Mitsubishi Electric MUCFH-GA35VB User manual

FLOOR AND CEILING TYPE AIR CONDITIONERS
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················5
3. SPECIFICATION·················································6
4. NOISE CRITERIA CURVES·······························7
5. OUTLINES AND DIMENSIONS ·························8
6. WIRING DIAGRAM ··········································10
7. REFRIGERANT SYSTEM DIAGRAM ··············11
8. PERFORMANCE CURVES······························13
9. ACTUATOR CONTROL····································24
10. SERVICE FUNCTIONS·····································24
11. TROUBLESHOOTING ······································25
12. DISASSEMBLY INSTRUCTIONS·····················35
13. PARTS LIST······················································42
14. RoHS PARTS LIST···········································48
HFC
utilized
R410A
MUCFH-GA35VB -
MUCFH-GA50VB -
MUCFH-GA60VB - E1
E1
E1
SERVICE MANUAL
Models
OUTDOOR UNIT
NOTE:
This service manual describes technical data of the outdoor units.
RoHS compliant products have <G> mark on the spec name plate.
For servicing of RoHS compliant products, refer to the RoHS PARTS LIST (RoHS compliant).
Indoor unit service manual
MCFH-GA•VB Series (OB380)
No. OB381
REVISED EDITION-B
Revision B:
• The fan guard for MUCFH-GA 60VB-
has been changed.
E1
Please void OB381 REVSED EDITION-A.
MUCFH-GA50VB
OB381A--1.qxp 10.5.25 9:28 AM Page 1

2
TECHNICAL CHANGES
1
MUH-A12YV - ➔ MUCFH-GA35VB -
1. Indication of capacity has been changed. (BTU base ➔ kW)
MUCFH-A18WV - ➔ MUCFH-GA50VB -
1. Indication of capacity has been changed. (BTU base ➔ kW)
MUCFH-A24WV - ➔ MUCFH-GA60VB -
1. Indication of capacity has been changed. (BTU base ➔ kW)
E1E1
E1E1
E1E1
Refrigeration
oil
Refrigerant
New refrigerant
R410A
HFC-32: HFC-125 (50%:50%)
Pseudo-azeotropic refrigerant
Not included
A1/A1
72.6
-51.4
1.557
64
Non combustible
0
1730
From liquid phase in cylinder
Possible
Incompatible oil
Non
Non
Previous refrigerant
R22
R22 (100%)
Single refrigerant
Included
A1
86.5
-40.8
0.94
44.4
Non combustible
0.055
1700
Gas phase
Possible
Compatible oil
Light yellow
Non
Refrigerant
Composition (Ratio)
Refrigerant handling
Chlorine
Safety group (ASHRAE)
Molecular weight
Boiling point (:)
Steam pressure [25:](Mpa)
Saturated steam density [25:](Kg/K)
Combustibility
ODP w1
GWP w2
Refrigerant charge method
Additional charge on leakage
Kind
Color
Smell
w1 :Ozone Destruction Parameter : based on CFC-11
w2 :Global Warmth Parameter : based on CO2
INFORMATION FOR THE AIR CONDITIONER WITH R410A REFRIGERANT
•This room air conditioner adopts HFC refrigerant (R410A) which never destroys the ozone layer.
•Pay particular attention to the following points, though the basic installation procedure is same as that for R22 conditioners.
1As R410A has working pressure approximate 1.6 times as high as that of R22, some special tools and piping parts/
materials are required. Refer to the table below.
2Take sufficient care not to allow water and other contaminations to enter the R410A refrigerant during storage and
installation, since it is more susceptible to contaminations than R22.
3For refrigerant piping, use clean, pressure-proof parts/materials specifically designed for R410A. (Refer to 2. Refrigerant
piping.)
4Composition change may occur in R410A since it is a mixed refrigerant. When charging, charge liquid refrigerant to prevent
composition change.
Revision A :
•RoHS PARTS LIST has been added.
Revision B :
•The fan guard for MUCFH-GA 60VB- has been changed.
E1
OB381A--1.qxp 10.5.25 9:28 AM Page 2

