TECHNICAL DATA BOOK
CONTENTS
1. REFERENCE SERVICE MANUAL·············································2
2. SPECIFICATIONS ······································································3
3. OUTLINES AND DIMENSIONS················································10
4. WIRING DIAGRAM···································································28
5. REFRIGERANT SYSTEM DIAGRAM ······································38
6. PERFORMANCE CURVES······················································40
7. CORRECTION FACTORS························································42
8. APPLICABLE EXTENSION PIPE FOR EACH MODEL ··········43
9. AIR FLOW DATA······································································46
10. NOISE CRITERION CURVES ··················································58
11. OPTIONAL PARTS·····································································68
<Indoor unit>
[Model names]
R410A
PLA-RP·AA
PLA-RP·AA2
PEAD-RP·EA
PEAD-RP·EA2
PEAD-RP·GA
PKA-RP·GAL
PKA-RP·FAL
PCA-RP·GA
PCA-RP·HA
PSA-RP·GA
<Outdoor unit>
[Model names]
No. OCS06
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
PUHZ-P100/125/140VHA
January 2006
INVERTER
kW Model
OCS06-1.qxp 06.1.24 0:59 PM Page 1

2
For information on service, please refer to the service manual as follows.
Model name Service Ref. Service
Manual No.
PLA-RP50/60/71AA PLA-RP50/60/71AA.UK OC335
OC327
PLA-RP100/125/140AA2 PLA-RP50/60/71AA PLA-RP100/125/140AA2.UK OC357
PCA-RP50/60/71GA PCA-RP50/60/71GA OC328
PCA-RP100/125/140GA PCA-RP100/125/140GA
PCA-RP71/125HA PCA-RP71/125HA OC329
PKA-RP50GAL PKA-RP50GAL OC330
PKA-RP60/71/100FAL PKA-RP60/71/100FAL OC331
PSA-RP71/100/125/140GA PSA-RP71/100/125/140GA OC332
PEAD-RP50/60/71/125/140EA PEAD-RP50/60/71/125/140EA.UK
HWE05210
PEAD-RP100EA2 PEAD-RP100EA2.UK
PEAD-RP60/71/100GA PEAD-RP60/71/100GA.UK
HWE05060
1-2. OUTDOOR UNIT
Model name Service Ref. Service
Manual No.
OC359PUHZ-P100/125/140VHA PUHZ-P100/125/140VHA.UK
1-1. INDOOR UNIT
1REFERENCE SERVICE MANUAL
OCS06-1.qxp 06.1.24 0:59 PM Page 2

3
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -11:, W.B. -12:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP100AA2 PLA-RP125AA2 PLA-RP140AA2
Outdoor unit PUHZ-P100VHA PUHZ-P125VHA PUHZ-P140VHA
Cooling Capacity Btu/h 32,100 42,000 46,400
kW 9.4(4.9-11.2)12.3(5.5-14.0)13.6(5.5-15.0)
Total input kW 3.12 4.09 5.21
EER 3.01 3.01 2.61
Energy label class B B D
SHF 0.80 0.75 0.72
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-12.5)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.28 4.11 4.98
COP 3.41 3.41 3.21
Energy label class B B C
Booster heater kW - - -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 19-21-23-27 24-25-27-30
(Low-Medium2-Medium1-High)
CFM 670-740-810-950 850-880-950-1060
External pressure Pa 0 0
Sound level dB(A)33-36-39-41 37-40-43-45
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel)D : mm 840 (950)
H : mm 298 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/16)
Weight kg 32 (5)
Unit (Panel)lbs 71 (11)
Unit drain pipe I.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 60 100
CFM 2,120 3,530
Sound level at cooling dB(A)50 51 52
Sound level at heating dB(A)54 55 56
External finish Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 123
lbs 165 271
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2SPECIFICATIONS
2-1. CEILING CASSETTE TYPE
OCS06-1.qxp 06.1.24 0:59 PM Page 3

