Mitsubishi Electric Mr.SLIM PLA-A-BA4 Instruction manual

TECHNICAL DATA BOOK
<Indoor unit>
[Model names]
R410A
PLA-A·BA4
PKA-A·HA4
PKA-A·KA4
PCA-A·KA4/5
PEA-A·AA4
PEAD-A·AA4
<Outdoor unit>
[Model names]
No. DOCS14
No. DOCS15
REVISED EDITION-B
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS
PUZ-A18/A24/30/36NHA4
PUZ-A18/A24/30/36NHA4-BS
PUY-A12/18/A24/30/36NHA4
PUY-A12/18/A24/30/36NHA4-BS
PUZ-A42NHA5/A42NHA5-BS
PUY-A42NHA5/A42NHA5-BS
PUZ-HA30/36NHA4
September 2013
/
INVERTER HYPER HEATING INVERTER
CONTENTS
1. REFERENCE SERVICE MANUAL............................................. 2
2. SPECIFICATIONS....................................................................... 3
3. OUTLINES AND DIMENSIONS................................................ 15
4. POSITION OF THE CENTER OF GRAVITY ............................ 28
5. WIRING DIAGRAM................................................................... 30
6. REFRIGERANT SYSTEM DIAGRAM ...................................... 41
7. PERFORMANCE CURVES ...................................................... 45
8. PERFORMANCE CHART......................................................... 49
9. CORRECTION FACTORS ........................................................ 67
10. AIR FLOW DATA ...................................................................... 71
11. NOISE CRITERION CURVES .................................................. 86
12. OPTIONAL PARTS................................................................. 100
13. SYSTEM CONTROL............................................................... 102
*This data book is revised version
of OCS14 and OCS15.
Revision B:
• Model name change and
system control were added.
Please void DOCS14,DOCS15
REVISED EDITION-A.

2
For information on service, please refer to the service manual as follows.
1-1. INDOOR UNIT
Model name Service Ref. Service
Manual No.
PLA-A12/18/24/30/36/42BA4 PLA-A12/18/24/30/36/42BA4 OCH482
OCB482A
HWE0905A
BWE10130
HWE0807C
BWE11480
PCA-A24/30/36/42KA4 PCA-A24/30/36KA4.TH
PCA-A42KA5.TH
PEA-A12/18AA4 PEA-A12/18AA4R1.TH
PEAD-A24/30/36/42AA4 PEAD-A24/30/36/42AA4
PUZ-HA30/36NHA4 PUZ-HA30/36NHA4
OCH501
OCB501
OCH483
OCB483
OCH488A
OCB488
PKA-A12/18HA4 PKA-A12/18HA4
PKA-A24/30/36KA4 PKA-A24/30/36KA4.TH
1-2. OUTDOOR UNIT
Model name Service Ref. Service
Manual No.
PUZ-A18NHA4
PUZ-A24/30/36NHA4
PUZ-A18NHA4-BS
PUZ-A24/30/36NHA4-BS
PUY-A12/18NHA4
PUY-A24/30/36NHA4
PUY-A12/18NHA4-BS
PUY-A24/30/36NHA4-BS
PUZ-A18NHA4R1
PUZ-A24/30/36NHA4
PUZ-A18NHA4R1-BS
PUZ-A24/30/36NHA4-BS
PUY-A12/18NHA4R1
PUY-A24/30/36NHA4
PUY-A12/18NHA4R1-BS
PUY-A24/30/36NHA4-BS
PUZ-A42NHA5
PUZ-A42NHA5-BS
PUY-A42NHA5
PUY-A42NHA5-BS
PUZ-A42NHA5
PUZ-A42NHA5-BS
PUY-A42NHA5
PUY-A42NHA5-BS
OCH481C
OCB481A
OCH512
OCB512
OCH504
OCB504
1REFERENCE SERVICE MANUAL

3
2SPECIFICATIONS
2-1. INVERTER CEILING CASSETTE TYPE
Model name Indoor unit
Outdoor unit
Cooling Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
COP W/W
*1 HSPF (IV/V) Btu/h/W
Heating Rated Capacity Btu/h
at low ambient Total Input W
*2 COP W/W
Power supply Phase, Cycle, Voltage
Breaker size A
Voltage Indoor - Outdoor S1-S2
Indoor - Outdoor S2-S3
Indoor - Remote Controller
Indoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Air flow DRY CFM
(Lo-M2-M1-Hi) WET
Air flow DRY
(Lo-M2-M1-Hi) WET
CFM
CMM
CMM
External pressure Pa
Sound level dB(A)
(Lo-M2-M1-Hi)
External finish (Panel)
Dimension W : mm [inch]
Unit (Panel)D : mm [inch]
H : mm [inch]
Weight kg
Unit (Panel)lbs
Field drain pipe size O.D.
mm [inch]
Remote Controller
Outdoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Compressor
R.L.A
L.R.A.
Air flow CMM [CFM]
Refrigerant Control
Defrost Method
Sound level at cooling dB(A)
Sound level at heating dB(A)
External finish
Dimension W : mm [inch]
D : mm [inch]
H : mm [inch]
Weight kg [lbs]
kg [lbs, oz]
Refrigerant Type
Charge
Oil L [oz]
Refrigerant pipe size Gas side O.D. mm [inch]
Liquid side O.D. mm [inch]
Refrigerant pipe length Height difference
Length
Refrigerant Piping
Connection Method
PLA-A12BA4 PLA-A18BA4 PLA-A24BA4 PLA-A30BA4 PLA-A36BA4 PLA-A42BA4
PUY-A12NHA4
PUY-A12NHA4-BS
PUY-A18NHA4
PUY-A18NHA4-BS
PUY-A24NHA4
PUY-A24NHA4-BS
PUY-A30NHA4
PUY-A30NHA4-BS
PUY-A36NHA4
PUY-A36NHA4-BS
PUY-A42NHA5
PUY-A42NHA5-BS
12,000 18,000 24,000 30,000 35,000 42,000
12,000 18,000 24,000 30,000 35,000 42,000
6,000 8,000 12,000 12,000 12,000 18,000
1260 1940 2500 4100 4500 4600
9.5 9.3 9.6 7.3 7.8 9.1
13.5 14.2 13.6 13.6 14.2 14.4
1.7 3.0 5.1 7.2 8.1 10.9
0.84 0.81 0.76 0.73 0.74 0.71
------
------
------
------
------
------
------
------
------
1phase, 60Hz, 208/230V
15 25 30
AC 208 / 230V
DC24V
DC12V
1 2
15
0.51 1.00
50 120
390-420-460-530 420-490-570-640 490-570-640-740 710-810-920-1060 780-880-990-1090
350-390-420-490 390-460-530-600 460-530-600-710 670-770-880-1030 740-850-950-1060
11-12-13-15 12-14-16-18 14-16-18-21 20-23-26-30 22-25-28-31
10-11-12-14 11-13-15-17 13-15-17-20 19-22-25-29 21-24-27-30
0
27-28-29-31 28-29-31-32 28-30-32-34 32-34-37-40 34-36-39-41
White Munsell 6.4Y 8.9 / 0.4
840 (950) [ 33-1/16 (37-3/8) ]
840 (950) [ 33-1/16 (37-3/8) ]
258 (35) [ 10-3/16 (1-3/8) ] 298 (35) [ 11-3/4 (1-3/8) ]
22 (6) 23 (6) 25 (6)
49 (13) 51 (13) 55 (13)
32 [ 1-1/4 ]
Attached in Grille
13 18 25 26
15 20 30 40
0.35 0.75 0.4 + 0.4
40 75 86 + 86
SNB130FQCM1 TNB220FLHM ANB33FCTMT
12 20
14 17.5 27.5
34 [1,200] 55 [1,940] 100 [3,530]
Linear Expansion Valve
-
46 48 48 51
- - -
Ivory Munsell 3Y 7.8/1.1
800 [31-1/2] 950 [37-3/8]
300+23 [11-13/16 + 7/8] 330+30 [13 + 1-3/16]
600 [23-5/8] 943 [37-1/8] 1350 [53-1/8]
37 [82] 40 [89] 74 [163] 112 [247]
R410A
1.3 [2 lbs 14 oz] 1.7 [3 lbs 12 oz] 3.0 [6 lbs 10 oz] 4.5 [10 lbs]
0.65 (MEL56) [20] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
12.7 [1/2] 15.88 [5/8]
6.35 [1/4] 9.52 [3/8]
Max. 30m [Max.100ft]
Max. 30m [Max.100ft] Max. 50 [Max.165ft]
Not Supplied
Flared
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)

