TECHNICAL & SERVICE MANUAL
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
CONTENTS
1. TECHNICAL CHANGES................................... 2
2. SAFETY PRECAUTION....................................2
3. OVERVIEW OF UNITS...................................... 5
4. SPECIFICATIONS.............................................7
5. DATA.................................................................. 8
6. OUTLINES AND DIMENSIONS...................... 18
7. WIRING DIAGRAM......................................... 20
8. NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION..... 22
9. TROUBLESHOOTING.................................... 32
10. ELECTRICAL WIRING.................................... 75
11. REFRIGERANT PIPING TASKS..................... 78
12. DISASSEMBLY PROCEDURE....................... 82
13. PARTS LIST.....................................................87
14. RoHS PARTS LIST..........................................90
15. OPTIONAL PARTS..........................................95
OUTDOOR UNIT
No. OC376
REVISED EDITION-C
[Service Ref.]
PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
PUMY-P100VHMA
PUMY-P125VHMA
PUMY-P140VHMA
PUMY-P100VHMA-BS
PUMY-P125VHMA-BS
PUMY-P140VHMA-BS
HFC
utilized
R410A
Model name
indication
June 2008
NOTE :
· This service manual describes technical data of outdoor unit.
As for indoor units, refer to its service manual.
· RoHS compliant products have <G> mark on the spec name plate.
· For servicing of RoHS compliant products, refer to the RoHS PARTS LIST.
[Model name]
<Outdoor unit>
PUMY-P100VHM
PUMY-P125VHM
PUMY-P140VHM
PUMY-P100VHMA
PUMY-P125VHMA
PUMY-P140VHMA
PUMY-P100VHMA-BS
PUMY-P125VHMA-BS
PUMY-P140VHMA-BS
Revision:
· PUMY-P100/125/140
VHMA-BS are added in
REVISED EDITION-C.
· Some descriptions have
been modified.
· Please void OC376
REVISED EDITION-B

2
2SAFETY PRECAUTION
Cautions for units utilizing refrigerant R410A
2-1. CAUTIONS RELATED TO NEW REFRIGERANT
Use new refrigerant pipes.
Make sure that the inside and outside of refrige-
rant piping are clean and it has no contamination
such as sulfur hazardous for use, oxides, dirt,
shredded particles, etc.
In addition, use pipes with specified thickness.
Store the piping to be used during installation
indoors and keep both ends of the piping sealed
until just before brazing. (Leave elbow joints, etc.
in their packaging.)
Use ester oil, ether oil or alkylbenzene oil (small
amount) as the refrigerant oil applied to flares
and flange connections.
Avoid using thin pipes.
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition
change may occur in refrigerant and the efficiency will be
lowered.
Do not use refrigerant other than R410A.
If other refrigerant (R22 etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil etc.
Use a vacuum pump with a reverse flow check
valve.
Vacuum pump oil may flow back into refrigerant cycle and
that can cause deterioration of refrigerant oil etc.
Use the following tools specifically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A refrigerant.
Keep the tools with care.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the efficiency will be lowered.
Flare tool
Electronic refrigerant
charging scale
Vacuum pump adaptor
Size adjustment gauge
Gauge manifold
Torque wrench
Gas leak detector
Charge hose
Tools for R410A
Contamination inside refrigerant piping can cause deterio-
ration of refrigerant oil etc.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
If large amount of mineral oil enters, that can cause deterio-
ration of refrigerant oil etc.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
PUMY-P100VHM PUMY-P100VHMA
PUMY-P125VHM PUMY-P125VHMA
PUMY-P140VHM PUMY-P140VHMA
Compressor(MC) and oil have been changed.
ANB33FDCMT ANB33FDHMT
Ester oil Ether oil
Electrical parts below have been changed.
1Controller board (MULTI.B.) 2Noise filter circuit board (N.F.)
3Active filter module(ACTM) 4Relay(52C), Resister(RS)(Including N.F.)
PEFY-P15 can be connected.