3
NOTE : The unit of pressure has been changed to MPa on the international system of units(SI unit system).
The conversion factor is: 1(MPa [Gauge]) =10.2(kgf/ff[Gauge])
New Specification Current Specification
The incompatible refrigeration oil easily separates from
refrigerant and is in the upper layer inside the suction muffler.
Raising position of the oil back hole enables to back the
refrigeration oil of the upper layer to flow back to the
compressor.
Since refrigerant and refrigerating oil are compatible each,
refrigeration oil goes back to the compressor through the
lower position oil back hole.
Compressor
Suction muffler
Oil back hole
Refrigeration oil
Refrigerant
Compressor
Suction muffler
Oil back hole
Refrigeration oil /Refrigerant
Compressor
-30 -20 -10 0 10 20 30 40 50 60
-0.5
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
(MPa [Gauge])
R410A
R22
Conversion chart of refrigerant temperature and pressure
Saturated liquid pressure
(:)
NOTE : The unit of pressure has been changed to MPa on the
international system of units(SI unit system).
The conversion factor is: 1(MPa [Gauge]) =10.2(kgf/ff[Gauge])
R410A tools Can R22 tools be used?
Gas leak detector
R410A has high pressures beyond the measurement range of existing
gauges. Port diameters have been changed to prevent any other refrigerant
from being charged into the unit.
Hose material and cap size have been changed to improve the pressure
resistance.
Dedicated for HFC refrigerant.
6.35 mm and 9.52 mm
Description
Clamp bar hole has been enlarged to reinforce the spring strength in the tool.
Provided for flaring work (to be used with R22 flare tool).
Provided to prevent the back flow of oil. This adapter enables you to use
vacuum pumps.
It is difficult to measure R410A with a charging cylinder because the
refrigerant bubbles due to high pressure and high-speed vaporization
No
No
No
Yes
Yes
New
New
New
Gauge manifold
Charge hose
Torque wrench
Flare tool
Flare gauge
Vacuum pump
adapter
Electronic scale for
refrigerant charging
No : Not Substitutable for R410A Yes : Substitutable for R410A
No 12.7 mm and 15.88 mm
1.Tools dedicated for the air conditioner with R410A refrigerant
The following tools are required for R410A refrigerant. Some R22 tools can be substituted for R410A tools.
The diameter of the service port on the stop valve in outdoor unit has been changed to prevent any other refrigerant being
charged into the unit. Cap size has been changed from 7/16 UNF with 20 threads to 1/2 UNF with 20 threads.
OB381A--1.qxp 10.5.25 9:28 AM Page 3

4
R410A
Pipe diameter
mm
6.35
9.52
12.7
15.88
17
22
26
29
Dimension of flare nut
R22
17
22
24
27
2Flaring work and flare nut
Flaring work for R410A pipe differs from that for R22 pipe.
For details of flaring work, refer to Installation manual “FLARING WORK”.
Electronic scale for refrigerant charging
Outdoor unit
Refrigerant gas
cylinder
operating valve
Refrigerant gas cylinder
for R410A with siphon
Refrigerant (liquid)
Service port
Gauge manifold
valve (for R410A)
Union
Liquid pipe
Gas pipe
Stop valve
Indoor unit
Charge hose (for R410A)
3.Refrigerant oil
Apply the special refrigeration oil (accessories: packed with indoor unit) to the flare and the union seat surfaces.
4.Air purge
•Do not discharge the refrigerant into the atmosphere.
Take care not to discharge refrigerant into the atmosphere during installation, reinstallation, or repairs to the refrigerant
circuit.
•Use the vacuum pump for air purging for the purpose of environmental protection.
5.Additional charge
For additional charging, charge the refrigerant from liquid phase of the gas cylinder.
If the refrigerant is charged from the gas phase, composition change may occur in the refrigerant inside the cylinder and the
outdoor unit. In this case, ability of the refrigeration cycle decreases or normal operation can be impossible. However,
charging the liquid refrigerant all at once may cause the compressor to be locked. Thus, charge the refrigerant slowly.
2.Refrigerant piping
1Specifications
Use the refrigerant pipes that meet the following specifications.
•Use a copper pipe or a copper-alloy seamless pipe with a thickness of 0.8 mm (6.35, 9.52, 12.7), 1.0 mm (15.88).
Never use any pipe with a thickness less than 0.8 mm (6.35, 9.52, 12.7), 1.0 mm (15.88), as the pressure resistance is
insufficient.
Wall
thickness
Outside diameter
Pipe mm
For liquid
For gas
6.35
9.52
12.7
15.88
0.8 mm
0.8 mm
0.8 mm
1.0 mm
Heat resisting foam plastic
Specific gravity 0.045 Thickness 8 mm
Insulation material
OB381A--1.qxp 10.5.25 9:28 AM Page 4

