Mitsubishi Electric C80 Series User manual

Introduction
This manual covers the items required for maintaining the MITSUBISHI CNC C80 Series.
Read this manual thoroughly and understand the product's functions and performance before starting to use.
The unit names, cable names and various specifications are subject to change without notice. Please confirm these before
placing an order.
Be sure to keep this manual always at hand.
CAUTION
For items described as "Restrictions" or "Usable State" in this manual, the instruction manual issued by the
machine tool builder (MTB) takes precedence over this manual.
Items not described in this manual must be interpreted as "not possible".
This manual is written on the assumption that all the applicable functions are included. Some of them, however,
may not be available for your NC system. Refer to the specifications issued by the machine tool builder before
use.
Refer to the manuals issued by the machine manufacturer for each machine tool explanation.
Some screens and functions may differ depending on the NC system (or its version), and some functions may
not be possible. Please confirm the specifications before use.
Do not connect NC system to the Internet-connected network.
To maintain the safety of the NC system against unauthorized access from external devices via the network,
take appropriate measures.
In this manual, the following abbreviations might be used.
MTB: Machine tool builder
Also refer to the manuals on "Manual List" as necessary.

Manual List
Manuals related to M800/M80/E80/C80 Series are listed as follows.
These manuals are written on the assumption that all optional functions are added to the targeted model.
Some functions or screens may not be available depending on the machine or specifications set by MTB. (Confirm the
specifications before use.)
The manuals issued by MTB take precedence over these manuals.
Manual IB No. Purpose and Contents
M800/M80/E80 Series
Instruction Manual IB-1501274 Operation guide for NC
Explanation for screen operation, etc.
C80 Series
Instruction Manual IB-1501453 Operation guide for NC
Explanation for screen operation, etc.
M800/M80/E80/C80 Series
Programming Manual
(Lathe System) (1/2)
IB-1501275 G code programming for lathe system
Basic functions, etc.
M800/M80/E80/C80 Series
Programming Manual
(Lathe System) (2/2)
IB-1501276 G code programming for lathe system
Functions for multi-part system, high-accuracy function, etc.
M800/M80/E80/C80 Series
Programming Manual
(Machining Center System) (1/2)
IB-1501277 G code programming for machining center system
Basic functions, etc.
M800/M80/E80/C80 Series
Programming Manual
(Machining Center System) (2/2)
IB-1501278 G code programming for machining center system
Functions for multi-part system, high-accuracy function, etc.
M800/M80/E80/C80 Series
Alarm/Parameter Manual IB-1501279 Alarms
Parameters

Manuals for MTBs (NC)
Manuals for MTBs (drive section)
Manual IB No. Purpose and Contents
M800/M80/E80/C80 Series
Specifications Manual (Function) IB-1501505 Model selection
Outline of various functions
M800/M80/E80/C80 Series
Specifications Manual (Hardware) IB-1501506 Model selection
Specifications of hardware unit
M800W/M80W Series
Connection and Setup Manual IB-1501268 Detailed specifications of hardware unit
Installation, connection, wiring, setup (startup/adjustment)
M800S/M80/E80 Series
Connection and Setup Manual IB-1501269 Detailed specifications of hardware unit
Installation, connection, wiring, setup (startup/adjustment)
C80 Series
Connection and Setup Manual IB-1501452 Detailed specifications of hardware unit
Installation, connection, wiring, setup (startup/adjustment)
M800/M80/E80 Series
PLC Development Manual IB-1501270
Electrical design
I/O relation (assignment, setting, connection), field network
Development environment (PLC on-board, peripheral
development environment), etc.
M800/M80/E80 Series
PLC Programming Manual IB-1501271
Electrical design
Sequence programming
PLC support functions, etc.
M800/M80/E80/C80 Series
PLC Interface Manual IB-1501272 Electrical design
Interface signals between NC and PLC
M800/M80/E80 Series
Maintenance Manual IB-1501273 Cleaning and replacement for each unit
Other items related to maintenance
C80 Series
Maintenance Manual IB-1501454 Cleaning and replacement for each unit
Other items related to maintenance
Manual IB No. Contents
MDS-E/EH Series
Specifications Manual IB-1501226 Specifications for power supply regeneration type
MDS-E/EH Series
Instruction Manual IB-1501229 Instruction for power supply regeneration type
MDS-EJ/EJH Series
Specifications Manual IB-1501232 Specifications for regenerative resistor type
MDS-EJ/EJH Series
Instruction Manual IB-1501235 Instruction for regenerative resistor type
MDS-EM/EMH Series
Specifications Manual IB-1501238 Specifications for multi-hybrid, power supply regeneration type
MDS-EM/EMH Series
Instruction Manual IB-1501241 Instruction for multi-hybrid, power supply regeneration type
DATA BOOK IB-1501252 Specifications of servo drive unit, spindle drive unit, motor, etc.

