MINOURA M70-R - SCHEMA User manual

M70-R Schematics
BF-3
UF-9
UF-8
UF-6
UF-7
M5-2
BF-4
BF-6
MF-3
EM-1
EM-2
EM-3
EM-4
EM-5
EM-6 EM-17
EM-8
EM-11
LM-10
BF-3: M70/80 Main Frame (White) EM-1: Outer Cap
BF-4: Leg Rubber Cover (Red) EM-2: Axle Holder
BF-6: Leg Rubber EM-3: Drive Roller & Bearing
UF-6: Right Side Coupling & Clamp Lever EM-4: Main Housing
UF-7: Clamp Lever Guide EM-5: Alloy Plate
UF-8: Left Side Coupling EM-6: Magnet Plate (M70/80-R)
UF-9: Coupling Lock Ring (Red) EM-8: Flywheel Cover (White)
M5-2: Rubber Foot Cap (29mm) EM-9: Remote Base
MF-3: Micro Adjust Knob Set EM-10:Cable Guide
LM-10: Base Plate EM-11:Connecting Plate
LM-14: Remote Shifter (Black) EM-17:Flywheel (600g)
BF-4
BF-6
(Remote version)
EM-9
EM-10
LM-14
