Mitsubishi Electric QD62E User manual

High-Speed Counter Mod ule
User’s Manual
(Hardware)
QD62
QD62E
QD62D
Thank you for buying the Mitsubishi general-purpose programmable
controller MELSEC-Q Series
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
MODEL QD62 (E/D)-U-H-JE
MODEL
CODE 13JQ69
IB(NA)-0800059-E(0712)MEE
Controller
©1999 MITSUBISHI ELECTRIC CORPORATION

A
-1
DANGER
CAUTION
zSAFETY PRECAUTIONS z
(Always read before starting use)
Before using this product, please read this manual and the relevant manuals introduced in
this manual carefully and pay full attention to safety to handle the product correctly.
The instructions given in this manual are concerned with this product. For the safety
instructions of the programmable controller system, please read the CPU module user's
manual.
In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in medium or slight personal injury or physical damage.
Note that the CAUTION level may lead to a serious consequence according to the
circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please keep this manual in a safe place for future reference and also pass this manual on to
the end user.
[DESIGN PRECAUTIONS]
DANGER
zDepending on the malfunction of the external output transistor, there may be cases
where the output is ON or OFF status. Install external monitoring circuitry for output
signals that may lead to major accidents.
CAUTION
zDo not bunch the control wires or communication cables with the main circuit or power
wires, or install them close to each other.
They should be installed 150 mm(5.9 inch) or more from each other.
Not doing so could result in noise that may cause malfunction.

A
-2
[INSTALLATION PRECAUTIONS]
CAUTION
zUse the programmable controller in an environment that meets the general specifications
contained in the CPU user's manual to use.
Using this programmable controller in an environment outside the range of the general
specifications may cause electric shock, fire, malfunction, and damage to or deterioration
of the product.
zWhen installing the module, securely insert the module fixing tabs into the mounting
holes of the base module while pressing the installation lever located at the bottom of the
module downward.
Improper installation may result in malfunction, breakdown or dropping out of the module.
Securely fix the module with screws if it is subject to vibration during use.
zTighten the screws within the range of specified torque.
If the screws are loose, it may cause fallout, short circuits, or malfunction.
If the screws are tightened too much, it may cause damage to the screw and/or the
module, resulting in fallout, short circuits or malfunction.
zCompletely turn off the externally supplied power used in the system before mounting or
removing the module.
Not doing so could result in damage to the product.
Not doing so may cause electric shock or damage to the module.
zDo not directly touch the conductive area or electronic components of the module.
Doing so may cause malfunction or failure in the module.
[WIRING PRECAUTIONS]
CAUTION
zPerform correct pressure-displacement, crimp-contact or soldering for connector wire
connections using the tools specified by the manufactures.
Attach connectors to the module securely.
zBe careful not to let foreign matters such as sawdust or wire chips get inside the module.
These may cause fires, failure or malfunction.
zThe top surface of the module is covered with protective film to prevent foreign objects
such as cable offcuts from entering the module when wiring.
DO not remove this film until the wiring is complete.
Before operating the system, be sure to remove the film to provide adequate heat
ventilation.
zBe sure to fix communication cables or power supply cables leading from the module by
placing them in the duct or clamping them.
Cables not placed in the duct or without clamping may hang or shift, allowing them to be
accidentally pulled, which may cause a module malfunction and cable damage.
zWhen removing the communication cable from the module, do not pull the cable. When
removing the cable with a connector, hold the connector on the side that is connected to
the module.
Pulling the cable that is still connected to the module may cause malfunction or damage
to the module or cable.
zAlways ground the shielded cable on the encoder side (relay box).
Otherwise, malfunction may occur.
zWhen wiring, be sure to verify the rated voltage of the product as well as the terminal
layout. Fire or failure may result if incorrect voltage is input or incorrect wiring is
performed.
zConnecting terminals with incorrect voltage may result in malfunction or mechanical
failure.