Manuals for MTBs (Others)
■For M800/M80/E80 Series
■For C80 Series
Manual No. Purpose and Contents
GOT2000 Series User’s Manual
(Hardware) SH-081194 Outline of hardware such as part names, external dimensions,
installation, wiring, maintenance, etc. of GOTs
GOT2000 Series User’s Manual
(Utility) SH-081195 Outline of utilities such as screen display setting, operation method, etc. of GOTs
GOT2000 Series User’s Manual
(Monitor) SH-081196 Outline of each monitor function of GOTs
GOT2000 Series Connection
Manual (Mitsubishi Electric
Products)
SH-081197 Outline of connection types and connection method between
GOT and Mitsubishi Electric connection devices
GT Designer3 (GOT2000) Screen
Design Manual SH-081220 Outline of screen design method using screen creation
software GT Designer3
Manual No. Purpose and Contents
GOT2000/GOT1000 Series CC-Link
Communication Unit User's Manual IB-0800351 Explanation for handling CC-Link communication unit (for GOT2000 series/GOT1000 series)
GX Developer Version 8 Operating
Manual (Startup) SH-080372E Explanation for system configuration, installation, etc. of PLC
development tool GX Developer
GX Developer Version 8 Operating
Manual SH-080373E Explanation for operations using PLC development tool GX Developer
GX Converter Version 1 Operating
Manual IB-0800004E Explanation for operations using data conversion tool GX Converter
MELSEC-Q CC-Link System Master/
Local Module User’s Manual SH-080394E Explanation for system configuration, installation, wiring, etc.
of master/local modules for CC-Link system
GOT2000 Series Connection
Manual (Non-Mitsubishi Electric
Products 1)
SH-081198ENG
Explanation for connection types and connection method
between GOT and other company's devices
GOT2000 Series Connection
Manual (Non-Mitsubishi Electric
Products 2)
SH-081199ENG
GOT2000 Series Connection
Manual (Microcomputers, MODBUS/
Fieldbus Products, Peripherals)
SH-081200ENG
Explanation for connection types and connection method
between GOT and microcomputers, MODBUS/fieldbus
products, peripherals
GT SoftGOT2000 Version1
Operating Manual SH-081201ENG
Explanation for system configuration, screen configuration
and operation method of monitoring software GT
SoftGOT2000
Manual No. Purpose and Contents
MELSEC iQ-R Module Configuration
Manual SH-081262 Outline of system configuration, specifications, installation, wiring, maintenance, etc.
MELSEC iQ-R CPU Module User’s
Manual (Startup) SH-081263 Outline of specifications, procedures before operation, troubleshooting, etc. for CPU module
MELSEC iQ-R CPU Module User’s
Manual (Application) SH-081264 Outline of memory, functions, devices, parameters, etc. for
CPU module
QCPU User’s Manual (Hardware
Design, Maintenance and
Inspection)
SH-080483
Outline of specifications, necessary knowledge to configure
the system and maintenance-related descriptions for Q series
CPU module, etc.
GX Works3 Operating Manual SH-081215 Outline of functions, programming, etc.

