Mio MiVue 795 Series User manual

User Manual
MiVue™795 / 798 Series

4
Getting to know your dash cam
Note: The screenshots and other presentations shown in this manual may differ from the ones
generated by the actual product.
1
2
3
5
6
9
4
7
8
10
11
12
13
1Power button
2 Device mount socket
3Mini-USB connector
4Shutdown button
5 LCD screen
6Microphone
7System indicator
8 Event button
9Memory card slot
10
Parking indicator
11
Speaker
12
Camera lens
13
Function keys

5
Using your dash cam in a vehicle
Precautions and notices
lDo not operate the device while driving. Using this product does not change the
requirement for a driver to take full responsibility for his or her behavior. This
responsibility includes observing all trafc rules and regulations in order to avoid
accidents, personal injury or property damage.
lA window mount is needed when using the dash cam in a car. Make sure that
you place the dash cam in an appropriate place, so as not to obstruct the driver’s
view or deployment of airbags.
lMake sure that no object is blocking the camera lens and no reective material is
placed near the lens. Please keep the lens clean.
lIf the car’s windscreen is tinted with a coating, it may impact the recording
quality.
lTo ensure the highest quality recordings, you are advised to place the dash cam
near the rear view mirror.
lSelect an appropriate location for mounting the device in a vehicle. Never place
the device where the driver’s eld of vision is blocked.
lIf the car’s windscreen is tinted with a reective coating, it may be athermic and
impact the GPS reception. In this instance, please mount your device where
there is a “clear area.”
lThe system will automatically calibrate the G sensor of the device during start-
up. To avoid G sensor malfunction, always turn the device on AFTER you mount
it in the vehicle properly.

6
Mounting the dash cam
Make sure that your car is parked on level ground. Follow the instructions to mount
your dash cam in a vehicle securely.
1. Before attaching the device mount to the windscreen, it is recommended to clean
the windscreen with rubbing alcohol and make sure that the installation area is
free of dust, oil and grease. Attach the mount to the windscreen ( 1), and press
the tab ( 2) to lock the suction cup in place.
1
2
2. When adjusting the angle of mounting, make
sure that the camera’s view is parallel with the
level ground and the ground/sky ratio is close
to 6/4.
3. Route the cable through the top ceiling and the
A-pillar so that it does not interfere with driving.
Make sure that the cable installation does not
interfere with the vehicle's airbags or other
safety features.

7
Note: The installation illustrations are for your reference only. The placement of the devices and
cables may vary depending on the vehicle model. If you encounter any problems during installation,
contact a skilled installer (such as the service personnel of the vehicle) for assistance.
MiVue rear camera
Depending on your model, your device may support a rear camera (may be sold
separately).
1Mounting pad
2 Camera lens
3 Adjustment bolt
4Micro-USB connector
16
1
2
34
Follow the illustration to connect the rear camera to the dash cam.
Y cable Rear camera cable
Car charger

8
Using a memory card
Note:
lDO NOT apply pressure to the centre of the memory card.
lMiTAC does not guarantee the product’s compatibility with memory cards from all manufacturers.
l Beforeyoustartrecording,pleaseformatthememorycardtoavoidmalfunctioncausedbylesnot
created by the dash cam.
lTurn the device off before removing the memory card.
You must insert a memory card (not supplied) before you can start recording. The
dash cam supports the Class 10 memory cards with 8 GB – 128 GB capacity. You
should use separate MicroSD cards for recording and for regular data storage.
Hold the card (MicroSD) by the edges and gently insert it into
the slot as shown in the illustration.
To remove a card, gently push the top edge of the card inwards
to release it and pull it out of the slot.
Formatting a card
To format a memory card (all data will be erased), press > Format.
Turning the dash cam on
Complete the installation according to the instructions in the “Using your dash cam
in a vehicle” section. Once the vehicle engine is started, the dash cam automatically
turns on. The System indicator glows in green when the dash cam is powered.
Power button
Press and hold the Power button for 2 seconds to manually turn the dash cam on
and off. When the dash cam is turned on, press to switch the LCD screen on and off.