4
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -11:, W.B. -12:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP100EA2 PEAD-RP125EA PEAD-RP140EA
Outdoor unit PUHZ-P100VHA PUHZ-P125VHA PUHZ-P140VHA
Cooling Capacity Btu/h 32,100 42,000 46,400
kW 9.4(4.9-11.2)12.3(5.5-14.0)13.6(5.5-15.0)
Total input kW 3.12 4.38 5.21
EER 3.01 2.81 2.61
Energy label class B C D
SHF 0.86 0.83 0.84
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-12.5)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.28 4.11 4.98
COP 3.41 3.41 3.21
Energy label class B B C
Booster heater kW - - -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 33.5-42 33.5-42 36.5-46
(Low-High)CFM 1183-1483 1183-1483 1288-1624
External pressure Pa 70(130)
Sound level dB(A)44-50 44-50 46-51
(Low-High)(
130Pa : 46-52)( 130Pa : 46-52)( 130Pa : 47-53)
External finish Galvanized sheets
Dimension W : mm 1415 1715
D : mm 740
H : mm 325
W : inch 55-11/16 67-1/2
D : inch 29-1/8
H : inch 12-13/16
Weight kg 65 65 70
lbs 143 143 154
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 60 100
CFM 2,120 3,530
Sound level at cooling dB(A)50 51 52
Sound level at heating dB(A)54 55 56
External finish Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 123
lbs 165 271
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-2. CEILING-CONCEALED TYPE
OCS06-1.qxp 06.1.24 0:59 PM Page 4

5
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
w1. If optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP100GA
Outdoor unit PUHZ-P100VHA
Cooling Capacity Btu/h 32,100
kW 9.4(4.9-11.2)
Total input kW 3.60
EER 2.61
Energy label class D
SHF 0.85
Heating Capacity Btu/h 38,200
kW 11.2(4.5-12.5)
Total input kW 3.49
COP 3.21
Energy label class C
Booster heater kW -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 32
Indoor unit Air flow CMM 26.5-33
(Low-High)CFM 935-1165
External pressure Pa 10/50/70
Sound level dB(A)40-43/42-45/42-46
(Low-High)(
10/50/70Pa)
External finish Galvanized sheets
Dimension W : mm 1411
D : mm 740
H : mm 275
W : inch 55-9/16
D : inch 29-1/8
H : inch 10-13/16
Weight kg 50
lbs 111
Unit drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 60
CFM 2,120
Sound level at cooling dB(A)50
Sound level at heating dB(A)54
External finish Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 75
lbs 165
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
OCS06-1.qxp 06.1.24 0:59 PM Page 5

6
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
w1. If optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PKA-RP100FAL
Outdoor unit PUHZ-P100VHA
Cooling Capacity Btu/h 32,100
kW 9.4(4.9-11.2)
Total input kW 3.12
EER 3.01
Energy label class B
SHF 0.79
Heating Capacity Btu/h 38,200
kW 11.2(4.5-12.5)
Total input kW 3.49
COP 3.21
Energy label class C
Booster heater kW -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 32
Indoor unit Air flow CMM 22-28
(Low-High)CFM 780-990
External pressure Pa 0
Sound level dB(A)41-46
(Low-High)
External finish
Munsell 3.4Y 7.7/0.8
Dimension W : mm 1680
D : mm 235
H : mm 340
W : inch 66-1/8
D : inch 9-1/4
H : inch 13-3/8
Weight kg 28
lbs 62
Unit drain pipe O.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 60
CFM 2,120
Sound level at cooling dB(A)50
Sound level at heating dB(A)54
External finish
Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 75
lbs 165
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-3. WALL-MOUNTED TYPE
OCS06-1.qxp 06.1.24 0:59 PM Page 6