Reference Manual for MTBs
Manual No. Purpose and Contents
M800/M80 Series Smart safety
observation Specification manual BNP-C3072-022
Explanation for smart safety observation function
C80 Series Smart safety observation
Specification manual BNP-C3077-022
M800/M80 Series CC-Link (Master/
Local) Specification manual BNP-C3072-089 Explanation for CC-Link
M800/M80 Series PROFIBUS-DP
Specification manual BNP-C3072-118 Explanation for PROFIBUS-DP communication function
M800/M80 Series Interactive cycle
insertion (Customization)
Specification manual
BNP-C3072-121-
0003 Explanation for interactive cycle insertion
M800/M80 Series EtherNet/IP
Specifications manual BNP-C3072-263 Explanation for EtherNet/IP

Precautions for Safety
Always read the specifications issued by the MTB, this manual, related manuals and attached documents before installation,
operation, programming, maintenance or inspection to ensure correct use. Understand this numerical controller, safety items
and cautions before using the unit.
This manual ranks the safety precautions into "DANGER", "WARNING" and "CAUTION".
Note that even items ranked as " CAUTION", may lead to major results depending on the situation. In any case, important
information that must always be observed is described.
The following sings indicate prohibition and compulsory.
The meaning of each pictorial sing is as follows.
DANGER
When the user may be subject to imminent fatalities or major injuries if handling is mistaken.
WARNING
When the user may be subject to fatalities or major injuries if handling is mistaken.
CAUTION
When the user may be subject to bodily injury or when physical damage may occur if handling is mistaken.
This sign indicates prohibited behavior (must not do).
For example, "Keep fire away" is indicated by .
This sign indicates a thing that is critical (must do).
For example, "it must be grounded" is indicated by .
CAUTION CAUTION rotate ob-
ject
CAUTION HOT Danger Electric
shock risk
Danger explosive
Prohibited
Disassembly is pro-
hibited
KEEP FIRE AWAY General instruction Earth ground

MITSUBISHI CNC is designed and manufactured solely for applications to machine tools to be used for industrial purpos-
es.
Do not use this product in any applications other than those specified above, especially those which are substantially in-
fluential on the public interest or which are expected to have significant influence on human lives or properties.
1. Items related to prevention of electric shocks
2. Items related to prevention of fire
For Safe Use
WARNING
Do not open or remove the front cover while the power is ON or during operation. The high voltage terminals
and charged sections are exposed, and this could result in electric shocks.
Do not remove the front cover even when the power is OFF, except for the wiring works or periodic inspec-
tions. The inside of the controller and drive unit are charged, and this could result in electric shocks.
Always wait at least 15 minutes after turning the power OFF. Then, check the voltage with a tester, etc., be-
fore wiring works, inspections or connecting with peripheral devices. Failure to observe this could result in
electric shocks.
Earth ground the controller, drive unit and motor according to the local laws. (In Japan, ground the 200V
Series input products with Class C or higher protective grounding and the 400V Series input with Class D
or higher protective grounding.)
All wiring works, maintenance and inspections must be carried out by a qualified technician. Failure to ob-
serve this could result in electric shocks. Contact your nearby Service Center or Service Station for replac-
ing parts and servicing.
Wire the controller, drive unit and motor after installation. Failure to observe this could result in electric
shocks.
Do not operate the switches with wet hands. Failure to observe this could result in electric shocks.
Do not damage, apply excessive stress, place heavy things on or sandwich the cables. Failure to observe
this could result in electric shocks.
Insulate the power lead using a fixed terminal block. Failure to observe this could result in electric shocks.
Completely turn off the externally supplied power used in the system before wiring. Not doing so could re-
sult in electric shock or damage to the product.
When turning on the power supply or operating the module after wiring, be sure that the module's terminal
covers are correctly attached. Not attaching the terminal cover could result in electric shock.
CAUTION
Install the controller, drive unit, motor and regenerative resistor on non-combustible material. Installation
directly on or near combustible materials could result in fires.
If any malfunction in the unit is observed, shut off the power at the unit’s power supply side. Continuous
flow of large current could result in fires.
Install an appropriate no fuse breaker (NFB) and contactor (MC) on the power input section of the drive unit
and configure the sequence that shuts the power off upon drive unit’s emergency stop or alarm.
When a breaker is shared for multiple power supply units, the breaker may not function upon short-circuit
failure in a small capacity unit. Do not share a breaker for multiple units as this is dangerous.
Incorrect wiring and connections could cause the devices to damage or burn.