A
-3
Revisions
*The manual number is given on the bottom left of the back cover.
Print Date *Manual Number Revision
Sep., 1999 IB-(NA)-0800059-A First edition
Dec., 1999 IB-(NA)-0800059-B
Addition
Conformation to the EMC Directice and Low Voltage
Instruction
Nov., 2001 IB-(NA)-0800059-C
Partial correction
Contact adress (Back cover)
Sep., 2007 IB-(NA)-0800059-D
Partial correction
SAFETY PRECAUTION, CONTENTS
Chapter 2, 3, 5, Section 5.2, 5.3
Dec., 2007 IB-(NA)-0800059-E
Partial correction
SAFETY PRECAUTION, CONTENTS, Conformation to
the EMC Directive and Low Voltage Instruction
Chapter 2, 4, 5, 6
This manual confers no industrial property rights or any rights of any other kind, nor does it
confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for
any problems involving industrial property rights which may occur as a result of using the
contents noted in this manual.
©1999 MITSUBISHI ELECTRIC CORPORATION

A
-4
CONTENTS
1. Overview ········································································································1
2. Performance Specifications ···········································································2
3. Installation······································································································3
3.1 Handling Precautions ···············································································3
3.2 Handling Environment ··············································································4
4. Part Identification Names ···············································································5
5. External Wiring·······························································································6
5.1 Wiring Precautions ···················································································7
5.2 External Wiring ·························································································8
5.3 Intelligent Function Module Switch Settings ···········································14
6. External Dimensions Diagram······································································14

1
About the Manuals
The following manuals are also related to this product.
Order them if necessary.
Related Manuals
Manual name Manual No.
(Model code)
Model QD62, QD62E, QD62D High-Speed Counter Module
User's Manual
SH-080036
(13JL95)
Conformation to the EMC Directive and Low Voltage Instruction
When incorporating the Mitsubishi programmable controller into other machinery or
system and keeping compliance with the EMC and low voltage directives, refer to
Chapter 3, "EMC Directives and Low Voltage Directives" of the User's Manual (Hardware)
included with the CPU module or base unit used.
The CE logo is printed on the rating plate on the main body of the programmable
controller that conforms to the EMC directive and low voltage instruction.
1. Overview
This user's manual describes the specifications and the part identification
names of the following modules that are used with the CPU module for
MELSEC-Q series: Model QD62 High-speed Counter Module (hereinafter
referred to as QD62), Model QD62E High-speed Counter Module (hereinafter
referred to as QD62E), and Model QD62D High-speed Counter Module
(Hereinafter referred to as QD62D).

2
2. Performance Specifications
The following table shows the performance specifications of the high-speed
counter modules:
Model
Item QD62 QD62E QD62D
Number of I/O
occupied point 16 points (I/O assignment: Intelligent 16 points)
Number of channels 2 channels
Phase 1-phase input, 2-phase input
Count
input
signal
Signal
level 5/12/24 V DC 2 to 5 mA
EIA rated RS-422-A
Differential Line Driver Level
{ AM26LS31 (Texas
Instruments Incorporated) or
equivalent}
Counting
speed
(max) *1
200/100/10 kPPS
(Depends on the Intelligent Function Module switch
settings)
500/200/100/10 kPPS
(Depends on the Intelligent
Function Module switch
settings)
Counting
range 32-bit signed binary (-2147483648 to 2147483647)
Model UP/DOWN Preset counter + Ring counter function
500 kPPS
(QD62D only) 200 kPPS 100 kPPS 10 kPPS
1 1
2
(Min. phase
differential for
2-phase input:
0.5μs)
2. 5 2. 5
5
(Min. phase
differential for
2-phase input:
1.25μs)
5 5
10
(Min. phase
differential for
2-phase input:
2.5μs)
50 50
100
(Min. phase
differential for
2-phase input:
25μs)
Counter
Minimum
count
pulse
width
(Duty ratio
50 %)
Comparis
on range 32-bit signed binary
Coincide
nce
output Comparis
on result Set value < Count value; Set value = Count value; Set value > Count value
Preset
External
input Function
start
5/12/24 V DC 2 to 5 mA
5/12/24 V DC 2-5 mA
(EIA rated RS-422-A
Differential Line Driver may
be connected)
External
output
Coinciden
ce output
Transistor (sink type) output
2 points/channel 12/24 V DC
0.5A/point; 2A/common
Transistor (source type) output
2 points/channel 12/24 V DC
0.1A/point; 0.4A/common
Transistor (sink type) output
2 points/channel 12/24 V DC
0.5A/point; 2A/common
Applicable
connectors
A6CON1 (Soldering type ,straight out); A6CON2 (Solderless type ,straight out);
A6CON3 (Pressure welding type ,straight out); A6CON4 (Soldering type ,usable for
straight out and diagonal out)
5 V DC internal
current consumption 0.30 A 0.33 A 0.38 A
Weight 0.11 kg 0.11 kg 0.12 kg
*1: Counting speed is affected by pulse rise and fall time. Possible counting speeds are
shown in the following chart. Note that if a pulse that has a large rise and/or fall time is
counted, a miscount may occur.
(Unit:μs) (Unit:μs) (Unit:μs) (Unit:μs)

