Mission 529 USB Power Converter Quick Start Guide V1.0
STOP! Please read this before connecting your Mission 529
What is the 529?
The Mission 529 is the world’s first USB to effects pedal
power converter. Connected to a power supply such as a
wall charger, rechargeable battery pack, or computer USB
port, the 529 provides 5 isolated 9V effects pedal power
outputs.
Two 529’s can be chained together via USB link, to power
up to 10 pedals.
What’s in the box?
1 x Mission 529 Power Converter
1 x 5V 12W Wall power supply
1 x 10’ USB cable
1 x 3’ USB cable
5 x 2’ 2.1mm power cables
1 x 10,000mAh battery pack (optional)
Power
Each 529 can support a maximum of 1200mA (4 x 150mA
and 1 x 500mA). This is dependent on the USB power
source. The 529 is provided with a 2.4A USB plug-in power
supply which can power up to two 529’s. When using a
plug-in power supply or battery other than those supplied
with the 529, check the specifications to determine the
power output.
Connections
Connect the USB IN on the 529 to the included USB wall
charger using a USB A-B cable. When USB power is present
the LED’s next to the outputs will illuminate blue.
Connect your 9V pedals to the appropriate power outputs
using the supplied power cables. Note that all outputs are
center pin negative. Use an appropriate polarity reversal
adapter, if using center pin positive pedals.
Scan QR Code for more information
https://missionengineering.com/support/529-electronic-user-guide

FCC Declaration of Conformity
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that the
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that of the receiver.
Consult the dealer or an experienced radio/TV technician for
help.
Mission Engineering Inc
529 Power Converter
Specifications
Input
5V USB 2.0 Type B
Outputs
4 x 9V 150mA
1 x 9V 500mA
1 x 5V USB Type A
Min: 160mA
Max: 2400mA
All outputs center pin negative
Quiescent Current
160mA
Dimensions
4.5” x 1.75” x 1”
0.25lbs
Construction
Aluminum case
Blue anodized
