SERVICE MANUAL
CONTENTS
1. TECHNICAL CHANGES································ 2
2. PART NAMES AND FUNCTIONS··················3
3. SPECIFICATION ········································6
4. OUTLINES AND DIMENSIONS ·····················8
5. WIRING DIAGRAM···································10
6. REFRIGERANT SYSTEM DIAGRAM ···········12
7. SERVICE FUNCTIONS······························13
8. MICROPROCESSOR CONTROL ················15
9. TROUBLESHOOTING·······························23
10. DISASSEMBLY INSTRUCTIONS·················41
No. OBH732
REVISED EDITION-C
Outdoor unit service manual
MUZ-GL•NA, MUY-GL•NA Series (OBH733)
MXZ-C•NA, MXZ-C•NAHZ Series (OCH573)
NOTE:
RoHS compliant products have <G> mark on the spec name plate.
PARTS CATALOG (OBB732)
MSZ-GL06NA -U1
MSZ-GL09NA -U1
MSZ-GL12NA -U1
MSZ-GL15NA -U1
MSZ-GL18NA -U1
MSZ-GL24NA -U1
Models
MSZ-GL18NA
MSY-GL18NA
INDOOR UNIT
Revision C:
• For the airflow of MSZ-GL24NA- U1 and MSY-
GL24NA- U1 on the specification table has
been corrected (3. SPECIFICATION).
OBH732 REVISED EDITION-A is void.
MSY-GL09NA -U1
MSY-GL12NA -U1
MSY-GL15NA -U1
MSY-GL18NA -U1
MSY-GL24NA -U1

2
MSZ-GL18NA - U1 MSY-GL18NA - U1
MSZ-GL24NA - U1 MSY-GL24NA - U1
1. New model
1TECHNICAL CHANGES
Use the specied refrigerant only
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the spec labels provided with our products.
We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused by
failure to follow the instructions.
Revision A:
• MSZ-GL06/09/12/15NA- U1 and MSY-GL09/12/15NA- U1 have been added.
Revision B:
• 3. SPECIFICATION has been corrected.
MSZ-GL06NA - U1 MSY-GL09NA - U1
MSZ-GL09NA - U1 MSY-GL12NA - U1
MSZ-GL12NA - U1 MSY-GL15NA - U1
MSZ-GL15NA - U1
1. New model
Revision C:
• For the airflow of MSZ-GL24NA- U1 and MSY-GL24NA- U1 on the specification table has been corrected
(3. SPECIFICATION).
OBH732C

3
2PART NAMES AND FUNCTIONS
MSZ-GL06NA MSZ-GL09NA MSZ-GL12NA MSZ-GL15NA
MSY-GL09NA MSY-GL12NA MSY-GL15NA
Remote controller
Operation indicator lamp
Remote control receiving section
Emergency operation switch
Horizontal vane
Air outlet
Air filter
Air inlet
Heat exchanger
Front panel
Air cleaning filter
(Anti-Allergy Enzyme
Filter)
(Nano platinum filter )
Display section
ACCESSORIES
Installation plate 1
Attachment screws for the installation plate
4 × 25 mm 5
Remote controller holder 1
Screws for 3.5 × 16 mm (Black) 2
Battery (AAA) for remote controller 2
Wireless remote controller 1
Felt tape (For left or left-rear piping) 1
Air cleaning lter 2
OBH732C

4
MSZ-GL18NA
MSY-GL18NA
ACCESSORIES
Installation plate 1
Installation plate xing screw 4 × 25 mm 5
Remote controller holder 1
Fixing screw for 3.5 × 16 mm (Black) 2
Battery (AAA) for remote controller 2
Wireless remote controller 1
Felt tape (Used for left or left-rear piping) 1
Air cleaning lter 2
Remote controller
Operation indicator lamp
Remote control receiving section
Emergency operation switch
Horizontal vane
Air outlet
Air filter
Air inlet
Heat exchanger
Front panel
Air cleaning filter
(Anti-Allergy Enzyme
Filter)
(Nano platinum filter )
Display section
OBH732C