3. Items related to prevention of bodily injury or property damage
4. Other items
Always follow the precautions below as well. Incorrect handling could result in faults, injuries or electric shocks, etc.
(1) Product and manual
(2) Transportation and installation
DANGER
When transporting or installing a built-in IPM spindle or linear servomotor, be careful so that your hand or
property is not trapped in the motors or other metal objects. Also keep the devices with low magnetic tol-
erance away from the product.
CAUTION
Do not apply voltages to the connectors or terminals other than voltages indicated in the connection and
setup manual for the controller or specifications manual for the drive unit. Failure to observe this could
cause bursting, damage, etc.
Incorrect connections could cause the devices to rupture or damage, etc. Always connect the cables to the
indicated connectors or terminals.
Incorrect polarity (+ -) could cause the devices to rupture or damage, etc.
Persons wearing medical devices, such as pacemakers, must stay away from this unit. The electromagnetic
waves could adversely affect the medical devices.
Fins on the rear of the unit, regenerative resistor and motor, etc., may be hot during operation and for a
while after the power has been turned OFF. Do not touch or place the parts and cables, etc. close to these
sections. Failure to observe this could result in burns.
Do not enter the machine’s movable range during automatic operation. Keep your hands, feet or face away
from the spindle during rotation.
CAUTION
For items described as "Restrictions" or "Usable State" in this manual, the instruction manual issued by
the machine tool builder (MTB) takes precedence over this manual.
Items not described in this manual must be interpreted as "not possible"
This manual is written on the assumption that all the applicable functions are included. Some of them, how-
ever, may not be available for your NC system. Refer to the specifications issued by the machine tool build-
er before use.
Refer to the manuals issued by the machine manufacturer for each machine tool explanation.
Some screens and functions may differ depending on the NC system (or its version), and some functions
may not be possible. Please confirm the specifications before use.
Do not connect NC system to the Internet-connected network.
To maintain the safety of the NC system against unauthorized access from external devices via the network,
take appropriate measures.
CAUTION
Correctly transport the products according to the mass.
Use motor’s suspension bolts to transport the motor itself. Do not use it to transport the motor after instal-
lation onto the machine.
Do not stack the products exceeding the indicated limit.
Do not hold the cables, shaft or detector when transporting the motor.

Do not transport the controller or drive unit by suspending or holding the connected wires or cables.
Do not hold the front cover when transporting the unit, or the front cover could come off, causing the unit
to drop.
Install on a non-combustible place where the unit's or motor's mass can be withstood according to the in-
struction manual.
The motor does not have a complete water-proof (oil-proof) structure. Do not allow oil or water to contact
or enter the motor. Prevent the cutting chips from being accumulated on the motor as they easily soak up
oil.
When installing the motor facing upwards, take measures on the machine side so that gear oil, etc., will not
enter the motor shaft.
Do not remove the detector from the motor. (The detector installation screw is treated with sealing.)
Do not allow foreign matters, especially, conductive foreign matters such as screws or metal chips, or com-
bustible foreign matters such as oil, to enter the controller, drive unit or motor. Failure to observe this could
result in rupture or damage.
Do not get on the product or place heavy objects on it.
Provide prescribed distance between the controller/drive unit and inner surface of the control panel/other
devices.
Do not install or operate the controller, drive unit or motor that is damaged or has missing parts.
Take care not to cut hands, etc. with the heat radiating fins or metal edges.
Do not block the intake/outtake ports of the motor with the cooling fan.
Install the controller’s display section and operation board section on the spot where cutting oil will not
reach.
The controller, drive unit and motor are precision devices, so do not drop or apply thumping vibration and
strong impacts on them.
Store and use the units according to the environment conditions indicated in each specifications manual.
When disinfectants or insecticides must be used to treat wood packaging materials, always use methods
other than fumigation (for example, apply heat treatment at the minimum wood core temperature of 56 °C
for a minimum duration of 30 minutes (ISPM No. 15 (2009))).
If products such as units are directly fumigated or packed with fumigated wooden materials, halogen sub-
stances (including fluorine, chlorine, bromine and iodine) contained in fumes may contribute to the erosion
of the capacitors. When exporting the products, make sure to comply with the laws and regulations of each
country.
Do not use the products in conjunction with any components that contain halogenated flame retardants
(bromine, etc). Failure to observe this may cause the erosion of the capacitors.
Securely fix the motor to the machine. The motor could come off during operation if insecurely fixed.
Always install the motor with reduction gear in the designated direction. Failure to observe this could result
in oil leaks.
Always install a cover, etc., over the shaft so that the rotary section of the motor cannot be touched during
motor rotation.
When installing a coupling to the servomotor shaft end, do not apply impacts by hammering, etc. The de-
tector could be damaged.
Use a flexible coupling when connecting with a ball screw, etc., and keep the shaft core deviation smaller
than the tolerable radial load of the shaft.
Do not use a rigid coupling as an excessive bending load may be applied on the shaft and could cause the
shaft to break.
Do not apply a load exceeding the tolerable level onto the motor shaft. The shaft or bearing could be dam-
aged.
Before using this product after a long period of storage, please contact the Mitsubishi Service Station or
Service Center.
CAUTION

