Mitsubishi Electric AJ65BT-D75P2-S3 User manual

AJ65BT-D75P2-S3 Positioning Module
User's Manual

A - 1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full
attention to safety to handle the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of
the programmable controller system, refer to the user's manual for the CPU module used.
In this manual, the safety instructions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to
serious consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future
reference.

A - 2
[Design Precautions]
WARNING
Failure to observe this could lead to accidents for incorrect outputs or malfunctioning.
Configure safety circuits external to the programmable controller to ensure that the entire
system operates safely even when a fault occurs in the external power supply or the
programmable controller.
Failure to do so may result in an accident due to an incorrect output or malfunction.
(1) Configure an emergency stop circuit and interlock circuit such as a positioning upper
limit/lower limit to prevent mechanical damage outside the programmable controller.
(2) The machine zero point return operation is controlled by the zero point return direction
and zero point return speed data. Deceleration starts when the near-point dog turns ON.
Thus, if the zero point return direction is incorrectly set, deceleration will not start and the
machine will continue to travel. Configure an interlock circuit to prevent mechanical
damage outside the programmable controller.
(3) When the positioning module detects an error, the motion slows down and stops or the
motion suddenly stops, depending on the stop group setting in parameter.
Set the parameters to meet the specifications of the positioning control system used.
In addition, set the OPR parameters and positioning data within the specified setting range.
When a data link results in a communication error, the operating status of the station in
communication error changes depending on the type of the used data link. Using the
communication status information, configure an interlock circuit in the sequence program to
ensure that the system will operate safely.
For the method of checking the station in communication error and its operating status at
communication error, refer to the corresponding data link manual.
[Design Precautions]
CAUTION
Do not install the control lines or communication cables together with the main circuit lines or
power cables.
Keep a distance of 100mm or more between them.
Failure to do so may result in malfunction due to noise.

A - 3
[Installation Precautions]
CAUTION
Use the programmable controller in an environment that meets the general specifications in
this manual.
Failure to do so may result in electric shock, fire, malfunction, or damage to or deterioration of
the product.
Securely fix the module using the DIN rail or mounting screws and fully tighten the mounting
screws within the specified torque range. If the screws are loose, it may result in fallout, short
circuits, or malfunctions. Tightening the screw too far may cause damages to the screws and/or
the module, resulting in a fallout, short circuits, or malfunctions.
Securely connect the external device connection connector and peripheral device connection
connector into the module connector until a click is heard.
Improper connection could lead to a connection fault, and to incorrect inputs and outputs.
When not connecting the drive unit and peripheral device, always install a cover on the
connector section.
Failure to observe this could lead to malfunctioning.
[Wiring Precautions]
WARNING
Check the rated voltage and terminal layout before wiring to the programmable controller, and
connect the cables correctly. Connecting a power supply with a different voltage rating or
incorrect wiring may cause a fire or failure.
Check the terminal layout before wiring to the module, and connect the cables correctly.
Prevent foreign matter such as dust or wire chips from entering the module.
Such foreign matter can cause a fire, failure, or malfunction.
[Wiring Precautions]
!CAUTION
Tighten the terminal screws within the range of the specified torque.
If the terminal screws are loose, it may result in short circuits, or malfunctions. Tightening the
terminal screws too far may cause damages to the terminal screws and/or the module, resulting
in short circuits, or malfunctions.
Be sure there are no foreign substances such as sawdust or wiring debris inside the module.
Such debris could cause fires, failure, or malfunction.
Individually ground the FG terminal of the programmable controller with a ground resistance of
100 ohms or less. Failure to do so may result in malfunction.
Place the cables in a duct or clamp them.
If not, dangling cable may swing or inadvertently be pulled, resulting in damage to the module
or cables or malfunction due to poor contact.
Keep a certain distance between the control wires and the communication cables.
Noise can cause a malfunction.
When disconnecting a cable from the module, do not pull on the cable itself. Disconnect cables
not fitted with a connectors by holding and pulling the cable connector.
Disconnect cables not fitted with a connector by removing the screws from the part connected
to the module can cause damage to the module or cable, or ,malfunction due to cable
connection faults.