5
PART NAMES AND FUNCTIONS
2
MUCFH-GA35VB
MUCFH-GA60VB
ACCESSORIES
Item
Drain socket
Drain cap [33
Drain cap [16
Q'ty
1
2
–
1
2
1
MUCFH-GA35VB MUCFH-GA50VB
1
2
–
MUCFH-GA60VB
Air inlet
Piping
Drain hose
Air outlet
Drain outlet
(back and side)
Air inlet
Piping
Drain hose
Air outlet
Drain outlet
(back and side)
Air inlet
Piping
Drain hose
Air outlet
Drain outlet
(back and side)
MUCFH-GA50VB
OB381A--1.qxp 10.5.25 9:28 AM Page 5

6
SPECIFICATION
3
Outdoor model
Function
Power supply
Capacity
Dehumidification
Air flow(High)
Power outlet
Running current
Power input
Power factor
Starting current
Compressor motor current
Fan motor current
Model
Output
Winding
resistance(at 20:)
Model
Winding
resistance(at 20:)
Dimensions WOHOD
Weight
Sound level(High)
Fan speed(High)
Fan speed regulator
Refrigerant filling
capacity(R410A)
Refrigeration oil (Model)
Thermistor RT61(at 0:)
kW
r/h
K/h
A
A
W
%
A
A
A
W
"
"
mm
kg
dB
rpm
kg
cc
k"
Single phase
230V, 50Hz
2,196
15
94
37
0.39
RN196VHSHT
1,300
C-R 1.80
C-S 3.00
RA6V50-PA
WHT-BLK 79.5
BLK-RED 83.0
850o605o290
47
52
828
1
1.85
520 (NEO22)
33.18
Cooling
4.8
2.4
8.01
1,730
7.62
2.65
Heating
5.0
—
8.38
1,810
7.99
2.65
Single phase
230V, 50Hz
2,760
25
98
74
0.58
NN29VBAHT
1,900
C-R 0.80
C-S 1.64
RA6V85-DA
WHT-BLK 68.8
BLK-RED 93.1
840o850o330
74
53
730
1
2.20
1,200 (NEO22)
33.18
Cooling
6.0
3.1
10.51
2,370
9.93
2.45
Heating
6.8
—
11.71
2,640
11.13
2.50
Electrical data
Compressor
Fan motor
Special remarks
Coefficient of performance(C.O.P)
Capacity
Single phase
230V, 50Hz
1,710
10
98
29
0.31
RN135VHSHT
900
C-R 2.79
C-S 3.36
RA6V33-JB
WHT-BLK 215.1
BLK-RED 306.9
780o540o255
40
49
825
1
1.00
620 (NEO22)
33.18
Cooling
3.5
1.5
4.85
1,094
4.54
3.02
Heating
3.7
—
4.23
954
3.92
3.63
MUCFH-GA35VB MUCFH-GA50VB MUCFH-GA60VB
NOTE: Test conditions are based on ISO 5151.
Cooling : Indoor DB27°C WB19°C Heating : Indoor DB20°C WB 15.5°C
Outdoor DB35°C WB(24°C) Outdoor DB 7°C WB 6°C
Indoor-Outdoor piping length : 5m
OB381A--1.qxp 10.5.25 9:28 AM Page 6

7
NOISE CRITERIA CURVES
4
MUCFH-GA50VB
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
FUNCTION
COOLING
HEATING
52
SPL(dB(A))LINE
Test conditions,
Cooling : Dry-bulb temperature 35: Wet-bulb temperature (24:)
Heating : Dry-bulb temperature 7: Wet-bulb temperature 6:
MUCFH-GA60VB
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
FUNCTION
COOLING
HEATING
53
SPL(dB(A))LINE
Test conditions,
Cooling : Dry-bulb temperature 35: Wet-bulb temperature (24:)
Heating : Dry-bulb temperature 7: Wet-bulb temperature 6:
OUTDOORUNIT
MICROPHONE
1m
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
APPROXIMATE
TERESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
Test conditions,
Cooling : Dry-bulb temperature 35: Wet-bulb temperature (24:)
Heating : Dry-bulb temperature 7: Wet-bulb temperature 6:
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
MUCFH-GA35VB
FUNCTION
COOLING
HEATING
49
SPL(dB(A))LINE
OB381A--1.qxp 10.5.25 9:28 AM Page 7