9
Restarting the dash cam
Occasionally, you may need to perform a hardware reset when the dash cam stops
responding or if it appears to be “frozen” or unresponsive. To restart the dash cam,
press and hold the Power button until the system powers off; press the Power button
again to turn the dash cam on.
If the system does not shut down by keeping the Power button pressed, you can
force it to shut down by inserting a small rod (such as a straightened paperclip) into
the Shutdown button on the device.
System icons
Various system icons on the status bar at the top of the screen provide the status
information of your device. The icons displayed will vary depending on your device
model and state.
1Recording indicator
2WIFI status
3Time display
4Microphone status
5 GPS signal
6Power status
7 Current GPS car speed
1 2 3 5 64
7

10
Function keys
The device provides four function keys to control the corresponding icons displayed
on the LCD screen. The keys' functions may vary on different screens.
Takes a photo.
Enters Parking mode.
Adds a custom safety (speed) camera.
Opens the Menu screen.
(Recording screen)
Moves to the next option.
Acts as the ENTER button.
Moves to the previous option.
Acts as the BACK button.
(Menu screen)
Switching screens
Once you connect the rear camera and start recording, the screen displays the
PIP (picture-in-picture) mode. You can switch the front and rear camera images by
pressing .

11
Setting the date and time
To make sure that the date and time of your recordings are correct, check the
settings before you begin recording.
1. Press > System >Date/Time.
2. Do one of the following:
lSelect Use GPS time, and then select the time zone of your location. The
system will set date and time according to the GPS location.
lSelect Manual, and the system will display the date and time setting screen.
Use / to adjust the value of the selected eld; press and repeat
the step until all elds have been changed. When done, press .
Recording in driving mode
Continuous recording
The system will automatically begin continuous recording in few seconds after start-
up. The System indicator ashes in green and amber alternately while the recording
is in progress.
When continuous recording is in progress, you can manually stop recording by
pressing . Press to return to the recording screen; the system will start
continuous recording automatically.
The recording may be divided into several video clips; recording will not stop
between video clips. When your memory card lls up with continuous recordings, it
will automatically record over the oldest existing les in this category.
The continuous recordings can be found in the “Normal” category for le playback.

12
Event recording
By default, if an event happens such as a sudden impact, high speed driving, an
aggressive turn or an accidental crash during continuous recording, the G sensor will
prompt the dash cam to start recording the event.
Note: You can change the sensitivity level of the G sensor by selecting > Video Recording >
G-Sensor Sensitivity.
The event recording will save moments before and moments after the event. When
your memory card lls up with event recordings, it will automatically record over the
oldest existing les in this category.
If you want to manually start an event recording while continuous recording is in
progress, press the Event button.
The event recordings can be found in the “Event” category for le playback.
Parking mode
Your dash cam supports the parking recording function. You must use an additional
power source to record the video during the Parking mode, such as a Mio
uninterruptible power cable which is sold separately. For more information on using
a Mio power cable, see the provided documentation in its package.
The Parking mode is disabled by default. Before enabling the Parking mode,
please check the memory storage allocation of your device. Select > System
> Storage Allocation to set a proper allocation for parking recording. Changing
the allocation will erase the memory card, so save any videos or photos to your
computer rst.
You can enable the function by selecting > Parking Mode > Detection > On.
(The icon will appear on the screen.) When the Parking mode detection is
enabled, the system will enter the Parking mode when the car stops moving for
about 5 minutes.

13
In the Parking mode, parking recordings could be triggered only when movements
or vibrations are detected. The parking recording will save the duration from seconds
before the event until seconds after the event. When your memory card lls up with
parking recordings, it will automatically record over the oldest existing les in this
category.
Note:
lYou can press to manually enter the Parking mode while continuous recording is in progress.
lThe parking recording is triggered by the G sensor and motion detection of the device. You can
changethecongurationbyselecting > Parking mode > Motion Detection and G-Sensor
Sensitivity.
lThe rear camera (optional) does not support motion detection.
To exit the Parking mode and resume continuous recording, press . If
movements are detected and recorded during the Parking mode, you will be asked
to playback the video when you exit the Parking mode.
The parking recordings can be found in the “Parking” category for le playback.
Camera mode
The dash cam allows you to take a photo.
lIf the recording is in progress, press to take a photo. (This function is not
available when the rear camera is connected.)
lPress > Camera >.
The photos can be found in the “Photo” category for le playback.

14
Playback mode
To select a video or photo for playback:
1. Press > File Playback.
2. Select the desired type.
3. Press / to select the desired le from the list and then press to
start playback.
4. During playback, you can:
lPress to return to the list.
lWhile playing videos, press / to play the previous/next video.
Press to display the pop-up menu to select:
lPlay / Pause: Starts or pauses the playback.
lPlay rear video / Play front video: The "D" icon displayed on the thumbnail
on the playlist indicates that the video comes with a corresponding rear
video. While playing the video, you can use this option to switch between
the front and rear videos.
Note: Thevideolesrecordedbythefrontandrearcameraswillbesavedseparately
in the corresponding folders of the memory card. If you move or delete a front video, its
corresponding rear video will be processed synchronously.
lMove to Event: Moves the le to the “Event” category.
lTransfer video / Transfer photo: Uploads the selected video/photo to your
smartphone.
lDelete: Deletes the le.
lWhile viewing photos, press / to display the previous/next photo.
Press to delete the le.

