Minolta PageWorks Pro 25 User manual

Quick Guide for Installation and Reference
PageWorks 25

Step 1 Unpacking the Printer ..................... 1
Reference 1 Printer Parts..................................... 4
Reference 2 PageWorks 25 Overview ................. 5
Reference 3 Control Panel ................................... 6
Step 2 Installing the Imaging Cartridge .... 8
Step 3 Loading Paper................................ 10
Step 4 Connecting the Power Cord ......... 13
Step 5 Turning the Power On/Off ............. 13
Step 6 Printing a Test Page ...................... 14
Step 7 Connecting the Printer to the
Computer (Local Connection)......16
Step 8 Installing the Printer Driver .......... 17
Reference 4 Printer Menus................................. 19
Reference 5 Troubleshooting............................. 23
Contents

1
Before operating your printer, read this Quick Guide carefully
from cover to cover. Use this guide for reference.
1.
Take the items and accessories shown above out of the carton.
Note
2.
Remove the plastic bag and peel off the shipping tape from the printer.
After unpacking, keep all packing materials out of the reach of children.
Unpacking the Printer
Step 1
32
11.Printer
2.Accessories
User’s Manual
Printer Driver
User’s Manual
for Windows 3.1
Quick Guide
CD-ROM
Floppy Diskette
Power cord
Paper Size Label
Warranty card
Registration card
3.Imaging Cartridge

2
3.
Pull out Tray 1 and remove the cushion from Tray 1.
Close Tray 1.
4.
Pull out Tray 2 and remove the cushion from Tray 2.
Close Tray 2.
Step 1

3
5.
Pull the side cover release lever and open the side cover.
Peel off the protective sheet from the image transfer roller.
Close the side cover.
Step 1

4
Printer Parts
Reference 1
Control
panel
Power
switch
Tray 1
(multipurpose
tray)
Tray 2
(500-sheet
tray)
Side cover
Side cover
release lever
Paper size
selection dial
Parallel inter-
face connector
Power cord
socket
Imaging
cartridge

5
Note
The duplex unit, manual feed tray, 500-sheet paper feed unit, 250-sheet paper feed
unit, 2500 sheet tray, 5-bin mail-bin, 10-bin mail-bin (including the horizontal transport
unit andupper attachment), SIMM and NIC (Network Interface Card) are all available
options for your printer. For more information, please refer to the User’s Manual.
PageWorks 25 Overview
Reference 2
Upper attachment (option) 5-bin Mail-bin (option)
Horizontal
transport unit (option)
Printer Duplex unit
(option)
10-bin Mail-bin
(option) 2500 sheet tray (LCC) (option)
Manual feed unit
(option)
Tray 3/4/5
(250-sheet paper
feed unit) (option)
(500-sheet paper
feed unit) (option)

6
The control panel consists of a display panel (LCD), three indicator lights
and eight function keys.
Indicator Lights
There are three indicator lights that the printer uses to alert you to the
following situations:
Indicator On Off Blinking
On Line The printer is ready
to receive data. The printer cannot receive data. Going off-line.
Data Dataisbeingstored
in the printer memo-
ry.
No data is stored in
the printer memory. The printer is re- ceiving and pro-
cessing data.
Message Engine error.
The printer requires
service.
No error. Recoverable error,
such as paper emp-
ty, paper misfeed,
etc.
Control Panel
Reference 3
Data Message On Line Proceed Tray 1 Paper Shift
Job Cancel
Menu Item Select Enter
1Data indicator
2Message indicator
3On Line indicator
4On Line key
5Proceed key
6Tray1 Paper key
7Shift key
8Enter/Job Cancel key
9Select key
10 Item key
11 Menu key
12 LCD
12 34567
89101112

7
Key Functions
Note
Press this key to switch between online and offline modes. The printer
must be online in order to receive data.
Press this key to resume printing after one of the following situations has
occurred:
- when a Paper Size Error occurs.
- when a Memory Overflow or Job Too Complex error occurs.
- when the LOAD XX message appears due to a paper size error.
Press this key in order to enter the mode for setting the paper size (when
the dial on the Tray1 is set to User set) and media type for Tray1. You can
only enter this mode when the printer is off-line.
The shift key performs various functions when pressed in combination with
the following other keys:
Menu key: each menu will be displayed and rotated in reverse order.
Item key: each item will be displayed and rotated in reverse order.
Select key: each user selection value is displayed and rotated in reverse
order.
Press this key to enter the Menu mode when the printer is off-line. Press
this key repeatedly to display the Menu group in order.
Press this key to enter the Item mode when the printer is in the Menu
mode. Press this key repeatedly to display the items in order.
Pressthiskeytoenter theUserSelectionmodewhentheprinterisineither
the Item mode or the Tray1 Paper Menu mode. Press this key repeatedly
to view the user selection values in order. Press and hold the Select key
in order to increase the value at high speed.
Press this key to save User Selection settings. This key can be pressed in
combination with the Shift key to cancel a job that is currently being pro-
cessed and to clear the data for ajob from the printer’s memory. A job can
only be cancelled by using the Enter/Job Cancel key in combination with
the Shift key when the printer is off-line and when the Data indicator is ei-
ther on or blinking.
In order to cancel a job using the Enter/Job Cancel key through the proce-
dure described above, the printer must be off-line. You can force the printer
to go off-line by pressing the On Line key while printing.
Reference 3
On Line
Proceed
Tray 1 Paper
Shift
Menu
Item
Select
Job Cancel
Enter

8
Installing the Imaging Cartridge
Step 2
1.
Pull the side cover release lever
and open the side cover.
2.
Take the imaging cartridge out of
the carton.
Holding it with both hands, shake
it left and right, forward and
back.
3.
Carefully remove the packing tape that is adhered to the grips by pulling
from the bottom up.