7
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -11:, W.B. -12:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP100GA PCA-RP125GA PCA-RP140GA
Outdoor unit PUHZ-P100VHA PUHZ-P125VHA PUHZ-P140VHA
Cooling Capacity Btu/h 32,100 42,000 46,400
kW 9.4(4.9-11.2)12.3(5.5-14.0)13.6(5.5-15.0)
Total input kW 3.35 4.38 5.21
EER 2.81 2.81 2.61
Energy label class C C D
SHF 0.77 0.78 0.76
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-12.5)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.49 4.98 4.98
COP 3.21 2.81 3.21
Energy label class C D C
Booster heater kW - - -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 20-21-23-25 27-30-32-34
(Low-Medium2-Medium1-High)
CFM 705-840-810-885 955-1060-1130-1200
External pressure Pa 0 0
Sound level dB(A)40-41-43-45 41-43-45-46 42-44-46-48
(Low-Medium2-Medium1-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 1310 1620
D : mm 680
H : mm 270
W : inch 51-9/16 63-3/4
D : inch 26-3/4
H : inch 10-5/8
Weight kg 37 43 45
lbs 82 95 99
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 60 100
CFM 2,120 3,530
Sound level at cooling dB(A)50 51 52
Sound level at heating dB(A)54 55 56
External finish Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 123
lbs 165 271
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-4. CEILING-SUSPENDED TYPE
OCS06-1.qxp 06.1.24 0:59 PM Page 7

8
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚C D.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C
4. Above data based on indicated voltage
w1. If optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP125HA
Outdoor unit PUHZ-P125VHA
Cooling Capacity Btu/h 42,000
kW 12.3(5.5-14.0)
Total input kW 4.38
EER 2.81
Energy label class C
SHF 0.78
Heating Capacity Btu/h 47,100
kW 13.8(5.0-16.0)
Total input kW 4.30
COP 3.21
Energy label class C
Booster heater kW -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 30-38
(Low-High)CFM 1060-1350
External pressure Pa 0
Sound level dB(A)44-50
(Low-High)
External finish Stainless steel
Dimension W : mm 1520
D : mm 650
H : mm 280
W : inch 59-7/8
D : inch 25-5/8
H : inch 11
Weight kg 56
lbs 124
Unit drain pipe I.D. mm 26
inch 1
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A)51
Sound level at heating dB(A)55
External finish
Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 123
lbs 271
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
OCS06-1.qxp 06.1.24 0:59 PM Page 8

9
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor: D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚C D.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚C D.B. 21:, W.B. 15:
Lower limit D.B. 17˚C D.B. -11:, W.B. -12:
4. Above data based on indicated voltage
wIf optional Air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PSA-RP100GA PSA-RP125GA PSA-RP140GA
Outdoor unit PUHZ-P100VHA PUHZ-P125VHA PUHZ-P140VHA
Cooling Capacity Btu/h 32,100 42,000 46,400
kW 9.4(4.9-11.2)12.3(5.5-14.0)13.6(5.5-15.0)
Total input kW 3.12 4.38 5.64
EER 3.01 2.81 2.41
Energy label class B C E
SHF 0.83 0.76 0.75
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-12.5)14.0(5.0-16.0)16.0(5.0-18.0)
Total input kW 3.28 4.98 5.69
COP 3.41 2.81 2.81
Energy label class B D D
Booster heater kW - - -
Power supply Phase {1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 24-31 26-33 27-35
(Low-High)CFM 850-1060 920-1165 955-1240
External pressure Pa 0
Sound level dB(A)44-49 46-51 47-52
(Low-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 600
D : mm 350
H : mm 1900
W : inch 23-5/8
D : inch 13-3/4
H : inch 74-13/16
Weight kg 51 53
lbs 112 117
Unit drain pipeO.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 60 100
CFM 2,120 3,530
Sound level at cooling dB(A)50 51 52
Sound level at heating dB(A)54 55 56
External finish Ivory Munsell 5Y 7/1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75 123
lbs 165 271
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-5. FLOOR STANDING TYPE
OCS06-1.qxp 06.1.24 0:59 PM Page 9