1TECHNICAL CHANGES

3
Gravimeter
Unit
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
No. Tool name Specifications
1Gauge manifold ·Only for R410A
·Use the existing fitting specifications. (UNF1/2)
·Use high-tension side pressure of 5.3MPa·G or over.
2Charge hose ·Only for R410A
·Use pressure performance of 5.09MPa·G or over.
3Electronic scale
4Gas leak detector ·Use the detector for R134a, R407C or R410A.
5Adaptor for reverse flow check ·Attach on vacuum pump.
6Refrigerant charge base
7Refrigerant cylinder ·Only for R410A ·Top of cylinder (Pink)
·Cylinder with syphon
8Refrigerant recovery equipment
[1] Cautions for service
(1) Perform service after recovering the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) When performing service, install a filter drier simultaneously.
Be sure to use a filter drier for new refrigerant.
[2] Additional refrigerant charge
When charging directly from cylinder
· Check that cylinder for R410A on the market is syphon type.
· Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)
Although "-BS" model has been designed to be resistant to salt damage,observe the following precautions to maintain the
performance of the unit.
1. Avoid installing the uint in a location where it will be exposed directly to seawater or sea breeze.
2. If the cover panel may become covered with salt, be sure to install the unit in a location where the salt will be washed away by
rainwater. (If a sunshade is installed, rainwater may not clean the panel.)
3. To ensure that water does not collect in the base of the outdoor unit, make sure that the base is level, not at angle. Water
collecting in the base of the outdoor unit could cause rust.
4. If the unit is installed in a coastal area, clean the unit with water regularly to remove any salt buil-up.
5. If the unit is damaged during installation or maintenance, be sure to repair it.
6. Be sure to check the condition of the unit regularly.
7. Be sure to install the unit in a location with good drainage.
2-2. PRECAUTIONS FOR SALT PROOF TYPE "-BS" MODEL

4
Cautions for refrigerant piping work
New refrigerant R410A is adopted for replacement inverter series. Although the refrigerant piping work for R410A is same
as for R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the working
pressure of R410A is 1.6 time higher than that of R22, their sizes of flared sections and flare nuts are different.
1Thickness of pipes
Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness
shown below. (Never use pipes of 0.7mm or below.)
2Dimensions of flare cutting and flare nut
The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that,
R410A is a refrigerant, which has higher risk of leakage because its working pressure is higher than that of other refriger-
ants. Therefore, to enhance airtightness and intensity, flare cutting dimension of copper pipe for R410A have been speci-
fied separately from the dimensions for other refrigerants as shown below. The dimension B of flare nut for R410A also
have partly been changed to increase intensity as shown below. Set copper pipe correctly referring to copper pipe flaring
dimensions for R410A below. For 1/2 and 5/8 inch, the dimension B changes. Use torque wrench corresponding to each
dimension.
3Tools for R410A (The following table shows whether conventional tools can be used or not.)
