Mitsubishi Electric CC-Link IE Field NZ2GF12A-60IOLH8 User manual

CC-Link IE Field Network Waterproof
Remote IO-Link Module User's Manual
-NZ2GF12A-60IOLH8

1
COPYRIGHT
This document is protected by the law of copyright, whereby all rights established therein remain with the company Mitsubishi
Electric Corporation. Reproduction of this document or parts of this document is only permissible within the limits of the legal
determination of Copyright Law. Alteration or abridgement of the document is not permitted without the explicit written
approval of the company Mitsubishi Electric Corporation.
PRECAUTIONS REGARDING WARRANTY AND
SPECIFICATIONS
The NZ2GF12A-60IOLH8 was jointly developed and manufactured by Mitsubishi Electric and Balluff GmbH. Note that
warranty information and specifications are different from those of other MELSEC products.
• Warranty
*1 Please note that repairs and failure analysis are refused due to the structure of this product. Therefore, free replacement is arranged for
the failure of our responsibility during the warranty period.
• General specifications
Item NZ2GF12A-60IOLH8 Other programmable controller products
(example: MELSEC iQ-R series)
Repair and analysis n/a*1 7 years after production discontinuation
Item NZ2GF12A-60IOLH8 Other programmable controller products
(example: MELSEC iQ-R series)
Operating ambient temperature 0 to 55(0 to 40for UL listed) 0 to 55(0 to 60when using an extended temperature
range base unit)
Equipment class Class Class 

2
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle
the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable
controller system, refer to the user's manual for the CPU module used.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to serious
consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future reference.
[Design Precautions]
[Design Precautions]
WARNING
●When a communication failure occurs in the network, data in the master/local module are held. Check
Data link status (each station) (SW00B0 to SW00B7) and configure an interlock circuit in the program
to ensure that the entire system will operate safely.
●When the module is disconnected due to a communication failure in the network or the CPU module is
in the STOP status, all outputs are held or turned off according to the parameter setting.
Configure an interlock circuit in the program to ensure that the entire system will always operate
safely even in such a case. Failure to do so may result in an accident due to an incorrect output or
malfunction.
●Outputs may remain on or off due to a failure of the module. Configure an external circuit for
monitoring output signals that could cause a serious accident.
●Do not use any "use prohibited" signals as a remote I/O signal since they are used by the system. Do
not write any data to the "use prohibited" areas in the remote register. If these operations are
performed, an accident may occur due to an incorrect output or malfunction.
CAUTION
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●During control of an inductive load such as a lamp, heater, or solenoid valve, a large current
(approximately ten times greater than normal) may flow when the output is turned from off to on.
Therefore, use a module that has a sufficient current rating.
WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in
minor or moderate injury or property damage.

3
[Security Precautions]
[Installation Precautions]
[Installation Precautions]
[Wiring Precautions]
WARNING
●To maintain the security (confidentiality, integrity, and availability) of the programmable controller and
the system against unauthorized access, denial-of-service (DoS) attacks, computer viruses, and other
cyberattacks from external devices via the network, take appropriate measures such as firewalls,
virtual private networks (VPNs), and antivirus solutions.
WARNING
●Shut off the load power supply (all phases) used in the system before mounting or removing a
module. Failure to do so may result in electric shock or cause the module to fail or malfunction.
CAUTION
●Use the module in an environment that meets the general specifications in this manual. Failure to do
so may result in electric shock, fire, malfunction, or damage to or deterioration of the product.
●Do not directly touch any conductive parts and electronic components of the module. Doing so can
cause malfunction or failure of the module.
●Securely fix the module with mounting screws. Otherwise, the module will be greatly affected by
vibration, causing failure of the module.
●Securely connect the cable connectors. Poor contact may cause malfunction.
●After the first use of the product, do not mount/remove the connector more than 50 times (IEC 61131-
2 compliant). Exceeding the limit may cause malfunction.
WARNING
●Shut off the load power supply (all phases) used in the system before wiring. Failure to do so may
result in electric shock or cause the module to fail or malfunction.
●In an output circuit, when a load current exceeding the rated current or an overcurrent caused by a
load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an
external safety circuit, such as a fuse.