4
Model name Indoor unit
Outdoor unit
Cooling Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
COP W/W
*1 HSPF (IV/V) Btu/h/W
Heating Rated Capacity Btu/h
at low ambient Total Input W
*2 COP W/W
Power supply Phase, Cycle, Voltage
Breaker size A
Voltage Indoor - Outdoor S1-S2
Indoor - Outdoor S2-S3
Indoor - Remote Controller
Indoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Air flow DRY CFM
(Lo-M2-M1-Hi) WET CFM
Air flow DRY CMM
(Lo-M2-M1-Hi) WET CMM
External pressure Pa
Sound level dB(A)
(Lo-M2-M1-Hi)
External finish (Panel)
Dimension W : mm [inch]
Unit (Panel)D : mm [inch]
H : mm [inch]
Weight kg
Unit (Panel)lbs
Field drain pipe size O.D.
mm [inch]
Remote Controller
Outdoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Compressor
R.L.A
L.R.A.
Air flow CMM [CFM]
Refrigerant Control
Defrost Method
Sound level at cooling dB(A)
Sound level at heating dB(A)
External finish
Dimension W : mm [inch]
D : mm [inch]
H : mm [inch]
Weight kg [lbs]
kg [lbs, oz]
Refrigerant Type
Charge
Oil L [oz]
Refrigerant pipe size Gas side O.D. mm [inch]
Liquid side O.D. mm [inch]
Refrigerant pipe length Height difference
Length
Refrigerant Piping
Connection Method
PLA-A18BA4 PLA-A24BA4 PLA-A30BA4 PLA-A36BA4 PLA-A42BA4
PUZ-A18NHA4
PUZ-A18NHA4-BS
PUZ-A24NHA4
PUZ-A24NHA4-BS
PUZ-A30NHA4
PUZ-A30NHA4-BS
PUZ-A36NHA4
PUZ-A36NHA4-BS
PUZ-A42NHA5
PUZ-A42NHA5-BS
18,000 24,000 30,000 35,000 42,000
18,000 24,000 30,000 35,000 42,000
8,000 12,000 12,000 12,000 18,000
1940 2500 4100 4500 4600
9.3 9.6 7.3 7.8 9.1
14.2 13.6 13.6 14.2 14.4
3.0 5.1 7.2 8.1 10.9
0.81 0.76 0.73 0.74 0.71
20,000 28,000 34,000 38,000 48,000
19,000 26,000 32,000 37,000 45,000
8,000 12,000 12,000 12,000 18,000
1900 2570 3370 3300 4450
2.93 2.96 2.78 3.28 2.96
9.8 / 7.5 8.5 / 6.8 8.7 / 6.9 9.3 / 7.3 9.3 / 7.2
13,000 16,000 23,000 25,000 30,000
1590 2200 3050 3070 4300
2.40 2.14 2.20 2.37 2.05
1phase, 60Hz, 208/230V
15 25 30
AC 208 / 230V
DC24V
DC12V
1 2
15
0.51 1.00
50 120
420-490-570-640 490-570-640-740 710-810-920-1060 780-880-990-1090
390-460-530-600 460-530-600-710 670-770-880-1030 740-850-950-1060
12-14-16-18 14-16-18-21 20-23-26-30 22-25-28-31
11-13-15-17 13-15-17-20 19-22-25-29 21-24-27-30
0
28-29-31-32 28-30-32-34 32-34-37-40 34-36-39-41
White Munsell 6.4Y 8.9 / 0.4
840 (950) [ 33-1/16 (37-3/8) ]
840 (950) [ 33-1/16 (37-3/8) ]
258 (35) [ 10-3/16 (1-3/8) ] 298 (35) [ 11-3/4 (1-3/8) ]
22 (6) 23 (6) 25 (6)
49 (13) 51 (13) 55 (13)
32 [ 1-1/4 ]
Attached in Grille
13 18 25 26
20 30 40
0.35 0.75 0.4 + 0.4
40 75 86 + 86
SNB130FQCM1 TNB220FLHM ANB33FCTMT
12 20
14 17.5 27.5
34 [1,200] 55 [1,940] 100 [3,530]
Linear Expansion Valve
Reverse Cycle
48 48 51
47 50 55
Ivory Munsell 3Y 7.8/1.1
800 [31-1/2] 950 [37-3/8]
300+23 [11-13/16+7/8] 330+30 [13 + 1-3/16]
600 [23-5/8] 943 [37-1/8] 1350 [53-1/8]
41 [91] 75 [165] 114 [251]
R410A
1.7 [3 lbs 12 oz] 3.0 [6 lbs 10 oz] 4.5 [10 lbs]
0.65 (MEL56) [20] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
12.7 [1/2] 15.88 [5/8]
6.35 [1/4] 9.52 [3/8]
Max. 30m [Max.100ft]
Max. 30m [Max.100ft] Max. 50 [Max.165ft]
Not Supplied
Flared
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)

5
2-2. INVERTER WALL-MOUNTED TYPE
Model name Indoor unit PKA-A12HA4 PKA-A18HA4 PKA-A24KA4 PKA-A30KA4 PKA-A36KA4
Outdoor unit
PUY-A12NHA4-BS
PUY-A12NHA4
PUY-A18NHA4-BS
PUY-A18NHA4
PUY-A24NHA4-BS
PUY-A24NHA4
PUY-A30NHA4-BS
PUY-A30NHA4
PUY-A36NHA4-BS
PUY-A36NHA4
Cooling Max. Capacity Btu/h 12,000 18,000 24,000 30,000 34,200
Rated Capacity Btu/h 12,000 18,000 24,000 30,000 34,200
Min. Capacity Btu/h 6,000 8,000
2240
8.0
15.3
5.2
0.68
12,000
2270
10.6
17.0
5.0
0.77
12,000
4130
7.3
15.5
8.1
0.70
12,000
5030
6.8
14.0
9.2
0.70
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h
-----
Rated Capacity Btu/h -----
Min. Capacity Btu/h -----
Total Input W -----
COP W/W -----
*1 HSPF (IV/V) Btu/h/W
-----
Heating Rated Capacity Btu/h -----
at low ambient Total Input W -----
*2 COP W/W -----
Power supply Phase, Cycle, Voltage 1phase , 60Hz , 208/230V
Breaker size A 15 25 30
Voltage Indoor - Outdoor S1-S2 AC 208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote Controller DC12V : Wired type
Indoor unit MCA A 1
MOCP A 15
Fan Motor F.L.A. 0.33 0.36 0.57
Fan Motor Output W 30 56
Air flow DRY CMM 9-10.5-12 18-20-22 20-23-26
(Lo-Mid-Hi) WET CMM 8-9.5-11 16-18-20 18-21-23
Air flow DRY CFM 320-370-425 635-705-775 705-810-920
(Lo-Mid-Hi) WET CFM 290-335-380 570-635-700 635-730-830
External pressure Pa 0
Sound level dB(A) 36-40-43 39-42-45 43-46-49
(Lo-Mid-Hi)
External finish (Panel) White Munsell 1.0Y 9.2/0.2
Dimension W : mm [inch] 898 [35-3/8] 1170 [46-1/16]
Unit (Panel) D : mm [inch] 295 [11-5/8]249 [9-13/16]
H : mm [inch] 365 [14-3/8]295 [11-5/8]
Weight kg 13 21
Unit (Panel) lbs 29 46
Field drain pipe size I.D. mm [inch] 16 [5/8]
Remote Controller Attached in Indoor Unit
Outdoor unit MCA A 13 18 25
MOCP A 15 20 30 40
Fan Motor F.L.A. 0.35 0.75
Fan Motor Output W 40 75
Compressor SNB130FQCM1 TNB220FLHM
R.L.A 12
L.R.A. 14 17.5
Air flow CMM [CFM] 34 [1,200] 55 [1,940]
Refrigerant Control Linear Expansion Valve
Defrost Method
-
Sound level at cooling dB(A) 46 48 48
Sound level at heating dB(A)
- -
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm [inch] 800 [31-1/2] 950 [37-3/8]
D : mm [inch] 300+23 [11-13/16 + 7/8] 330+30 [13 + 1-3/16]
H : mm [inch] 600 [23-5/8] 943 [37-1/8]
Weight kg [lbs]
kg [lbs, oz]
37 [82] 40 [89] 74[163]
Refrigerant Type R410A
Charge 1.3 [2 lbs 14 oz] 1.7 [3 lbs 12 oz] 3.0 [6 lbs 10 oz]
Oil L [oz] 0.65 (MEL56) [20] 0.87 (FV50S) [28]
Refrigerant pipe size Gas side O.D. mm [inch] 12.7 [1/2] 15.88 [5/8]
Liquid side O.D. mm [inch] 6.35 [1/4] 9.52 [3/8]
Refrigerant pipe length Height difference Max. 30m [Max. 100ft]
Length Max. 30m [Max. 100ft] Max. 50m [Max. 165ft]
Refrigerant Piping Not Supplied
Connection Method Flared
1190
10.1
15.2
2.0
0.81
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)