A - 4
[Startup and Maintenance Precautions]
!CAUTION
Do not touch any terminal while power is on.
Doing so will cause electric shock or malfunction.
Never disassemble or modify the module.
Failure to observe this could lead to trouble, malfunctioning, injuries or fires.
Switch off all phases of the externally supplied power used in the system before cleaning or
tightening the screws.
Failure to turn all phases OFF could lead to electric shocks.
Make sure to install or remove the module from the panel after switching off all phases of the
externally supplied power for the system.
Failure to turn all phases OFF could lead to module trouble or malfunctioning.
Before starting test operation, set the parameter speed limit value to the slowest value, and
make sure that operation can be stopped immediately if a hazardous state occurs.
Do not install/remove the terminal block more than 50 times after the first use of the product.
(IEC 61131-2 compliant)
Always make sure to touch the grounded metal to discharge the electricity charged in the body,
etc., before touching the module.
Failure to do so may cause a failure or malfunctions of the module.
[Precautions for use]
!CAUTION
Note that when the reference axis speed is designated for interpolation operation, the speed of
the partner axis (2nd axis) may be larger than the set speed (larger than the speed limit value).
[Disposal Precautions]
!CAUTION
When disposing of the product, handle it as industrial waste.

A - 5
CONDITIONS OF USE FOR THE PRODUCT
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or
serious accident; and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the
PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general
industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED
TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT,
PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO
PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT
INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN
MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND
GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other
cases in which the public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a
special quality assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator
and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for
Recreation and Amusement, and Safety devices, handling of Nuclear or Hazardous Materials or
Chemicals, Mining and Drilling, and/or other applications where there is a significant risk of injury to
the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the
PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is
limited only for the specific applications agreed to by Mitsubishi and provided further that no special
quality assurance or fail-safe, redundant or other safety features which exceed the general
specifications of the PRODUCTs are required. For details, please contact the Mitsubishi representative
in your region.

A - 6
REVISIONS
*The manual number is given on the bottom left of the back cover.
Print Date * Manual Number Revision
Apr., 1998 IB (NA)-66824-A First printing
Apr., 2003 IB (NA)-66824-B Complete review
Oct., 2003 IB (NA)-66824-C Complete review
Feb.,2004 IB (NA)-66824-D
Partial correction addition
CONTENTS, Section 3.5, Section 5.6.2, Section 7.1.2, Section 8.2.5,
Section 8.2.6, Section 10.1.2, Section 10.3.3 to Section 10.3.5,
Section 10.3.8, Appendix 13, INDEX
Jun., 2005 IB (NA)-66824-E Partial correction addition
SAFETY INSTRUCTIONS, Generic Terms and Abbreviations,
Section 3.4.2, Section 4.2.2, Section 4.3, Section 4.5.1, Section 4.5.3,
Section 4.8.1, Section 5.1.2, Section 5.2.1, Section 5.3, Section 5.7.2,
Section 6.1.1, Section 6.6.1, Section 6.6.5, Section 8.1.1,
Section 8.2.4 to Section 8.2.8, Section 8.5, Section 9.1.2,
Section 9.15, Section 9.2.6, Section 9.2.8 to Section 9.2.11,
Section 10.3.9, Section 11.3.1, Section 12.2.1, Section 14.4.3,
Section 12.4.4, Section 12.5.1, Section 12.5.2, Section 12.7.1,
Section 12.7.5, Section 12.7.6, Section 13.4, Section 14.2,
Section 14.3, Appendix 5.1, Appendix 11, Appendix 12
Jul., 2006 IB (NA)-66824-F Partial correction addition
Appendix 7.1, INDEX
Sep., 2007 IB(NA)-66824-G Partial revisions
Section 5.1.2, Section 5.2.1, Section 5.6.1, Section 5.7.1
Apr., 2015 IB(NA)-66824-H Addition
CONDITIONS OF USE FOR THE PRODUCT
Partial correction addition
SAFETY PRECAUTIONS, INTRODUCTION, ABOUT MANUALS,
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES,
GENERIC TERMS AND ABBREVIATIONS, Section 1.3, 2.3, 2.4, 3.1,
3.2, 3.7.1, 3.7.3, 3.7.4, 4.1.2, 4.1.3, 4.2.1, 4.3, 4.5.1, 4.5.2, 4.8.1,
5.1.1, 5.2.3, 5.3, 5.5, 6.1.1, 6.1.2, 9.1.4, 9.1.5, 9.2.7, 10.1.1, 10.1.2,
10.3.5, 10.3.8, 10.4.1, 10.4.2, 12.3.2, 12.4.3, 12.4.4, 12.5.3, 13.4,
Appendix 1, 2, 3.2, 5.1, 5.2, 5.3, 6.1, 7.1, 8.1, 9.1, 11, 12,
WARRANTY
Jun., 2017 IB(NA)-66824-I Partial correction addition
Appendix 8.1, 9.1, 12
Japanese Manual Version SH-3654-K
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses.
Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which
may occur as a result of using the contents noted in this manual.
1998 MITSUBISHI ELECTRIC CORPORATION