10
3OUTLINES AND DIMENSIONS
PLA-RP60,71AA
PLA-RP50AA
Models
PLA-RP100,125,140AA2
241
281
A
258
298
B
80
84
C
Receiver Operation lamp
DEFROST/STAND BY lamp
Emergency operation switch (cooling)
A (WIRELESS PANEL)
Emergency operation switch (heating)
Branch duct hole
(Cut out hole)
{175
{150
14 - {2.8
Burring hole
350
90
70_
100 100 90
100 130
155
167
Suspension bolt pitch
Ceiling hole
Branch
duct hole
Suspension bolt pitch
Ceiling hole
840
197 159
159
605
159192
98
89
C
840
860 - 91020 - 45 20 - 45
20 - 4520 - 45
Fresh air intake
Branch duct hole
860 - 910
810
159
16
Terminal block
Drain pipe
VP-25connection
(O.D.{32)
Ceiling surface
Power line entry
Suspension bolt lower edge
Suspension bolt M10
or W3/8
Control wire entry
Feeding hole
(Drain pump) 37428660
17+5
0
30
190
170
140
50 - 70
105
A
B
1
2
High efficiency filter
& Fresh air intake casement (option)
17+5
0135
Air outlet hole
Vane motor
Auto vane
Drain hole
Grille
Air outlet hole
Air intake hole
411
Air intake hole
Air intake grille 577
77 51
M
M
M
A
M
950
51 77
950 577 411
RP50
Use the current nuts meeting the pipe size of the outdoor unit.
Available pipe size
Factory flare nut attachment to the heat-exchanger.
1LIQUID SIDE
2GAS SIDE
RP60 RP71
[6.35 [6.35 — —
[9.52 [9.52 [9.52 [9.52
[12.7 — — —
[15.88 [15.88 [15.88 [15.88
———[19.05
RP100, 125, 140
Detail drawing of fresh air intake
3 - {2.8
Burring hole {125
Burring hole pitch
{100
(Cut out hole)
Ceiling surface
120_
120_
158
Unit : mm
INDOOR UNIT
PLA-RP50AA PLA-RP60AA PLA-RP71AA
PLA-RP100AA2 PLA-RP125AA2 PLA-RP140AA2
OCS06-1.qxp 06.1.24 0:59 PM Page 10

11
PEAD-RP50EA
PEAD-RP60EA
PEAD-RP71EA
PEAD-RP100EA2
PEAD-RP125EA
PEAD-RP140EA
2
1
3
4
5
6
7
Refrigerant piping flare connection (liquid [F copper tube):HP
Refrigerant piping flare connection (gas [G copper tube):LP
Drain R1(External thread)
Electrical parts box
Drain Pump (Option)
Drain Pipe (Option) ... Flexible joint VP-25(I.D.
[ 32)
Filter
R407C Outdoor unit : 9.52
F
R410A Outdoor unit : 6.35 w
R407C Outdoor unit : 9.52 w
Outdoor unit (SUZ) : 6.35
EDCBA
804830
- 305772
Model
RP60
R407C Outdoor unit : 15.88
G
R410A Outdoor unit : 12.7 w
15.88
104410702902801012
RP50
wSetting at shipment
2
1
3
4
Air inlet
Air outlet
Access door 55
50~150
81
197
Service space:500 or more
Keep duct-work length 850mm or more.
Be sure to apply the air filter
near the air inlet grille.
5
6
75 44
18
365~465
B 81
10
56 355
7
159
243
Air outlet
Air inlet
7
Lifting bolt hole
(14×22)
10- [ 3 (RP35,50)
12-
[ 3 (RP60)
In case of rear inlet
In case of bottom inlet 10-
[ 3 (RP35,50)
12-
[ 3 (RP60)
D30
C
10
81BC
A
450
450
10- [ 3 (RP35,50)
12-
[ 3 (RP60)
176
40
288
256
3.5 3.5
10
109 179
10
35
24
30640
30
21
277 80
45
282
13
13E
A
61 227
29
85
40 176
10
15
3.5
256 BC 81
10
81
A
Set
R407C outdoor unit : 19.05158416104704601552RP140
15.8810441070290 F
R410A Outdoor unit : 15.88 w
EDCBA
12841310370360
2801012
1252
Model
RP100,125
RP71
w Setting at shipment
7
44
243
308
323
75
6
5
13
Refrigerant piping flare connection (liquid [9.52 copper tube):HP
Refrigerant piping flare connection (gas [F copper tube):LP
Drain R1 (External thread)
Electrical parts box
Drain Pump (Option)
Drain Pipe (Option) ... Flexible joint VP25(I.D.[32)
Filter
Service space:500 or more
81
365~465
197
81
50~150
55
29
Access door
Air outlet
Air inlet
43
12
7
6
5
4
3
2
1
113
307 122
12-[3
(14x22)
Lifting bolt hole
45
Set
210
12-[3
450
450
140
282
680
3.5 3.5
30
319
261
181
40
30
A
C B 81
10
375
10 80
C B 81
A
E 13
30D
20
35
30
1053 169
Keep duct-work length 850mm or more.
Be sure to apply the air filter
near the air inlet grille.
Unit : mm
OCS06-1.qxp 06.1.24 0:59 PM Page 11