5
Remote controller
Display section
Front panel
Air filter
(Nano platinum filter)
Air inlet
Air cleaning filter
(Electrostatic anti-allergy
enzyme filter)
Air outlet
Horizontal vane
Heat exchanger
Operation indicator lamp
Remote control receiving section
Emergency operation switch
MSZ-GL24NA
MSY-GL24NA
ACCESSORIES
Installation plate 1
Installation plate xing screw 4 × 25 mm 7
Remote controller holder 1
Fixing screw for 3.5 × 16 mm (Black) 2
Battery (AAA) for remote controller 2
Wireless remote controller 1
Felt tape (Used for left or left-rear piping) 1
Air cleaning lter 2
OBH732C

6
3SPECIFICATION
Indoor model MSZ-GL15NA
MSY-GL15NA
MSZ-GL18NA
MSY-GL18NA
MSZ-GL24NA
MSY-GL24NA
Power supply V, phase, Hz 208/230, 1, 60
Max. fuse size (time delay)/ Disconnect switch A 15 20/15
Min. circuit ampacity A 1.0
Fan motor F.L.A 0.76 0.67 0.76
Airow
Super High - High - Med. -
Low - Quiet (GL15/18)
Powerful - Super High -
High - Med. - Low (GL24)
COOL Dry
(Wet) CFM
533 - 420 - 335 - 272 - 205
(498 - 385 - 300 - 237 - 170)
646 - 522 - 417 - 332 - 258
(581 - 470 - 375 - 299 - 232)
738 - 628 - 544 - 469 - 388
(661 - 562 - 487 - 420 - 347)
HEAT Dry
(MSZ)CFM
463 - 367 - 304 - 247 - 205 646 - 565 - 469 - 385 - 297 738 - 628 - 544 - 469 - 388
Moisture removal pt./h 2.7 2.1 5.1
Sound level
Super High - High - Med. -
Low - Quiet (GL15/18)
Powerful - Super High -
High - Med. - Low (GL24)
Cooling dB(A) 49 - 44 - 38 - 32 - 26 49 - 44 - 38 - 33 - 28 53 - 49 - 45 - 41 - 34
Heating
(MSZ)dB(A) 46 - 40 - 35 - 30 - 26 48 - 43 - 38 - 33 - 28 52 - 49 - 45 - 41 - 32
Fan speed
Super High - High - Med. -
Low - Quiet (GL15/18)
Powerful - Super High -
High - Med. - Low (GL24)
Cooling rpm
1,280 - 1,060 - 880 - 740 - 600 1,170 - 990 - 830 - 700 - 580 1,300 - 1,140 - 1,010 - 900 - 770
Heating
(MSZ)rpm
1,140 - 950 - 810 - 690 - 600 1,170 - 1,050 - 910 - 780 - 640 1,300 - 1,140 - 1,010 - 900 - 730
Cond. drain connection O.D. in. 5/8
Dimensions
W
in.
31-7/16 36-5/16 43-5/16
D 9-1/8 9-13/16 9-3/8
H11-5/8 12 12-13/16
Weight Ib. 22 28 37
External nish Munsell 1.0Y 9.2/0.2
Control voltage (by built-in transformer) 12 - 24 VDC
NOTE: Test conditions are based on AHRI 210/240.
Indoor model MSZ-GL06NA MSZ-GL09NA
MSY-GL09NA
MSZ-GL12NA
MSY-GL12NA
Power supply V, phase, Hz 208/230, 1, 60
Max. fuse size (time delay)/ Disconnect switch A 15
Min. circuit ampacity A 1.0
Fan motor F.L.A 0.76
Airow
Super High - High - Med. -
Low - Quiet
COOL Dry
(Wet) CFM 399 - 321 - 237 - 170 - 145
(364 - 286 - 201 - 134 - 109)
HEAT Dry CFM 406 - 321 - 237 - 170 - 145
Moisture removal pt./h –1.5 2.5
Sound level
Super High - High - Med. -
Low - Quiet
Cooling dB(A)
43 - 37 - 30 - 22 - 19
45 - 37 - 30 - 22 - 19
Heating
(MSZ)dB(A) 43 - 37 - 30 - 22 - 19
Fan speed
Super High - High - Med. -
Low - Quiet
Cooling rpm 1,020 - 860 - 670 - 530 - 470
Heating
(MSZ)rpm 1,040 - 860 - 670 - 530 - 470
Cond. drain connection O.D. in. 5/8
Dimensions
W
in.
31-7/16
D 9-1/8
H11-5/8
Weight Ib. 22
External nish Munsell 1.0Y 9.2/0.2
Control voltage (by built-in transformer) 12 - 24 VDC
OBH732C