A - 7
MEMO

A - 8
INTRODUCTION
Thank you for purchasing the Mitsubishi Electric general-purpose programmable controller MELSEC-A Series.
Always read through this manual, and fully comprehend the functions and performance of the A Series PLC
before starting use to ensure correct usage of this product.
When applying the program examples introduced in this manual to an actual system, ensure the applicability
and confirm that it will not cause system control problems.
CONTENTS
SAFETY PRECAUTIONS............................................................................................................................ A- 1
CONDITIONS OF USE FOR THE PRODUCT ........................................................................................... A- 5
REVISIONS .................................................................................................................................................. A- 6
INTRODUCTION.......................................................................................................................................... A- 8
CONTENTS.................................................................................................................................................. A- 8
ABOUT MANUALS .......................................................................................................................................A- 15
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES.........................................................A- 16
USING THIS MANUAL (1)............................................................................................................................A- 17
USING THIS MANUAL (2)............................................................................................................................A- 18
USING THIS MANUAL (3)............................................................................................................................A- 19
GENERIC TERMS AND ABBREVIATIONS ................................................................................................A- 20
ENCLOSED PARTS .....................................................................................................................................A- 21
SECTION 1 PRODUCT SPECIFICATIONS AND HANDLING
1. PRODUCT OUTLINE 1- 1 to 1- 20
1.1 Positioning control.................................................................................................................................. 1- 2
1.1.1 Features of D75P2 .......................................................................................................................... 1- 2
1.1.2 Purpose and applications of positioning control............................................................................. 1- 4
1.1.3 Mechanism of positioning control ................................................................................................... 1- 6
1.1.4 Outline design of positioning system .............................................................................................. 1- 8
1.1.5 Communicating signals between D75P2 and each module........................................................... 1- 10
1.2 Flow of system operation........................................................................................................................ 1- 12
1.2.1 Flow of all processes........................................................................................................................ 1- 12
1.2.2 Outline of starting ............................................................................................................................. 1- 14
1.2.3 Outline of stopping ........................................................................................................................... 1- 16
1.2.4 Outline for restarting......................................................................................................................... 1- 17
1.3 Outline of communication ....................................................................................................................... 1- 18
1.3.1 Cyclic transmission........................................................................................................................... 1- 19
1.3.2 Transient transmission ..................................................................................................................... 1- 20
2. SYSTEM CONFIGURATION 2- 1 to 2- 12
2.1 General image of system....................................................................................................................... 2- 2
2.2 List of configuration devices .................................................................................................................. 2- 4
2.3 Applicable system .................................................................................................................................. 2- 6
2.4 Precautions for use ................................................................................................................................ 2- 8

A - 9
3. SPECIFICATIONS AND FUNCTIONS 3- 1 to 3- 44
3.1 General specifications............................................................................................................................ 3- 2
3.2 Performance specifications.................................................................................................................... 3- 4
3.3 List of functions ..................................................................................................................................... 3- 6
3.3.1 D75P2 control functions.................................................................................................................. 3- 6
3.3.2 D75P2 main functions ..................................................................................................................... 3- 8
3.3.3 D75P2 auxiliary functions and common functions .......................................................................... 3- 10
3.3.4 Combination of D75P2 main functions and auxiliary functions ...................................................... 3- 12
3.4 Specifications of input/output signals for master module ...................................................................... 3- 14
3.4.1 List of input/output signals ............................................................................................................... 3- 14
3.4.2 Details of input signals (D75P2 Master module)....................................................................... 3- 17
3.4.3 Details of output signals (Master module D75P2) .................................................................... 3- 21
3.5 Remote registers..................................................................................................................................... 3- 23
3.6 Transmission delay time ......................................................................................................................... 3- 32
3.7 Specifications of input/output interfaces with external devices ............................................................. 3- 35
3.7.1 Electrical specifications of input/output signals ............................................................................... 3- 35
3.7.2 Signal layout for external device connection connector.................................................................. 3- 38
3.7.3 List of input/output signal details...................................................................................................... 3- 39
3.7.4 Input/output interface internal circuit................................................................................................ 3- 42
4. INSTALLATION, WIRING AND MAINTENANCE OF THE PRODUCT 4- 1 to 4- 30
4.1 Outline of installation, wiring and maintenance..................................................................................... 4- 2
4.1.1 Installation, wiring and maintenance procedures........................................................................... 4- 2
4.1.2 Names of each part......................................................................................................................... 4- 3
4.1.3 Handling precautions ...................................................................................................................... 4- 5
4.2 Installation .............................................................................................................................................. 4- 7
4.2.1 Precautions for installation.............................................................................................................. 4- 7
4.2.2 Installation/removal of module ........................................................................................................ 4- 9
4.3 Connection of CC-Link dedicated cable................................................................................................. 4- 12
4.4 Module setting ......................................................................................................................................... 4- 14
4.4.1 Station number setting of module.................................................................................................... 4- 14
4.4.2 Transmission speed setting of module............................................................................................ 4- 15
4.5 Wiring/connection.................................................................................................................................... 4- 16
4.5.1 Precautions for wiring/connection.................................................................................................... 4- 16
4.5.2 Wiring the external device connection connector pins.................................................................... 4- 20
4.5.3 Connecting the connector ................................................................................................................ 4- 24
4.6 Confirming the installation and wiring..................................................................................................... 4- 25
4.6.1 Items to confirm when installation and wiring are completed ......................................................... 4- 25
4.7 Single module test................................................................................................................................... 4- 26
4.8 Maintenance............................................................................................................................................ 4- 30
4.8.1 Precautions for maintenance ........................................................................................................... 4- 30
4.8.2 Disposal instructions ........................................................................................................................ 4- 30