12
PEAD-RP60GA
PEAD-RP71GA
PEAD-RP100GA
Unit : mm
Model ABCDE
7
7
9
8
9.52
9.52
15.88
15.88
8
10
FG H J
RP60
RP71
RP100
1125
1125
1365
1090
1090
1330
1050
1050
1290
1012
1012
1252
840
840
1080
Outdoor unit(SUZ) : 6.35
Other outdoor unit : 9.52 w
R410A Outdoor unit : 15.88 w
R407C Outdoor unit : 19.05
wSetting at shipment
OCS06-1.qxp 06.1.24 0:59 PM Page 12

13
PKA-RP50GAL
BYOFF
ON STAND HEATCOOL
OFF BY
ON STAND COOL HEAT
ÅrÇoÇoÅqÅ@ëOñ Å@ÇeÇqÇnÇmÇs ÅrÇoÇoÅqÅ@ëOñ Å@ÇeÇqÇnÇmÇs
r.SLI
m m
MITSUBISHIELECTRICMITSUBISHIELECTRIC
r.S
L
I
m m
MITSUBISHIELECTRICMITSUBISHIELECTRIC
Knock out hole for right piping Refrigerant pipe.Drain pipe. Wiring hole
21
Right side Less than 15
70 245
60
235
Auto vane
Front view
Air intake
Air intake
Air intake
Air intake
198
53
340
715 225
340 80 280 233
990
21
Left side
Knock out hole for left piping Refrigerant pipe.Drain pipe.Wiring hole. 60
70 245
(Necessary clearance for Unit installation)
Right side
Allowing clearances Front view
Less than 130
50 or more 150 or more
180 or more 30 or more
for bolts
Left-rear piping hole
left-rear piping
R52.5 R52.5
Installation plate balance point hole
Details of installation plate
49-[5hole
for tapping screw
Knock out hole for right-rear piping Right-rear
piping hole
Unit center
14-[14hole
Knock out hole for
425
420
170
190
210
230
0
322 0 35 55 80 130 190 230 272 310 0
35
95
150
205
260
320
345
495
20
75
135
190
245
300
360
405
495
32
0
w1 Sleeves are available on the market. w2 This size shows the lower end of through hole.
[90~[100[90 Through hole
Sleeve w1
50 Model
R52.5
R52.5
Gas pipe
Liquid pipe
Terminal block for Terminal block to outdoor unit
Filter grip
Service panel (Power supply access)
(Flexible hose total length800) (Right side piping
installation)
(Left side piping
installation)
Unit drain pipe O.D.20
Front view(to open the grille)
700
449 86
581 54
31 280
35
Knock out hole for under piping Refrigerant piping.Drain pipe. Wiring hole
12-Louvers(manual)
Air outlet
Lower side
80
50
395400
190
60
70 35
79
160 40
235
705
power supply (Heater (PKH-P50GALH only))
153
GAS SIDE
LIQUID SIDE
RP50 P50
[6.35 [9.52 [12.7 [15.88
—
[9.52
—
[15.88
Use the current nuts meeting the pipe size of the outdoor unit. Available pipe size
: Factory flare nut attachment to the heat - exchanger.
Unit : mm
OCS06-1.qxp 06.1.24 0:59 PM Page 13

