The MistAwayTM Drum-based Misting System
Assemble the Drum-based Misting System (continued)
H. Verify other connectors are tight:
oThe YELLOW wires should be connected to the BLACK & WHITE wires for the
agitator (if equipped)
oThe ORANGE wires should be connected to the Zone Solenoid Valve (if equipped)
oThe RED wires are not used at this time.
I. Align the chassis with the four holes on the drum lid. The chassis should be oriented such that
the pump is on the same side as the large bung in the drum lid.
J. Insert the ½” pump suction line (with float switch attached) up through the ¾” grommet on the
drum lid and into the ½” fitting on the pump.
oPush the pipe in firmly and then pull it back to ensure it is locked into the fitting.
oThe float switch float must be oriented towards the center of the drum.
K. Insert the ¼” black tubing of the auto drain valve assembly up through the ¼” grommet in the
drum lid and into the ¼” fitting on the pump discharge.
oPush the tubing in firmly and then pull back to ensure it is locked into the fitting.
L. If the system is equipped with an agitator, insert the agitator line up through the ½” grommet in
the drum lid, through the hole in the chassis, and into the ½” fitting on the agitator.
oPush the tubing in firmly and then pull back to ensure it is locked into the fitting.
M. Secure the chassis to the drum lid with the provided bolts, flat washers, lock washers and
nuts.
oUse two 7/16” wrenches to secure the bolts.
oInstallation sequence is bolt, chassis, drum lid, flat washer, lock washer, nut.
oThe flat washer, lock washer, and nut should be on the underside of the drum lid.
oNote that the four chassis mounting holes in the drum lid have been oversized to ease
assembly. Ensure that the chassis mounting bolts are tightened so that the chassis
does not slide around in the mounting holes
N. VERIFY THAT THE FLOAT SWITCH FLOAT IS ORIENTED TOWARDS THE CENTER OF
THE DRUM and then secure the drum lid to the drum, ensuring that lip is tightly pressed down
to the drum around the entire circumference of the drum.
O. Screw the Remote Antenna to the threaded connector on the chassis (located just behind the
controller).
P. Verify that the anti-vibration spacers are installed on the hinge pins between the enclosure lid
and the enclosure
oIf the anti-vibration spacers have become dislodged during shipment, two spares
spacers have been provided with the Misting System.
oUse a small flat-tipped screwdriver to replace the spacers on the hinge pins, if
necessary.