(3) Items related to wiring
Following the UN recommendations, battery units and batteries should be transported based on the inter-
national regulations such as those determined by International Civil Aviation Organization (ICAO), Interna-
tional Air Transport Association (IATA), International Maritime Organization (IMO) and U.S. Department of
Transportation (DOT).
Due to ventilation problems, do not install the base units vertically or horizontally when C80 is mounted on
a board, etc.
Install the basic base unit on a flat surface. Unevenness or warping of the surface can apply undue force to
printed circuit boards and lead to operation failures.
Avoid fitting basic unit in proximity to vibration sources such as large electromagnetic contractors and no-
fuse circuit breakers; fit the unit on a separate panel or at a distance.
To limit the effects of reflected noise and heat, leave 100mm or more clearance to instruments fitted in front
of CNC CPU (on the rear of the door). Similarly, leave 50mm or more clearance between instruments and
the left and right sides of the basic base unit.
CAUTION
Correctly wire this product. Failure to observe this could result in motor runaway, etc.
Incorrect connections could cause devices to damage. Connect the cables to designated connectors.
Do not install a phase advancing capacitor, surge absorber or radio noise filter on the output side of the
drive unit.
Correctly connect the output side (terminal U, V, W). The motor will not run properly if incorrectly connect-
ed.
Always install an AC reactor per each power supply unit.
Always install an appropriate breaker per each power supply unit. A breaker cannot be shared for multiple
power supply units.
Do not directly connect a commercial power supply to the motor. Failure to observe this could result in
faults.
When using an inductive load such as relays, always connect a diode in parallel to the load as a noise
countermeasure.
When using a capacitive load such as a lamp, always connect a protective resistor serially to the load to
suppress rush currents.
Do not mistake the direction of the surge absorption diode to be installed on the DC relay for the control
output signal. If mistaken, the signal will not be output due to fault in the drive unit, and consequently the
protective circuit, such as emergency stop, could be disabled.
Do not connect or disconnect the connection cables between each unit while the power is ON.
Do not connect or disconnect the PCBs while the power is ON.
Do not pull the cables when connecting/disconnecting them.
Securely tighten the cable connector fixing screw or fixing mechanism. The motor could come off during
operation if insecurely fixed.
Always treat the shield cables indicated in the Connection Manual with grounding measures such as cable
clamps.
Separate the signal wire from the drive line or power line when wiring.
CAUTION
RA RA
COM COM
Control
output
signal
Drive unit
Control
output
signal
Drive unit
(24VDC) (24VDC)