14
Unit : mm
PKA-RP60FAL
PKA-RP71FAL
235
45
235
45
235
45
235
62.5
13
58 42
340
197
Top
Front Right side
Left side 1400
1090 Air intake 235
C
Knock out hole for right piping
Refrigerant pipe. Drain pipe
Knock out hole for
left piping
Drain hose for
left-hand side piping Drain hose
Lower side
Auto vanes
(Gas pipe) Drain hose O.D.20
Bolt
Gas pipe
15
(Liquid pipe)
Liquid pipe [9.52(3/8F)
Gas pipe [15.88(5/8F)
Liquid pipe
A
30
32
39 98
37
74
439
100
30
37
74
4
2980
280
3030
18430
60
10
39
37
65
100
AB C
Knock out hole for wiring
25
1110 183
240
B
1120 552
55
120 107
111
Air outlet
552 Air outlet
Louvers (manual)
Under panel
Removable at left-hand
side piping Knock out hole for under-piping
Refrigerant pipe. Drain pipe
Rear piping opening
Range for left rear piping opening
12-ø6 hole for
tapping screw
66-ø6 hole for
tapping screw
Wall fixture
Unit center
32-ø12 hole for bolt 225
18 18 91
900
990 455 285
245
19
240 280 314
610 90
Drainage range
on left-hand side Drainage range on right-hand side
10 91=(910)
180
Terminal block for heater (PKH only)
Terminal block for indoor/outdoor connecting line
Display section
Receiving
section
Power lamp
Emergency switch(Heat)
Emergency switch(Cool)
Defrosting Initial heating lamp
OCS06-1.qxp 06.1.24 0:59 PM Page 14

15
Unit : mm
PKA-RP100FAL
235
45
235
45
235
45
235
45
235
62.5
13
58 42
340
197
Top
Front Right side
Display section
Receiving
section
Power lamp
Emergency switch(Heat)
Emergency switch(Cool)
Defrosting Initial heating lamp
Left side 1680
1370 Air intake 235
C
Knock out hole for right piping
Knock out hole for left piping
Drain hose for left-hand side piping Drain hose
Drain hose
Lower side
Auto vane
(Gas pipe)
Bolt
Gas pipe
15
(Liquid pipe)
Liquid pipe
A
30
32
39 98
37
74
439
100
30
37
74
4
2980
280
3030
18430
60
10
39
37
65
100
AB C
Knock out hole for wiring
25
1110 183
240
B
1400
55
120 102
111
694 Air outlet 694 Air outlet
Louvers (manual)
Under panel
(Removable at left-hand side piping)
Knock out hole for under-piping
Refrigerant pipe. Drain pipe
Rear piping opening
Range for left rear piping openingRange for left rear piping opening
12-ø6 hole for tapping screw
84-ø6 hole for
tapping screw
Wall fixture
Unit out line Unit center
41-ø12 hole for bolt 295 225
18 18 91
900
1270 595 285
245
19
240 280 314
750 90
Drainage range
on right-hand side
13 91=(1183)
180
Drainage range
on left-hand side
Terminal block for heater (PKH only)
Terminal block for indoor/outdoor connecting line
Drain hose O.D.20
: Factory flare nut attachment to the
heat-exchanger.
GAS SIDE
LIQUID SIDE
RP100
[9.52
[15.88
[19.05
P100
[9.52
[19.05
Use the current nuts meeting the pipe size
of the outdoor unit.
Available pipe size
OCS06-1.qxp 06.1.24 0:59 PM Page 15