A - 10
5. DATA USED FOR POSITIONING CONTROL (List of buffer memory addresses) 5- 1 to 5-112
5.1 Types of data.......................................................................................................................................... 5- 2
5.1.1 Parameters and data required for control....................................................................................... 5- 2
5.1.2 Setting items for positioning parameters ........................................................................................ 5- 4
5.1.3 Setting items for zero point return parameters............................................................................... 5- 6
5.1.4 Setting items for positioning data.................................................................................................... 5- 7
5.1.5 Setting items for start block data .................................................................................................... 5- 9
5.1.6 Setting items for condition data ....................................................................................................... 5- 10
5.1.7 Types and roles of monitor data ...................................................................................................... 5- 11
5.1.8 Types and roles of control data ....................................................................................................... 5- 14
5.2 List of parameters ................................................................................................................................... 5- 18
5.2.1 Basic parameters 1 .......................................................................................................................... 5- 18
5.2.2 Basic parameters 2 .......................................................................................................................... 5- 24
5.2.3 Detailed parameters 1...................................................................................................................... 5- 28
5.2.4 Detailed parameters 2...................................................................................................................... 5- 36
5.2.5 Zero point return basic parameters ................................................................................................. 5- 45
5.2.6 Zero point return detailed parameters ............................................................................................. 5- 52
5.3 List of positioning data ............................................................................................................................ 5- 57
5.4 List of start block data ............................................................................................................................. 5- 71
5.5 List of condition data ............................................................................................................................... 5- 76
5.6 List of monitor data.................................................................................................................................. 5- 80
5.6.1 System monitor data ........................................................................................................................ 5- 80
5.6.2 Axis monitor data.............................................................................................................................. 5- 90
5.7 List of control data.................................................................................................................................. 5-100
5.7.1 System control data ........................................................................................................................ 5-100
5.7.2 Axis control data .............................................................................................................................. 5-106
6. SEQUENCE PROGRAM USED FOR POSITIONING CONTROL 6- 1 to 6- 66
6.1 Information necessary for program creation ............................................................................................ 6- 2
6.1.1 When ACPU/QCPU (A mode) is used .............................................................................................. 6- 2
6.1.2 When QCPU (Q mode)/QnACPU is used ....................................................................................... 6- 15
6.2 Precautions for creating program ........................................................................................................... 6- 22
6.3 List of devices used................................................................................................................................. 6- 23
6.4 Creating a program ................................................................................................................................. 6- 29
6.4.1 General configuration of program.................................................................................................... 6- 29
6.4.2 Positioning control operation program............................................................................................. 6- 30
6.5 Positioning program examples ............................................................................................................... 6- 33
6.5.1 When using FROM/TO command with ACPU/QCPU-A (A mode) ................................................ 6- 33
6.5.2 When using dedicated commands with ACPU/QCPU-A (A mode) ...............................................6- 40
6.5.3 When using dedicated commands with QCPU (Q mode)/QnACPU.............................................. 6- 46
6.6 Program details ....................................................................................................................................... 6- 51
6.6.1 Initialization program ........................................................................................................................ 6- 51
6.6.2 Start details setting program ............................................................................................................ 6- 52
6.6.3 Start program.................................................................................................................................... 6- 53
6.6.4 Restart program ............................................................................................................................... 6- 61
6.6.5 Stop program.................................................................................................................................... 6- 64