4
[Wiring Precautions]
[Wiring Precautions]
CAUTION
●Always ground the module using the included FG screw and FG strap. Failure to do so may result in
electric shock or malfunction.
●Check the rated voltage and terminal layout before wiring to the module, and connect the cables
correctly. Connecting a power supply with a different voltage rating or incorrect wiring may cause fire
or failure.
●Tighten the waterproof plugs, waterproof caps, and module mounting screws within the specified
torque range. Undertightening can cause short circuit, fire, or malfunction. Overtightening can
damage the waterproof plug, waterproof cap, and module mounting screw, resulting in short circuit or
malfunction.
CAUTION
●The product specifications are satisfied only when all of waterproof plugs and waterproof caps are
installed with the recommended connectable devices and all screws are tightened with an appropriate
torque.
●Prevent foreign matter such as dust or wire chips from entering the module. Such foreign matter can
cause a fire, failure, or malfunction.
●Clamp the cables connected to the module. If not, dangling cable may swing or inadvertently be
pulled, resulting in damage to the module or cables or malfunction due to poor contact.
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable
with connector, hold the connector part of the cable. Pulling the cable connected to the module may
result in malfunction or damage to the module or cable.
●Wiring and replacement of a module must be performed by qualified maintenance personnel with
knowledge of protection against electric shock. For wiring methods, refer to "INSTALLATION AND
WIRING" in this manual.
●Consider fully the operating environment and input response time of CQ and Q terminals because the
module may take in noise as input when it is used in SIO mode (digital input).

5
[Startup and Maintenance Precautions]
[Startup and Maintenance Precautions]
[Disposal Precautions]
WARNING
●Do not touch any connector while power is on. Doing so will cause electric shock or malfunction.
●Shut off the load power supply (all phases) used in the system before cleaning the module or
retightening screws or connector screws. Failure to do so may cause the module to fail or malfunction.
CAUTION
●Do not disassemble or modify the modules. Doing so may cause failure, malfunction, injury, or a fire.
●Do not drop or apply strong shock to the module. Doing so may damage the module.
●Shut off the load power supply (all phases) used in the system before mounting or removing a
module. Failure to do so may result in electric shock or cause the module to fail or malfunction.
●After the first use of the product, do not mount/remove the connector more than 50 times (IEC 61131-
2 compliant). Exceeding the limit may cause malfunction.
●Before handling the module or connection cables, touch a conducting object such as a grounded
metal to discharge the static electricity from the human body. Failure to do so may cause the module
to fail or malfunction.
●Startup and maintenance of a control panel must be performed by qualified maintenance personnel
with knowledge of protection against electric shock. Lock the control panel so that only qualified
maintenance personnel can operate it.
CAUTION
●When disposing of this product, treat it as industrial waste.

6
CONDITIONS OF USE FOR THE PRODUCT
(1) MELSEC programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;
and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the
case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.
MITSUBISHI ELECTRIC SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO
ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT
LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the
PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY
INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN MITSUBISHI ELECTRIC USER'S, INSTRUCTION
AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the
public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality
assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,
Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and
Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or property.
Notwithstanding the above restrictions, Mitsubishi Electric may in its sole discretion, authorize use of the PRODUCT in
one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific
applications agreed to by Mitsubishi Electric and provided further that no special quality assurance or fail-safe,
redundant or other safety features which exceed the general specifications of the PRODUCTs are required. For details,
please contact the Mitsubishi Electric representative in your region.
(3) Mitsubishi Electric shall have no responsibility or liability for any problems involving programmable controller trouble and
system trouble caused by DoS attacks, unauthorized access, computer viruses, and other cyberattacks.

7
INTRODUCTION
Thank you for purchasing the CC-Link IE Field Network waterproof remote IO-Link module (hereafter abbreviated as IO-Link
module).
This manual describes the procedures, system configuration, parameter settings, functions, and troubleshooting of the IO-
Link module.
Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the
functions and performance of the IO-Link module to handle the product correctly.
When applying the program examples provided in this manual to an actual system, ensure the applicability and confirm that it
will not cause system control problems.
Please make sure that the end users read this manual.
Relevant product
NZ2GF12A-60IOLH8
Unless otherwise specified, this manual describes the program examples in which the remote I/O signals and
remote registers are assigned for an IO-Link module as follows.
• Remote input signal: RX0 to RX4F
• Remote output signal: RY0 to RY4F
• Remote register: RWr0 to RWr83, RWw0 to RWw83
For the assignment of remote I/O signals and remote registers, refer to the following.
User's manual for the master/local module used