15
Safety camera alerts
Note: For legal reasons, the safety camera function is not available in all countries.
You can receive alerts to warn you about the
locations of safety (speed) cameras which will
enable you to monitor your speed through these
areas.
When a safety camera appears and is positioned
in the detectable direction, you will receive alerts.
The screen will display the visual alert and you will
also receive audio warnings.
When the alert sound setting is set to Beep:
lWhen your car approaches a safety camera, you will receive a normal beep alert.
lWhen your car approaches a safety camera at a speed over the set threshold,
you will receive a persistent beep alert until your car speed drops lower than the
appropriate speed limit.
lWhen your car passes through a safety camera, you will be notied by a different
beep alert.
You can change the settings about how you want to receive the safety camera alerts.
See the “System settings” section for information.
Adding a safety camera
Note:YoucanaddacustomsafetycameraonlywhenaGPSxisestablished.
Your dash cam allows you to customise the safety camera database. You can add
up to 100 custom safety cameras in your dash cam.
Follow the steps to congure a custom safety camera:

16
1. To add a custom safety camera in the current location, press on the
recording screen.
2. The next time when you pass by the location, you will receive alerts by the dash
cam.
3. To view the information of the custom safety camera, select >SafetyCam >
Custom SafetyCam and then select the safety camera that you want to check.
4. Press to remove the custom safety camera from the dash cam.
Updating safety camera data
MiTAC does not warrant that all types and locations of safety camera data are
available as cameras may be removed, relocated or new cameras installed.
Occasionally, MiTAC may offer you updates of safety camera data. Visit the Mio
website for available downloads and follow the instructions to complete update.
Getting connected
MiVue Pro app
The MiVue Pro app allows you to view, share and back up the videos recorded on a
MiVue dash cam via WIFI. Search for "MiVue Pro" in Apple App Store or in Google
Play Store to download the app for free.
Note:
lThe MiVue Pro app is compatible with iOS 9.0 (and above) and Android 5.0 (and above) devices.
MiTAC does not guarantee the product’s compatibility with smartphones from all manufacturers.
lNot all MiVue dash cam models support the MiVue Pro app or all its features.

17
Setting up a WIFI connection
The WIFI function allows you to connect the dash cam to your smartphone. The
WIFI function is disabled by default. You can enable WIFI by selecting > WIFI >
On. Once enabled, the WIFI setting screen displays the SSID and password of the
dash cam.
On your smartphone, follow the steps to set up the WIFI connection.
1. Make sure that you have enabled the WIFI function on the smartphone.
2. Open the MiVue Pro app and tap the "+" icon.
3. Tap Select WIFI and then select the dash cam you want to connect to.
4. Tap Done to complete the WIFI connection.
5. Once the devices are connected, the screen will display the main page ( ).
Note: The WIFI connection between your Mio and smartphone is not Internetenabled.
You can check the WIFI connection status by the WIFI icon on the dash cam.
The dash cam is connected to the smartphone and paired with the
MiVue Pro app.
The dash cam is not connected to the smartphone.

18
The dash cam is connected to the smartphone but not paired with the
MiVue Pro app yet.
On your smartphone, open the MiVue Pro app and keep it awake. You can now
transfer videos by pressing the Event button.
System settings
Note: Not all setting items and options are available for all models.
To customise the system settings, press .
lFile Playback
Plays the recorded videos and photos.
lCamera
Press to enter Camera mode.
lWIFI
Enables or disables WIFI.
lSound Recording
Sets if you want to include sounds in the recordings.
lTPMS
TPMS (Tyre Pressure Monitoring System) is an electronic assistant device
installed in the car's tyres to monitor the air pressure via your MiVue dash cam.
You will receive alerts if the tyres are under (or over) inated.
To congure the TPMS settings, press .
l
Units: Sets the unit of the pressure (psi, Bar, kPa or kg/cm
2
) and temperature
(ºC or ºF).

