USER MANUAL
TIME TO COUNT PROBE
STTC /STTC-W
code 83023 / 88914

USER MANUAL
STTC / STTC-W
code 83023 / 88914
March 2017

USER MANUAL
STTC / STTCW
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
3 / 14
WARNING
CANBERRA
cannot be held responsible for any damage incurred by the buyer due to faulty use,
connection to the wrong voltage, or non
-observance of the instructions found in this manual.
The informa
tion contained herein may be altered without notice.
Any full or partial reproduction of this document may only be made after obtaining prior permission
from
CANBERRA.

USER MANUAL
STTC / STTC-C
4 / 14
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex

USER MANUAL
STTC / STTCW
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
5 / 14
TABLE OF CONTENTS
1. PRESENTATION .....................................................................................................................................7
2. CHARACTERISTICS...............................................................................................................................8
2.1. STTC MECHANICAL CHARACTERISTICS ...............................................................................................8
2.2. STTC-W V2 MECHANICAL CHARACTERISTICS......................................................................................8
2.3. ELECTRICAL CHARACTERISTICS ..........................................................................................................8
2.4. ENVIRONNENTAL CHARACTERISTICS....................................................................................................8
2.5. PHYSICAL CHARACTERISTICS ..............................................................................................................9
3. PROBE FUNCTIONING ........................................................................................................................11
3.1. UNITS DISPLAY .................................................................................................................................11
3.2. IDENTIFICATION OF THE PROBE FUNCTIONING MODE ...........................................................................11
3.3. ALARM SET POINTS...........................................................................................................................11
3.4. PROPER DETECTOR FUNCTION TESTING .............................................................................................11
3.5. PROBES PARAMETERS SETTING.........................................................................................................11
3.6. DATA LOGGING.................................................................................................................................11
4. USE ........................................................................................................................................................12
4.1. CONNECTING THE PROBE ..................................................................................................................12
4.2. CONNECTING THE STTC-W PROBE ...................................................................................................12
4.3. DISCONNECTING THE STTC PROBE ...................................................................................................13
4.4. CONNECTING THE STTC TO THE CSP-COM......................................................................................13

USER MANUAL
STTC / STTC-C
6 / 14
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex

USER MANUAL
STTC / STTCW
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
7 / 14
1. PRESENTATION
The STTC probe is intended for the measurements of the ambient equivalent dose rate for gamma
radiations. It can be connected to any CSP survey meter via the appropriate connection cable. It allows
to widen the measure dynamics of the device and to run remote measurements up to 20 meters. It
comes under the shape of a compact and sturdy metal case which contains the Geiger-Müller detector,
the high voltage supply and the pulses shapers.
Due to its wide range of measure, it can be used in nuclear power plant to control very variable gamma
streams, but also in medicine or in emergency situation (measure after accident, fire brigades). It is also
possible to use this probe in measure of environment, combined with a remote communication device
CSP-COM, if the measure of the background is not exactly required.
STTC-W is the waterproof version of STTC. It includes a 20 meters cable on a reel and ballast. STTC-
W cable is mounted on probe body via a cable gland to ensure good waterproofness down to 40
meters.
The STTC probe can be connected to CSP survey meters and radiameters such as :
-Avior 4000 with a firmware version 1.08 or superior,
-Radiagem 4000 with a firmware version 4.22 or superior,
It can also be connected to a PC :
-equipped with CSPS Software version 2.0 or superior,
-equipped with a software using CSP-PL ™.
Note: the new versions of the firmware can be downloaded for free on the Canberra website:
www.canberra.com. See the user manual of the survey meter for the complete update procedure.
For connecting the probe to the CSP-COM, an aluminium adapter ring is provided.
STTC-W
STTC

USER MANUAL
STTC / STTC-C
8 / 14
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
2. CHARACTERISTICS
2.1. STTC MECHANICAL CHARACTERISTICS
The groove on the probe body indicates the position of the detector center.
Weight: 130g
The probe housing is made of aluminium, and easy to decontaminate.
2.2. STTC-W V2 MECHANICAL CHARACTERISTICS
The groove on the probe body indicates the position of the detector centre.
Weight : 400 g
The probe housing is made of aluminium, and easy to decontaminate.
2.3. ELECTRICAL CHARACTERISTICS
Supply by Radiagem: + 5V, maximum
Supply by PC: + 5 V, maximum
Autonomy: > 80 h if connected to Radiagem
Consumption: 9 mA to 40 mA according to the dose rate.
2.4. ENVIRONNENTAL CHARACTERISTICS
Temperature limit: from - 10°C to + 50°C (14°F to 122°F).
Relative humidity: from 40 to 95 % at 35°C (95°F).
160 mm
133.5 mm
30 mm
35 mm
Detector
position
145 mm
162 mm
30 mm
45 mm
Detector
position