Carry out wiring so that there is no possibility of short circuit between wires, nor of dangerous state.
Use wires and cables whose wire diameter, heat resistance level and bending capacity are compatible with
the system.
Ground the device according to the requirements of the country where the device is to be used.
Wire the heat radiating fins and wires so that they do not contact.
When using the RS-232C device as a peripheral device, caution must be paid for connector connection/dis-
connection. Always use a double-OFF type AC power supply switch on the device side, and connect/dis-
connect the connector with the AC power supply on the device side OFF.
Using a stabilized power supply without overcurrent protection may cause the unit's failure due to miswir-
ing of 24V.
12V, 5V, and 3.3V output from connectors are to supply the power for dedicated peripheral devices. Do not
use for other equipment to supply the power since we do not guarantee the NC operation by voltage down
or noise sneaking.
When using an inductive load such as a relay, always connect a diode in parallel to the load to prevent a
counter-electromotive force.
When the rush current exceeds the maximum output current, always connect a protective resistor serially
to the load to suppress rush currents.
The wires from the surge absorber should be connected without extensions.
Be sure to ground the earth terminal FG and LG with Class D or higher grounding (Ground resistance: 100Ω
or less). Otherwise it may cause electric shock or operation failure.
When wiring in the unit, be sure that it is done correctly by checking the product's rated voltage and the
terminal layout. Connecting a power supply that is different from the rating or incorrectly wiring the product
could result in fire or damage.
External connections shall be crimped or pressure welded with the specified tools, or correctly soldered.
Imperfect connections could result in short circuit, fire, or operation failure.
Tighten the terminal screws within the specified torque range. If the terminal screws are loose, it could re-
sult in short circuit, fire, or operation failure. Tightening the terminal screws too far may cause damages to
the screws and/or the module, resulting in drop, short circuit, or operation failure.
Be sure there are no foreign matters such as sawdust or wiring debris inside the module. Such debris could
cause fire, damage, or operation failure.
The module has an ingress prevention label on its top to prevent foreign matter, such as wiring debris, from
entering the module during wiring. Do not remove this label during wiring. Before starting system opera-
tion, be sure to remove this label because of heat dissipation.
When connecting to a personal computer and a unit with the USB interface, an electric shock or a unit fail-
ure may occur. It depends on the type of computer to be connected, or the use environment.
Operate these correctly according to the manual of a unit and a personal computer.
Observe the following cautions when a personal computer in an AC power supply is used.
(1) For a personal computer that uses a 3-pin power plug or power plug with a ground lead type, make sure
to use a plug socket including a ground input electrode or ground the earth lead, respectively.
And, ensure to ground a personal computer and a unit with Class D or higher grounding (Ground resis-
tance: 100Ωor less).
(2) For a personal computer that uses a 2-pin power plug without ground lead, make sure to connect the
unit to the personal computer according to the following procedures. And, it is recommended to supply
the same power supply line to a personal computer and the unit.
(a) Pull out the power plug of the personal computer from the AC outlet.
(b) Confirm that the power plug of the personal computer has been pulled out from the AC outlet, and
connect USB cables, the extension cable or the bus connection cable of a GOT.
(c) Insert the power plug of the personal computer into the AC outlet.
CAUTION
RS-232C
NC unit Device Switch AC socket

(4) Set up
(5) Operation and adjustments
WARNING
Do not cancel the emergency stop before confirming the basic operation.
Always set the stored stroke limit. Failure to set this could result in collision with the machine end.
CAUTION
If the battery low warning is issued, save the machining programs, tool data and parameters in an input/
output device, and then replace the battery. When the battery alarm is issued, the machining programs, tool
data and parameters may be destroyed. Reload the data after replacing the battery.
Do not adjust the spindle when possible risks associated with adjustment procedures are not thoroughly
taken into consideration.
Be careful when touching spindle's rotating section, or your hand may be caught in or cut.
It is dangerous to restore the backup data of other machine when the absolute position is established be-
cause the zero point will be established with the absolute position of the linear axis rewritten, thus the zero
point position is off the right position. Initialize the zero point again.
Restoration by SRAM data is available only if the rotary axis motor has not rotated in a same direction
30,000 times or more since the acquisition of the data. Otherwise, the zero point of the rotary axis will
change by turning the power OFF and ON after writing the SRAM data, which will cause danger. Make sure
the zero point is not off the right position. The use of this method should be limited to when necessary, such
as when replacing an NC unit, and requires enough safety confirmation before executing.
CAUTION
If the operation start position is set from a block in the program and the program is started, the program
before the set block is not executed. Please confirm that G and F modal and coordinate values are appro-
priate. If there are coordinate system shift commands or M, S, T and B commands before the block set as
the start position, carry out the required commands using the MDI, etc. If the program is run from the set
block without carrying out these operations, there is a danger of interference with the machine or of ma-
chine operation at an unexpected speed, which may result in breakage of tools or machine tool or may
cause damage to the operators.
Under the constant surface speed control (during G96 modal), if the axis targeted for the constant surface
speed control moves toward the spindle center, the spindle rotation speed will increase and may exceed
the allowable speed of the workpiece or chuck, etc. In this case, the workpiece, etc. may jump out during
machining, which may result in breakage of tools or machine tool or may cause damage to the operators.
Check and adjust programs and each parameter before starting operation. Failure to observe this could re-
sult in unpredictable operations depending on the machine.
Do not make drastic adjustments or changes as the operation could become unstable.
In the explanation on bits, set all bits not used, including blank bits, to "0".