8
OUTLINES AND DIMENSIONS
5
MUCFH-GA35VB
320
25
43-
35-
155
90
104
74
260
10
780
500
122
40
540
320 285 255
Service panel
Gas refrigerant
pipe joint
Refrigerant pipe
(flared) [12.7
Liquid refrigerant
pipe joint
Refrigerant pipe
(flared) [6.35
Air out
Air in
Air in
109 32
110
147
Drainage
3 holes [33
100mm or more
100mm or more
100mm or more
350mm or more
REQUIRED SPACE
400mm or more
Unit: mm
100mm or more
100mm or more
100mm or more
350mm or more
500mmor more
REQUIRED SPACE
MUCFH-GA50VB
Drainage
3 holes [33 Air out
Air in
Air in
Service panel
Liquid refrigerant
pipe joint
Refregerant pipe
(flared) [6.35
Gas refregerant
pipe joint
Refregerant pipe
(flared) [12.7
35-
30-
30
100
161
157
74
850
500
183
20 292
605 248
35
350
50
290
310 345
20
355
90
Drainage
hole [16.2
OB381A--1.qxp 10.5.25 9:28 AM Page 8

9
MUCFH-GA60VB
30-
35-
155
90
198
40
515
299
66
34
51
330
360
850
430
500
80
121
840
Open as a rule
500mm or more if
the front and both
sides are open
100mm or more
200mm or more if
there are obstacles
to both sides
Open as a rule
500mm or more if the back,
both sides and top are open 350mm or more
100mm or more
Liquid refrigerant
pipe joint
Refrigerant pipe
(flared) [6.35
Service panel
Gas refrigerant
pipe joint
Refrigerant pipe
(flared) [15.88
REQUIRED SPACE
Unit: mm
OB381A--1.qxp 10.5.25 9:28 AM Page 9

10
WIRING DIAGRAM6
MUCFH-GA35VB
SYMBOL
T61
TB1,TB2
21S4
52C
SYMBOL
MF
NR61
RT61
SR61,SR62
SYMBOL
C1
C65
DSAR
F61
MC
NAME NAME NAME
COMPRESSOR CAPACITOR
OUTDOOR FAN CAPACITOR
SURGE ABSORBER
FUSE(2A)
COMPRESSOR(INNER PROTECTOR)
VARISTOR
DEFROST THERMISTOR
SOLID STATE RELAY
TRANSFORMER
TERMINAL BLOCK
R.V. COIL
COMPRESSOR CONTACTOR
OUTDOOR FAN MOTOR
(INNER FUSE)
MC
CN661
3
1
2CN721
21S4
MF
SR62
SR61
TAB20
GRN/YLW
BLU
CIRCUIT BREAKER
POWER SUPPLY
BLU
BRN
DSAR
BLK
BRN
RED
DEICER P.C.BOARD
4
C1
BLK
RED
3
WHT
S
C
R
CN730
RT61
BLK
2
3
1
RED
WHT
12V
TO
CONNECTING
INDOOR UNIT
TB2
3
N
TB1
L
N
PE
~/N
NR61
F61
T61 C65
CN711
52C
230V 50Hz
NOTE:1. About the indoor side electric wiring refer to the indoor unit electric wiring diagram for servicing.
2. Use copper conductors only. (For field wiring)
3. Symbols below indicate.
/: Terminal block, : Connector
MUCFH-GA50VB
MC
CN661
3
1
2
CN721
21S4
MF
SR62
SR61
TAB20
GRN/YLW
BLU
CIRCUIT BREAKER
POWER SUPPLY BLU
BRN
DSAR
BLK
BRN
RED
DEICER P.C.BOARD
4
C1
BLK
RED
3
WHT
S
C
R
CN730
RT61
BLK
2
3
1
RED
WHT
12V
TO
CONNECTING
INDOOR UNIT
TB2
3
N
TB1
L
N
PE
~ /N
NR61
F61
T61
C65
CN711
52C
230V 50Hz
234
WHT
BLK RED ORN
1
1.About the indoor side electric wiring refer to the indoor unit electric wiring diagram for servicing.
2.Use copper conductors only. (For field wiring)
3.Symbols below indicate.
: Connector
: Terminal block
NOTES:
SYMBOL
C1
C65
DSAR
F61
MC
NAME
COMPRESSOR CAPACITOR
OUTDOOR FAN CAPACITOR
SURGE ABSORBER
FUSE (2A)
COMPRESOR (INNER PROTECTOR)
SYMBOL
MF
NR61
RT61
SR61,SR62
T61
NAME
OUTDOOR FAN MOTOR (INNER PROTECTOR)
VARISTOR
DEFROST THERMISTOR
SOLID STATE RELAY
TRANSFORMER
SYMBOL
TB1,TB2
21S4
52C
NAME
TERMINAL BLOCK
R.V. COIL
COMPRESSOR CONTACTOR
OB381A--1.qxp 10.5.25 9:28 AM Page 10