6
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
Model name Indoor unit PKA-A18HA4 PKA-A24KA4 PKA-A30KA4 PKA-A36KA4
Outdoor unit
PUZ-A18NHA4-BS
PUZ-A18NHA4
PUZ-A24NHA4-BS
PUZ-A24NHA4
PUZ-A30NHA4-BS
PUZ-A30NHA4
PUZ-A36NHA4-BS
PUZ-A36NHA4
Cooling Max. Capacity Btu/h 18,000 24,000 30,000 34,200
Rated Capacity Btu/h 18,000 24,000 30,000 34,200
Min. Capacity Btu/h 8,000
2240
8.0
15.3
5.2
0.68
12,000
2270
10.6
17.0
5.0
0.77
12,000
4130
7.3
15.5
8.1
0.70
12,000
5030
6.8
14.0
9.2
0.70
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h 20,000 28,000 34,000 38,000
Rated Capacity Btu/h 19,000 26,000 32,000 37,000
Min. Capacity Btu/h 8,000
1970
2.83
9.5 / 7.6
12,000
2330
3.27
10.8 / 8.6
12,000
3150
2.98
8.9 / 7.1
2850
2.37
12,000
3610
3.00
9.3 / 7.5
Total Input W
COP W/W
*1 HSPF
( / ) Btu/h/W
Heating Rated Capacity Btu/h 13,000
1670
2.28
18,000
2200
2.40
23,000 25,000
3030
2.42
at low ambient Total Input W
*2 COP W/W
Power supply Phase, Cycle, Voltage 1phase , 60Hz , 208/230V
Breaker size A 15 25 30
Voltage
Indoor - Outdoor S1-S2 AC 208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote Controller DC12V : Wired type
Indoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Air flow DRY CMM
(Lo-Mid-Hi) WET CMM
Air flow DRY CFM
(Lo-Mid-Hi) WET CFM
External pressure Pa
Sound level dB(A)
(Lo-Mid-Hi)
External finish (Panel)
Dimension W : mm [inch]
Unit (Panel) D : mm [inch]
H : mm [inch]
Weight kg
Unit (Panel) lbs
Field drain pipe size I.D. mm [inch]
Remote Controller Attached in Indoor Unit
Outdoor unit MCA A 13 18 25
MOCP A 20 30 40
Fan Motor F.L.A. 0.35 0.75
Fan Motor Output W 40 75
Compressor SNB130FQCM1 TNB220FLHM
R.L.A 12
L.R.A. 14 17.5
Air flow CMM [CFM] 34 [1,200] 55 [1,940]
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 48 48
Sound level at heating dB(A) 47 50
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm [inch] 800 [31-1/2] 950 [37-3/8]
D : mm [inch] 300+23 [11-13/16+7/8] 330+30 [13 + 1-3/16]
H : mm [inch] 600 [23-5/8] 943 [37-1/8]
Weight kg [lbs]
kg [lbs, oz]
41 [91] 75 [165]
Refrigerant Type R410A
Charge 1.7 [3 lbs 12 oz] 3.0 [6 lbs 10 oz]
Oil L [oz] 0.65 (MEL56) [20] 0.87 (FV50S) [28]
Refrigerant pipe size Gas side O.D. mm [inch] 12.7 [1/2] 15.88 [5/8]
Liquid side O.D. mm [inch] 6.35 [1/4] 9.52 [3/8]
Refrigerant pipe length Height difference Max. 30m [Max. 100ft]
Length Max. 30m [Max. 100ft] Max. 50m [Max. 165ft]
Refrigerant Piping Not Supplied
Connection Method Flared
1
15
0.33 0.36 0.57
30 56
9-10.5-12 18-20-22 20-23-26
8-9.5-11 16-18-20 18-21-23
320-370-425 635-705-775 705-810-920
290-335-380 570-635-700 635-730-830
0
36-40-43 39-42-45 43-46-49
White Munsell 1.0Y 9.2/0.2
898 [35-3/8] 1170 [46-1/16]
295 [11-5/8]249 [9-13/16]
365 [14-3/8]295 [11-5/8]
13 21
29 46
16 [5/8]

7
Model name Indoor unit PCA-A24KA4 PCA-A30KA4 PCA-A36KA4 PCA-A42KA5
Outdoor unit
PUY-A24NHA4-BS
PUY-A24NHA4
PUY-A30NHA4-BS
PUY-A30NHA4
PUY-A36NHA4-BS
PUY-A36NHA4
PUY-A42NHA5-BS
PUY-A42NHA5
Cooling Max. Capacity Btu/h 24,000 30,000 35,000 42,000
Rated Capacity Btu/h 24,000 30,000 35,000 42,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2340 3760 4630 4110
EER Btu/h/W 10.3 8.0 7.6 10.2
SEER Btu/h/W 16.8 14.5 14.4 15.8
Moisture Removal Pints/h 5.8 8.3 8.5 11.7
*1 SHF 0.73 0.69 0.73 0.69
Heating Max. Capacity Btu/h
----
Rated Capacity Btu/h ----
Min. Capacity Btu/h ----
Total Input W ----
COP W/W ----
*1 HSPF (IV/V) Btu/h/W ----
Heating Rated Capacity Btu/h ----
at low ambient Total Input W ----
*2 COP W/W ----
Power supply Phase, Cycle, Voltage 1phase , 60Hz , 208/230V
Breaker size A 25 30
Voltage Indoor - Outdoor S1-S2 AC 208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote Controller DC12V
Indoor unit MCA A 1 2
MOCP A 15
Fan Motor F.L.A. 0.54 0.97
Fan Motor Output W 95 160
Air flow DRY CMM 15-16-17-19 22-24-26-28
(Lo-M2-M1-Hi) WET CMM 14-15-16-18 20-22-24-26
Air flow DRY CFM 530-565-600-670 775-850-920-990
(Lo-M2-M1-Hi) WET CFM 495-530-565-635 705-775-850-920
External pressure Pa 0
Sound level dB(A)33-35-37-40
16-17-18-20
15-16-17-19
565-600-635-705
530-565-600-670
35-37-39-41 37-39-41-43
23-25-27-29
21-23-25-27
810-885-955-1025
740-810-885-955
39-41-43-45
(Lo-M2-M1-Hi)
External finish (Panel)White Munsell 6.4Y 8.9/0.4
Dimension W : mm [inch] 1600 [63]1280 [50-3/8]
Unit (Panel)D : mm [inch] 680 [26-3/4]
H : mm [inch] 230 [9-1/16]
Weight kg 32 36
Unit (Panel)lbs 71 79
39
86
Field drain pipe size O.D.
mm [inch] 26 [1-1/32]
Remote Controller Attached in Indoor Unit
Outdoor unit MCA A 18 25 26
MOCP A 30 40
Fan Motor F.L.A. 0.75 0.4 + 0.4
Fan Motor Output W 75 86 + 86
Compressor TNB220FLHM ANB33FCTMT
R.L.A 12 20
L.R.A. 14 17.5 27.5
Air flow CMM [CFM] 55 [1,940] 100 [3,530]
Refrigerant Control Linear Expansion Valve
Defrost Method
-
Sound level at cooling dB(A)48 51
Sound level at heating dB(A) - -
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm [inch] 950 [37-3/8]
D : mm [inch] 330+30 [13 + 1-3/16]
H : mm [inch] 943 [37-1/8] 1350 [53-1/8]
Weight kg [lbs]
kg [lbs]
74[163] 112 [247]
Refrigerant Type R410A
Charge 3.0 [6 lbs 10 oz] 4.5 [10 lbs]
Oil L [oz] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
Refrigerant pipe size Gas side O.D. mm [inch] 15.88 [5/8]
Liquid side O.D. mm [inch] 9.52 [3/8]
Refrigerant pipe length Height difference Max. 30m [Max. 100ft]
Length Max. 50m [Max. 165ft]
Refrigerant Piping Not Supplied
Connection Method Flared
2-3. INVERTER CEILING-SUSPENDED TYPE
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)

8
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
Model name Indoor unit PCA-A24KA4 PCA-A30KA4 PCA-A36KA4 PCA-A42KA5
Outdoor unit
PUZ-A24NHA4-BS
PUZ-A24NHA4
PUZ-A30NHA4-BS
PUZ-A30NHA4
PUZ-A36NHA4-BS
PUZ-A36NHA4
PUZ-A42NHA5-BS
PUZ-A42NHA5
Cooling Max. Capacity Btu/h 24,000 30,000 35,000 42,000
Rated Capacity Btu/h 24,000 30,000 35,000 42,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2340 3760 4630 4110
EER Btu/h/W 10.3 8.0 7.6 10.2
SEER Btu/h/W 16.8 14.5 14.4 15.8
Moisture Removal Pints/h 5.8 8.3 8.5 11.7
*1 SHF 0.73 0.69 0.73 0.69
Heating Max. Capacity Btu/h 28,000 34,000 38,000 48,000
Rated Capacity Btu/h 26,000 32,000 37,000 45,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2310 3210 3190 3830
COP W/W 3.30 2.92 3.40 3.44
*1 HSPF (IV/V) Btu/h/W 10.9 / 8.9 9.2 / 7.1 10.2 / 8.1 10.2 / 8.3
Heating Rated Capacity Btu/h 18,000 23,000 25,000 30,000
at low ambient Total Input W 2220 2940 2800 3820
*2 COP W/W 2.38 2.29 2.62 2.30
Power supply Phase, Cycle, Voltage 1phase , 60Hz , 208/230V
Breaker size A 25 30
Voltage Indoor - Outdoor S1-S2 AC 208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote Controller DC12V
Indoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Air flow DRY CMM
(Lo-M2-M1-Hi) WET CMM
Air flow DRY CFM
(Lo-M2-M1-Hi) WET CFM
External pressure Pa
Sound level dB(A)
(Lo-M2-M1-Hi)
External finish (Panel)
Dimension W : mm [inch]
Unit (Panel) D : mm [inch]
H : mm [inch]
Weight kg
Unit (Panel) lbs
Field drain pipe size O.D. mm [inch] 26 [1-1/32]
Remote Controller Attached in Indoor Unit
Outdoor unit MCA A 18 25 26
MOCP A 30 40
Fan Motor F.L.A. 0.75 0.4 + 0.4
Fan Motor Output W 75 86 + 86
Compressor TNB220FLHM ANB33FCTMT
R.L.A 12 20
L.R.A. 14 17.5 27.5
Air flow CMM [CFM] 55 [1,940] 100 [3,530]
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 48 51
Sound level at heating dB(A) 50 55
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm [inch] 950 [37-3/8]
D : mm [inch] 330+30 [13 + 1-3/16]
H : mm [inch] 943 [37-1/8] 1350 [53-1/8]
Weight kg [lbs]
kg [lbs]
75 [165] 114 [251]
Refrigerant Type R410A
Charge 3.0 [6 lbs 10 oz] 4.5 [10 lbs]
Oil L [oz] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
Refrigerant pipe size Gas side O.D. mm [inch] 15.88 [5/8]
Liquid side O.D. mm [inch] 9.52 [3/8]
Refrigerant pipe length Height difference Max. 30m [Max. 100ft]
Length Max. 50m [Max. 165ft]
Refrigerant Piping Not Supplied
Connection Method Flared
1 2
15
0.54 0.97
95 160
15-16-17-19 22-24-26-28
14-15-16-18 20-22-24-26
530-565-600-670 775-850-920-990
495-530-565-635 705-775-850-920
0
33-35-37-40
16-17-18-20
15-16-17-19
565-600-635-705
530-565-600-670
35-37-39-41 37-39-41-43
23-25-27-29
21-23-25-27
810-885-955-1025
740-810-885-955
39-41-43-45
White Munsell 6.4Y 8.9/0.4
1600 [63]1280 [50-3/8]
680 [26-3/4]
230 [9-1/16]
32 36
71 79
39
86