A - 11
7. MEMORY CONFIGURATION AND DATA PROCESS 7- 1 to 7- 16
7.1 Configuration and roles of D75P2 memory........................................................................................... 7- 2
7.1.1 Configuration and roles of D75P2 memory .................................................................................... 7- 2
7.1.2 Buffer memory area configuration .................................................................................................. 7- 5
7.2 Data transmission process .................................................................................................................... 7- 6
SECTION 2 CONTROL DETAILS AND SETTING
8. ZERO POINT RETURN CONTROL 8- 1 to 8- 24
8.1 Outline of zero point return control ........................................................................................................ 8- 2
8.1.1 Three types of zero point return control ......................................................................................... 8- 2
8.2 Machine zero point return ...................................................................................................................... 8- 4
8.2.1 Outline of the machine zero point return operation........................................................................ 8- 4
8.2.2 Machine zero point return method.................................................................................................. 8- 5
8.2.3 Zero point return method (1): Near-point dog method ................................................................... 8- 6
8.2.4 Zero point return method (2): Stopper stop method 1) .................................................................. 8- 8
8.2.5 Zero point return method (3): Stopper stop method 2) ................................................................... 8- 11
8.2.6 Zero point return method (4): Stopper stop method 3) ................................................................... 8- 14
8.2.7 Zero point return method (5): Count method 1) .............................................................................. 8- 16
8.2.8 Zero point return method (6): Count method 2) .............................................................................. 8- 18
8.3 Data setting method zero point return .................................................................................................... 8- 20
8.4 High-speed zero point return .................................................................................................................. 8- 21
8.4.1 Outline of the high-speed zero point return operation .................................................................... 8- 21
8.5 Positioning to the zero point ................................................................................................................... 8- 23
9. MAIN POSITIONING CONTROL 9- 1 to 9- 62
9.1 Outline of main positioning controls....................................................................................................... 9- 2
9.1.1 Data required for main positioning control...................................................................................... 9- 3
9.1.2 Operation patterns of main positioning controls............................................................................. 9- 4
9.1.3 Designating the positioning address................................................................................................ 9- 14
9.1.4 Confirming the current value............................................................................................................ 9- 15
9.1.5 Control unit "degree" handling ......................................................................................................... 9- 17
9.1.6 Interpolation control.......................................................................................................................... 9- 19
9.2 Setting the positioning data ................................................................................................................... 9- 22
9.2.1 Relation between each control and positioning data ...................................................................... 9- 22
9.2.2 1-axis linear control .......................................................................................................................... 9- 23
9.2.3 2-axis linear interpolation control ..................................................................................................... 9- 25
9.2.4 1-axis fixed-dimension feed control ................................................................................................. 9- 29
9.2.5 2-axis fixed-dimension feed control (interpolation) ........................................................................ 9- 31
9.2.6 2-axis circular interpolation control with auxiliary point designation ............................................... 9- 33
9.2.7 2-axis circular interpolation control with center point designation .................................................. 9- 39
9.2.8 Speed control ................................................................................................................................... 9- 46
9.2.9 Speed/position changeover control ................................................................................................. 9- 48
9.2.10 Current value change..................................................................................................................... 9- 56
9.2.11 JUMP command............................................................................................................................. 9- 60

