Mitsubishi Electric XL6600U User manual

X
XL L6 66 60 00 0U U
&
&
X
XL L6 65 50 00 0U U
XGA
PROJECTOR

2
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U
P PR RO OJ JE EC CT TO OR RS S
XL6600U & XL6500U
XGA Projector
What is XL6600U/XL6500U?...............................................................................
Key Selling Points...............................................................................................
Why Mitsubishi Digital Projectors?...................................................................4
Product Specifications .......................................................................................5
Key Features .......................................................................................................6
New Features.......................................................................................................8
Warranty ..............................................................................................................8
Accessories.........................................................................................................8
Product Description (XL6600U) .........................................................................9
Product Description (XL6500U) .......................................................................10

3
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U
P PR RO OJ JE EC CT TO OR RS S
What is the XL6600U & XL6500U?
The new Mitsubishi XL6600U & XL6500U are native XGA (1024x768 LCD installation
projectors that shine bright at 6000 ANSI lumens (XL6600U and 5000 ANSI lumens
(XL6500U , offer a rich 1000:1 contrast ratio and weighs less than 22.1lbs.
Presenters will enjoy the versatile features the XL6600U & XL6500U has to offer, such
as the flexible connectivity options for video and data sources, anti-theft features that
prevent tampering or unauthorized usage, and an economical design for large
auditoriums or rooms with ambient lighting, restaurants or hotel conference rooms, as
well as school auditoriums and corporate boardrooms. School administrators will
especially enjoy how the XL6600U & XL6500U can be fully integrated into classrooms or
meeting rooms. Remote control operations are handled via the RS-232C
communication system, as well as via an RJ45 input.
Built-in security features such as Password Menu Lock, Motion Alarm and Screen
Capture security prevent any unauthorized projector removal. An external computer
output is available for monitor hookups that can enable teachers to face the class during
a lecture. The XL6600U & XL6500U also include a lamp life rating up to 4000-hours (low
mode , Mitsubishi’s exclusive Express Replacement Assistance (ERA warranty, and an
amazing 1-year or 500hrs (whichever comes first lamp warranty.
The XL6600U & XL6500U installation projectors come with high quality
standards…which ultimately will capture the attention of your audiences by delivering
bright, razor-sharp images with vibrant colors and exceptional detail.
Key Selling Points
The following are a few key selling points of the XL6600U & XL6500U:
• 3-LCD Technology for outstanding image quality
• Native XGA resolution (1024 x 768
• 6000 ANSI lumens (XL6600U
• 5000 ANSI lumens (XL6500U
• Contrast ratio of 1000:1
• Up to 4,000 hours of lamp life (low mode
• Color Enhancer (Gamma correction, RGB-COLOR, RGB-TINT
• RS-232C compatibility
• RJ45 remote management
• sRGB specification mode
• Ultra quiet 29dBA noise reduction
• Optional projection lenses
• Anti-theft features (Password Menu Lock, Motion Alarm & Screen Capture security
• Digital keystone (vertical/horizontal
• Motorized lens shift, as well as focus and zoom
• Backed by Mitsubishi outstanding Warranty and exclusive ERA Programs:
o 3-years parts and labor
o 3-years Express Replacement Assistance (ERA
o 1-year or 500 hours (whichever comes first lamp warranty