8
CONTENTS
COPYRIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
PRECAUTIONS REGARDING WARRANTY AND SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
RELEVANT MANUALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
CHAPTER 1 PART NAMES 14
CHAPTER 2 SPECIFICATIONS 20
2.1 General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.2 Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.3 Function List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
CHAPTER 3 PROCEDURES BEFORE OPERATION 27
CHAPTER 4 SYSTEM CONFIGURATION 29
4.1 Applicable Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2 Recommended Connectable Device List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
CHAPTER 5 INSTALLATION AND WIRING 33
5.1 Installation Environment and Installation Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Installation environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Installation position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Installation direction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Fixing the IO-Link module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.3 Wiring the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.4 Wiring of Ethernet Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.5 Wiring the IO-Link Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.6 Attaching Waterproof Caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.7 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
CHAPTER 6 Parameter Setting 45
6.1 CC-Link IE Field Network Parameter Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Setting via the engineering tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.2 IO-Link Module Parameter Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Setting via the engineering tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Setting via a program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.3 Changing the IO-Link Module Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Setting via the engineering tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Setting via a program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.4 IO-Link Device Parameter Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setting procedure when FDC and CommDTM are used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Conversion procedure of IODD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Creation procedure of FDC project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Procedure for adding M_CommDTM-IOLink. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

9
CONTENTS
Procedure for configuring communication setting with M_CommDTM-IOLink . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Parameter writing procedure to IO-Link device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
CHAPTER 7 FUNCTIONS 63
7.1 IO-Link Master Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
IO-Link cyclic transmission function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
IO-Link transient communication function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
IO-Link device setting automatic upload/download function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
IO-Link device validation function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Disconnection detection function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Swap function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7.2 SIO Mode Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
SIO input function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
SIO output function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Number of SIO output ON times integration function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
7.3 Power Supply Monitoring Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
7.4 Short-Circuit Detection Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
7.5 Initial Operation Setting Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
7.6 CC-Link IE Field Network Communication Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Cyclic transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Transient transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Output HOLD/CLEAR setting function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
CC-Link IE Field Network diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
CHAPTER 8 MODULE FUNCTION BLOCKS 97
CHAPTER 9 PROGRAMMING 99
9.1 Precautions for Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
9.2 Program Example of Setting Parameters Using a Dedicated Instruction . . . . . . . . . . . . . . . . . . . . . . . . . 101
9.3 Example of Program to Communicate with an IO-Link Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
CHAPTER 10 MAINTENANCE AND INSPECTION 115
CHAPTER 11 TROUBLESHOOTING 117
11.1 Checking the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
11.2 Unit Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.3 Checking the Status of IO-Link Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
11.4 Troubleshooting for Each Phenomenon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
11.5 Checking for the Error Codes and the Warning Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
11.6 List of Error Codes and the Warning Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
List of Error Codes and the Warning Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Error Code List (Communication Error) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
APPENDICES 129
Appendix 1 Remote I/O Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
List of remote I/O signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Details of remote input signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Details of remote output signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Appendix 2 Remote Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
List of remote register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

10
Details of Remote Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Appendix 3 Processing Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Appendix 4 EMC and Low Voltage Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Measures to comply with the EMC Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Requirements to compliance with the Low Voltage Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Appendix 5 How to Check the Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Appendix 6 External Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Appendix 7 Additional or Changed Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Additional functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
INDEX 154
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .156
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .157
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158

11
RELEVANT MANUALS
e-Manual refers to the Mitsubishi FA electronic book manuals that can be browsed using a dedicated tool.
e-Manual has the following features:
• Required information can be cross-searched in multiple manuals.
• Other manuals can be accessed from the links in the manual.
• The hardware specifications of each part can be found from the product figures.
• Pages that users often browse can be bookmarked.
• Sample programs can be copied to an engineering tool.
Manual name [manual number] Description Available form
CC-Link IE Field Network Waterproof Remote IO-
Link Module User's Manual
[SH-081761ENG] (this manual)
Part names, specifications, procedures before operation, system
configuration, installation, wiring, parameter settings, functions, programming,
and troubleshooting of the IO-Link module
Print book
e-Manual
PDF

