Miniature Scenery Tornadodo User manual

Preparation
Once you clear some table space you will need a
hobby knife and glue (PVA, wood glue, hobby glue)
and a file or small piece of sandpaper to be used for
cleaning up any tiny imperfections.
It s a good idea to familiarise yourself with how the
pieces fit together before gluing.
Getting Started
I. Parts should remove easily from the board by
pressing through and popping them out. It s a
good idea to cut through the tiny joins first
though, and some parts (particularly smaller,
more detailed parts) may need more careful
persuasion.
II. Use a file or sand paper last to completely
remove the tabs that might remain.
III. Parts may be a very tight fit, slight trimming
or sanding of parts may be needed for ease of
assembly.
Construction
Slot the parts together as shown by the pic-
tures below, applying glue wherever there is
a connection.
Allow the model to completely dry before
painting it. This is a complex kit with many
small parts. Allowing each section to dry
thoroughly before heading to the next is
strongly recommended.
INSTRUCTIONS
Tornadodo
The exclusive copyright on the model designs are the property of Waggys Workshop Ltd. © Copyright Waggys Workshop Ltd., 2018. All rights reserved.
Some parts of this kit are very
fine, or have engraving very
close to edges. Make sure you
cut through any tabs carefully
with a hobby knife first to avoid
damage.

It’s a good idea to familiarise
yourself with how the stand
locates at this point.
Note that it will work with and
without the troop pod.
Make sure the Stub ings are
horizontal.

Glue the lower stabilizer
surface securely to top of the
engine exhausts.
There will be a gap here:

You can give the tail rotors a
bit of twist before gluing
them in place for a more
exciting look.

This can be a tight fit.

Toothpicks (2mm diameter)
25mm long.

This Kit Provides alternative parts
for the rotor assembly.
A simple, one piece , flat part and
a more involved option that al-
lows for More Complex, but
AY cooler angled blades.
A Jig is also provided to help
align the individual rotor blades
(green)
Be VERY CAREFUL not to glue
your model to the jig.
The Easy way.
DO NOT GLUE
ANYTHING TO THE
GREEN JIG!!!!!!!

DO NOT GLUE
ANYTHING TO THE
GREEN JIG!!!!!!!
DO NOT GLUE
ANYTHING TO THE
GREEN JIG!!!!!!!
( I may have mentioned this
earlier...)

Choose the angle
you want to place
the rotor blades at
and carefully glue
them in place, work-
ing alternately from
opposite sides.
Superglue is useful
here. Position the
part first, a place a
drop of superglue
where the parts con-
nect.
DO NOT GLUE
ANYTHING TO THE
GREEN JIG!!!!!!!