4
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U
P PR RO OJ JE EC CT TO OR RS S
Why Mitsubishi Digital Projectors?
At Mitsubishi, making a projector that impresses a presenter is only half the job. We
believe that impressing the audience is the real motivation behind every presentation.
That's why we go through great lengths to develop a line of award-winning business and
home theater projectors that capture the full attention of any audience. A projector is
only successful if it helps you deliver your message with clarity and impact!
Mitsubishi's line of powerful, high-brightness DLP
®
and LCD projectors can bring all of
your great ideas to light. With a wide range of business and home theater projectors to
choose from, there is one that will fit your presentation requirements and budget. Each
Mitsubishi projector packs the most versatile array of innovative, performance enhancing
features available today—enabling you to make bigger, longer lasting impressions.
With Mitsubishi, you have added peace of mind knowing you are partnering with the
industry leader in both business and home theater projection technology. We are
recognized worldwide for our innovation, durability, and impeccable projector
performance. While technology is important, we also design our products to be user
friendly. Our responsive and thoroughly trained Technical Support team is just a
phone call away to provide assistance on all of your technical needs.
We are also very confident in the QUALITY of our projectors. We back this statement
up by offering an Outstanding Warranty Program and a superior lamp warranty. We
are confident that all of our Mitsubishi customers are always receiving a HIGH QUALITY
and HIGH-VALUE solution, even after the sale of our projectors is completed...for added
peace of mind.

5
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U
P PR RO OJ JE EC CT TO OR RS S
XL6600U & XL6500U PRODUCT SPECIFICATIONS
Display Technology 1.3" 3-LCD (with Micro Lens
Resolution 1024 x 768 (Total 786,432 pixels
Brightness 6000 ANSI lumens (XL6600U
5000 ANSI lumens (XL6500U
Contrast Ratio 1000:1
Zoom/Focus Powered Focus & Zoom (Zoom Ratio 1.3:1
Projection Lens f=51-64mm , F=1.8-2.1 (12.5’-16.1’@100"
Off set axis 19 up : 1 down (default with Variable H+V Powered Lens Shift (Excluding OL-
X500FR ,
Picture Size 60-300 (inch
Source Lamp 275W (Shut Off Time 2000Hrs with Low Mode (220W:Shut Off Time 4000Hrs
PC Compatibility Resolution; 640 x 400 (Expand – 1024 x 768 (Real - 1600 x 1200 (Compress
Sync on Green available
Video Compatibility
NTSC / NTSC 4.43 / PAL (including PAL-M, N / SECAM / PAL-60, Component
Video; 480i/p(525i/p , 576i/p(625i/p , 720p(750p 50/60Hz , 1080i(1125i 50/60Hz ,
1080p(1125p 50/60Hz SCART (RGB + 1V sync, only Mini D-Sub 15pin Terminal
Input Terminals
PC; 5 BNC x 1, Mini D-Sub 15pin x 1, DVI-D(with HDCP x 1, PC Audio; Stereo mini
jack (φ3.5mm x 2, Video: RCA x 1 or BNC x 1, S-VIDEO (4pin x 1 or S-VIDEO Y/C
(BNC , Video Audio; RCA (L/R x 2
Output Terminal RGB; Mini D-Sub 15 pin x 1
Audio; Stereo mini jack (φ3.5mm x 1 (Variable Out
Communication
Terminal
LAN（RJ-45 ; x 1 (Projector control & RS-232C; D-Sub 9pin x 1
USB; x 1 (for Mouse Cursor Control
Wired remote (IN ; x 1 (φ3.5mm Stereo mini jack
Wired remote (OUT : x 1 (φ3.5mm Stereo mini jack
Scanning Rate [H] 15 - 100 kHz, [V] 50 - 120 Hz, [Dot clock] max.162 MHz
Audio Speaker 10W Mono
Height Adjuster Screw type Front leg (0 to 7 degree variable
Hand Remote Control
 Projector Fully Control & USB Mouse Cursor Control
 Power Point Page Up/Down and Home/End via USB
 High brightness Laser pointer (with cancelable mode & Wired remote
Power consumption 430 W / 4.4 A
Dimension 17.4” x 8.14” x 17.04” mm (Including detachable Terminal Cover
Weight 9.8kg / 21.6lbs (exclude detachable Terminal Cover
Power requirements AC 100 - 240 V, 50/60Hz
Fan Noise 35 dBA / 29 dBA (at Lamp low mode
Supplied Accessories
 AC Power Cable
 AV cable: 1.5m (RCA pins, 3 wires x 1
 RGB cable: 1.8m (mini D-sub 15 pin x1
 RS-232C cable: 1.8m (D-sub 9 pin x 1
 Remote unit x 1 & Remote Battery x 1
 Terminal Cover x 1 (Including detachable Anti Theft Alarm
 Safety Pin for Anti Theft Alarm x 2 & Anti Theft Alarm Battery x 1
 User Manual (CD-ROM , Safety Manual
 Sticker x 3 (For Anti Theft Alarm & Filter x 1
Optional Accessories Spare Lamp bulb (VLT-XL6600LP
Warranty 3-yrs parts/labor,3-yrs Express Replacement Assistance (ERA , I-yr or 500hrs
(whichever comes first lamp warranty