A - 12
10. ADVANCED POSITIONING CONTROL 10- 1 to 10- 22
10.1 Outline of advanced positioning control ............................................................................................ 10- 2
10.1.1 Data required for advanced positioning control ......................................................................... 10- 3
10.1.2 "Start block data" and "condition data" configuration................................................................. 10- 4
10.2 Advanced positioning control execution procedure ........................................................................ 10- 6
10.3 Setting the start block data ................................................................................................................ 10- 7
10.3.1 Relation between various controls and start block data ............................................................ 10- 7
10.3.2 Block start (normal start) ........................................................................................................... 10- 8
10.3.3 Condition start .............................................................................................................................. 10- 10
10.3.4 Wait start....................................................................................................................................... 10- 11
10.3.5 Simultaneous start ...................................................................................................................... 10- 12
10.3.6 Stop............................................................................................................................................... 10- 13
10.3.7 Repeated start (FOR loop) ......................................................................................................... 10- 14
10.3.8 Repeated start (FOR condition) ................................................................................................. 10- 15
10.3.9 Restrictions when using the NEXT start...................................................................................... 10- 16
10.4 Setting the condition data ................................................................................................................... 10- 17
10.4.1 Relation between various controls and the condition data ......................................................... 10- 17
10.4.2 Condition data setting examples ................................................................................................. 10- 19
10.5 Starting advanced positioning control ................................................................................................ 10- 20
10.5.1 Starting advanced positioning control ......................................................................................... 10- 20
10.5.2 Example of start program for advanced positioning control ....................................................... 10- 21
11. MANUAL CONTROL 11- 1 to 11- 22
11.1 Outline of manual control ................................................................................................................. 11- 2
11.1.1 Two manual control methods ..................................................................................................... 11- 2
11.2 JOG operation.................................................................................................................................... 11- 4
11.2.1 Outline of JOG operation ............................................................................................................ 11- 4
11.2.2 JOG operation execution procedure .......................................................................................... 11- 7
11.2.3 Setting the required parameters for JOG operation................................................................... 11- 8
11.2.4 Creating start programs for JOG operation................................................................................. 11- 10
11.2.5 JOG operation example ............................................................................................................... 11- 12
11.3 Manual pulse generator operation...................................................................................................... 11- 16
11.3.1 Outline of manual pulse generator operation.............................................................................. 11- 16
11.3.2 Manual pulse generator operation execution procedure ............................................................ 11- 19
11.3.3 Setting the required parameters for manual pulse generator operation .................................... 11- 20
11.3.4 Starting the manual pulse generator operation........................................................................... 11- 21
12. CONTROL AUXILIARY FUNCTIONS 12- 1 to 12- 82
12.1 Outline of auxiliary functions.............................................................................................................. 12- 2
12.1.1 Outline of auxiliary functions ....................................................................................................... 12- 2
12.2 Auxiliary functions specifically for machine zero point returns ......................................................... 12- 4
12.2.1 Zero point return retry function ................................................................................................... 12- 4
12.2.2 Zero point shift function ............................................................................................................. 12- 8
12.3 Functions for compensating the control ............................................................................................. 12- 11
12.3.1 Backlash compensation function ................................................................................................. 12- 11
12.3.2 Electronic gear function ............................................................................................................... 12- 13

A - 13
12.3.3 Near pass mode function ............................................................................................................. 12- 18
12.4 Functions to limit the control ............................................................................................................... 12- 22
12.4.1 Speed limit function...................................................................................................................... 12- 22
12.4.2 Torque limit function..................................................................................................................... 12- 24
12.4.3 Software stroke limit function ....................................................................................................... 12- 27
12.4.4 Hardware stroke limit function ..................................................................................................... 12- 33
12.5 Functions to change the control details.............................................................................................. 12- 35
12.5.1 Speed change function ................................................................................................................ 12- 35
12.5.2 Override function .......................................................................................................................... 12- 40
12.5.3 Acceleration/deceleration time change function .........................................................................12- 42
12.5.4 Torque change function ............................................................................................................... 12- 45
12.6 Absolute position restoration function ................................................................................................ 12- 47
12.7 Other functions .................................................................................................................................... 12- 53
12.7.1 Step function................................................................................................................................. 12- 53
12.7.2 Skip function ................................................................................................................................. 12- 58
12.7.3 M code output function................................................................................................................. 12- 60
12.7.4 Teaching function......................................................................................................................... 12- 64
12.7.5 Command in-position function ..................................................................................................... 12- 69
12.7.6 Stepping motor mode function..................................................................................................... 12- 72
12.7.7 Acceleration/deceleration processing function............................................................................ 12- 75
12.7.8 Indirectly specification function .................................................................................................... 12- 78
13. COMMON FUNCTIONS 13- 1 to 13- 10
13.1 Outline of common functions ............................................................................................................. 13- 2
13.2 Parameter initialization function......................................................................................................... 13- 3
13.3 Execution data backup function ........................................................................................................ 13- 5
13.4 LED display function .......................................................................................................................... 13- 7
13.5 Clock data function.............................................................................................................................. 13- 10
14. TROUBLESHOOTING 14- 1 to 14- 40
14.1 Troubleshooting when the "ERR" LED on the Master Module is Flashing ...................................... 14- 2
14.2 Error and warning details................................................................................................................... 14- 4
14.3 List of errors ....................................................................................................................................... 14- 8
14.4 List of warnings ................................................................................................................................... 14- 34
14.5 Start during error history ..................................................................................................................... 14- 40
APPENDICES Appendix- 1 to Appendix- 62
Appendix 1 Change with Upgrade.................................................................................................. Appendix- 2
Appendix 2 External dimension drawing ........................................................................................ Appendix- 3
Appendix 3 Format sheets ............................................................................................................ Appendix- 4
Appendix 3.1 Positioning module operation chart .................................................................... Appendix- 4
Appendix 3.2 Parameter setting value entry table ..................................................................... Appendix- 6
Appendix 3.3 Positioning data setting value entry table ............................................................Appendix- 12
Appendix 4 Positioning data (No. 1 to 100), List of buffer memory addresses ............................Appendix- 13