(6) Usage
CAUTION
Use C80 in an environment that meets the general specifications contained in "C80 Series Connection and
Setup Manual". Using C80 in an environment outside the range of the general specifications could result in
electric shock, fire, operation failure, and damage to or deterioration of the product.
When mounting the module, be sure to insert the module fixing hook on the module's bottom into the mod-
ule fixing hole on the base unit. Incorrect mounting could cause an operation failure or a damage/drop of
the unit.
Hold down the module loading lever at the module bottom and securely insert the fixing hook into the fixing
hole in the base unit. Install the module with the module fixing hole as a supporting point. Incorrect mount-
ing could cause an operation failure or a damage/drop of the unit.
Be sure to fix all the modules with screws to prevent them from dropping. The fixing screws (M3 x 12) are
to be prepared by user.
Tighten the screw in the specified torque range. Under tightening may cause a drop, short circuit or oper-
ation failure. Over tightening may cause a drop, short circuit or operation failure due to damage to the screw
or module.
Be sure to install the extension cable to connectors of the basic base unit correctly. After installation, check
them for looseness. Poor connections could cause an input or output failure.
Completely turn off the externally supplied power used in the system before installation or removing the
module. Not doing so could result in electric shock or damage to the product.
Do not install/remove the module on to/from base unit or terminal block more than 50 times, after the first
use of the product. Mounting/dismounting over 50 times may cause an operation failure.
Do not directly touch the module's conductive parts or electronic parts. Touching these parts could cause
an operation failure or give damage to the module.
Do not touch the heat radiating fins of CNC CPU module while the power is ON and for a short time after the
power is turned OFF. In this timing, these parts become very hot and may lead to burns. Remove the mod-
ules with close attention.
When removing the unit, always remove the fixing screws and then take the fixing hook out from the fixing
hole. Incorrect removal will damage the module fixing hook.
When the module fixing screws are used, remove the screws first and module from the base unit. Failure to
do so may damage the module.
The module surface temperature may be high immediately after power-off. When the module is removed,
pay attention to the burn injury.
Install an external emergency stop circuit so that the operation can be stopped and the power turns OFF
immediately when unforeseen situation occurs. A contactor, etc., is required in addition to the shutoff func-
tion mounted in the controller.
Turn OFF the power immediately if any smoke, abnormal noise or odor is generated from the controller,
drive unit or motor.
Only a qualified technician may disassemble or repair this product.
Do not alter.
The metal part becomes the high temperature.

(7) Troubleshooting
Use a noise filter, etc. to reduce the effect of electromagnetic disturbances in the case where electromag-
netic disturbances could adversely affect the electronic devices used near the drive unit.
Use the drive unit, motor and each regenerative resistor with the designated combination. Failure to ob-
serve this could result in fires or faults.
The combination of the motor and drive unit that can be used is determined. Be sure to check the models
of motor and drive unit before test operation.
The brakes (electromagnetic brakes) mounted in the servomotor are used for the purpose of holding, and
must not be used for normal braking. Also, do not run the motor with the motor brake applied. Motor brake
is used for the purpose of holding.
For the system running via a timing belt, install a brake on the machine side so that safety can be ensured.
Be sure to confirm SERVO OFF (or READY OFF) when applying the electromagnetic brake. Also, be sure to
confirm SERVO ON prior to releasing the brake.
When using the DC OFF type electromagnetic brake, be sure to install a surge absorber on the brake termi-
nal.
Do not connect or disconnect the cannon plug while the electromagnetic brake’s power is ON. The cannon
plug pins could be damaged by sparks.
After changing programs/parameters, or after maintenance/inspection, always carry out a test operation be-
fore starting actual operation.
Use the power that are complied with the power specification conditions (input voltage, input frequency,
tolerable instantaneous power failure time) indicated in each specifications manual.
When making detector cables, do not mistake connection. Failure to observe this could result in malfunc-
tion, runaway or fire.
CAUTION
Use a motor with electromagnetic brakes or
establish an external brake mechanism for the
purpose of holding; this serves as counter-
measures for possible hazardous situation
caused by power failure or product fault.
Use a double circuit structure for the electro-
magnetic brake's operation circuit so that the
brakes will activate even when the external
emergency stop signal is issued.
The machine could suddenly restart when the power is restored after an instantaneous power failure, so
stay away from the machine. (Design the machine so that the operator safety can be ensured even if the
machine restarts.)
To secure the absolute position, do not shut off the servo drive unit’s control power supply when its battery
voltage drops (warning 9F) in the servo drive unit side.
If the battery voltage drop warning alarm occurs in the controller side, make sure to back up the machining
programs, tool data and parameters, etc. with the input/output device before replacing the battery. Depend-
ing on the level of voltage drop, memory loss could have happened. In that case, reload all the data backed
up before the alarm occurrence.
CAUTION
MBR EMG
Motor
Electro-
magnetic
brake
Shut off with motor
brake control output
Shut off with CNC brake
control PLC output
24VDC