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
0.8
0.8
0.8
1.0
—
0.8
0.8
0.8
1.0
1.0
Nominal
dimensions(inch)
Diagram below: Piping diameter and thickness
Outside
diameter (mm)
Thickness (mm)
R410A R22
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
9.1
13.2
16.6
19.7
—
9.0
13.0
16.2
19.4
23.3
Nominal
dimensions(inch)
Flare cutting dimensions
Outside
diameter
Dimension A ( )
+0
-0.4
(mm)
R410A R22
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
17.0
22.0
26.0
29.0
—
17.0
22.0
24.0
27.0
36.0
Nominal
dimensions(inch)
Flare nut dimensions
Outside
diameter
Dimension B
(mm)
R410A R22
Gauge manifold
Charge hose
Gas leak detector
Refrigerant recovery equipment
Refrigerant cylinder
Applied oil
Safety charger
Charge valve
Vacuum pump
Flare tool
Bender
Pipe cutter
Welder and nitrogen gas cylinder
Refrigerant charging scale
Vacuum gauge or thermis-
tor vacuum gauge and
vacuum valve
Charging cylinder
Air purge, refrigerant charge
and operation check
Gas leak check
Refrigerant recovery
Refrigerant charge
Apply to flared section
Prevent compressor malfunction
when charging refrigerant by
spraying liquid refrigerant
Prevent gas from blowing out
when detaching charge hose
Vacuum drying and air
purge
Flaring work of piping
Bend the pipes
Cut the pipes
Weld the pipes
Refrigerant charge
Check the degree of vacuum. (Vacuum
valve prevents back flow of oil and refri-
gerant to thermistor vacuum gauge)
Refrigerant charge
Tool exclusive for R410A
Tool exclusive for R410A
Tool for HFC refrigerant
Tool exclusive for R410A
Tool exclusive for R410A
Ester oil, ether oil and
alkylbenzene oil (minimum amount)
Tool exclusive for R410A
Tool exclusive for R410A
Tools for other refrigerants can
be used if equipped with adop-
ter for reverse flow check
Tools for other refrigerants
can be used by adjusting
flaring dimension
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants
can be used
Tool exclusive for R410A
Tools and materials Use R410A tools Can R22 tools be used?
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
Can R407C tools be used?
Ester oil, ether oil:
Alkylbenzene oil: minimum amount
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.)
: Tools for other refrigerants can be used under certain conditions.
: Tools for other refrigerants can be used.
Dimension A
Dimension B

5
Branching pipe
components Branch header
(2 branches)
Branch header
(4 branches)
Branch header
(8 branches)
CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
Outdoor unit
Capacity
50% ~130% of outdoor unit capacity *2
Type 15(VHMA)/20(VHM) ~Type 140
1~ 8 unit
Indoor
unit that
can be
connected
Number of units
Total system wide capacity
5HP
PUMY-P125VHM
PUMY-P125VHMA
PUMY-P125VHMA-BS
6HP
PUMY-P140VHM
PUMY-P140VHMA
PUMY-P140VHMA-BS
Type 15(VHMA)/20(VHM) ~ Type 125
1~ 6 unit
4HP
PUMY-P100VHM
PUMY-P100VHMA
PUMY-P100VHMA-BS
3OVERVIEW OF UNITS
3-1. UNIT CONSTRUCTION
15
20
25
32
40
50
63
71
80
100
125
140
–
20VCM-E
25VCM-E
32VCM-E/32VBM-E
40VCM-E/40VBM-E
50VBM-E
63VBM-E
–
80VBM-E
100VBM-E
125VBM-E
–
–
20VLMD-E
25VLMD-E
32VLMD-E
40VLMD-E
50VLMD-E
63VLMD-E
–
80VLMD-E
100VLMD-E
125VLMD-E
–
15VMS/(L)-E
20VML-E / VMM-E
25VML-E / VMM-E
32VML-E / VMM-E
40VMH-E / VMM-E
50VMH-E / VMM-E
63VMH-E / VMM-E
71VMH-E / VMM-E
80VMH-E / VMM-E
100VMH-E / VMM-E
125VMH-E / VMM-E
140VMM-E
–
20VM-E
25VM-E
32VM-E
40VM-E
50VM-E
63VM-E
71VM-E
80VM-E
100VM-E
125VM-E
–
–
20VBM-E
25VBM-E
32VGM-E
40VGM-E
50VGM-E
–
–
–
–
–
–
–
20VLEM-E
25VLEM-E
32VLEM-E
40VLEM-E
50VLEM-E
63VLEM-E
–
–
–
–
–
–
20VLRM-E
25VLRM-E
32VLRM-E
40VLRM-E
50VLRM-E
63VLRM-E
–
–
–
–
–
–
–
–
–
40VGM-E
–
63VGM-E
–
–
100VGM-E
125VGM-E
–
PLFY-P PLFY-P PEFY-P PDFY-P PKFY-P PCFY-P PFFY-P PFFY-P
–
–
–
–
–
–
–
–
80VMH-E-F
–
–
140VMH-E-F
PEFY-P
Capacity
Model
Cassette Ceiling
4-way flow 2-way flow
–
20VBM-E
25VBM-E
32VBM-E
40VBM-E
–
–
–
–
–
–
–
PMFY-P
1-way flow
Ceiling
Concealed
Ceiling
mounted
built-in
Ceiling
Suspended
Ceiling
Concealed
(Fresh Air) *1
Wall
Mounted
Floor standing
Exposed Concealed
Remote
controller
Name
Model number
Functions
M-NET remote controller
PAR-F27MEA-E
• A handy remote controller for use in conjunction
with the Melans centralized management system.