9
2-4. INVERTER CEILING CONCEALED TYPE (PEA/PEAD)
Model name Indoor unit PEA-A12AA4 PEA-A18AA4 PEA-A18AA4
Outdoor unit PUY-A12NHA4 PUY-A18NHA4 PUZ-A18NHA4
PUY-A12NHA4-BS PUY-A18NHA4-BS PUZ-A18NHA4-BS
Cooling Max. Capacity Btu/h 12,000 18,000 18,000
Rated Capacity Btu/h 12,000 18,000 18,000
Min. Capacity Btu/h 6,000 8,000 8,000
Total Input W 1240 2150 2150
EER Btu/h 9.7 8.4 8.4
SEER Btu/h 13.8 14.3 14.3
Moisture Removal Pints/h 2.47 3.26 3.26
SHF 0.77 0.80 0.80
Heating Max. Capacity Btu/h - - 20,000
Rated Capacity Btu/h - - 19,000
Min. Capacity Btu/h - - 8,000
Total Input W - - 1540
COP W/W - - 3.61
HSPF(IV/V) Btu/h/W - - 10.0 / 8.0
Heating
at low ambient
Rated Capacity Btu/h - - 13,000
Total Input W - - 1520
COP W/W - - 2.51
Power supply Phase,Cycle,Voltage 1phase, 60Hz, 208/230V
Breaker size A 15
Voltage Indoor - Outdoor S1-S2 AC208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote controller DC12V
Indoor unit MCA A 1 2
MOCP A 15 15
Fan Motor F.L.A 0.57 0.74
Fan Motor Output W 96
Air ow DRY
(Lo-Mid-Hi) WET
CMM 7-9-11 12-15-18
CMM 6-8-10 11-14-17
Air ow DRY
(Lo-Mid-Hi) WET
CFM 247-317-388 423-529-635
CFM 222-285-349 381-476-572
External pressure in.WG [Pa] 0.02/0.06/0.14/0.20 [5/15/35/50]
Sound level
(Lo-Mid-Hi)
dB(A) 23-28-33 30-34-38
External nish Galvanized
Dimension
Unit (Panel)
W:mm[inch] 990[39] 1190[46-7/8]
D:mm[inch] 700[27-9/16] 700[27-9/16]
H:mm[inch] 200[7-7/8] 200[7-7/8]
Weight kg 21 27
Unit lbs 48 60
Field Drain pipe seize O.D. mm[inch] 32 [1-9/32]
Remote Controller Attached in indoor Unit
Outdoor unit MCA A 13
MOCP A 15 20
Fan Motor F.L.A. 0.35
Fan Motor Output W 40
Compressor SNB130FQCM1
R.L.A. 12
L.R.A. 14
Air ow CMM[CFM] 34 [1,200]
Refrigerant Control Linear Expansion Valve
Defrost Method - - Reverse Cycle
Sound level at cooling dB(A) 46 48
Sound level at heating dB(A) - - 47
External nish Ivory Munsell 3Y 7.8/1.1
Dimension W:mm[inch] 800 [31-1/2]
D:mm[inch] 300+23 [11-13/16+7/8]
H:mm[inch] 600 [23-5/8]
Weignt kg[lbs] 37[82] 40[89] 41[91]
Refrigerant Type R410A
Charge kg[lbs,oz] 1.3 [2lbs 14oz] 1.7 [3lbs 12oz]
Oil L[oz] 0.65 (MEL 56) [20]
Refrigerant pipe size Gas side O.D. mm[inch] 12.7 [1/2]
Liquid side O.D. mm[inch] 6.35 [1/4]
Refrigerant pipe length Height difference Max. 30m [Max.100ft]
Length Max. 30m [Max.100ft]
Refrigerant Piping Not Supplied
Connection Method Flared
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
*1
*1
*2

10
Model name Indoor unit PEAD-A24AA4 PEAD-A30AA4 PEAD-A36AA4 PEAD-A42AA4
Outdoor unit PUY-A24NHA4 PUY-A30NHA4 PUY-A36NHA4 PUY-A42NHA5
PUY-A24NHA4-BS PUY-A30NHA4-BS PUY-A36NHA4-BS PUY-A42NHA5-BS
Cooling Max. Capacity Btu/h 24,000 30,000 35,000 42,000
Rated Capacity Btu/h 24,000 30,000 35,000 42,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2400 3850 4850 5350
EER Btu/h 10.0 7.7 7.2 7.8
SEER Btu/h 16.0 15.5 15.0 13.8
Moisture Removal Pints/h 6.9 8.6 7.9 9.0
SHF 0.68 0.68 0.75 0.76
Heating Max. Capacity Btu/h - - - -
Rated Capacity Btu/h - - - -
Min. Capacity Btu/h - - - -
Total Input W - - - -
COP W/W - - - -
HSPF(IV/V) Btu/h/W - - - -
Heating
at low ambient
Rated Capacity Btu/h - - - -
Total Input W - - - -
COP W/W - - - -
Power supply Phase,Cycle,Voltage 1phase, 60Hz, 208/230V
Breaker size A 25 30
Voltage Indoor - Outdoor S1-S2 AC208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote controller DC12V
Indoor unit MCA A 2.63 2.73 3.30 3.50
MOCP A 15 15 15 15
Fan Motor F.L.A 2.10 2.18 2.64 2.80
Fan Motor Output W 121 244
Air ow DRY
(Lo-Mid-Hi) WET
CMM 14.5-18-21 17.5-21-25 24-29-34 29.5-35.5-42
CMM 14-17-19 16-19-23 22-27-32 27-33-40
Air ow DRY
(Lo-Mid-Hi) WET
CFM 512-636-742 618-742-883 847-1024-1201 1042-1254-1483
CFM 494-600-671 565-671-812 777-953-1130 953-1165-1412
External pressure in.WG [Pa] [35/50/70/100/150]
Sound level
(Lo-Mid-Hi)
dB(A) 30-33-37 30-34-39 33-38-42 36-40-44
External nish Galvanized
Dimension
Unit (Panel)
W:mm[inch] 1100[43-5/16] 1400[55-1/8]
D:mm[inch] 732[28-7/8]
H:mm[inch] 250[9-7/8]
Weight kg 33 41 43
Unit lbs 73 91 95
Field Drain pipe seize O.D. mm[inch] 32 [1-1/4]
Remote Controller Attached in indoor Unit
Outdoor unit MCA A 18 25 26
MOCP A 30 40
Fan Motor F.L.A. 0.75 0.4+0.4
Fan Motor Output W 75 86+86
Compressor TNB220FLHM ANB33FCTMT
R.L.A. 12 20
L.R.A. 14 17.5 27.5
Air ow CMM[CFM] 55 [1,940] 100[3,530]
Refrigerant Control Linear Expansion Valve
Defrost Method -
Sound level at cooling dB(A) 48 51
Sound level at heating dB(A) -
External nish Ivory Munsell 3Y 7.8/1.1
Dimension W:mm[inch] 950 [37-3/8]
D:mm[inch] 330+30 [13+1-3/16] 1350[53-1/8]
H:mm[inch] 943 [37-1/8] 118[260]
Weignt kg[lbs] 75[165] 112[247]
Refrigerant Type R410A
Charge kg[lbs,oz] 3.0 [6 lbs 10oz] 4.5 [10lbs]
Oil L[oz] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch] 15.88[5/8]
Liquid side O.D. mm[inch] 9.52[3/8]
Refrigerant pipe length Height difference Max. 30m [Max.100ft]
Length Max. 50m [Max.165ft]
Refrigerant Piping Not Supplied
Connection Method Flared
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
*1
*1
*2