7
(2) OPERATION
Mode Condition
Intake air temperature (°F)
Indoor Outdoor
DB WB DB WB
Cooling
Standard temperature 80 67 95 —
Maximum temperature 90 73 115 —
Minimum temperature 67 57 14 —
Maximum humidity 78% —
Heating
Standard temperature 70 60 47 43
Maximum temperature 80 67 75 65
Minimum temperature 70 60 -4 -5
3-1. OPERATING RANGE
(1) POWER SUPPLY
Rated voltage Guaranteed voltage (V)
Indoor unit
208/230 V
1 phase
60 Hz
Min. 187 208 230 Max. 253
3-2. OUTLET AIR SPEED AND COVERAGE
● The air coverage is the figure up to the
position where the air speed is 1 ft./s.,
when air is blown out horizontally from
the unit properly at the High speed posi-
tion.
The coverage should be used only as a
general guideline since it varies accord-
ing to the size of the room and furniture
arranged inside the room.
Model Mode Function Airow
(CFM)
Air speed
(ft./s.)
Coverage (ft.)
MSZ-GL06NA
HEAT Dry 406 20.6 29.5
COOL Dry 321 16.3 23.5
Wet 286 14.5 21.0
MSZ-GL09NA
MSY-GL09NA
HEAT Dry 406 20.6 29.5
COOL Dry 321 16.3 23.5
Wet 286 14.5 21.0
MSZ-GL12NA
MSY-GL12NA
HEAT Dry 406 20.6 29.5
COOL Dry 321 16.3 23.5
Wet 286 14.5 21.0
MSZ-GL15NA
MSY-GL15NA
HEAT Dry 463 23.4 33.5
COOL Dry 420 21.3 30.5
Wet 385 19.5 28.0
MSZ-GL18NA
MSY-GL18NA
HEAT Dry 646 29.5 44.0
COOL Dry 646 29.5 44.0
Wet 581 26.5 39.7
MSZ-GL24NA
MSY-GL24NA
HEAT Dry 738 18.0 36.9
COOL Dry 738 18.0 36.9
Wet 661 16.1 33.2
OBH732C

8
Unit: inch
MSZ-GL18NA
MSY-GL18NA
4OUTLINES AND DIMENSIONS
Piping
Insulation Ø2 O.D
Liquid line Ø5/16 15-3/8 (Flared connection Ø1/4)
Gas line Ø15/32 13-3/8 (Flared connection Ø1/2)
Drain hose
Insulation Ø1-1/8 Connected part Ø5/8 O.D
3/4
6-1/4
2-5/16
2-1/4
2-1/2
9-13/16
3/16
35-13/16
36-5/16
1/4
27-15/16 6-5/16
2-1/16
12
2-9/16
2-13/16
2-1/2
2-9/16
3-11/16
2-1/16
9-7/16
10-5/16
1/8
8-7/8 8-7/8 3-11/16
8-3/4
10-3/8
2-5/16 15-7/8
8-11/16
3-11/16
7/8
1×7/16 Oblong hole
7/16×13/16
Oblong hole
Installation plate
Indoor unit
Wall hole Ø3
Air in
Installation plate
8-1/16
15-3/16
1-5/8
8-11/16
3
1-11/16
2-9/16
2-9/16
4-1/2
5-3/4
1/4
Air out
Piping
Drain hose
3-15/16
MSZ-GL06NA MSZ-GL09NA MSZ-GL12NA MSZ-GL15NA
MSY-GL09NA MSY-GL12NA MSY-GL15NA
Piping
Insulation ø1 - 3/8 O.D
Liquid line ø1/4 19 - 11/16 (Flared connection ø1/4)
Gas line ø3/8 16 - 15/16
(Flared connection: ø3/8 (GL06/09/12NA), ø1/2 (GL15NA))
Drain hose Insulation ø1-1/8 O.D Connected part ø5/8 O.D
OBH732C

9
MSZ-GL24NA
MSY-GL24NA
Unit: inch
OBH732C

10
MSZ-GL18NA
MSY-GL18NA
5WIRING DIAGRAM
MSZ-GL06NA MSZ-GL09NA MSZ-GL12NA MSZ-GL15NA
MSY-GL09NA MSY-GL12NA MSY-GL15NA
OBH732C