16
PCA-RP50GA
NOTES:
1. Use M10 or W3/8 screws for anchor bolt.
2. When optional drain lift-up mechanism is installed, always provide
upward piping for refrigerant piping.
180
210
157
15 85
182 liquid
201 gas
241 (Drainage)
Air intake
918
161 90
254
680
506 56
Electrical box
226
70
6
2
7
17
150
140 70
320 80
933 (suspension bolt pitch)
983
1000
Air outlet
81
904
76
525 928 352
263
171
138
86
46 175 1
131
38 38 79
161 32
179
42
6~7
Ceiling
Electrical box [Front view]
When electrical
box is pulled
down
3
2
8
514
[15.88
[9.52
P50
[15.88
[12.7
[6.35
Available pipe size
[9.52
4GAS SIDE
5LIQUID SIDE
RP50
Use the current nuts meeting the pipe size of the outdoor unit.
: Factory flare nut attachment to the heat-exchanger.
1Drainage pipe connection (26mm I.D.)
2Drainage pipe connection (for the left arrangement)
3Knock out hole for left drain-piping arrangement
4Refrigerant-pipe connection (gas pipe side/flared connection)
5Refrigerant-pipe connection (liquid pipe side/flared connection)
6Knock out hole for upper drain pipe arrangement
7Knock out hole for left drain pipe arrangement
8Knock out hole for wiring arrangement
Unit : mm
OCS06-1.qxp 06.1.24 0:59 PM Page 16

17
PCA-RP60GA
PCA-RP71GA
161 90
254
680
506 56
1240 (suspension bolt pitch)
140
150
320 80
17
70
6
1290
1214
210 180
81 76
1310
Air outlet
1228
Air intake
85
182
201
241
15
157
(liquid)
(5/8F gas)
(Drainage)
7
2
Electrical box
70
226
3
2
8
514
Electrical box
When electrical
box is pulled
down
[ Front view ]
Ceiling
32
179
161
38 3879
42
6~7
525 1235 416
263
171
138
86
131
175 1
46
: Factory flare nut attachment to the heat-exchanger.
4GAS SIDE
5LIQUID SIDE
Use the current nuts meeting the pipe size of the outdoor unit.
Available pipe size
RP71,P60,P71 RP60
[6.35
[9.52
[15.88
[9.52
[15.88
1Drainage pipe connection (26mm I.D.)
2Drainage pipe connection (for the left arrangement)
3Knock out hole for left drain-piping arrangement
4Refrigerant-pipe connection (gas pipe side/flared connection)
5Refrigerant-pipe connection (liquid pipe side/flared connection)
6Knock out hole for upper drain pipe arrangement
7Knock out hole for left drain pipe arrangement
8Knock out hole for wiring arrangement
Unit : mm
NOTES:
1. Use M10 or W3/8 screws for anchor bolt.
2. When optional drain lift-up mechanism is installed, always provide
upward piping for refrigerant piping.
OCS06-1.qxp 06.1.24 0:59 PM Page 17

18
PCA-RP100GA
161 90
254
680
506 56
1228
Air intake
1214
270
207
81 96
1310
Air outlet
1240 (suspension bolt pitch)
140
150
320 80
18
70
6
87
182
198
245
16
217
(3/8F liquid)
(5/8F, 3/4F gas)
(Drainage)
7
2
Electrical box
70
229
3
28514
Electrical box
When electrical
box is pulled
down
[ Front view ]
Ceiling
93
160
38 38 140
42 239
6~7
525 1235 687 263
171
138
86
192
236 1
45
Use the current nuts meeting the pipe size of the outdoor unit.
:Factory flare nut attachment to the heat-exchanger.
4GAS SIDE
5
LIQUID SIDE
Available pipe size
RP100
[9.52
[15.88
[19.05
P100
[9.52
[19.05
1Drainage pipe connection (26mm I.D.)
2Drainage pipe connection (for the left arrangement)
3Knock out hole for left drain-piping arrangement
4Refrigerant-pipe connection (gas pipe side/flared connection)
5Refrigerant-pipe connection (liquid pipe side/flared connection)
6Knock out hole for upper drain pipe arrangement
7Knock out hole for left drain pipe arrangement
8Knock out hole for wiring arrangement
Unit : mm
NOTES:
1. Use M10 or W3/8 screws for anchor bolt.
2. When optional drain lift-up mechanism is installed, always provide
upward piping for refrigerant piping.
OCS06-1.qxp 06.1.24 0:59 PM Page 18