The New XL6600U & XL6500U model adds value in many of the following
categories:
• Technology • Cost of Ownership
• Ease of Use •
••
• Flexibility
XL6600U & XL6500U KEY FEATURES
TECHNOLOGY
Display
Technology 1. ” -LCD (with Micro Lens)
Contrast Ratio
1000: 1
Delivers an exceptional contrast ratio for high contrasts between dark and light images for
unbelievable clarity and a truer more realistic picture quality.
Brightness 6000 ANSI lumens (XL6600U) & 5000 ANSI lumens (XL6500U)
Delivering a strikingly bright picture with crisp vivid images for an overall high quality picture.
Native Resolution
XGA 1024 x 768
Native resolution of 1024 x 768 (Total 786,432 pixels to provide crisp, clear images and
resolution
Picture in Picture Supports picture-in-picture mode for dual images being displayed simultaneously
Digital Keystone Supports for both horizontal and vertical lens shift for installation assistance
EASE OF USE
Menu Driven
YES
Includes an easy to use menu driven options (Image, Installation, Feature, Signal , so all
configuration is performed at your fingertips.
Remote Control
YES
Includes a remote control for ease of use. Supports a distance of approximately 32 ft when it is
pointed directly at the projector and approximately 16 ft when pointed at the screen.
FLEXIBILITY
Output options RGB, Audio
Includes support for a 15pin RGB and a single stereo mini jack for audio output
Input Connectivity
options
RGB, RCA, S-Video, BNC, DVI, Audio
Includes support for flexible input configuration options for both data and video (15pin RGB, RCA,
S-Video, BNC, DVI as well as audio support with a 3.5mm stereo mini jack
COST OF OWNERSHIP
Lamp Life
Up to 4000 hrs
With the optimum temperature control design of the light source and its circuitry design
technology, the XL6600U & XL6500U can support a lamp life of up to 4000 hours. This long lamp
life helps lower the overall cost of ownership and maintenance of the projector.
Warranty
Backed by Mitsubishi’s outstanding warranty and exclusive ERA programs:
o 3-years parts and labor
o 3-years Express Replacement Assistance (ERA
o 1-year or 500hrs (whichever comes first lamp warranty

7
Remember…
While technology is important, we also design our products to be user friendly.
Our responsive and thoroughly trained Technical Support team is just a phone
call away to provide assistance on all of your projector’s technical needs.
We are also very confident in the QUALITY of our projectors. We back this
statement up by offering an Outstanding Warranty Program and a superior lamp
warranty. We are confident that all of our Mitsubishi customers are always
receiving a HIGH QUALITY and HIGH-VALUE solution, even after the sale of our
projectors is completed...for added peace of mind.