19
l
Front Tyre Sensors: Sets the minimum/maximum pressure and maximum
temperature for the front tyres.
l
Rear Tyre Sensors: Sets the minimum/maximum pressure and maximum
temperature for the rear tyres.
l
Sensor Location: Sets the sensors' locations.
l
Learning Mode: When new TPMS sensors are installed, use this option for the
dash cam to detect the new sensors.
Note: For more information on installing and using TPMS, see the documentation that comes
with the product.
lDriving Safety
The dash cam provides advanced driving safety functions to make your driving
safer.
l
Calibration: Follow the steps to calibrate the system.
1. Drive the vehicle in the middle of the lane.
2. Ask a passenger to select this option and then follow the on-screen
instructions to complete calibration.
Please adjust your device to
align the red line with the
horizon, and the green line
with the centre of the lane.
Please align the blue line with
the hood.
Note: You are advised to calibrate the system constantly in order to be alerted properly.
lLDWS: Select Beep or Voice to enable the LDWS (Lane Departure Warning
System) function. The system will alert you when it detects that the GPS car
speed is over 60 km/h and the car has strayed from its intended lane.
lHeadlight Reminder: Once enabled, the system will remind you to turn the
lights on when you are driving after dark. The default setting is Off.

20
lDriver Fatigue Alert: Once enabled, the system will remind you to take a
break for a long-distance drive (2 hours, 3 hours or 4 hours). The default
setting is Off.
lEco Drive Indicator: Once enabled, the system will display the Eco drive
indicator on the screen. The colour of the indicator will change (red, yellow or
green) depending on your driving status to remind you to drive more efciently.
The default setting is Off.
lFCWS: Select Beep or Voice to enable the FCWS (Forward Collision Warning
System) function. The system will alert you when the car moves slowly and
gets too close to the car ahead.
lStop and Go: Once enabled, the system will alert you when the car ahead has
proceeded to go after being stopped for longer than 10 seconds. The default
setting is Off.
lSafetyCam
Sets how you want to be notied of safety cameras. The available settings
include:
lAlert Sound: Turns on (Beep or Voice) or off (Mute) the alert sound.
lAlert Distance: The system will alert you at a preset distance (Short,
Medium or Long) when a safety camera is detected.
lAlert Method: Sets the alert distance function according to the current GPS
car speed (Smart Alert) or the speed limit (Standard Alert).
lThreshold: Sets the speed value for the dash cam to start offering alerts.
lCruise Speed Alert: Sets the limit for the cruise speed. When you drive at a
cruise speed over the set value, you will receive alerts by the dash cam.
lCustom SafetyCam: Lists all custom safety cameras which are sorted by the
created time.

21
lParking Mode
Allows you to change the settings of Parking mode. The available settings
include:
lDetection: When enabled, the dash cam will automatically start recording
when it detects movements or if an event happens in Parking mode.
lDetection Method: Sets the parking detection method to Only G-sensor,
Only Motion or Both Motion & G-sensor.
lAuto Entry: Sets the mode (Low, Medium, High or Manual) for the system
to enter Parking mode automatically.
lMotion Detection: Sets the sensitivity level of motion detection to Low,
Medium or High.
lG-Sensor Sensitivity: Sets the sensitivity level of the G sensor that allows
automatic triggering of the parking recording when the dash cam is in Parking
mode.
lLED Indicator: Turns on or off the parking indicator.
lVideo Recording
Changes the settings of recording, including:
lVideo Clip Length: Sets the length of each video clip for a continuous
recording.
lVideo Resolution: Sets the resolution of the video.
lWDR: Enables the Wide Dynamic Range (WDR) function to improve the dash
cam's image quality under high-contrast lighting conditions.
lEV: Sets the exposure level to adjust the brightness of the image.
lFrequency: Sets the frequency for the camera to avoid problems caused by
articial light sources that are not constant.

22
lG-Sensor Sensitivity: Sets the sensitivity level of the G sensor that allows
automatic triggering of the event recording while continuous recording is in
progress.
lStamps: Sets the information (Coordinates or G-Sensor) that will be
displayed on the recorded video.
lSpeed stamp: Displays the driving speed on the recorded video.
lText stamp: Displays customisable text information.
lSystem
Allows you to change the system settings of the device.
lSatellites: Displays the status of the GPS/GLONASS signal reception. You
can press and then select GPS or GLONASS for better signal reception if
the need arises.
lDate/Time: Sets the system date and time.
lSystem Sound: Enables or disables system notication sounds.
lWelcome Sound: Enables or disables the notication sounds during start-up.
lVolume: Adjusts the volume level.
lLCD Standby
lAlways On: Keeps the LCD on.
lHUD: Turns off the LCD (in specied time) but still displays the time and
speed information.
l10 sec / 1 min / 3 min: Sets the timer for the LCD to turn off automatically
after recording starts.
lLanguage: Sets the language.
lDistance Unit: Sets the preferred distance unit.