19
PCA-RP125GA
PCA-RP140GA
161 90
254
680
506 56
1535
Air intake
1524
270
207
81 96
1620
Air outlet
1547(suspension bolt pitch)
140
150
320 80
18
70
6
87
182
198
245
16
217
(3/8F liquid)
(5/8F, 3/4F gas)
(Drainage)
7
2
Electrical box
70
229
328514
Electrical box
When electrical
box is pulled
down
[ Front view ]
Ceiling
93
160
38 38 140
42 239
6~7
525 1545 687 263
171
138
86
192
236 1
45
:Factory flare nut attachment to the heat-exchanger.
RP125,140
[19.05
[15.88
[9.52
Use the current nuts meeting the pipe size of the outdoor unit.
4GAS SIDE
5LIQUID SIDE
Available pipe size P125,140
[19.05
[9.52
1Drainage pipe connection (26mm I.D.)
2Drainage pipe connection (for the left arrangement)
3Knock out hole for left drain-piping arrangement
4Refrigerant-pipe connection (gas pipe side/flared connection)
5Refrigerant-pipe connection (liquid pipe side/flared connection)
6Knock out hole for upper drain pipe arrangement
7Knock out hole for left drain pipe arrangement
8Knock out hole for wiring arrangement
Unit : mm
NOTES:
1. Use M10 or W3/8 screws for anchor bolt.
2. When optional drain lift-up mechanism is installed, always provide
upward piping for refrigerant piping.
OCS06-1.qxp 06.1.24 0:59 PM Page 19

20
Ceiling
Less than
Less than
or more
Less than
or more or more
300
<Suspension bolt pitch>
model:PAC-SG38KF-E (12pcs.)
Filter element for the exchange
1.Use M10 or W3/8 screw for anchor bolt.
NOTES.
Option parts:duct flange( [200). model: PAC-SF28OF-E(1 pc.)
Knock out hole for wiring arrangement : 2- [27
(122)
<Filter contour dimension>
16
handle
100 1001136
366
480
176
318
650
<Flexible hose(accessory)>
Terminal block box
9Terminal block(remote controller)
8Terminal block(indoor/outdoor connecting line)
78
Inspection port (pipe sensor)
The half bottom of FAN CASING can be separated. Adjustable part
288
360
<Air outlet>
<Suspension bolt pitch>
<Air outlet>
<Air intake>
<Air intake>
Filter (3-pieces)
Terminal block box
5
2
1
4
3
Knock out hole for upper refrigerant-pipe arrangement
69
2
1
Flexible hose(accessory) Drainage pipe connection(26mm I.D.)
2Refrigerant-pipe connection(gas pipe side/flared connection : 5/8F)
38
105
85
90˚
Electrical box
Rear wall
500
250
2 ~ 3
(Gap to ceiling)
Allowing clearances
<gas>
<liquid>
7
Knock out hole (duct for fresh air intake): 2- [200
6 5 1 3 4Knock out hole for behind refrigerant-piping arrangement
Refrigerant-pipe connection(liquid pipe side/flared connection : 3/8F)
Suspension bolt
130
210
45
165
120
1224
1180
75
1136
986
1098
70
243
254
175
197
110 21
130 15
258 110 102
320 80
90
14018
75
70~90
650
13
289
75
280
495
43
295
[222
[200
PCA-RP71HA Unit : mm
OCS06-1.qxp 06.1.24 0:59 PM Page 20
