D-1010-ATVN Instruction Manual 430-450 MHz Power Amplifier
1
D-1010-ATVN
430-450 MHz AMPLIFIER
The MIRAGE D-1010-ATVN represents the latest in 430-450 MHz Power amplifiers. It incorporates
features that make it the most versatile and useful amplifier available today. The D-1010-ATVN will
amplify FM, SSB, and CW signals. It has variable SSB delay, remote Keying, over-temperature protection,
and remote control operation when using the optional RC-1, Remote.
SPECIFICATIONS
FREQUENCY RANGE....................430-450 MHz
POWER.............................................INPUT: 3-15 watts
OUTPUT: Min of 100 watts with 10W in
MODES.............................................FM, SSB, CW, ATV with modifications
DC POWER ...................................... 13.6 VDC @ 20 amps nominal
FUSE.................................................35 AMP (internally mounted)
IMPENDANCE.................................50 Ohm input and output
DUTY CYCLE..................................Intermittent-internal overtemp
SIZE...................................................12" x 3" x 5-1/2"
WEIGHT...........................................5 LBS
INSTALLATION
The D-1010-ATVN may be mounted using the brackets (supplied when request is
returned via warranty card) or simply placed in a convenient operating position. The D-
1010-ATVN must have adequate ventilation for the finned heat-sink. Use #8 or larger
wire to connect the D-1010-ATVN to the battery is recommended. RG-8U, or the
equivalent, should be used between the D-1010-ATVN and the antenna. The antenna
should be matched to better than 1.5:1 for best performance. SWR greater than 3:1 may
cause damage to the amplifier voiding and warranty.
FRONT PANEL FUNCTIONS
POWER ON/OFF..............................This switch turns the power amplifier ON and OFF.
SSB/FM.............................................Selects the relay time-delay for the mode of
operation. In either the SSB or FM position, the
amplifier is still biased for linear operation.
LED (Power/On) ...............................This LED will go out if the amplifier overheats. It
will come back on when the amplifier cools.
LED (Tx)...........................................This LED will light during transmitting periods.

D-1010-ATVN Instruction Manual 430-450 MHz Power Amplifier
2
REAR PANEL FUNCTIONS
"RADIO"........................................... This connects to the transmitter or transceiver.
"ANT" ............................................... This connects to the antenna.
RCA Jack ..........................................This connector can be used to ground key the
transmit relay if the input signal is too weak to
activate the RF sensing circuit which normally
handles the function.
6-Pin Remote Connector................... The RC-1 Remote Control Head connects here.
PRECAUTIONS
OUTPUT POWER............................ The D-1010-ATVN puts out enough power to cause
heating of the antenna coax. RG-8 or equivalent is
recommended between the amplifier and antenna.
HEAT SINK TEMPERATURE........Along with high power output, comes the
possibility of high heat sink temperatures. The D-
1010-ATVN must be mounted where air can
circulate over the heat sink. The D-1010-ATVN
has a built-in thermostat that will turn it "OFF" at
170 degrees F. The amplifier will not come back on
until the temperature drops to 140 degrees F.
INPUT POWER................................Input power should not exceed 15 watts. Higher
power than this may cause failure of the input
transistor. This will VOID ANY WARRANTY.
SSB OPERATION............................The D-1010-ATVN can be overdriven causing the
SSB signal to be distorted. When using the D-
1010-ATVN on SSB, the drive level or the mic gain
from the exciter should be adjusted for best "on the
air" performance.
INTERNAL ADJUSTMENTS
SSB DELAY .....................................This allows the XMT relay delay time to be adjusted
to various lengths. Access to this adjustment is
through the hole in the left side of the cover, behind
the front panel. A small screwdriver can be used to
make the adjustment.
RF ADJUSTMENTS ........................There are no internal adjustments dealing with the
RF amplifier board. Tuning of the RF amplifier is
preset at the factory by our technicians.
FUSE.................................................A 35-amp fuse is located under the cover on the PC
board. Should the fuse "blow," determine the cause
and use the exact type in the unit as a replacement.

D-1010-ATVN Instruction Manual 430-450 MHz Power Amplifier
3
"ATV MOD".....................................Remove .1 mfd cap and 10 ohm resistor which
crosses over both final power transistors and
connects each base to its collect lead. These
cap/resistor networks are designed to eliminate low
frequency oscillations and will distort ATV signals.
IN CASE OF DIFFICULTY
1. Check for loose antenna or B+ connections.
2 Check SWR of antenna.
3. Look for bad or lossy coax.
TECHNICAL ASSISTANCE
If you have any problem with this unit first check the appropriate section of this manual.
If the manual does not reference your problem or your problem is not solved by reading
the manual you may call MIRAGE at 601-323-8287. You will be best helped if you have
your unit, manual and all information on your station handy so you can answer any
questions the technicians may ask.
You can also send questions by mail to MIRAGE, 921 HWY 25 South, Starkville, MS
39759 or by Fax to 601-323-6551. Send a complete description of your problem, an
explanation of exactly how you are using your unit, and a complete description of your
station.
