Miniature Scenery TWISTED STEAMPUNK CATCHWAGON User manual

TWISTED STEAMPUNK
CATCHWAGON

Preparation
You will need:
- Cutting mat or something to protect your table.
- PVA/Wood glue or superglue if you prefer.
- Small file or sand paper.
- Small blade / hobby knife
General Process
- Clear plenty of table space, you will need it.
- Parts should remove easily from the board by pressing through and
popping them out. It’s a good idea to cut through the tiny joins first
though, and some parts (particularly smaller, more detailed parts) may
need more carful persuasion.
- Use file or sand paper to remove the small bur caused by the con-
nection to the frame.
- It’s a good idea to familiarise yourself with how the pieces fit to-
gether before gluing.
- Slot the parts together as shown by the pictures below, applying
glue wherever there is a connection. (unless shown otherwise)
- Parts may be a very tight fit, slight trimming or sanding of parts
may be needed for ease of assembly.
Instructions
TWISTED
CATCHWAGON

Important Note: Through-
out the construction of this kit
parts such as the body of the
horse will need to be aligned
carefully. Use the holes provid-
ed to insert (DO NOT GLUE)
some of the provided 2mm tub-
ing to help with this. The in-
structions will tell you when
it’s time to glue the tubing in.

Alignment point
Cut tubing to 10mm length
and glue centrally.

Hole should be clear !

Hole should be clear !

Hole should be clear !

WELCOME to the TINIEST
BITS in the kit!
They’re especially fiddly.

Holes should be clear !

Cut tubing to 40mm length
and glue centrally.

Cut tubing to 40mm length
and glue centrally.
Cut tubing to 18mm length
and glue
Tubing should protrude by
approximately 2mm.

Cut tubing to 8mm length
and glue. Cut a small notch
to better represent a
whistle.
4mm dowel