A - 14
Appendix 5 Connection examples with servo amplifiers manufactured
by MITSUBISHI Electric Coporation ............................................................................Appendix- 16
Appendix 5.1 Connection example of D75P2 and MR-H A
(Differential driver (Open collector)) ......................................................................Appendix- 16
Appendix 5.2 Connection example of D75P2 and MR-J2/J2S- A
(Differential driver (Open collector)) ......................................................................Appendix- 18
Appendix 5.3 Connection example of D75P2 and MR-C A
(Differential driver (Open collector)) ....................................................................Appendix- 20
Appendix 6 Connection examples with stepping motors manufactured
by ORIENTALMOTOR Co., Ltd. ..................................................................................Appendix- 21
Appendix 6.1 Connection example of D75P2 and VEXTA UPD (Open collector).....................Appendix- 21
Appendix 7 Connection examples with servo amplifiers manufactured
by Panasonic Co., Ltd. .................................................................................................Appendix- 22
Appendix 7.1 Connection example of D75P2 and MINAS-A series (Differential driver) ...........Appendix- 22
Appendix 8 Connection examples with servo amplifiers manufactured
by SANYO DENKI Co., Ltd. .........................................................................................Appendix- 23
Appendix 8.1 Connection example of D75P2 and PYO series (Differential driver) ...................Appendix- 23
Appendix 9 Connection examples with servo amplifiers manufactured
by YASKAWA Electric Corporation..............................................................................Appendix- 24
Appendix 9.1 Connection example of D75P2 and - series (Differential driver) ....................Appendix- 24
Appendix 10 Comparisons with A1SD75P -S3 and AD75P -S3 modules ................................Appendix- 25
Appendix 11 MELSEC Explanation of positioning terms................................................................Appendix- 27
Appendix 12 Positioning control troubleshooting ............................................................................Appendix- 49
Appendix 13 List of buffer memory addresses................................................................................Appendix- 55
INDEX Index- 1 to Index- 10

A - 15
ABOUT MANUALS
The following manuals are also related to this product.
In necessary, order them by quoting the details in the tables below.
Related Manuals
Manual Name Manual Number
(Model Code)
AJ65BT-D75P2-S3 Positioning Module User's Manual (Hardware)
This manual describes performance specifications, input/output interface, names of each part and
startup procedures of the AJ65BT-D75P2-S3 positioning module. (enclosed with module)
IB-66829
(13JL48)
CC-Link System Master/Local Module Type AJ61BT11/A1SJ61BT11 User's Manual
This manual describes the system configuration, performance specifications, functions, handling, wiring
and troubleshooting of the AJ61BT11 and A1SJ61BT11 (sold separately).
IB-66721
(13J872)
CC-Link System Master/Local Module Type AJ61QBT11/A1SJ61QBT11 User's Manual
This manual describes the system configuration, performance specifications, functions, handling, wiring
and troubleshooting of the AJ61QBT11 and A1SJ61QBT11 (sold separately).
IB-66722
(13J873)
MELSEC-Q CC-Link System Master/Local Module User's Manual
This manual describes the system configuration, performance specifications, functions, handling, wiring
and troubleshooting of the QJ61BT11N (sold separately).
SH-080394E
(13JR64)
MELSEC-L CC-Link System Master/Local Module User's Manual
This manual describes system configuration, performance specifications, functions, handling, wiring, and
troubleshooting of the LCPU with built-in CC-Link (sold separately).
SH-080895ENG
(13JZ41)
MELSEC iQ-R CC-Link System Master/Local Module User's Manual (Application)
This manual describes functions, parameter settings, programming, troubleshooting, I/O signals, and
buffer memory of the CC-Link system master/local module (sold separately).
SH-081270ENG
(13JX19)
Type AnSHCPU/AnACPU/AnUCPU/QCPU-A (A Mode) Programming Manual (Dedicated
Instructions)
This manual describes the instructions extended for the AnSHCPU/AnACPU/AnUCPU/QCPU-A (A
Mode) (sold separately).
IB-66251
(13J742)
QnACPU Programming Manual (Special Function Module)
This manual describes dedicated instructions for the special function modules (sold separately).
SH-4013
(13JF56)
MELSEC iQ-R Programming Manual (Instructions, Standard Functions/Function Blocks)
This manual describes instructions for the CPU module, dedicated instructions for the intelligent function
modules, and standard functions/function blocks (sold separately).
SH-081266ENG
---
Positioning module software package type SW1IVD-AD75P Operating Manual
This manual describes the methods of creating data (such as parameters and positioning data.),
transmitting the data to the module, monitoring the positioning and testing, using the above software
package (enclosed with each software package product).
IB-66714
(13J915)
GX Configurator-AP Version 1 Operating Manual
This manual describes the methods of creating data (such as parameters and positioning data),
transmitting the data to the module, monitoring the positioning and testing, using the above software
package (sold separately)*1.
IB-66900
(13J948)
*1 This manual is stored in the CD-ROM of the software package as PDF file.
For those who would like to order the manual separately, the printed version is optionally available and so
please ask it with the manual number (model code) in the table above.