• Addresses must be set.
• Addresses setting is not necessary.
MA remote controller
PAR-21MAA
*1. It is possible only by 1:1 system.
(1 indoor unit of Fresh Air type is connected with 1 outdoor unit.)
Operating temperature range (outdoor temperature) for fresh air type indoor units differ from other indoor units.
Refer to 3-2(3).
*2. When the indoor unit of Fresh Air type is connected with the outdoor unit, the maximum connectable total indoor unit
capacity is 110%(100% in case of heating below -5:(23˚F)).
Decorative panel

6
3-2. UNIT SPECIFICATIONS
(2) Method for identifying MULTI-S model
(1) Outdoor Unit
Indoor unit < When using Model 80 > Outdoor unit <When using model 125 >
(3) Operating temperature range
Notes D.B. : Dry Bulb Temperature
W.B. : Wet Bulb Temperature
w1. 10~46°C DB : In case of connecting PKFY-P20/P25 type indoor unit.
P L F Y - P 80 V BM - E PU M Y - P 125 V H M A - BS
PAC type
AM
BM
KM
M
KM
LMD
Frequency
conversion
controller
Refrigerant
R407C/R22
R410A
commonness
Refrigerant
R410A
NEW frequency converter
one-to-many air conditioners
(flexible design type)
Indicates equivalent
to Cooling capacity
(k cal / h)
Indicates equivalent
to Cooling capacity
(k cal / h)
Power supply
V: Single phase
220-230-240V 50Hz
220V 60Hz
Power supply
V: 1-phase
220-230-240V : 50Hz
220V : 60Hz
L : Ceiling cassette
K : Wall-mounted type
E : Hidden skylight type
C : Ceiling suspended type
M: Ceiling cassette type
F : Floor standing type
}
M-NET
control
Outdoor unit
model type
Sub-number Sub-number
M-NET control
Frequency
conversion
controller
Outdoor unit
MULTI-S
Salt proof type
Cooling
W.B. 15~24°C
D.B. -5~46°C +1
Heating
D.B. 15~27°C
W.B. -15~15°C
Indoor-side intake air temperature
Outdoor-side intake air temperature
Cooling / Heating capacity indicates the maximum value at operation under the following condition.
w. Cooling Indoor : D.B. 27°C / W.B. 19.0°C
Outdoor : D.B. 35°C
Heating Indoor : D.B. 20°C
Outdoor : D.B. 7°C / W.B. 6°C
■In case of connecting fresh air type indoor unit
air type indoor
Capacity of Fresh
Cooling Heating
Indoor-side and Outdoor-side P80 D.B.21~43+2
W.B.15.5~35D.B.-10~20+3
intake air temperature P140 D.B.21~43+2
W.B.15.5~35D.B.-5~20+3
+2.Thermo-off(FAN-mode) automatically starts if the outdoor temp. is lower than 21D.B..
+3.Thermo-off(FAN-mode) automatically starts if the outdoor temp. is higher than 20D.B..
Service Ref.