12
TERMS
Unless otherwise specified, this manual uses the following terms.
Term Description
CC-Link IE Field Network A high-speed and large-capacity open field network that is based on Ethernet (1000BASE-T)
CommDTM (Communication DTM) A software module used to configure the communication setting required for communications between a personal
computer and field devices via the IO-Link master.
CPU module A generic term for the MELSEC iQ-R series CPU module, MELSEC-Q series CPU module, and MELSEC-L series CPU
module
Cyclic transmission A function by which data are periodically exchanged among stations on the same network using link devices (RX, RY,
RWw, and RWr)
Data link A generic term for cyclic transmission and transient transmission
Dedicated instruction An instruction that simplifies programming for using functions of intelligent function modules
Device DTM A software module used to configure the parameter settings of field devices or monitor field devices.
Disconnection A process of stopping data link if a data link error occurs
DTM (Device Type Manager) A software module used to configure the communication settings, set parameters of field devices, or monitor field
devices when an FDT frame application is used.
DTM catalog By registering the M_CommDTM-IOLink, the communication settings are automatically configured, and the list of
available DTMs is displayed.
Engineering tool Another term for the software package for the MELSEC programmable controllers
FDC An abbreviation for the MELSOFT FieldDeviceConfigurator
FDT (Field Device Tool) Software standard specifications for management, maintenance, adjustment, and development of field devices
FDT frame application A generic term for applications to use a DTM. An FDT frame application complies with the FDT/DTM open standard
Global label A label that is valid for all the program data when multiple program data are created in the project. The global label has
two types: a module specific label (module label), which is generated automatically by GX Works3, and an optional label,
which can be created for any specified device.
Intelligent device station A station that exchanges I/O signals (bit data) and I/O data (word data) with another station by cyclic transmission. This
station can perform transient transmission as well. This station responds to a transient transmission request from
another station and also issues a transient transmission request to another station.
IO-Link device An external device that supports IO-Link
IO-Link module An abbreviation for the CC-Link IE Field Network waterproof remote IO-Link module
IODD (IO-Link Device Description) This description consists of the XML file containing the IO-Link device information and the image file in the png format.
This description is supplied from a manufacturer of an IO-Link device.
IODD DTM Configurator A software program that operates the IODD file (device description file of IO-Link) as the Device DTM.
ISDU Data read from or written to parameters of IO-Link devices
Label A label that represents a device in a given character string
Link device A device (RX, RY, RWr, or RWw) in a module on CC-Link IE Field Network
Link special register (SW) Word data that indicates the operating status and data link status of a module on CC-Link IE Field Network
Link special relay (SB) Bit data that indicates the operating status and data link status of a module on CC-Link IE Field Network
Local station A station that performs cyclic transmission and transient transmission with the master station and other local stations.
The station is controlled by programs in the CPU module or other equivalent modules on the station.
M_CommDTM-IOLink CommDTM that supports communications with the IO-Link device via the IO-Link module.
Master station A station that controls the entire network. This station can perform cyclic transmission and transient transmission with all
stations. Only one master station can be used in a network.
Master/local module An abbreviation for the CC-Link IE Field Network master/local module
MELSOFT FieldDeviceConfigurator Configuration Tool, which is developed by Mitsubishi Electric Corporation. MELSOFT FieldDeviceConfigurator complies
with the FDT/DTM open standard and is used for parameter settings, maintenance, and adjustment of field devices as
an FDT frame application.
Module label A label that represents one of memory areas (I/O signals and buffer memory areas) specific to each module in a given
character string.
For the module used, GX Works3 automatically generates this label, which can be used as a global label.
Remote device station A station that exchanges I/O signals (bit data) and I/O data (word data) with another station by cyclic transmission. This
station responds to a transient transmission request from another station.
Remote I/O station A station that exchanges I/O signals (bit data) with the master station by cyclic transmission
Remote input (RX) Bit data input from a slave station to the master station (For some areas in a local station, data are input in the opposite
direction.)
User's manual for the master/local module used