11
Model name Indoor unit PEAD-A24AA4 PEAD-A30AA4 PEAD-A36AA4 PEAD-A42AA4
Outdoor unit PUZ-A24NHA4 PUZ-A30NHA4 PUZ-A36NHA4 PUZ-A42NHA5
PUZ-A24NHA4-BS PUZ-A30NHA4-BS PUZ-A36NHA4-BS PUZ-A42NHA5-BS
Cooling Max. Capacity Btu/h 24,000 30,000 35,000 42,000
Rated Capacity Btu/h 24,000 30,000 35,000 42,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2400 3850 4850 5350
EER Btu/h 10.0 7.7 7.2 7.8
SEER Btu/h 16.0 15.5 15.0 13.8
Moisture Removal Pints/h 6.9 8.6 7.9 9.0
SHF 0.68 0.68 0.75 0.76
Heating Max. Capacity Btu/h 28,000 34,000 38,000 48,000
Rated Capacity Btu/h 26,000 32,000 37,000 45,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2250 2990 3290 3820
COP W/W 3.38 3.13 3.29 3.45
HSPF(IV/V) Btu/h/W 10.2/8.2 9.4/7.2 9.8/7.9 10.0/8.0
Heating
at low ambient
Rated Capacity Btu/h 18,000 23,000 25,000 30,000
Total Input W 2130 2750 2810 3820
COP W/W 2.47 2.45 2.60 2.30
Power supply Phase,Cycle,Voltage 1phase, 60Hz, 208/230V
Breaker size A 25 30
Voltage Indoor - Outdoor S1-S2 AC208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote controller DC12V
Indoor unit MCA A 2.63 2.73 3.30 3.50
MOCP A 15 15 15 15
Fan Motor F.L.A 2.10 2.18 2.64 2.80
Fan Motor Output W 121 244
Air ow DRY
(Lo-Mid-Hi) WET
CMM 14.5-18-21 17.5-21-25 24-29-34 29.5-35.5-42
CMM 14-17-19 16-19-23 22-27-32 27-33-40
Air ow DRY
(Lo-Mid-Hi) WET
CFM 512-636-742 618-742-883 847-1024-1201 1042-1254-1483
CFM 494-600-671 565-671-812 777-953-1130 953-1165-1412
External pressure in.WG [Pa] [35/50/70/100/150]
Sound level
(Lo-Mid-Hi)
dB(A) 30-33-37 30-34-39 33-38-42 36-40-44
External nish Galvanized
Dimension
Unit (Panel)
W:mm[inch] 1100[43-5/16] 1400[55-1/8]
D:mm[inch] 732[28-7/8]
H:mm[inch] 250[9-7/8]
Weight kg 33 41 43
Unit lbs 73 91 95
Field Drain pipe seize O.D. mm[inch] 32 [1-1/4]
Remote Controller Attached in indoor Unit
Outdoor unit MCA A 18 25 26
MOCP A 30 40
Fan Motor F.L.A. 0.75 0.4+0.4
Fan Motor Output W 75 86+86
Compressor TNB220FLHM ANB33FCTMT
R.L.A. 12 20
L.R.A. 14 17.5 27.5
Air ow CMM[CFM] 55 [1,940] 100[3,530]
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 48 51
Sound level at heating dB(A) 50 55
External nish Ivory Munsell 3Y 7.8/1.1
Dimension W:mm[inch] 950 [37-3/8]
D:mm[inch] 330+30 [13+1-3/16] 1350[53-1/8]
H:mm[inch] 943 [37-1/8] 118[260]
Weignt kg[lbs] 75[165] 114[251]
Refrigerant Type R410A
Charge kg[lbs,oz] 3.0 [6 lbs 10oz] 4.5 [10lbs]
Oil L[oz] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch] 15.88[5/8]
Liquid side O.D. mm[inch] 9.52[3/8]
Refrigerant pipe length Height difference Max. 30m [Max.100ft]
Length Max. 50m [Max.165ft]
Refrigerant Piping Not Supplied
Connection Method Flared
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
Operating range
Indoor intake air temperature
D.B. 35°C(95°F), W.B. 21.7°C(71°F)
D.B. 19.4°C(67°F), W.B. 13.9°C(57°F)
D.B. 26.7°C(80°F), W.B. 19.4°C(67°F)
D.B. 21.1°C(70°F), W.B. 15.6°C(60°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -11.1°C(12°F), W.B. -12.2°C(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
*1
*1
*2

12
Model name Indoor unit PLA-A36BA4 PKA-A36KA4
Outdoor unit PUZ-HA36NHA4 PUZ-HA36NHA4
Cooling Max. Capacity Btu/h 34,200
Rated Capacity Btu/h 33,500
Min. Capacity Btu/h
36,000
34,000
18,000
2,690
12.6
17.0
7.1
0.71
18,000
2,790
12.0
16.2
8.7
0.71
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h 40,000 40,000
Rated Capacity Btu/h 38,000 38,000
Min. Capacity Btu/h 18,000 18,000
3,410
3.27
10.0 / 7.8
Total Input W 3,230
COP W/W 3.45
10.0 / 8.0
*1 HSPF(IV/V) Btu/h/W
Heating at 17°F(-8.3°C) Max.Capacity Btu/h 38,000 38,000
Total Input W 5,300 6,010
*2 COP W/W 2.10 1.85
Heating at 5°F(-15°C) Max. Capacity Btu/h 38,000 38,000
6,760
1.65
Total Input W 5,860
*3 COP W/W 1.90
PLA-A30BA4
PUZ-HA30NHA4
30,000
30,000
18,000
2,450
12.2
15.6
7.2
0.73
34,000
32,000
18,000
3,440
2.73
9.4 / 7.1
32,000
5,720
1.64
32,000
6,630
1.41
PKA-A30KA4
PUZ-HA30NHA4
30,000
30,000
18,000
2,500
12.0
16.5
8.1
0.70
34,000
32,000
18,000
2,930
3.20
9.5 / 7.3
32,000
5,080
1.85
32,000
5,770
1.63
Power supply Phase, Cycle, Voltage 1phase, 60Hz, 208/230V 1phase, 60Hz, 208/230V
Breaker size A 30 30
Voltage Indoor - Outdoor S1 - S2 AC208/230V AC208/230V
Indoor - Outdoor S2 - S3 DC24V DC24V
Indoor - Remote Controller DC12V DC12V : Wired type
Indoor unit MCA A 2 1
MOCP A 15 15
Fan Motor F.L.A. 1.00 0.57
Fan Motor Output W 120
Airflow DRY CMM 20-23-26-30 20-23-26
Airflow WET CMM 19-22-25-29 18-21-23
Airflow DRY CFM 710-810-920-1060 705-810-920
Airflow WET CFM 670-770-880-1030
1
0.51
50
14-16-18-21
13-15-17-20
490-570-640-740
460-530-600-710 635-730-830
External pressure Pa 0 0
Sound level dB(A) 32-34-37-4028-30-32-34 43-46-49
0.36
56
18-20-22
16-18-20
635-705-775
570-635-700
39-42-45
External finish (Grille) White Munsell 6.4Y 8.9/0.4 White Munsell 1.0Y 9.2/0.2
Dimension Unit (Grille) W : mm[inch] 840(950) [33-1/16(37-3/8)] 1170 [46-1/16]
D : mm[inch] 840(950) [33-1/16(37-3/8)] 295 [11-5/8]
H : mm[inch]
298(35) [11-3/4(1-3/8)] 365 [14-3/8]
Weight Unit(Grille) kg 25(6)
258(35) [10-3/16(1-3/8)]
23(6)
Weight Unit(Grille) lbs 55(13)
21
46
Field drain pipe size mm[inch] O.D. 32 [1-1/4] I.D. 16 [5/8]
Remote Controller Attached in Grille Attached in Indoor unit
Outdoor unit MCA A 28
MOCP A 40
Fan Motor F.L.A. 0.4 + 0.4
Fan Motor Output W 60 + 60
Compressor Type ANB33FJEMTANB33FJEMT ANB33FJEMT
R.L.A. 18
L.R.A. 27.5
Air flow CMM[CFM] 100[3,530]
Refrigerant Control Electronic Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 52
Sound level at heating dB(A) 53
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm[inch] 950 [37-3/8]
D : mm[inch] 330 + 30 [13 + 1-3/16]
H : mm[inch] 1,350 [53-1/8]
Weight kg[lbs] 120 [265]
Refrigerant Type R410A
Charge kg[lbs, oz] 5.5 [12 lbs]
Oil L[oz] 1.4(FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch] 15.88 [5/8]
Liquid side O.D. mm[inch] 9.52 [3/8]
Refrigerant pipe length Height difference Max.30m [Max.100ft]
Length Max.75m [Max.245ft]
Refrigerant Piping Not Supplied
Connection Method Flared
28
40
0.4 + 0.4
60 + 60
ANB33FJEMT
18
27.5
100[3,530]
Electronic Expansion Valve
Reverse Cycle
52
53
Ivory Munsell 3Y 7.8/1.1
950 [37-3/8]
330 + 30 [13 + 1-3/16]
1,350 [53-1/8]
120 [265]
R410A
5.5 [12 lbs]
1.4(FV50S) [45]
15.88 [5/8]
9.52 [3/8]
Max.30m [Max.100ft]
Max.75m [Max.245ft]
Not Supplied
Flared
51(13)
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
*3.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -15°C(5°F), W.B. -15°C(5°F)
Operating range Indoor intake air temperature
D.B. 32°C(90°F), W.B. 23°C(73°F)
D.B. 19°C(66°F), W.B. 15°C(59°F)
D.B. 28°C(83°F)
D.B. 17°C(63°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -25°C(-13°F), W.B. -25°C(-13°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
2-5. HYPER HEATING INVERTER