Capacity Cooling (kW)
Heating (kW)
PUMY-P140VHM
PUMY-P140VHMA
PUMY-P140VHMA-BS
15.5
18.0
3.3
PUMY-P125VHM
PUMY-P125VHMA
PUMY-P125VHMA-BS
14.0
16.0
2.9
PUMY-P100VHM
PUMY-P100VHMA
PUMY-P100VHMA-BS
11.2
12.5
2.2Motor for compressor (kW)

7
4 SPECIFICATIONS
*3
*3
*3
*3
*3
*3
*3
*3
PUMY-P125VHM
PUMY-P125VHMA
PUMY-P125VHMA-BS
Cooling Capacity kW 14.0
Heating Capacity kW 16.0
Input (Cool) kW 4.32
Input Current (Cool) A
20.0/19.1/18.3, 20.0
Input (Heat) kW 4.33
Input Current (Heat) A
20.0/19.1/18.3, 20.0
EER (Cool) 3.24
COP (Heat) 3.69
Connectable indoor units (Max.) 8
Max. Connectable Capacity kW 18.2 (130%)
Power Supply Single phase , 50Hz 220/230/240V, 60Hz 220V
Breaker Size 32A
Sound level (Cool/Heat) dB 50 / 52
External finish Munsell 3Y 7.8/1.1
Refrigerant control Linear Expansion Valve
Compressor Hermetic
VHM:ANB33FDCMT, VHMA:ANB33FDHMT
Model
Motor output kW 2.9
Starting method Inverter
Crankcase heater W —
Heat exchanger Plate fin coil (Anti corrosion fin treatment)
Fan Fan (drive) %No. Propeller fan %2
Fan motor output kW 0.060 + 0.060
Airflow m3/min(CFM) 100 (3,530)
Dimensions (HxWxD) W mm(in.) 950(37-3/8)
D mm(in.) 330+30(13+1-3/16)
H mm(in.) 1,350(53-1/8)
Weight kg(lbs) 127(280)
Refrigerant R410A
Charge kg(lbs) 8.5 (18.7)
Protection High pressure protection HP switch
devices Compressor protection Discharge thermo, Over current detection
Fan motor protection Overheating/Voltage protection
Oil (Model) 2.3 (VHM:MEL56, VHMA:FV50S)
Total Piping length (Max.) m
L
120
Farthest m 80
Max. Height difference m 30
Chargeless length m 50
Piping diameter Gas :mm(in) 15.88 (5/8)
Liquid :mm(in) 9.52 (3/8)
Guaranteed operation range (cool) -5~ 46DB
(heat) -15~ 15WB
*1
*2
Power factor (Cool)
Power factor (Heat)
%
%
98.4
98.5
PUMY-P100VHM
PUMY-P100VHMA
PUMY-P100VHMA-BS
11.2
12.5
3.34
15.4/14.8/14.1, 15.4
3.66
16.9/16.2/15.5,16.9
3.35
3.42
6
14.5 (130%)
49 / 51
2.2
98.4
98.4
PUMY-P140VHM
PUMY-P140VHMA
PUMY-P140VHMA-BS
15.5
18.0
5.35
24.7/23.6/22.7,24.7
5.58
25.8/24.7/23.6,25.8
2.90
3.23
8
20.2 (130%)
51 / 53
3.3
98.4
98.4
Rating conditions (JIS B 8616)
Cooling Indoor : D.B. 27:/ W.B. 19:
Outdoor : D.B. 35:/ W.B. 20:
Heating Indoor : D.B. 20:
Outdoor : D.B. 7:/ W.B. 6:
Note. *1. 20m :In case of installing outdoor unit lower than indoor
unit.
*2. 10~46:DB :In case of connecting PKFY-P20/P25 type indoor
unit.
*3. Electrical data is for only outdoor unit.

8
5DATA
5-1. COOLING AND HEATING CAPACITY AND CHARACTERISTICS
5-1-1. Method for obtaining system cooling and heating capacity:
To obtain the system cooling and heating capacity and the electrical characteristics of the outdoor unit, first add up the ratings
of all the indoor units connected to the outdoor unit (see table below), and then use this total to find the standard capacity with
the help of the tables on 5-2.STANDARD CAPACITY DIAGRAM.