8
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U/ /L LU U
P PR RO OJ JE EC CT TO OR R
What are some of the Key New Features of the XL6600U & XL6500U?
• 3-LCD Technology
• 6000 ANSI lumens (XL6600U
• 5000 ANSI lumens (XL6500U
• 1000:1 Contrast ratio
• Up to 4.000 hours of lamp life (low mode)
• Weighs approximately 21.6 lbs
• Anti-theft (Password Security, Motion Alarm and Screen Capture security
• Digital keystone (vertical/horizontal
• Low noise level at 29dBA (low mode)
• RS232 compatibility
• Picture in Picture support
• sRGB specification mode
• Hushed 29dba noise level
• Color Enhancer (Gamma correction, RGB-COLOR, RGB-TINT
• Flexible connectivity support for both data and video inputs
• Outstanding Warranty and exclusive ERA programs
Is the warranty included with the purchase of the XL6600U & XL6500U or is
it something I need to purchase separately?
The XL6600U & XL6500U includes an outstanding warranty program, as well as
Mitsubishi’s exclusive Express Replacement Assistance (ERA programs…and they are
both included with the purchase of the XL6600U & XL6500U.
• 3-years parts and labor
• 3-years Express Replacement Assistance (ERA
• 1-yr or 500hrs (whichever comes first lamp warranty
XL6600U & XL6500U Accessories
The following is a list of available optional accessories for the XL6600U & XL6500U:
Replacement Lamp Optional Lens
Part Number
VLT-XL6600LP
Ceiling Mount
Part Number
XL5950CM
Hard Rolling Case
Part Number
XL-7000-ATAC
*Demo units are available at discounted price. Please check with your Mitsubishi Account Representative
for dealer pricing and volume pricing.
Short Throw Zoom Ratio 1.3-1.6 OL-X500SZ
Tele Throw Zoom Ratio 3.4-5.2 OL-X500TZ
Long Throw Zoom Ratio 2.4-3.3 OL-X500LZ
Rear Projection Short Throw OL-X500FR

9
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U/ /L LU U
P PR RO OJ JE EC CT TO OR R
XL6600U Product Descriptions:
25 Words
The XL6600U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details.
50 Words
The XL6600U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details. The XL6600U delivers super
bright 6000 lumen images with a rich 1000:1 contrast. This installation model is great for
presenting in large meeting rooms and conference halls.
75 Words
The XL6600U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details. The XL6600U delivers super
bright 6000 lumen images with a rich 1000:1 contrast ratio. This installation model is
great for presenting in large meeting rooms or conference halls that may be exposed to
ambient lighting. Additionally this model also includes support for picture in picture
functionality and has an ultra-quiet noise level at 29dBA rating.
100 Words
The XL6600U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details. The XL6600U delivers super
bright 6000 lumen images with an amazing 1000:1 contrast ratio. This installation model
is great for presenting in large meeting rooms or conference halls that may be exposed
ambient lighting. Additionally this projector includes picture in picture functionality,
remote management capabilities and operates at an ultra-quiet 29dBA noise level. It
also includes a DVI connectivity input to support true HD digital-to-digital images, as well
as a 3-year warranty and an amazingly long 4000 hour lamp life.

10
X XL L6 66 60 00 0U U & & X XL L6 65 50 00 0U U/ /L LU U
P PR RO OJ JE EC CT TO OR R
XL6500U Product Descriptions:
25 Words
The XL6500U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details.
50 Words
The XL6500U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details. The XL6500U delivers super
bright 5000 lumen images with a rich 1000:1 contrast. This installation model is great for
presenting in large meeting rooms and conference halls.
75 Words
The XL6500U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details. The XL6500U delivers super
bright 5000 lumen images with a rich 1000:1 contrast ratio. This installation model is
great for presenting in large meeting rooms or conference halls that may be exposed to
ambient lighting. Additionally this model also includes support for picture in picture
functionality and has an ultra-quiet noise level at 29dBA rating.
100 Words
The XL6500U is a native XGA (1024 x 768 projector. It includes the latest LCD
technology for the sharpest definition to image details. The XL6500U delivers super
bright 5000 lumen images with an amazing 1000:1 contrast ratio. This installation model
is great for presenting in large meeting rooms or conference halls that may be exposed
ambient lighting. Additionally this projector includes picture in picture functionality,
remote management capabilities and operates at an ultra-quiet 29dBA noise level. It
also include a DVI connectivity input to support true HD digital-to-digital images, as well
as a 3-year warranty and an amazingly long 4000 hour lamp life