13
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
*3.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -15°C(5°F), W.B. -15°C(5°F)
Operating range Indoor intake air temperature
D.B. 32°C(90°F), W.B. 23°C(73°F)
D.B. 19°C(66°F), W.B. 15°C(59°F)
D.B. 28°C(83°F)
D.B. 17°C(63°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -25°C(-13°F), W.B. -25°C(-13°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
Model name Indoor unit PCA-A36KA4
Outdoor unit PUZ-HA36NHA4
Cooling Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h 18,000
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h 40,000
Rated Capacity Btu/h 38,000
Min. Capacity Btu/h 18,000
Total Input W 3,270
COP W/W 3.41
10.3 / 8.2
*1 HSPF(IV/V) Btu/h/W
Heating at 17°F(-8.3°C) Max. Capacity Btu/h 38,000
Total Input W 5,720
*2 COP W/W 1.95
Heating at 5°F(-15°C) Max. Capacity Btu/h 38,000
Total Input W 6,550
*3 COP W/W 1.70
PCA-A30KA4
PUZ-HA30NHA4
30,000
30,000
18,000
2,480
12.1
16.1
8.3
0.69
34,000
32,000
18,000
2,990
3.14
9.3 / 7.2
32,000
5,170
1.81
32,000
5,830
1.61
Power supply Phase, Cycle, Voltage 1phase, 60Hz, 208/230V
Breaker size A 30
Voltage Indoor - Outdoor S1 - S2 AC208/230V
Indoor - Outdoor S2 - S3 DC24V
Indoor - Remote Controller DC12V
Indoor unit MCA A 2
MOCP A 15
Fan Motor F.L.A. 0.97
Fan Motor Output W 160
Airflow DRY (Lo-M2-M1-Hi) CMM 22-24-26-28
Airflow WET (Lo-M2-M1-Hi) CMM 20-22-24-26
Airflow DRY (Lo-M2-M1-Hi) CFM 775-850-920-990
Airflow WET (Lo-M2-M1-Hi) CFM 705-775-850-920
1
0.54
95
16-17-18-20
15-16-17-19
565-600-635-705
530-565-600-670
External pressure Pa 0
Sound level (Lo-M2-M1-Hi) dB(A) 37-39-41-4335-37-39-41
External finish (Grille) White Munsell 6.4Y 8.9/0.4
Dimension Unit (Grille) W : mm[inch] 1280 [50-3/8]
D : mm[inch] 680 [26-3/4]
H : mm[inch]
Weight Unit(Grille) kg 36
230 [9-1/16]
32
Weight Unit(Grille) lbs 79
Field drain pipe size mm[inch] O.D. 26 [1-1/32]
Remote Controller Attached in Grille
Outdoor unit MCA A 28
MOCP A 40
Fan Motor F.L.A. 0.4 + 0.4
Fan Motor Output W 60 + 60
Compressor Type ANB33FJEMT
R.L.A. 18
L.R.A. 27.5
Air flow CMM[CFM] 100[3,530]
Refrigerant Control Electronic Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 52
Sound level at heating dB(A) 53
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm[inch] 950 [37-3/8]
D : mm[inch] 330 + 30 [13 + 1-3/16]
H : mm[inch] 1,350 [53-1/8]
Weight kg[lbs] 120 [265]
Refrigerant Type R410A
Charge kg[lbs, oz] 5.5 [12 lbs]
Oil L[oz] 1.4(FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch] 15.88 [5/8]
Liquid side O.D. mm[inch] 9.52 [3/8]
Refrigerant pipe length Height difference Max.30m [Max.100ft]
Length Max.75m [Max.245ft]
Refrigerant Piping Not Supplied
Connection Method Flared
71
1600 [63]
36,000
34,000
2,810
12.1
16.6
8.2
0.73

14
NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7°C(80°F), W.B. 19.4°C(67°F) Outdoor : D.B. 35°C(95°F), W.B. 23.9°C(75°F)
(heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. 8.3°C(47°F), W.B. 6.1°C(43°F)
*2.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -8.3°C(17°F), W.B. -9.4°C(15°F)
*3.Conditions (heating)-Indoor : D.B. 21.1°C(70°F), W.B. 15.6°C(60°F) Outdoor : D.B. -15°C(5°F), W.B. -15°C(5°F)
Operating range Indoor intake air temperature
D.B. 32°C(90°F), W.B. 23°C(73°F)
D.B. 19°C(66°F), W.B. 15°C(59°F)
D.B. 28°C(83°F)
D.B. 17°C(63°F)
Outdoor intake air temperature
D.B. 46°C(115°F)
D.B. -18°C(0°F)*
D.B. 21.1°C(70°F), W.B. 15°C(59°F)
D.B. -25°C(-13°F), W.B. -25°C(-13°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5°C(23°F)DB.)
Model name Indoor unit
Outdoor unit
Cooling Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
EER Btu/h/W
SEER Btu/h/W
Moisture Removal Pints/h
*1 SHF
Heating Max. Capacity Btu/h
Rated Capacity Btu/h
Min. Capacity Btu/h
Total Input W
COP W/W
*1 HSPF(IV/V) Btu/h/W
Heating at 17°F(-8.3°C) Max. Capacity Btu/h
Total Input W
*2 COP W/W
Heating at 5°F(-15°C) Max. Capacity Btu/h
Total Input W
*3 COP W/W
PEA-A18AA4×2
PUZ-HA36NHA4
36,000
34,000
18,000
2700
12.5
16.8
6.7
0.78
40,000
38,000
18,000
3150
3.53
10.4/8.2
38,000
5400
2.06
38,000
6100
1.82
PEAD-A30AA4
PUZ-HA30NHA4
30,000
30,000
18,000
2500
12.0
16.5
8.9
0.67
34,000
32,000
18,000
2750
3.41
9.5/7.3
32,000
4930
1.90
32,000
5420
1.73
PEAD-A36AA4
PUZ-HA36NHA4
36,000
34,000
18,000
2800
12.1
16.8
7.3
0.76
40,000
38,000
18,000
3150
3.53
10.4/8.2
38,000
5400
2.06
38,000
6100
1.82
Power supply Phase, Cycle, Voltage 1phase, 60Hz, 208/230V
Breaker size A 30
Voltage Indoor - Outdoor S1 - S2 AC208/230V
Indoor - Outdoor S2 - S3 DC24V
Indoor - Remote Controller DC12V
Indoor unit MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Airflow DRY (Lo-Mid-Hi) CMM
Airflow WET (Lo-Mid-Hi) CMM
Airflow DRY (Lo-Mid-Hi) CFM
Airflow WET (Lo-Mid-Hi) CFM
2
15
0.74
96
12-15-18
11-14-17
423-529-635
381-476-572
[5/15/35/50]
30-34-38
1190[46-7/8]
700[27-9/16]
200[7-7/8]
27
60
2.73
15
2.18
0.121
17.5-21-25
16-19-23
618-742-883
565-671-812
30-34-39
Galvanized
1100[43-5/16]
33
73
[35/50/70/100/150]
732[28-7/8]
250[9-7/8]
15.88 [5/8] / 12.7[1/2]
9.52 [3/8] / 6.35[1/4]
15.88 [5/8]
9.52 [3/8]
3.30
15
2.64
0.244
24-29-34
22-27-32
847-1024-1201
777-953-1130
33-38-42
1400[5-1/8]
41
91
External pressure Pa
Sound level (Lo-Mid-Hi) dB(A)
External finish
Dimension Unit (Panel) W : mm[inch]
D : mm[inch]
H : mm[inch]
Weight Unit kg
lbs
Field drain pipe size mm[inch] 32 [1-1/4]
Remote Controller Attached in indoor Unit
Outdoor unit MCA A 28
MOCP A 40
Fan Motor F.L.A. 0.4 + 0.4
Fan Motor Output W 60 + 60
Compressor Type ANB33FJEMT
R.L.A. 18
L.R.A. 27.5
Air flow CMM[CFM] 100[3,530]
Refrigerant Control Electronic Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 52
Sound level at heating dB(A) 53
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm[inch] 950 [37-3/8]
D : mm[inch] 330+30 [13 + 1-3/16]
H : mm[inch] 1,350 [53-1/8]
Weight kg[lbs] 120 [265]
Refrigerant Type R410A
Charge kg[lbs, oz] 5.5 [12 lbs]
Oil L[oz] 1.4(FV50S) [45]
Refrigerant pipe size Gas side O.D. mm[inch]
Liquid side O.D. mm[inch]
Refrigerant pipe length Height difference Max.30m [Max.100ft]
Length Max.75m [Max. 245ft]
Refrigerant Piping Not Supplied
Connection Method Flared

15
INDOOR UNIT
PLA-A12BA4 PLA-A18BA4 PLA-A24BA4 PLA-A30BA4 PLA-A36BA4 PLA-A42BA4
3OUTLINES AND DIMENSIONS
Unit: inch (mm)
14-27/32
11-3/16
2-3/8
+5 0
(7.5)
+35 -5
(160)
(500)
(950)
Floor
Min.94-1/2(2400)
from floor
Entire
periphery
(36)
(83)
(83)
(36)
(500)
(950)
(597)
(597)
( 158)
(Φ175) (350)
(Ф150)
(14-Φ2.8)
(167)
(155)
(130)
(100)
(90) (90)
(100) (100)
(35)
(17 )
+3/16
0
(190)
(156)
(105)
(50~70)
(140)
(170)
(377)
(284)
(60)
(24)
(187.5)
(840)
(160)
(160)
(20~45)
to 1-25/32
(860~910)
(620)
(605 )
-3/16 +1-3/8
(90)
(150)
(160)
(7.5)
(20~45)
1-25/32
Corner pocket
In case of IR wireless remote controller
In case of standard grille
Note1. As for drain pipe, please use VP-25(O.D. Φ1-1/4(Φ32) PVC TUBE).
Drain pump is included.
Max. liftng height is 70-7/18(850mm) from the ceiling.
2. As for suspension bolt, please use M10 or W3/8.(Procured at local site)
3. Electrical box may be removed for the service purpose.
Make sure to slack the electrical wire little bit for control/power wires connection.
4. The height of the indoor unit is able to be adjusted with the grille attached.
5. For the installation of the optional high efficiency filter or optional multi-functional casement.
1) Add 5-5/16(135mm) to the dimensions marked on the figure.
2) The optional high efficiency filter must be used jointly with the multi-functional casement.
6. When installing the branch ducts, be sure to insulate adequately.
Otherwise condensation and dripping may occur.
(It becomes the cause of dew drops/water dew.)
7. As for necessary installation/service space, please refer to the left figure.
Drain hole
Drain pump clean hole
and Drain emergency
drainage hole
For MA-Remote controller
terminal block
Emergency operation switch<Cooling>
Emergency operation switch<Heating>
Indoor unit
Ceiling
Cut out hole
Burring hole pitch
3-Φ1/8(3-Φ2.8)
Burring hole
Detail drawing of fresh air intake hole
Burring hole
14-Φ1/8
Cut out hole
Burring hole pitch
Cut out hole
Detail connecting of Branch duct(Both aspects)
(77)
3-1/32
(85)
3-11/32
(298)
11-3/4
11-1/16
(281)
(74)(80)(258)(241)
2-29/32
3-5/32
10-3/16
PLA-A36BA4
PLA-A42BA4
PLA-A24BA4
PLA-A30BA4
9-1/2
DCBA
2
Refrigerant pipe
····Φ15.88
Flared connection
····5/8 inch
Refrigerant pipe
····Φ12.7
Flared connection
····1/2 inch
1
Refrigerant pipe
····Φ6.35
Flared connection
····1/4 inch
Refrigerant pipe
····Φ9.52
Flared connection
····3/8 inch
Models
PLA-A12BA4
PLA-A18BA4
Min.19-11/16(500)
Grille
Ceiling
Suspension bolt
lower edge
Vane motor
Air intake grille
Air outlet hole
Air outlet hole
Auto vane
(Air outlet)
Air intake hole
Air intake hole
Grille
Ceiling
Keep 25/64(10) to 19/32(15)
between unit ceiling
and ceiling slab.
)(
Connected the attached
flexible pipe or socket.
Drain pipe
connected to VP-25
Suspension bolt
M10 or W3/8
Branch duct hole
Fresh air
intake hole
Branch duct hole
Ceiling hole
Suspension bolt pitch
Suspension bolt pitch
Ceiling hole
(5/16)(5/16)
23-13/16
24-13/32
DEFROST/STAND BY lamp
Receiver
Operation lamp
For wiring replacement kit
terminal block
6-5/16
6-5/16
1
2
3-15/16
5-1/8
13-25/32
3-17/32
3-15/16 3-15/16
3-17/32
70˚
6-9/16 6-3/32
Φ5-29/32
Φ6-7/8
19-11/16
19-11/16
23-1/2
M
M
M
M
3-17/64
1-27/64
37-3/8
3-17/64
1-27/64
37-3/8 23-1/2
1-15/16~2-3/4
5-1/2
6-11/16
1-3/8
11/16
4-1/8
6-9/64
7-15/32
A
B
6-5/16
33-1/16(840)
5-29/32
3-17/32
C
D
33-1/16
7-3/8
25/32 to 1-25/32(20~45) 25/32 to 1-25/32(20~45)
33-27/32 to 35-13/16(860~910)
31-7/8(810)
25/32 to
33-27/32 to 35-13/1625/32
15/16
6-5/16
Indoor unit/Outdoor unit
connecting terminal block
Φ4-29/32(Φ125)
Φ3-15/16(Φ100)
6-7/32
120°
120°