(1) Capacity of indoor unit
5-1-2. Method for obtaining the heating and cooling capacity of an indoor unit:
(1) The capacity of each indoor unit (kW) = the capacity A (or B) o
(2) Sample calculation (using the system described above in 5-1-1. (2) ):
model capacity
total model capacity of all indoor units
During cooling: During heating:
• The total model capacity of the indoor unit is:
2.8 o2 + 5.6 o2=16.8kW
Therefore, the capacity of PKFY-P25VAM-E and
PLFY-P50VLMD-E will be calculated as follows by
using the formula in 5-1-2. (1):
Model 25=14.6 o= 2.43kW
Model 50=14.6 o= 4.87kW
• The total model capacity of indoor unit is:
3.2 o2 + 6.3 o2=19.0
Therefore, the capacity of PKFY-P25VAM-E and PLFY-
P50VLMD-E will be calculated as follows by using the
formula in 5-1-2. (1):
Model 25=16.33 o= 2.75kW
Model 50=16.33 o= 5.41kW
2.8
16.8
5.6
16.8
6.3
19.0
3.2
19.0
(2) Sample calculation
1System assembled from indoor and outdoor unit (in this example the total capacity of the indoor units is greater than that of
the outdoor unit)
Outdoor unit PUMY-P125VHM
Indoor unit PKFY-P25VAM-E o2 , PLFY-P50VLMD-E o2
2According to the conditions in 1, the total capacity of the indoor unit will be: 28 o2 + 56 o2 = 168
3The following figures are obtained from the 168 total capacity row of 5-2. STANDARD CAPACITY DIAGRAM :
Model 20
Model Number for indoor unit
Model Capacity 22
Model 15
17
Model 25
28
Model 32
36
Model 40
45
Model 50
56
Model 63
71
Model 71
80
Model 80
90
Model 100
112
Model 125
140
Model 140
160
Cooling
A 14.60
Heating
17.6
Cooling
19.4
Heating
3.99
Cooling
4.39
Heating
B 16.33
Capacity (kW) Outdoor unit power consumption (kW) Outdoor unit current (A)/230V

9
5-2. STANDARD CAPACITY DIAGRAM
5-2-1. PUMY-P100VHM PUMY-P100VHMA( -BS)
*Before calculating the sum of total capacity of indoor units, please convert the value into the kW model capacity
following the formula on 5-1-1.
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/220V Current(A)/230V Current(A)/240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
56 5.60 6.30 1.37 1.79 6.3 8.3 6.1 7.9 5.8 7.6
57 5.70 6.41 1.39 1.82 6.4 8.4 6.2 8.1 5.9 7.7
58 5.80 6.53 1.42 1.85 6.6 8.6 6.3 8.2 6.0 7.8
59 5.90 6.64 1.44 1.88 6.7 8.7 6.4 8.3 6.1 8.0
60 6.00 6.75 1.46 1.91 6.8 8.8 6.5 8.4 6.2 8.1
61 6.10 6.87 1.49 1.94 6.9 9.0 6.6 8.6 6.3 8.2
