MI1002-W User's Manual
-MI1002-W
-MI1002-W-CL

i
Precautions regarding Warranty
This product was developed and manufactured by Mitsubishi Electric Corporation in
collaboration with NEC Corporation.
Please see the following notes regarding the warranty and specifications of this product.
Warranty
MI1002-W、MI1002-W-CL
Gratis warranty term
18 months after delivery or,
24 months after manufacture
Onerous repair term after production
discontinuation
5 years
 When requesting repair of this product during the free warranty period, please present
the warranty attached to this product.
 Please read the guarantee provisions contained in the warranty.
 The repair period of this product after production discontinuation will depend on the
inventory status of the spare parts.
 It may take time to respond depending on the condition and timing of your inquiry.

ii
Conditions of Use for the Product
(1). This product ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead
to any major or serious accident; and
ii) where the backup and fail-safe function are systematically or automatically provided
outside of the PRODUCT for the case of any problem, fault or failure occurring in the
PRODUCT
(2). The PRODUCT has been designed and manufactured for the purpose of being used in
general industries. MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY
(INCLUDING, BUT NOT LIMITED TO ANY AND ALL RESPONSIBILITY OR LIABILITY
BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY INJURY OR
DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT
THAT ARE OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY
INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN MITSUBISHI'S USER,
INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND GUIDELINES
FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
 Nuclear Power Plants and any other power plants operated by Power companies,
and/or any other cases in which the public could be affected if any problem or
fault occurs in the PRODUCT.
 Railway companies or Public service purposes, and/or any other cases in which
establishment of a special quality assurance system is required by the Purchaser
or End User.
 Aircraft or Aerospace, Medical applications, Train equipment, transport equipment
such as Elevator and Escalator, Incineration and Fuel devices, Vehicles, Manned
transportation, Equipment for Recreation and Amusement, and Safety devices,
handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling,
and/or other applications where there is a significant risk of injury to the public or
property.

iii
Precautions for Use (Be Sure to Read)
This manual provides information necessary for safe and correct use of this product.
Keep this manual nearby so that you can refer to it as necessary. Be sure to read this manual before using
this product.
Safety Precautions
Follow the instructions in this document for the safe use of this product.
This manual describes hazardous parts of the product, possible hazards, and how to avoid them.
Components of the product with possible danger are indicated with a warning label placed on or around
them (or, in some cases, by printing the warnings on the computer).
In this manual or on warning labels, “Warning”or “Caution”is used to indicate a degree of danger.
These terms are defined as follows:
Indicates the potential for death or serious injury.
Indicates there is a risk of burns, other personal injury, or property
damage.
Precautions and notices against hazards are presented with one of the following three symbols.
Attention
This symbol indicates the presence of a hazard if
the instruction is ignored.
An image in the symbol illustrates the hazard type.
Example:
Electric shock risk
Prohibited
action
This symbol indicates prohibited actions. An image
in the symbol illustrates a particular prohibited
action.
Example:
Do not disassemble.
Mandatory
action
This symbol indicates mandatory actions. An
image in the symbol illustrates a mandatory action
to avoid a particular hazard.
Example:
Disconnect a plug.
(A label example used in this User’s Manual)
Symbol to draw attention Description of a warning Term indicating a degree of danger
Do not use the product if any smoke, odor, or noise is present.
If smoke, an abnormal odor or a sound is generated from the product,
immediately turn off the main unit, unplug the power cable from the outlet,
and then contact your nearest sales agent or maintenance service company.
A fire might result if you continue to use the product.

iv
Symbols Used in This Manual and on Warning Labels
Attention
Indicates the potential for smoke and/or
fire to occur.
Indicates the risk of electric shock.
Indicates the possibility that you get
your fingers pinched between the
mechanical parts resulting in injuries.
Indicates there is a risk of explosion that
can result in injuries.
Indicates the potential for damage
caused by high temperatures.
Indicates an attention that cannot be
specifically identified.
Prohibited actions
Do not disassemble, repair, or modify
this product. Otherwise, an electric shock
or fire may be caused.
Do not use this product in places near
water or liquids. Otherwise an electric
shock or fire may be caused.
Do not install this product near a fire.
Otherwise a fire may be caused.
Do not touch with wet hand. Otherwise,
an electric shock may be caused.
Do not touch this product. Otherwise, an
electric shock or burn may be caused.
Indicates a general prohibited action
that cannot be specifically identified.
Mandatory actions
Unplug the power cable of this product.
Otherwise, an electric shock or fire may
be caused.
Indicates a mandatory action that
cannot be specifically identified.
Make sure to follow the instruction.
Make sure equipment is properly
grounded. Otherwise, an electric shock
or fire may be caused.
Notations in this manual
Indicates items that must be observed in handling the hardware.

