60745
Vibration emission value ah<2,5 m/s2
Uncertainty K= 1,5 m/s2
WARNING!
The vibration and noise emission level given in this information
sheet has been measured in accordance with a standardized test
given in EN60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the
main applications of the tool. However if the tool is used for die-
rent applications, with dierent accessories or poorly maintained,
the vibration and noise emission may dier. This may signicantly
increase the exposure level over the total working period.
An estimation of the level of exposure to vibration and noise should
also take into account the times when the tool is switched o or
when it is running but not actually doing the job. This may signi-
cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from
the eects of vibration and/or noise such as: maintain the tool
and the accessories, keep the hands warm, organization of work
patterns.
WARNING Read all safety warnings and all instruc-
tions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
PRESS DEVICE SAFETY WARNINGS
Use protective equipment. Always wear goggles when using the
machine. The use of protective clothing is recommended, such as
dust mask, protective gloves, sturdy non-slip footwear, helmet and
ear defenders.
Never hold your ngers or other body parts in the working area of
the cylinder or the press jaws.
Do not hold the jaw levers with your hands during the pressing
operation.
Press tools and press devices must only be used by trained
personnel.
Check the press tools and press devices for cracks and other signs of
wear before each use.
Only use press tools and press devices that are in perfect technical
condition.
Have damage repaired immediately by an authorised workshop.
The machine may only be used with a press jaw inserted into it.
In the event of problems during the pressing process, press the
Emergency Stop button immediately and release the ON switch.
The valve will open and the piston will return to its initial position.
Compliance with the specied service work and service intervals is
mandatory.
Remove the battery pack before starting any work on the
appliance.
WORKING INSTRUCTIONS
Use only system-compatible press ttings and press jaws designed
for them.
Consult the documents provided by the system supplier for hand-
ling and assembly instructions for ttings and pipes.
Check whether the nominal width of the press tting corresponds
to the nominal width of the press jaws.
Make sure that the press jaw is fully closed when pressing is
complete.
Imperfect pipe joints must be compressed again using a new
tting.
After nishing the work, check the installation with appropriate
testing equipment and assure that it is leakproof!
The press device is not suitable for continuous operation. Following
30 minutes of continuous operation, a short break of at least 15
minutes must be taken to allow the device to cool down.
SPECIFIED CONDITIONS OF USE
The devices and the press jaws are designed exclusively for the
press-tting of pipes and ttings for which the relevant press jaws
are intended.
These press devices are intended exclusively for use with press jaws
approved by Milwaukee in agreement with the system supplier.
ONEKEY™
To learn more about the ONE-KEY functionality of this device,
please refer to the Quick Start guide included with this product or
go to http://www.milwaukeetool.com/one-key
To download the ONE-KEY app, visit the App Store or Google Play
from your smart device.
We considered the result to be within our minimum acceptable
performance level according to EN301489-1/ EN301489-17.

Deutsch
1616
English
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully
charged, after use.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture Store the battery packs in a 30% - 50%
charged condition Every six months of storage, charge the pack as
normal.
Do not dispose of used battery packs in the household refuse or
by burning them. Milwaukee Distributors oer to retrieve old
batteries to protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System M18 chargers for charging System M18 battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it o immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
No metal parts must be allowed to enter the battery section of the
charger (short circuit risk).
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legisla-
tion requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
The user can transport the batteries by road without further
requirements.
Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation and
transport are exclusively to be carried out by appropriately trained
persons and the process has to be accompanied by corresponding
experts.
When transporting batteries:
Ensure that battery contact terminals are protected and insulated
to prevent short circuit. Ensure that battery pack is secured against
movement within packaging. Do not transport batteries that are
cracked or leak. Check with forwarding company for further advice.
MAINTENANCE
Check that the press jaw and drive rolls move freely.
Clean and grease the press drives, locking bolts and cutting jaws
when you have nished work.
Service and repair work may only be carried out by authorised
specialist workshops.
The device contains hydraulic uid. Hydraulic uids pose a hazard
to groundwater. Uncontrolled draining or improper disposal is
punishable by law.
The next service deadline is indicated on the press device. This
service must be performed at least every 2 years or at the latest
when the LED display indicates that a service is due.
Replace worn press tools.
The ventilation slots of the machine must be kept clear at all times.
Use only Milwaukee accessories and Milwaukee spare parts. Should
components need to be replaced which have not been described,
please contact one of our Milwaukee service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the machine type printed on
the label and order the drawing at your local service agents or
directly at: TechtronicIndustriesGmbH, Max-Eyth-Straße10,
71364Winnenden, Germany.
ECDECLARATION OF CONFORMITY
We declare under our sole responsibility that the product described
under “Technical Data” fullls all the relevant provisions of the
directives
2011/65/EU (RoHS)
2006/42/EC
2014/53/EU
and the following harmonized standards have been used
EN62368-1:2014+AC:2015+A11:2017
EN60745-1:2009+A11:2011
ENISO 12100:2010
EN55014-1:2017+A11:2020
EN55014-2:2015
EN301489-1V2.2.3
EN301489-17V3.2.4
EN300 328V2.2.2
EN62479:2010
ENIEC 63000:2018
Winnenden, 2021-07-16
Alexander Krug / Managing Director
Authorized to compile the technical le
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364Winnenden, Germany
GB

Deutsch
1717
English
GBDECLARATION OF CONFORMITY
We declare as the manufacturer under our sole responsibility that
the product described under „Technical Data“fullls all the relevant
provisions of the following Regulations
S.I. 2012/3032 (as amended), S.I. 2008/1597 (as amended),
S.I. 2017/1206 (as amended) and that the following designated
standards have been used:
BS EN62368-1:2014+A11:2017
BS EN60745-1:2009+A11:2010
BS ENISO 12100:2010
BS EN55014-1:2017+A11:2020
BS EN55014-2:2015
EN301489-1V2.2.3
EN301489-17V3.2.4
EN300 328V2.2.2
BS EN62479:2010
BS ENIEC 63000:2018
Winnenden, 2021-07-16
Alexander Krug / Managing Director
Authorized to compile the technical le
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
GB
SYMBOLS
Please read the instructions carefully before starting the
machine.
CAUTION! WARNING! DANGER!
Remove the battery pack before starting any work on the
appliance.
WARNING!
Risk of injury from ejected fragments
Warning! Danger of crushing!
Accessory - Not included in standard equipment, available
as an accessory.
Always wear goggles when using the machine.
Service label
This device contains a button-type/coin cell lithium
battery.
Do not dispose of electric tools together with household waste
material. Electric tools andelectronic equipment thathave
reached the end oftheir life must be collected separately and
returned toan environmentally compatible recycling facility.
Check with your local authority orretailer for recycling advice
andcollectionpoint.
European Conformity Mark
British Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