62 6.20 6.98 1.51 1.97 7.0 9.1 6.7 8.7 6.4 8.4
63 6.30 7.09 1.54 2.00 7.1 9.2 6.8 8.8 6.5 8.5
64 6.40 7.20 1.56 2.03 7.2 9.4 6.9 9.0 6.6 8.6
65 6.50 7.32 1.59 2.06 7.4 9.5 7.0 9.1 6.7 8.7
66 6.60 7.43 1.62 2.09 7.5 9.7 7.2 9.2 6.9 8.9
67 6.70 7.54 1.64 2.12 7.6 9.8 7.3 9.4 7.0 9.0
68 6.80 7.66 1.67 2.15 7.7 9.9 7.4 9.5 7.1 9.1
69 6.90 7.77 1.70 2.18 7.9 10.1 7.5 9.6 7.2 9.2
70 7.00 7.88 1.73 2.22 8.0 10.3 7.7 9.8 7.3 9.4
71 7.10 8.00 1.76 2.25 8.1 10.4 7.8 10.0 7.5 9.5
72 7.20 8.11 1.79 2.28 8.3 10.5 7.9 10.1 7.6 9.7
73 7.30 8.22 1.82 2.31 8.4 10.7 8.1 10.2 7.7 9.8
74 7.40 8.33 1.85 2.34 8.6 10.8 8.2 10.3 7.8 9.9
75 7.50 8.44 1.88 2.37 8.7 11.0 8.3 10.5 8.0 10.0
76 7.60 8.56 1.91 2.41 8.8 11.1 8.4 10.7 8.1 10.2
77 7.70 8.67 1.94 2.44 9.0 11.3 8.6 10.8 8.2 10.3
78 7.80 8.78 1.97 2.47 9.1 11.4 8.7 10.9 8.4 10.5
79 7.90 8.89 2.00 2.50 9.2 11.6 8.8 11.1 8.5 10.6
80 8.00 9.00 2.04 2.54 9.4 11.7 9.0 11.2 8.6 10.8
81 8.10 9.10 2.07 2.57 9.6 11.9 9.2 11.4 8.8 10.9
82 8.20 9.20 2.10 2.60 9.7 12.0 9.3 11.5 8.9 11.0
83 8.30 9.30 2.14 2.64 9.9 12.2 9.5 11.7 9.1 11.2
84 8.40 9.40 2.17 2.67 10.0 12.3 9.6 11.8 9.2 11.3
85 8.50 9.50 2.21 2.70 10.2 12.5 9.8 11.9 9.4 11.4
86 8.60 9.60 2.24 2.74 10.4 12.7 9.9 12.1 9.5 11.6
87 8.70 9.70 2.28 2.77 10.5 12.8 10.1 12.2 9.7 11.7
88 8.80 9.80 2.32 2.80 10.7 12.9 10.3 12.4 9.8 11.9
89 8.90 9.90 2.35 2.84 10.9 13.1 10.4 12.6 10.0 12.0
90 9.00 10.00 2.39 2.87 11.1 13.3 10.6 12.7 10.1 12.2
91 9.10 10.10 2.43 2.91 11.2 13.5 10.7 12.9 10.3 12.3
92 9.20 10.22 2.47 2.94 11.4 13.6 10.9 13.0 10.5 12.5
93 9.30 10.33 2.50 2.97 11.6 13.7 11.1 13.1 10.6 12.6
94 9.40 10.45 2.54 3.01 11.7 13.9 11.2 13.3 10.8 12.8
95 9.50 10.56 2.58 3.04 11.9 14.1 11.4 13.4 10.9 12.9
96 9.60 10.67 2.62 3.08 12.1 14.2 11.6 13.6 11.1 13.1
97 9.70 10.79 2.66 3.11 12.3 14.4 11.8 13.8 11.3 13.2
98 9.80 10.90 2.70 3.15 12.5 14.6 11.9 13.9 11.4 13.3
99 9.90 11.02 2.75 3.19 12.7 14.7 12.2 14.1 11.7 13.5
100 10.00 11.13 2.79 3.22 12.9 14.9 12.3 14.2 11.8 13.6
101 10.10 11.24 2.83 3.26 13.1 15.1 12.5 14.4 12.0 13.8
102 10.20 11.36 2.87 3.29 13.3 15.2 12.7 14.5 12.2 13.9
103 10.30 11.47 2.91 3.33 13.5 15.4 12.9 14.7 12.3 14.1
104 10.40 11.59 2.96 3.36 13.7 15.5 13.1 14.9 12.5 14.2
105 10.50 11.70 3.00 3.40 13.9 15.7 13.3 15.0 12.7 14.4
106 10.60 11.81 3.05 3.44 14.1 15.9 13.5 15.2 12.9 14.6
107 10.70 11.93 3.09 3.47 14.3 16.0 13.7 15.3 13.1 14.7