A - 16
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low
Voltage Directives when incorporated into other machinery or equipment, certain
measures may be necessary. Please refer to one of the following manuals.
User's manual for the CPU module or head module used
Safety Guidelines
(This manual is included with the CPU module, base unit, or head module.)
The CE mark on the side of the programmable controller indicates compliance
with EMC and Low Voltage Directives.
(2) Additional measures
To ensure that this product maintains EMC and Low Voltage Directives, please
refer to one of the manuals listed under (1).

A - 17
USING THIS MANUAL (1)
The symbols used in this manual are shown below.
Unless otherwise specified, the "buffer memory" indicates the buffer memory of
the D75P2.
M
....... Symbol indicating master module buffer memory address.
Pr.*
....... Symbol indicating positioning parameter and zero point return
parameter item.
Da.*
....... Symbol indicating positioning data, start block data and condition
data item.
Md.*
....... Symbol indicating monitor data item.
Cd.*
....... Symbol indicating control data item.
(A serial No. is inserted in the * mark.)
Indication of values in this manual
The buffer memory address, error code and warning code are indicated in a
decimal value.
The X/Y device is indicated in a hexadecimal value.
The setting data and monitor data is indicated in a decimal or hexadecimal value.
An “H” attached at the end of the value indicates a hexadecimal value.
(Examples)
10 Decimal
10HHexadecimal

A - 18
USING THIS MANUAL (2)
The methods for reading this manual are shown below.
5.1 Types of data
5.2 List of parameters
5.3 List of positioning data
5.4 List of start block data
5.5 List of condition data
5.6 List of monitor data
5.7 List of control data
Chapter 7 MEMORY CONFIGURATION
AND DATA PROCESS
Chapter 6 SEQUENCE PROGRAM USED
FOR POSITIONING CONTROL Chapter 14 TROUBLESHOOTING
Chapter 13 COMMON FUNCTIONS
SECTION 1 PRODUCT SPECIFICATIONS AND HANDLING
Chapter 1 PRODUCT OUTLINE
Chapter 2 SYSTEM CONFIGURATION
Chapter 3 SPECIFICATIONS AND
FUNCTIONS
Chapter 4 INSTALLATION, WIRING
AND MAINTENANCE OF
THE PRODUCT
Chapter 5 DATA USED FOR
POSITIONING CONTROL
SECTION 2 CONTROL DETAILS AND SETTING
Chapter 8 ZERO POINT RETURN
CONTROL
Chapter 9 MAIN POSITIONING
CONTROL
Chapter 10 ADVANCED
POSITIONING CONTROL
Chapter 11 MANUAL CONTROL
Chapter 12 CONTROL AUXILIARY
FUNCTIONS
*Understand the data process in the D75P2 as necessary.
6) Remedies for "Errors" and "Warnings"
5) Create a sequence program for control
4) While referring to lists in "SECTION 2" and "Chapter 5",
set the data required for each control
3) Set the parameters
2) Install and wire the product
1) 2) 3) 4) 5) Test operation 6) Actual operation
1) Understand the product functions and specifications,
and design the system.