9
4.
Align the green guides on the imaging cartridge with the slot bearing the
green seal located inside of the printer.
Step 2
5.
Insert the imaging cartridge as
far as it will go inside of the
printer.
6.
Close the side cover.

10
Loading Paper onto Tray1
Loading Paper
Step 3
1.
Slide open Tray 1.
2.
Press down on the paper lifting
plate located inside of tray 1 until
it clicks into place.
3.
Adjust the green clip to the
appropriate paper size by
squeezing its sides and sliding it
through the runner at the bottom
of the tray.
4.
Press the green button located
near the outer edge of the tray to
adjust the paper guides.

11
Step 3
5.
Load the proper size of paper
within the guides. The stack of
paper that is loaded onto the tray
should not exceed the maximum
level indicator (see illustration).
6.
Close Tray1 and set the size of
paper loaded in the tray on the
dial.
Note
• Before setting the paper size, set the media type for Tray 1 through the
Tray 1 Paper Mode on the control panel.
• When printing on envelopes and custom sized paper, it is necessary to set
the dial to User Set and then specify the paper size in the Tray1 paper
menu through the Control Panel.
Loading Paper onto Tray2
1.
Slide open Tray 2.
2.
Press down on the paper lifting
plate located inside of tray 2 until
it clicks into place.

12
3.
If necessary, adjust the paper braces to the size of the paper to be loaded.
Use a phillip’s screwdriver to remove the braces from the tray. Be sure to
secure the braces into their new position using the screwdriver before pro-
ceeding to step 4.
Step 3
4.
Load the proper size of paper
within the braces. The stack of
paper that is loaded onto the tray
should not exceed the maximum
level indicator (see illustration).
5.
Set the size of paper loaded in
the tray on the dial, and close
Tray 2.

13
Connecting the Power Cord
Step 4
1.
Make sure that the printer’s
power switch is in the O(Off)
position.
2.
Connect one end of the power
cord that comes with the printer
to the power cord socket. Plug
the other end into a power outlet.
Turning the power OFF
Press the power switch to the O(Off) position to turn the printer off.
Note
DO NOT turn the power OFF while:
•printing
• the printer is receiving data from the computer (the indicator on the con-
trol panel is blinking)
• resetting the printer
Turning the Power On/Off
Step 5
Turning the power ON
After connecting the printer to a
power outlet, press the power
switch to the I(On) position.
In about 60 seconds, the READY
message is shown on the LCD
display, indicating that the printer
is ready to print.

14
Printing a Test Page
Step 6
1.
Turn the printer on.
Make sure that Letter-size paper
is loaded into the printer’s feeding
tray.
Make sure that the READY mes-
sage is shown on the LCD display.
2.
Press the On Line key to take
the printer off-line.
3.
Press the Menu key repeatedly
until the TEST MENU is found.
4.
Press the Item key once. CON-
FIG PRINT appears on the LCD
display.
On Line
Job Cancel
Enter
5.
Press the Enter key to start printing the test page.
Menu Item

15
Sample
Step 6

16
1.
Turn the printer and the computer off.
2.
Connect one end of the interface cable to the parallel port of the computer.
3.
Connect the other end of the cable to the parallel connector on the back of
the printer. Secure the cable using the two clips on the parallel connector.
Connecting the Printer to
the Computer (Local Connection)
Step 7

17
Install the printer driver to control printing from your computer.
You can install the printer driver for Windows 95, Windows 98 or Windows
NT 4.0 from the Minolta PageWorks 25 Printer Drivers CD-ROM.
Follow the instructions described below and for more details, see the
User’s Manual that comes with your printer.
Windows 95/98
Installing from CD-ROM (Auto Run)
1. Turn on your computer and start up Windows 95/98.
2. Insert the Minolta PageWorks 25 Printer Drivers CD-ROM into your
computer’s CD-ROM drive.
3. The opening window automatically appears on the screen.
Click PCL Driver and follow the instructions.
After installing the printer driver, the Minolta PageWorks/Pro 25 printer
icon appears in the Printers folder.
Note
Plug and Play installation
Make sure that the printer is connected to your computer with the parallel
interface cable.
1. Turn on the printer.
2. Turn on your computer and start up Windows 95/98.
3. At the Update Device Driver Wizard or Add New Hardware Wizard dia-
log box, make sure your printer name is displayed and click the Next but-
ton.
(If the Update Device Driver Wizard or Add New Hardware Wizard dialog
box does not appear, see “Auto Run”.)
If the auto run does not perform, double-click the Install.exe from the CD-
ROM. The opening window appears on the screen. Click PCL Driver and fol-
low the instructions that appear on your computer screen to complete the in-
stallation.
Installing the Printer Driver
Step 8