USER MANUAL
STTC / STTCW
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
9 / 14
STTC:
If non-connected: IP 67 (dust proof, water tight up to 1 m).
If connected: IP 55 (dust proof, protected from water jets)
STTC-W:
IP 68: waterproof down to 40 m.
2.5. PHYSICAL CHARACTERISTICS
Detector: compensated Geiger Müller counter.
Measure range: 10 µRem/h to 1000 Rem/h.
IEC approved measure range: 70 µRem/h to 1000 Rem/h.
IEC energy range: Gamma from 36 keV to 1,5 MeV.
Angular response: ±45°.
IEC Measurement accuracy: ±40% on the whole angular range and energy.
Response time < 8 s if rate < 10 mRem/h, otherwise < 2s
Background noise: (in an ambient less than 0.1 mGy/h): < 6 cpm
Sensitivity: 444 cpm/mrem/h
Angular Response
Ref Cs137
0,0
0,3
0,5
0,8
1,0
1,3
1,5
1,8
0°
-45°
-90°
-135°
180°
135°
90°
45°
48 keV
118 keV
208 keV
662 keV
1250 keV
60846
Angular Response relative to Cs137 at 10mSv/H in normal direction

USER MANUAL
STTC / STTC-C
10 / 14
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
Cs137 10 mSv/H
0,0
0,3
0,5
0,8
1,0
1,3
0°
-15°
-30°
-45°
-60°
-75°
-90°
-105°
-120°
-135°
-150°
-165°
180°
165°
150°
135°
120°
105°
90°
75°
60°
45°
30°
15°
Cs137 Angular Response
Energy response
Ref : Cs137 @ 10 mSv/h
0,7
0,8
0,9
1,0
1,1
1,2
1,3
10 100 1000 10000
Relative response
Energy (keV)
relative

USER MANUAL
STTC / STTCW
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
11 / 14
3. PROBE FUNCTIONING
3.1. UNITS DISPLAY
Rem/h for all the CSP survey meters; Rem for compatible survey meters (see user manual).
3.2. IDENTIFICATION OF THE PROBE FUNCTIONING MODE
The type of probe connected is shown on the survey meter display.
3.3. ALARM SET POINTS
The new STTC probes are delivered with 10 values for each unit with default setting stored in their
memory. They can be changed by connecting the probe to a computer with CSPS (Canberra Smart
Probe Software). Selection of the active alarm set point (used for the alarm triggering) is done on the
survey meter.
Units
STTC alarm set points
R/h
1m
2m
5m
10m
20m
50m
100m
1
10
100
R
2m
5m
10m
20m
50m
100m
1
10
100
1000
3.4. PROPER DETECTOR FUNCTION TESTING
The survey meter continually checks to ensure the detector registers a minimum count rate (due to the
background and the genvironment). If no pulses are detected within 180 s for STTC, the system
indicates there is a detector defect by displaying “FAIL” and by sounding 1 audible beep every
10 seconds.
3.5. PROBES PARAMETERS SETTING
The STTC probes parameters setting is performed through a direct link to a PC (USB connection, cord
78466).
The Calibration/Setup software (CSPS) enables to define equivalent activity coefficients, to calibrate the
probe under QA procedure, to modify the probe alarm set points and to download data from probe
memory to PC via a USB cable.
3.6. DATA LOGGING
The probes can store in their memory up to 1000 data stamped measurement points whom the date
and time are written by the connected instrument.
The recorded data are structured as follow: Index, Date, Time, Measurement, Unit, Measurement time.
The unit which is displayed depends on the user selection during the probe connection to the
instrument (§ 3.1).
The data logging running and measurement time setting are performed by the instrument connected.
The data download is performed with CSPS through a direct link to a PC (USB connection, cord
78466).