13
Remote output (RY) Bit data output from the master station to a slave station (For some areas in a local station, data are output in the
opposite direction.)
User's manual for the master/local module used
Remote register (RWr) Word data input from a slave station to the master station (For some areas in a local station, data are input in the
opposite direction.)
User's manual for the master/local module used
Remote register (RWw) Word data output from the master station to a slave station (For some areas in a local station, data are output in the
opposite direction.)
User's manual for the master/local module used
Reserved station A station reserved for future use. This station is not actually connected, but counted as a connected station
RIRD A generic term for J.RIRD, JP.RIRD, G.RIRD, and GP.RIRD
RIWT A generic term for J.RIWT, JP.RIWT, G.RIWT, and GP.RIWT
Sink A direction of a current. The current flows from the outside to an input terminal or output terminal. (Japan/North America)
Slave station A generic term for stations other than a master station: local station, remote I/O station, remote device station, and
intelligent device station
Source A direction of a current. The current flows from an input terminal or output terminal to the outside. (Europe)
Transient transmission A function of communication with another station, which is used when requested by a dedicated instruction or an
engineering tool
Term Description

14 1 PART NAMES
1PART NAMES
Part names of the IO-Link module
This section describes part names of the IO-Link module.
No. Name Application
(1) FG screw hole A hole for an FG screw
For the tightening torque of FG screws, refer to the following.
Page 36 Installation
(2) Module fixing hole This hole is used to fix the IO-Link module with a module mounting screw.
For the tightening torque of module mounting screws, refer to the following.
Page 36 Installation
(3) Communication
connectors
P1 PORT1 connector for CC-Link IE Field Network
Connect an Ethernet cable. (Page 38 Wiring of Ethernet Cable)
P2 PORT2 connector for CC-Link IE Field Network
Connect an Ethernet cable. (Page 38 Wiring of Ethernet Cable)
(4) Display part Displays the IO-Link module station number, errors, and other information.
Use the [SET] and [SEL.] buttons for operations. (Page 17 Operation specifications of the display part)
(5) Power supply connectors Connectors for the module/sensor power supply (US) (24VDC) and actuator power supply (UA) (24VDC).
(6) IO-Link connectors Connectors for IO-Link communication
(7) Signal label fixing part A ditch to fix supplied signal labels.
(1) (2)
(3)
(4)
(5)
(6)
(7)

1 PART NAMES
15
1
LED names of the IO-Link module
This section describes the LEDs of the IO-Link module.
No. Name Description
(1) DISPLAY1 LED This LED turns on/off when the remote output signal turns on/off.
DISPLAY1 LED and DISPLAY2 LED work in the same way.
For example, use a relevant remote output signal in a program so that the sequence processing can be checked via the LED.
The LED also shows the result of a unit test.
■Remote output signal
Green: Display LED1 and LED2 (RY20) are off, and Display LED1 and LED2 (RY21) are on.
Red: Display LED1 and LED2 (RY20) are on, and Display LED1 and LED2 (RY21) are off.
Orange: Display LED1 and LED2 (RY20) are on, and Display LED1 and LED2 (RY21) are on.
Red (flashing): A major error has occurred.
Off: Display LED1 and LED2 (RY20) are off, and Display LED1 and LED2 (RY21) are off.
■Unit test
Green: The unit test result is normal.
Red: The unit test result is abnormal.
(2) DISPLAY2 LED
(3) US LED Indicates the voltage status of the module/sensor power supply.
Green: The module/sensor power supply has no voltage error.
Red: The module/sensor power supply has a voltage error (18VDC or less).
Off: The module/sensor power supply is off or has a voltage error (11VDC or less).
UA LED Indicates the voltage status of the actuator power supply.
Green: The actuator power supply has no voltage error.
Red (flashing): The actuator power supply has a voltage error (18VDC or less).
Red: The actuator power supply is off or has a voltage error (11VDC or less).
RUN LED Indicates the operating status of the IO-Link module.
On: Operating normally.
Off: A module error has occurred.
ERR. LED Indicates the error status of the IO-Link module.
On: A module error has occurred.
Off: Operating normally.
(1) (2)
(3)
(6)
(4)
(5)
(7)