16
PKA-A12HA4 PKA-A18HA4 Unit: inch (mm)
1/2F (Φ12.7)
1/4F (Φ6.35)
Refrigerant
Piping
Drain hose
Gas pipe
Liquid pipe
Φ2-1/2~Φ3-1/8
(Φ65~Φ80)
Φ2-1/2~Φ3-1/8
(Φ65~Φ80)
Through hole
Sleeve
(purchased locally)
Center measurement hole Φ3/32(Φ2.5)
5/32(3.8)
2-1/4(58) 0
Wall hole for
left rear piping
Knock out hole for
left rear piping
2-3/4×12-3/16(70×310)
Wall hole for
right rear piping
77-Φ3/16(Φ5.1)
Tapping
screw hole
4-Φ5/16(Φ9)
Bolt hole Mount board
Indoor unit outline
0
5/8(16)
9-15/16(253.5)
9-1/8(232.5)
1-1/16(28.5)
1-9/16(41)
3-1/16(78.5)
4-1/16(103.5)
4-9/16(116)
6-1/2(166)
7(178.5)
8(203.5)
3-9/16(91)
13/16(21.8)
9-1/16(231.5)
10-3/4(273.2)
0
1-1/4(32.7)
2-9/16(66)
2-1/16(53.5)
5(128.5)
6(153.5)
3/4(20)
9/16(15)
14-5/8(372.3) 14(356.3) 12-7/8(237.5) 11-7/16(291.5) 10-3/8(265) 9-5/16(238) 8-13/16(225) 7-13/16(200)
4-7/8(125)
2-3/4(70)
9/16(15)
14-5/8(372.3) 14(356.3) 12-7/8(327.5) 10-3/8(265) 11-7/16(291.5) 7-13/16(200) 8-13/16(225) 4-7/8(125) 2-3/4(70) 0
17-5/8(449)
7-9/16(193.5)
7-1/16(180.3)
6-9/16(167)
5-1/2(140)
4-1/2(115)
6-13/16(174)
8-3/8(213)
9-5/16(238)
10-15/16(278.3)
15-1/2(394)
11-1/16(281)
17-5/8(449)
0
Emergency operation switch
(cooling/heating)
Terminal block for
MA-remote controller
Terminal block for power supply (option)
Front side(Grille open)
Terminal block for indoor/outdoor
connecting line
17-15/16(457)Gas pipe
21-3/16(539)Liquid pipe
6-5/8(169)
6-3/16(158)
24(610)Drain hose 7-3/16(184)
250mm,9-13/16inch or greater with optional drain pump installation.
Required space(Indoor unit)
(mm)
Air inlet
Air inlet
Air outlet
Min.1-31/32(50)
Min.9-13/16(250)
Min.5-7/8(150)
Min.8-5/8
(220)
Min.1-31/32(50)
Min.1/4(7)
Knock out hole for piping
D
2-3/16(56)
2-11/16(69)
3/16(6)
1-11/16(43)
C
2-3/16(56)7/16(12.5)
1-11/16(43)
B
1-3/4(46)
2-5/16(60)
2-5/16(59)
1-11/16(43)
A
1-11/16(43)
1-3/4(46)
2-3/16(56)
3/16(6)
A
Knock out hole
for right piping
Right side
Mount board
3/16(5)9-13/16(249)
Top side
15-3/16(387) 7-1/2(192)
7-3/4(197)
23-9/16(599)
CB
Operation lamp DEFROST/STAND BY lamp
Receiver
Louver(manual)
Vane(auto)
Knock out hole
for lower piping
Knock out hole
for lower piping
Under side
5/16(8)
24-1/16(612)
D
Knock out hole
for left piping
Left side
Front side
6-1/16(155)
2-1/8
(55)
27-1/16(688)
11-5/8(295)
35-3/8(898)
Φ5/8 (Φ16) O.D

17
PKA-A24KA4 PKA-A30KA4 PKA-A36KA4 Unit: inch (mm)
Front side
46-1/16(1170)
9-1/2(241)
33-21/32(855)2-29/32(74)
14-3/8(365)
Emergency operation switch
(cooling/heating)
Terminal block for Outdoor unit
Terminal block for
MA-remote controller
Front side(Grille open)
Terminal block for power supply (option)
Filter hook
6-1/16(154)
4-27/32(123)
18-31/32(482)Liquid pipe
17-15/32(444)Gas pipe
23-1/32(585)Drain hose 5-9/32(134)
Min.9/32(7)
Center measurement hole
Φ3/32(Φ2.5)
Knockout hole for
rear piping
2-15/16×18-29/32(75×480)
75-Φ3/16(Φ5.1)
Tapping
screw hole
Mount board
Wall hole for
right rear piping
Indoor unit outline
4-Φ11/32(Φ9) Bolt hole
Wall hole for
left rear piping
1/8(3)
R1-15/32(R37.5)
2-1/8(54) 0
5/8(15.5)
0
17-9/32(439) 0
17-9/32(439)
15-1/8(384)
13/32(10) 20-3/8(517.4) 17-7/8(454) 16-3/32(408.5) 15-1/8(384) 14-11/32(364) 12-3/8(314) 4-11/32(110) 2-3/8(60) 13/32(10) 18-5/16(465.5) 17-7/8(454)
16-3/32(408.5)
15-1/8(384.5) 14-11/32(364) 12-3/8(314) 4-11/32(110) 2-3/8(60)
1-1/4(32)
12-5/32(308.5)
31/32(25)
11-1/2(292)
11(279.5)
9-17/32(242)
7-9/16(192)
5-19/32(142)
4-29/32(125)
4-19/32(117)
3-15/16(100)
2-15/16(75)
1-31/32(50)
15-1/8(384)
0
13-3/4(349.2)
16-15/16(430.5)
1/2(12.5)
11-1/2(292)
10-13/32(264)
9-1/32(229.5)
8-17/32(217)
6-9/16(167)
5-3/32(129.5)
4-1/8(104.5)
3-7/16(87.5)
2-15/32(62.5)
1-15/32(37.5)
1/2(12.5)
2-1/8(54)
31/32(25)
0
12-1/4(311)
8-17/32(216.5)
13-11/32(339)
20-7/8(530.5)
7-7/16(189)
13-11/32(339)
17-11/16(449.2)
23-1/32(585)
23-1/32(585)
A
5/16(7.8)
3-1/32(77)
2-5/8(67)
2-9/16(65)
B
Knockout hole for piping
13/32(10.7)
2-9/16(65)
3-1/32(77)
3-7/16(87)
C
5/16(7.8)
2-9/16(65)
3-1/32(77)
2-5/8(67)
Louver(manual)
Vane(auto)
Knockout hole
for lower piping
Under side
BB
Receiver
DEFROST/STAND BY lamp
Operation lamp
2-19/32(66)
23/32(18)
1-1/4(32)
2-3/32(53)
1-3/16(30)
1-3/8(35)
Mount board
C
Knockout hole
for right piping
Right side
11-5/8(295) 3/16(5)
Left side
A
Knockout hole
for left piping
Top side
2-9/16(65.2)
5-17/32(140.3)
7/16(11)
17(431.7)16-11/16(423.7)
Air outlet
Air inlet
Min.1-7/8(48)
Min.9-27/32(250)
Required space(Indoor unit)
Min.3-31/32(100.5)
Min.8-21/32(220)
Min.2-1/16(52.3)
Refrigerant pipe: 3/8 O.D(Φ9.52)
Refrigerant pipe: 5/8 O.D(Φ15.88)
5/8(Φ16) O.D
Drain hose
Piping connection
Liquid pipe
Gas pipe
Through hole
Φ2-15/16
(Φ75) Φ2-15/16~Φ3-5/32
(Φ75~Φ80)
Sleeve
(purchased locally) Flared connection: 5/8F
Flared connection: 3/8F
1
2
3
1
2
3