(8) Maintenance, inspection and part replacement
CAUTION
Periodically back up the programs, tool data and parameters to avoid potential data loss. Also, back up
those data before maintenance and inspections.
The electrolytic capacitor’s capacity will drop due to deterioration. To prevent secondary damage due to
capacitor's faults, Mitsubishi recommends the electrolytic capacitor to be replaced approx. every five years
even when used in a normal environment. Contact the Service Center or Service Station for replacements.
Never perform a megger test (measure the insulation resistance) of the drive unit. Failure to observe this
could lead to faults.
Do not replace parts or devices while the power is ON.
Do not short-circuit, charge, overheat, incinerate or disassemble the battery.
Be careful not to break the heat radiating fins during maintenance or replacement.
Perform the daily and periodic inspections according to the maintenance manual.
Do not place fingers or hands in the clearance when opening or closing any opening.
Periodically replace consumable parts such as batteries according to the instruction manual.
Do not touch the lead sections such as ICs or the connector contacts.
Do not place the controller or servo amplifier on metal that may cause a power leakage or wood, plastic or
vinyl that may cause static electricity buildup.
When replacing the controller or servo amplifier, always set the new unit settings correctly.
After maintenance and inspections are completed, confirm that the position detection of the absolute posi-
tion detector function is correct.
The electrolytic capacitor will generate gas during a fault, so do not place your face near the controller or
servo amplifier.
If an error occurs in the self diagnosis of the controller or servo amplifier, confirm the check details accord-
ing to the instruction manual, and restore the operation.
If an error occurs, remove the cause, secure the safety and then resume operation after alarm release.
The unit may suddenly restart after a power failure is restored, so do not go near the machine. (Design the
machine so that the operator safety can be ensured even if the machine restarts.)
Always turn the power OFF before touching the servomotor shaft or coupled machines, as these parts may
lead to injuries.
Do not go near the machine during test operations or during operations such as teaching. Doing so may
lead to injuries.

(9) Disposal
(10) General precautions
CAUTION
Take the batteries, etc. off from the controller, drive unit and motor, and dispose of them as general indus-
trial wastes.
Do not alter or disassemble controller, drive unit, or motor.
Collect and dispose the spent batteries according to local laws.
Dispose the spent cooling fan according to local laws.
To explain the details, drawings given in the instruction manual, etc., may show the unit with the cover
or safety partition removed. When operating the product, always place the cover or partitions back to
their original position, and operate as indicated in the instruction manual, etc.

Treatment of waste
The following two laws will apply when disposing of this product. Considerations must be made to each law.
The following laws are in effect in Japan. Thus, when using this product overseas, the local laws will have a
priority. If necessary, indicate or notify these laws to the final user of the product.
(1) Requirements for "Law for Promotion of Effective Utilization of Resources"
(a) Recycle as much of this product as possible when finished with use.
(b) When recycling, often parts are sorted into steel scraps and electric parts, etc., and sold to scrap
contractors. Mitsubishi recommends sorting the product and selling the members to appropriate
contractors.
(2) Requirements for "Law for Treatment of Waste and Cleaning"
(a) Mitsubishi recommends recycling and selling the product when no longer needed according to item
(1) above. The user should make an effort to reduce waste in this manner.
(b) When disposing a product that cannot be resold, it shall be treated as a waste product.
(c) The treatment of industrial waste must be commissioned to a licensed industrial waste treatment
contractor, and appropriate measures, including a manifest control, must be taken.
(d) Batteries correspond to "primary batteries", and must be disposed of according to local disposal
laws.