108 10.80 12.04 3.14 3.51 14.5 16.2 13.9 15.5 13.3 14.9
109 10.90 12.16 3.18 3.55 14.7 16.4 14.1 15.7 13.5 15.0
110 11.00 12.27 3.23 3.59 14.9 16.6 14.3 15.9 13.7 15.2

10
Total capacity of Capacity(kW)
Power Consumption(kW) Current(A)/220V Current(A)/230V Current(A)/240V
indoor units* Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating
111 11.10 12.38 3.27 3.62 15.1 16.7 14.5 16.0 13.9 15.3
112 11.20 12.50 3.34 3.66 15.4 16.9 14.8 16.2 14.1 15.5
113 11.22 12.51 3.35 3.65 15.5 16.9 14.8 16.1 14.2 15.5
114 11.24 12.53 3.35 3.64 15.5 16.8 14.8 16.1 14.2 15.4
115 11.26 12.54 3.36 3.63 15.5 16.8 14.9 16.0 14.2 15.4
116 11.28 12.55 3.36 3.62 15.5 16.7 14.9 16.0 14.2 15.3
117 11.30 12.56 3.36 3.61 15.5 16.7 14.9 16.0 14.2 15.3
118 11.32 12.57 3.37 3.59 15.6 16.6 14.9 15.9 14.3 15.2
119 11.34 12.58 3.37 3.58 15.6 16.5 14.9 15.8 14.3 15.2
120 11.36 12.60 3.38 3.57 15.6 16.5 14.9 15.8 14.3 15.1
121 11.38 12.61 3.38 3.56 15.6 16.5 14.9 15.7 14.3 15.1
122 11.40 12.62 3.38 3.55 15.6 16.4 14.9 15.7 14.3 15.0
123 11.42 12.63 3.39 3.54 15.7 16.4 15.0 15.7 14.4 15.0
124 11.44 12.64 3.39 3.52 15.7 16.3 15.0 15.6 14.4 14.9
125 11.47 12.66 3.40 3.51 15.7 16.2 15.0 15.5 14.4 14.9
126 11.49 12.67 3.40 3.50 15.7 16.2 15.0 15.5 14.4 14.8
127 11.51 12.68 3.40 3.49 15.7 16.1 15.0 15.4 14.4 14.8
128 11.53 12.69 3.41 3.48 15.8 16.1 15.1 15.4 14.4 14.7
129 11.55 12.70 3.41 3.47 15.8 16.0 15.1 15.3 14.4 14.7
130 11.57 12.71 3.42 3.45 15.8 15.9 15.1 15.3 14.5 14.6
131 11.59 12.73 3.42 3.44 15.8 15.9 15.1 15.2 14.5 14.6
132 11.61 12.74 3.42 3.43 15.8 15.9 15.1 15.2 14.5 14.5
133 11.63 12.75 3.43 3.42 15.9 15.8 15.2 15.1 14.5 14.5
134 11.65 12.76 3.43 3.41 15.9 15.8 15.2 15.1 14.5 14.4
135 11.67 12.77 3.44 3.40 15.9 15.7 15.2 15.0 14.6 14.4
136 11.69 12.78 3.44 3.38 15.9 15.6 15.2 14.9 14.6 14.3
137 11.71 12.80 3.45 3.37 15.9 15.6 15.3 14.9 14.6 14.3
138 11.73 12.81 3.45 3.36 15.9 15.5 15.3 14.9 14.6 14.2
139 11.75 12.82 3.45 3.35 15.9 15.5 15.3 14.8 14.6 14.2
140 11.77 12.83 3.46 3.34 16.0 15.4 15.3 14.8 14.7 14.2
141 11.79 12.84 3.46 3.32 16.0 15.3 15.3 14.7 14.7 14.1
142 11.82 12.86 3.47 3.31 16.0 15.3 15.3 14.6 14.7 14.0
143 11.84 12.87 3.47 3.30 16.0 15.3 15.3 14.6 14.7 14.0
144 11.86 12.88 3.47 3.29 16.0 15.2 15.3 14.5 14.7 13.9
145 11.88 12.89 3.48 3.28 16.1 15.2 15.4 14.5 14.7 13.9