18
PCA-A24KA4 PCA-A30KA4 Unit: inch (mm)
When drain socket is installed
9-3/16(233)
Drainage
When drain socket is installed
9-11/16(246)
i-see sensor
14
liquid Φ3/8(Φ9.52) gas Φ5/8(Φ15.88)
Drainage
46-3/16(1173)
1/16(2) 1/16(2)50-3/8(1280)
1-7/8(48)5/16(8)
47-3/16(1198)
3-3/8(85)
7-3/16(182)
26-3/4(680)
18-3/4(476) 2-1/4(57)
9-1/16(230)
7-11/16(195)
3-7/16(88)
3-5/16(84)
3-1/8(80)
26-3/4(680)
12-5/8(320)
48-11/16(1237) (Suspension bolt pitch)
11/16(18)
5-1/2(140) 2-7/16(62)
5-7/8(150)
9-5/16(236)
7-7/8(200)
9-11/16(246)
2(51)
3/8(10)
3/16(5)
15-1/4(387)
3-3/8(86)
3-3/8(85)
4
1
7
1-1/2(38)
2
2-15/16(75)
When electrical box is pulled down
1/16(2)
10-1/4(260)
1/16(1)
7-1/12(190)
1-7/16(37)
5-7/16(138)
4-15/16(126)
In case of the rear pipe arrangement, make sure to remove the shaded portions from the independent piece. Then put the independent piece back in initial position.(The heat exchanger might be clogged because of dust)
8
Ceiling
Electrical box
3
5
[FRONT VIEW]
11/16(18)
4-3/4(121)
Φ4-15/16(Φ125)
7-1/2(190)
3(76)
4-7/8(124)
18-1/8(461)
1-13/16(46)
6
9-3/16(233)
2
NOTES. 1.Use M10 or W3/8 screw for anchor bolt. 2.Please be sure when installing the drain pump (option parts), refrigerant pipe will be only upward.
DEFROST/STAND BY lamp
Emergency operation switch <Cooling>
Receiver
Operation lamp
Emergency operation switch <Heating>
In case of wireless remote controller and i-see sensor(Optional Parts)
Knockout hole for upper drain pipe arrangement Knockout hole for fresh air intake Φ3-15/16(Φ100) Knockout hole for wiring arrangement Φ7/8(Φ22) Accessory...Drain socket (1(26mm) I.D.)
8 7 6
3 2 1 4 5
Drainage pipe connection(1(26mm)I.D.) Drainage pipe connection(for the left arrangement) Knockout hole for left drain-piping arrangement Refrigerant-pipe connection(gas pipe side/flared connection) Refrigerant-pipe connection(liquid pipe side/flared connection)
Electrical box
Air outlet
In case of wireless remote controller and i-see sensor (Optional Parts)
9/16
10(254)
7-1/16(180)
7
120°
8
Air intake

19
PCA-A36KA4 PCA-A42KA5 Unit: inch (mm)
When drain socket is installed
9-3/16(233)
When drain socket is installed
Drainage
9-11/16(246)
14
NOTES. 1.Use M10 or W3/8 screw for anchor bolt. 2.Please be sure when installing the drain pump (option parts), refrigerant pipe will be only upward.
6
80
26-3/4(680)
12-5/8(320)
61-5/16(1557) (Suspension bolt pitch)
11/16(18)
140
62
5-7/8(150)
2-7/165-1/2
3-1/8
Air outlet
58-3/4(1493)
1/16(2) 63(1600)
9-1/16(230)
7-11/16(195)
3-7/16(88)
3-5/16(84)
[FRONT VIEW]
5
1
1-7/8(48)5/16(8)
9-3/16(233)
1-13/16(46)
18-1/8(461)
4-7/8(124) 3(76)
7-1/2(190)
Φ4-15/16(Φ125)
4-3/4(121)
11/16(18)
3
Electrical box
Ceiling
8
In case of the rear pipe arrangement, make sure to remove the shaded portions from the independent piece. Then put the independent piece back in initial position.(The heat exchanger might be clogged because of dust)
4-15/16(126)
5-7/16(138)
1-7/16(37)
7-1/2(190)
1/16(1)
10-1/4(260)
1/16(2)
When electrical box is pulled down
2-15/16(75)
2
1-1/2(38)
7
4
3-3/8(85)
3-3/8(86)
15-1/4(387)
2
Electrical box
Air intake
59-3/4(1518)
26-3/4(680)
18-3/4(476)
57
182 85
7-3/16 3-3/8
2-1/4
In case of wireless remote controller and i-see sensor(Optional Parts)
Emergency operation switch <Heating>
Operation lamp
Receiver
Emergency operation switch <Cooling>
DEFROST/STAND BY lamp
9-5/16(236)
liquid Φ3/8(Φ9.52)
gas Φ5/8(Φ15.88)
Drainage
7-7/8(200)
9-11/16(246)
2(51)
3/8(10)
3/16(5)
9/16
In case of wireless remote controller and i-see sensor (Optional Parts)
1/16(2)
1
120°
2-15/16(75)
10(254)
7-1/16(180)
Knockout hole for upper drain pipe arrangement Knockout hole for fresh air intake Φ3-15/16(Φ100) Knockout hole for wiring arrangement Φ7/8(Φ22) Accessory...Drain socket (1(26mm)I.D.) Drainage pipe connection(1(26mm)I.D.) Drainage pipe connection(for the left arrangement) Knockout hole for left drain-piping arrangement Refrigerant-pipe connection (gas pipe side/flared connection) Refrigerant-pipe connection (liquid pipe side/flared connection)
8 7 6 5 4 3 2 11

20
PEA-A12AA4 PEA-A18AA4 Unit: mm (inch)
(46-7/8)
1190
(39)
990
N
(48-25/32)
1239
(40-29/32)
1039
M
ø12.7(1/2)
mm(in.)
(35-7/16)
(27-9/16)
(41-3/4)
(33-7/8)
(47-1/4)
(39-3/8)
(39-3/8)
(31-1/2)
(41-3/4)
(33-7/8)
(47-3/16)
(39-5/16)
(45-3/8)
(37-1/2)
(43-5/16)
(35-7/16)
ø6.35(1/4)
900 952 998 860 9800 1000 860 7700 20
24
L
900
K
9
J
1060
HG
1200
F
1000
E
11
D
1060
C
1100
B
1152
PEA-A12AA4
PEA-A18AA4
Model A
1198
Gas pipe Liquid pipe
12
Note1.Use M10 screw for the suspension bolt (field supply).
2.Keep the service space for the maintenance at the bottom.
3.This chart indicates for PEA-A12AA4 model, which has 2 fans.
PEA-A18AA4 models have 4 fans.
4.In case an inlet duct is used, remove the air filter (supply with
the unit), then install the filter (field supply) at suction side.
12
Drain pipe(O.D.ø32(1-1/4))
Terminal block (Remote controller transmission line)
Terminal block (Indoor/outdoor connecting line)
Refrigerant piping
flare connection (liquid)
Drain pipe(O.D.ø32(1-1/4))
(Emergency draining)
Knockout hole ø 27(1-3/32)
(Remote controller transmission line)
Knockout hole
ø 27(1-3/32)
(Indoor/outdoor connecting line)
L-ø2.9(1/8)
2X2-ø2.9(1/8)
2XE-ø2.9(1/8)
Control box
Air filter
Suspension bolt hole
4-14X30(9/16X1-3/16) Slot
Refrigerant piping
flare connection (gas)
Drain pipe(O.D.ø32(1-1/4))
(Spontaneous draining)
Air
inlet
Air
outlet
N
M
57(2-1/4)
57(2-1/4)
159(6-9/32)
345(13-19/32)
(3-9/16)
(5-29/32)
(2-25/32)(4-19/32)
70
10 (13/32)
(3-15/16)
(1-15/16) (24-5/8)
37(1-15/32)
200(7-7/8)
H
20(13/16)
157.5 (6-7/32)
20 (13/16)
100 (3-15/16)
37(1-15/32)
12(1/2)
12(1/2)
88(3-15/32)
100(3-15/16)XJ=K
100(3-15/16)
88(3-15/32)
10 (13/32)
49
25(1)
170(6-23/32)
102(4-1/32)
270(10-21/32)
116
150(Duct)
23(29/32)
100 25(1)
700(27-9/16)
677(26-21/32)
23 (29/32)
C
B (Suspension bolt pitch)23(29/32)
A
90
625 (Suspension bolt pitch)
D (Duct)
30(1-3/16) 100(3-15/16)X(E-1)=F
100(3-15/16)
20(13/16)
15(19/32)
(1-31/32 ~ 5-29/32)
(30-19/32)
(17-23/32)
(11-13/16)
(17-23/32)
More than 300
450
777
50(1-31/32)
50 ~ 150
50(1-31/32)
G450
Note2
Access door
Required space for service and maintenance
More than 20
More than 10
(13/16)
(13/32)
Access door
Ceiling surface
Make the access door at the appointed position
properly for service maintenance.
175±5(6-29/32±7/32)
Less than 300
Less than 550
(11-13/16)
(21-21/32)
Drain hose (I.D.ø32(1-1/4))
<accessory>
(Actual length)