3
Counting speed
switch settings 500 k 200 k 100 k 10 k
Rise/fall time Both 1 and 2 phase input
t = 0.5 µs or less 500 kPPS 200 kPPS 100 kPPS 10 kPPS
t = 1.25 µs or less 200 kPPS 200 kPPS 100 kPPS 10 kPPS
t = 2.5 µs or less — 100 kPPS 100 kPPS 10 kPPS
t = 25 µs or less — — 10 kPPS 10 kPPS
t = 500 µs — — — 500PPS
tt
Remark
Refer to the user's manual of the CPU module used for general
specifications of the QD62(E/D).
3. Installation
3.1 Handling Precautions
The following explains the precautionary notes on handling the module.
1) Do not drop or apply severe shock to the module case since it is made of
resin.
2) Do not remove the PCB of each module from its case. Doing so may
cause breakdowns.
3) Be careful not to let foreign particles such as wire chips get inside the
module.
These may cause fire, breakdowns and malfunctions.
4) The top surface of the module is covered with a protective film to prevent
foreign objects such as wire chips from entering the module when wiring.
Do not remove this film until the wiring is complete.
Before operating the system, be sure to remove the film to provide
adequate heat ventilation.
5) Tighten the module fixing screw within the following specified torque range.
If the screw is too loose, it may cause a drop, short circuit, or malfunction.
Excessive tightening may damage the screw and/or the module, resulting
in a drop, short circuit or malfunction.
Screw location Tightening torque range
Module fixing screws (M3 screws) *1 0.36 to 0.48 N⋅m
*1 The module can be easily fixed onto the base unit using the hook at the top
of the module.
However, it is recommended to secure the module with the module fixing
screw if the module is subject to significant vibration or shock.

4
6) To mount the module on the base unit, fully insert the module fixing latch
into the fixing hole in the base unit and press the module using the hole as
a fulcrum.
Improper installation may result in a malfunction or breakdown of the
module, or may cause the module to fall off.
3.2 Installation Environment
For further details, refer to the user's manual for the CPU module used.

5
4. Part Identification Names
The following explains the names of the various parts of the high-speed counter
module.
LED name Description
φA Lit: Voltage is being applied to the Phase A
pulse input terminal.
φB Lit: Voltage is being applied to the Phase B
pulse input terminal.
DEC. Lit: Counter is in the process of subtraction.
FUNC. Lit: Voltage is being applied to the function start
input terminal.
FUSE
Lit: Voltage is being applied to the external
power supply input terminal while the fuse in
the coincidence signal output section is
broken.
A20B20
A01
B01
Serial number plate