USER MANUAL
STTC / STTC-C
12 / 14
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
4. USE
4.1. CONNECTING THE PROBE
For the survey meters:
-Connect the probe to the survey meter via a 1,50 m cable (code 77336) or a 20 m cable (code
80653).
Example of a STTC connected to a RADIAGEM
A probe can be connected to the CSP surveymeter even if it is switched on. The host instrument
automatically detects the presence of a probe, if the cable is first connected to the probe and then to the
surveymeter (e.g.: Radiagem).
For the PC equipped with CSPS:
-Connect the probe to the PC via the cable code 78466.
4.2. CONNECTING THE STTC-W PROBE
For the survey meters:
-Connect directly the probe to the survey meter as shown below:

USER MANUAL
STTC / STTCW
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
13 / 14
For the PC equipped with CSPS :
-Connect the probe to the PC via the cable code 78466.
4.3. DISCONNECTING THE STTC PROBE
The probe is equipped with a locking connector, for disconnecting the cable from the probe :
-Pinch the probe side connector between thumb and forefinger,
-Pull on the connector to unlock it and simultaneously pull the cable side connector.
4.4. CONNECTING THE STTC TO THE CSP-COM
The aluminium ring provided with the STTC is necessary to connect the probe to the CSP-COM.
For more details on how to use it, please refer to the CSP-COM User manual (code 85501).
CSP-COM

USER MANUAL
STTC / STTC-C
14 / 14
85568_G.doc
MIRION TECHNOLOGIES (Canberra)
S.A.S,
BP249, ZI de Vauzelles, 37602 Loches Cedex
Warranty Statement
Canberra (we, us, our) warrants to the customer (you, your) that for a period of ninety (90) days from the date of shipment,
software provided by us in connection with equipment manufactured by us shall operate in accordance with applicable
specifications when used with equipment manufactured by us and that the media on which the software is provided shall be
free from defects. We also warrant that (A) equipment manufactured by us shall be free from defects in materials and
workmanship for a period of one (1) year from the date of shipment of such equipment, and (B) services performed by us in
connection with such equipment, such as site supervision and installation services relating to the equipment, shall be free from
defects for a period of one (1) year from the date of performance of such services.
If defects in materials or workmanship are discovered within the applicable warranty period as set forth above, Canberra shall,
at its option and cost (A) in the case of defective software or equipment, either repair or replace the software or equipment, or
(B) in the case of defective services, reperform such services.
LIMITATIONS
EXCEPT AS SET FORTH HEREIN, NO OTHER WARRANTIES OR REMEDIES, WHETHER STATUTORY, WRITTEN, ORAL,
EXPRESSED, IMPLIED (INCLUDING WITHOUT LIMITATION, THE WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE) OR OTHERWISE, SHALL APPLY. IN NO EVENT SHALL CANBERRA HAVE ANY
LIABILITY FOR ANY SPECIAL, EXEMPLARY, PUNITIVE, INDIRECT OR CONSEQUENTIAL LOSSES OR DAMAGES OF
ANY NATURE WHATSOEVER, WHETHER AS A RESULT OF BREACH OF CONTRACT, TORT LIABILITY (INCLUDING
NEGLIGENCE), STRICT LIABILITY OR OTHERWISE. REPAIR OR REPLACEMENT OF THE SOFTWARE OR EQUIPMENT
DURING THE APPLICABLE WARRANTY PERIOD AT CANBERRA’S COST, OR, IN THE CASE OF DEFECTIVE SERVICES,
REPERFORMANCE AT CANBERRA’S COST, IS YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY.
EXCLUSIONS
Our warranty does not cover damage to equipment which has been altered or modified without our written permission or
damage which has been caused by abuse, misuse, accident, neglect or unusual physical or electrical stress, as determined by
our Service Personnel.
We are under no obligation to provide warranty service if adjustment or repair is required because of damage caused by other
than ordinary use or if the equipment is serviced or repaired, or if an attempt is made to service or repair the equipment, by
other than our Service Personnel without our prior approval.
Our warranty does not cover detector damage due to neutrons or heavy charged particles. Failure of beryllium, carbon
composite, or polymer windows or of windowless detectors caused by physical or chemical damage from the environment is
not covered by warranty.
We are not responsible for damage sustained in transit. You should examine shipments upon receipt for evidence of damage
caused in transit. If damage is found, notify us and the carrier immediately. Keep all packages, materials and documents,
including the freight bill, invoice and packing list.
Software License
When purchasing our software, you have purchased a license to use the software, not the software itself. Because title to the
software remains with us, you may not sell, distribute or otherwise transfer the software. This license allows you to use the
software on only one computer at a time. You must get our written permission for any exception to this limited license.
BACKUP COPIES
Our software is protected by United States Copyright Law and by International Copyright Treaties. You have our express
permission to make one archival copy of the software for backup protection. You may not copy our software or any part of it
for any other purpose.
