Make sure to wear the attached
goggles and glove when you work.
JFX200-2513 / JFX500-2131
Cleaning procedure of head nozzle
Only when the nozzle drop out doesn’t recover with cleaning, daily care and maintenance, please clean
the head nozzle following the procedure below.
Procedure
1. Remove the left side cover of
the machine.
Remove the screw and remove the
cover.
2. Move the carriage(head) to the maintenance space.
(1) Press the key in LOCAL.
(2) Press the key.
(3) Press to select [HEAD MAINT.].
(4) Press the key.
• Before performing the maintenance, please make sure to attend the training by our engineers. Maintenance
without training may cause failure of the head.
• During maintenance, never rub the nozzles of the head. If rub the nozzle part, the water-repellent surface is
degraded and the head might need to be replaced.
Supply goods for cleaning
Nozzle swab (100) Cleaning stick (50) F200/LF200 Cleaning liquid
for maintenance (100mℓ)
No.SPC-0421 No.SPC-0527 No.SPC-0568
• Make sure to use designated supply goods for nozzle cleaning. Other cleaning goods may cause early
deterioration of the head.
• Head will move for maintenance, please be careful.
[JFX200] Remove the screws
at two positions.
[JFX500] Remove the screws
at four positions.
Cover
Cover
MAINT.

© 2016 MIMAKI ENGINEERING CO., LTD. M018365-00(D203018-10)-15042016
3. Wet a new “nozzle swab” or “clean stick” with the cleaning
solution.
Please wet enough the cleaning solution.
4. Clean the nozzle surface.
(1) Press the "nozzle swab" or "cleaning stick", absorbing cleaning liquid,
against nozzle surface softly for about 10 seconds.
(2) Perform the work (1) to the entire nozzle surface.
5. Press the key after the cleaning.
After initial operation, carriage (head) return to the original position.
Please close the cover.
6. Implement the cleaning [NORMAL].
Please operate with reference to Chapter 4 of the Operation Manual.
7. Perform test printing and check the print result.
Repeat the cleaning and test printing until the result becomes normal.
• Please do not reuse the used clean stick.
It may cause nozzle clogging.
• Please do not rub the nozzle surface and press down strongly
sponge part with your fingers. Nozzle surface is damaged, and it
may cause the discharging defects.
• Please do not re-use the clean stick which was used once. Always
use a new clean stick seconds.
Press softly for 10 seconds
Nozzle surface
