Miniature Scenery Zephyr Penguin User manual

Preparation
Once you clear some table space you will need a
hobby knife and glue (PVA, wood glue, hobby glue)
and a file or small piece of sandpaper to be used for
cleaning up any tiny imperfections.
It’s a good idea to familiarise yourself with how the
pieces fit together before gluing.
Getting Started
I. Parts should remove easily from the board by
pressing through and popping them out. It’s a
good idea to cut through the tiny joins first
though, and some parts (particularly smaller,
more detailed parts) may need more careful
persuasion.
II. Use a file or sand paper last to completely
remove the tabs that might remain.
III. Parts may be a very tight fit, slight trimming
or sanding of parts may be needed for ease of
assembly.
Construction
Slot the parts together as shown by the pic-
tures below, applying glue wherever there is
a connection.
Allow the model to completely dry before
painting it. This is a complex kit with many
small parts. Allowing each section to dry
thoroughly before heading to the next is
strongly recommended.
INSTRUCTIONS
Zephyr Penguin
The exclusive copyright on the model designs are the property of CNC Workshop Ltd. © Copyright CNC Workshop Ltd., 2006. All rights reserved. Made in Australia
Some parts of this kit are very
fine, or have engraving very
close to edges. Make sure you
cut through any tabs carefully
with a hobby knife first to avoid
damage.

ERRATA!!!
I goofed. Eaerly kits
will have a piece which
will need these bits
removed.
Sorry about that.

This Kit Provides alternative parts
for the rotor assembly.
A simple, one piece , flat part and
a more complex option that al-
lows for angled blades.
A Jig is also provided to help
align the individual rotor blades
(green)
Be VERY CAREFUL not to glue
your model to the jig.
This part
Replaces
these
parts (the
top ring
with the
indents
and the
Central
notched
hub.
NOTE THE DIRECTION OF
THE CENTRAL HUB IN RE-
LATION TO THE OUTER
RING. DO NOT GLUE
ANYTHING TO THE
GREEN JIG!!!!!!!

Choose the angle
you want to place
the rotor blades at
and carefully glue
them in place, work-
ing alternately from
opposite sides.
Superglue is useful
here. Position the
part first, a place a
drop of superglue
where the parts con-
nect.
You will have to
trim the top surface
flush after the as-
semble is dry, so the
next part fits prop-
erly.

Choose an angle that you like
for the rotor and glue into
position.

Make sure when you build the
two thrusters that you make
two opposites.

You are going to need a piece of plastic rod/ brass/tubing
about 4mm in diameter and 60mm long for this bit. If all else
fails, wrapping some paper around a wood BBQ skewer will
work just fine.

Toothpick. 2mm diameter.
Space these about a
millimetre apart.
If you like.

A toothpick can be used to
help align the parts here.