16 1 PART NAMES
*1 If both the CQ LED and Q LED flash, a short-circuit has occurred between the L+ and L- terminals.
The US LED, UA LED, LINK LED (P1), L ER LED (P1). LINK LED (P2), and L ER LED (P2) may turn on when
the module is powered on. This behavior does not indicate an error.
(4) LINK LED(P1) Indicates the link status of the PORT1 connector.
On: Linkup in progress
Off: Linkdown in progress
L ER LED(P1) Indicates the port status of the PORT1 connector.
Green: The IO-Link module received normal data.
Green (flashing): The network is configured in ring topology without using the loopback function.
Red: The IO-Link module received abnormal data.
Off: Linkdown in progress
(5) LINK LED(P2) Indicates the link status of the PORT2 connector.
On: Linkup in progress
Off: Linkdown in progress
L ER LED(P2) Indicates the port status of the PORT2 connector.
Green: The IO-Link module received normal data.
Green (flashing): The network is configured in ring topology without using the loopback function.
Red: The IO-Link module received abnormal data.
Off: Linkdown in progress
(6) CQ LED Indicates the operating status of the CQ terminal of each channel.
■In IO-Link mode
Green: Operating normally with IO-Link enabled.
Green (flashing every 0.5s): Communication is stopped with IO-Link enabled.
Green (flashing every 0.3s): Uploading IO-Link device parameters to the data storage, or downloading IO-Link device
parameters from the data storage
Red (flashing): An error is occurring due to any of the following reasons.
• The IO-Link device validation setting is enabled, and an IO-Link device is not compatible or identifiable.
• The data storage configuration is enabled, and an incompatible IO-Link device is connected.
• The configured process data size is smaller than that of the connected IO-Link devices.
• The module/sensor power supply (US) voltage is 13V or less.
Off: IO-Link is disabled.
■In SIO mode
Orange: I/O is on.
Off: I/O is off.
Red: An I/O setting error has occurred (short-circuit detection).
Red (flashing): An error has occurred (short-circuit detection).*1
(7) Q LED Indicates the operating status of the Q terminal of each channel.
Orange: I/O is on.
Off: I/O is off.
Red: An I/O setting error has occurred (short-circuit detection).
Red (flashing): An error has occurred (short-circuit detection).*1
No. Name Description

1 PART NAMES
17
1
Operation specifications of the display part
The display part is used to check information or directly set the station number and network number of the IO-Link module
without having to use engineering tools.
When an error occurs, error information is displayed to help users to troubleshoot the module.
■Display at startup
Information is displayed in the following order when the module is powered on.
■Main menu
Window transition of the main menu is as follows. Use the [SET] button to change the main menu.
No. Name Description
(1) [SET] button Used to change the main menu and determine changes of various settings.
Press and hold it to activate the Edit mode. In the edit mode, display lock (RY22) can be used to lock any operation. In the
locked state, a key icon is displayed on the LCD screen.
(2) [SEL.] button Used to change the display for network configuration and module information, and move the cursor between digits of a value.
(3) LCD screen Displays information of the IO-Link module.
The standby screen (IO-Link module station number) will appear if there is no operation for 10 seconds.
(1) The model name is displayed.
(2) The hardware and firmware versions are displayed.
(3) The station number is displayed.
(4) The network number is displayed.
(1) Standby screen: Displays the station number of the IO-Link module.
(2) Network configuration window: Used to configure the network.
(3) Module information window: Used to read information such as errors.
(4) Initialization window: Used to reset the settings to the factory default values.
(1) (2)
(3)
(1) (2) (3) (4)
(1) (2)
SET
SET
SET SET
(3) (4)

18 1 PART NAMES
■Network configuration
Window transition of the network settings window is as follows. Use the [SEL.] button to change the window.
The station number and network number can be changed by pressing and holding the [SET] button on the relevant window.
Operating procedure
(1) Press the [SEL.] button on the network configuration window of the main menu
(2) The station number is displayed.
(3) The network number is displayed.
(4) The number of RX/RY points used is displayed.
(5) The number of RWr/RWw points used is displayed.
1. Press the [SEL.] button on the network configuration window to display the station
number or network number window.
2. Press and hold the [SET] button to enter the edit mode.
3. Press the [SEL.] button to increment the value by one. (Pressing the [SEL.] button at 9
would reset the value to 0.) The cursor to change the digit starts at the far left by
default, and pressing the [SET] button changes the cursor location.
4. Press the [SET] button with the cursor located at the far right to save the value and
exit the edit mode. At this time, the backlight will flash and will be displayed on the
LCD screen. The changed value will be applied when the IO-Link module is restarted.
(2) (3)
SEL.
SEL.
SEL.
SEL.
SEL.
(4) (5)
(1)