v
Safety Notes
This section provides notes on using this product safely. Read this section carefully to ensure proper and
safe use of this product.
General notes
Do not use the product if any smoke, odor, or noise is present.
If smoke, an abnormal odor or a sound is generated from the product, immediately
turn off the main unit, unplug the power cable from the outlet, and then contact your
nearest sales agent or maintenance service company. A fire might result if you
continue to use the product.
Do not insert needles or metal objects.
Do not remove rubber caps or other covers on this product to insert needles, metal
objects, or other foreign objects into openings. Doing so may cause an electric shock,
burns, or fire.
Keep water or foreign objects away from the product.
Do not drop liquids such as water or other foreign objects such as a pin or a paper clip
into this product. Failure to follow this warning may cause an electric shock, a fire, or
malfunction. If such things accidentally enter the product, immediately turn off the
power and disconnect the plug from the outlet. Do not disassemble the product, and
contact your sales agent or a maintenance service company.

vi
Notes on power connections
Plug the power cable into an outlet that matches the voltage of the unit.
Plug the power cable supplied with this product(Only MI1002-W) into a 100V outlet in
line with the voltage inscribed on the unit. When using this product in a country or
region other than Japan, prepare a power cable corresponding to the power supply for
the country or region where this product will be used. Failure to use an appropriate
power cable may cause a fire.( When using the MI1002-W-CL, prepare a power cable
that conforms to the power supply to be used and the safety standards of the use
area.)
Do not hold the plug with a wet hand.
Do not insert/remove the power cable plug with wet hands.
Failure to follow this warning may cause an electric shock.
Do not connect or remove a ground wire or FG cable while the power cable is
connected to the outlet.
When using the 2-pin conversion plug(Only MI1002-W) and FG cable supplied with
this product, unplug the plug from the outlet before attaching or removing the ground
wire or FG cable. Even if the power is turned off, touching the ground wire while the
plug is plugged into the outlet may cause an electric shock, or may cause a short
circuit, resulting in fire.

vii
Plug the power cable into the specified outlet.
Use a 3-pin outlet with ground electrode or 2-pin outlet with ground terminal that
matches the specified voltage. If you are using a 2-pin outlet with ground terminal, use
a 2-pin conversion plug with a ground wire supplied with this product(Only MI1002-W)
and connect the ground wire securely to the ground terminal of the outlet. Use of an
outlet other than that specified may result in fire or electrical leakage.(When using the
MI1002-W-CL, prepare a power cable that conforms to the power supply to be used
and the safety standards of the use area.)
Do not use extension cords.
Do not install this product in any environment that requires an extension cord.
Connecting to a cord that does not conform to the power supply specifications of this
product may cause overheating, resulting in fire.
Do not connect power cable to overloaded extension cords.
The electric current exceeding the rated flow overheats the outlet, which may cause a
fire.

viii
Hold the plug part when removing the AC power cable.
Pull the plug by holding the plug part to disconnect the AC power cable. Pulling the AC
power cable out by the cable may cause breakage, resulting in electrical shock or fire.
Secure the AC power cable in place.
Be sure to secure the AC power cable in place. Incomplete insertion causes an
inadequate connection, which may result in heat generation or fire. Also, if dust
accumulates on the prongs and water drops adhere to the accumulated dust, it may
result in heat generation or cause fire.
Use the authorized AC power cable.
Use only the AC power cable supplied with the product(Only MI1002-W). Electric
current exceeding the rated flow could cause fire.(When using the MI1002-W-CL,
prepare a power cable that conforms to the power supply to be used and the safety
standards of the use area.) Also, observe the following precautions to prevent electrical
shock or fire caused by a damaged power cable.
●Do not stretch the power cable.
●Do not pinch the power cable.
●Do not bend the power cable.
●Keep chemicals away from the power
cable.
●Do not twist the power cable.
●Do not place any object on the power
cable.
●Do not step on the power cable.
●Do not use a rolled up power cable.
●Do not alter, modify, or repair the
power cable.
●Do not secure the power cable with
staples or equivalents.
●Do not use a damaged power cable. (Replace the damaged power cable with a
power cable of the same standard. Contact your sales agent or a maintenance
service company for replacement.)
Do not use the attached power cable, AC adapter, 2-pin conversion plug with
ground wire, FG cable, and power cable clamp for any other devices or
usage.
The power cable(Only MI1002-W), AC adapter, 2-pin conversion plug(Only MI1002-W)
with ground wire, FG cable, and power cable clamp that come with the product are
designed for this product and the safety is confirmed for use with this product. Do not
use them for any other products or purposes. Doing so may cause a fire or an electric
shock.
Do not turn on the power again immediately after turning off the power.
If the power is turned on immediately after turning off the power, a large inrush
current may flow.
After turning off the power, wait 10 seconds before turning the power on again.
