Mitsubishi Heavy Industries FDTC40ZIXVD Product guide

STANDARD INVERTER PACKAGED AIR-CONDITIONERS
V Multi System
(Split system, Air to air heat pump type)
Manual No. '10 •PAC-DB-142
DATA BOOK
CEILING CASSETTE-4 WAY COMPACT TYPE
Single type
FDTC40ZIXVD
50ZIXVD
60ZIXVD
Triple type
FDTC140VNTVD
140VSTVD
Single type
FDT40ZIXVD
50ZIXVD
60ZIXVD
71VNVD
100VNVD
100VSVD
125VNVD
125VSVD
140VNVD
140VSVD
Triple type
FDT140VNTVD
140VSTVD
200VSTVD
Single type
FDEN40ZIXVD
50ZIXVD
60ZIXVD
71VNVD
100VNVD
100VSVD
125VNVD
125VSVD
140VNVD
140VSVD
Triple type
FDEN140VNTVD
140VSTVD
200VSTVD
Twin type
FDEN71VNPVD
100VNPVD
100VSPVD
125VNPVD
125VSPVD
140VNPVD
140VSPVD
200VSPVD
250VSPVD
CEILING CASSETTE-4 WAY TYPE
DUCT CONNECTED-LOW/MIDDLE STATIC PRESSURE TYPE
CEILING SUSPENDED TYPE
Single type
FDUM50ZIXVD
60ZIXVD
71VNVD
100VNVD
100VSVD
125VNVD
125VSVD
140VNVD
140VSVD
Triple type
FDUM140VNTVD
140VSTVD
200VSTVD
DUCT CONNECTED-HIGH STATIC PRESSURE TYPE
Single type
FDU71VNVD
100VNVD
100VSVD
125VNVD
125VSVD
Twin type
FDUM100VNPVD
100VSPVD
125VNPVD
125VSPVD
140VNPVD
140VSPVD
200VSPVD
250VSPVD
Twin type
FDT71VNPVD
100VNPVD
100VSPVD
125VNPVD
125VSPVD
140VNPVD
140VSPVD
200VSPVD
250VSPVD
Double Twin type
FDT200VSDVD
250VSDVD
Twin type
FDTC71VNPVD
100VNPVD
100VSPVD
125VNPVD
125VSPVD
Double Twin type
FDTC200VSDVD
FDTC250VSDVD
FDU140VNVD
140VSVD
200VSVD
250VSVD
(OUTDOOR UNIT)
FDC71VN
100VN
100VS
125VN
125VS
FDC140VN
140VS
200VS
250VS
(INDOOR UNIT)
FDT40VD
50VD
60VD
71VD
100VD
125VD
FDEN40VD
50VD
60VD
71VD
100VD
125VD
Ragarding the Service Manual please see the Manual No.’10 • PAC-SM-143.

-
1
-
'10 • PAC-DB-142
TABLE OF CONTENTS
1. STANDARD INVERTER PACKAGED AIR-CONDITIONERS ............................... 2
2. V MULTI SYSTEM .................................................................................................246
3. OPTION PARTS .....................................................................................................273

-
2
-
'10 • PAC-DB-142
CONTENTS
1.1 SPECIFICATIONS ...........................................................................................
(1) Ceiling cassette-4way compact type (FDTC) ..............................................
(2) Ceiling cassette-4way type (FDT) ................................................................ 16
(3) Ceiling suspended type (FDEN) .................................................................. 40
(4) Duct connected-Low/Middle static pressure type (FDUM) ........................... 64
(5) Duct connected-High static pressure type (FDU) ........................................ 84
1.2 EXTERIOR DIMENSIONS ............................................................................... 93
(1) Indoor units .................................................................................................. 93
(2) Outdoor units ...............................................................................................105
1.4 NOISE LEVEL
1.5 CHARACTERISTICS OF FAN
1.7 PIPING SYSTEM
1.6 TEMPERATURE AND VELOCITY DISTRIBUTION
1.3 ELECTRICAL WIRING ....................................................................................112
1.8 RANGE OF USAGE & LIMITATIONS
(1) Indoor units ..................................................................................................112
(2) Outdoor units ...............................................................................................121
(3) Remote controller (Option parts) .................................................................110
1.9 SELECTION CHART
1.9.1 Capacity tables
1.9.2 Correction of cooling and heating capacity in relation to air flow rate control (fan speed)
(2) Ceiling cassette-4way type (FDT)
(1) Ceiling cassette-4way compact type (FDTC) ...............................................156
(3) Ceiling suspended type(FDEN)
...............................................................158
(4) Duct connected-Low/Middle static pressure type (FDUM)
...................................................................162
(5) Duct connected-High static pressure type (FDU) .......................................170
..........................167
1.9.3 Correction of cooling and heating capacity in relation to one way length of refrigerant piping
1.9.4 Height difference between the indoor unit and outdoor unit
1.10 APPLICATION DATA
1.10.1 Installation of indoor unit
(1) Ceiling cassette-4way compact type (FDTC)
.......................................................................174
...................................................................................174
(2) Ceiling cassette-4way type (FDT) ..............................................................180
(3) Ceiling suspended type(FDEN) .................................................................186
(4) Duct connected-Low/Middle static pressure type (FDUM) .........................190
(5) Duct connected-High static pressure type (FDU) .......................................194
1.10.2 Installation of wired remote controller ..................................................202
........................................................................................156
..........172
.....172
..............173
.................................................................................................126
........................................................................
........................................137
.............................................................................................145
............................................................152
.......................................................................................156
..............................................174
1. STANDARD INVERTER PACKAGED AIR-CONDITIONERS
4
4
131

-
3
-
'10 • PAC-DB-142
1.10.3 Installation of outdoor unit .....................................................................206
(1) Models SRC40～60ZIX-S ..........................................................................206
(2) Model FDC71VN ........................................................................................213
(3) Models FDC100～140VN,100～140VS .....................................................221
(4) Models FDC200,250VS .............................................................................229
(5) Method for connecting the accessory pipe (Models FDC200,250 only) ........236
1.10.4 Electric wiring work installation .............................................................238
1.10.5 Instructions for branching pipe set (DIS-WA1,WB1,TA1,TB1) ............243
How to read the model name
Example: FDTC 40 Z IXVD
Series code
Inveter type
Product capacity
Model name FDTC : Ceiling cassette-4way compact type
FDT : Ceiling cassette-4way type
FDEN : Ceiling suspended type
FDUM : Duct connected-Low/Middle static
pressure type
FDTC : Ceiling cassette-4way compact type
FDT : Ceiling cassette-4way type
FDEN : Ceiling suspended type
FDUM : Duct connected-Low/Middle static
pressure type
FDU : Duct connected-High static pressuret type
SRC : Outdoor unit
Example: FDTC 100 VN P VD
Series code
P : Twin type
: Single type
T : Triple type
D : Double Twin type
Applicable power source...See the specification
Product capacity
Model name
FDC : Outdoor unit
(blank)

-
4
-
'10 • PAC-DB-142
1.1. SPECIFICATIONS
(1) Ceiling cassette-4way compact type (FDTC)
(a) Single type
Model
Item
FDTC40ZIXVD
Indoor unit FDTC40VD Outdoor unit SRC40ZIX-S
Panel TC-PSA-25W-E
Power source 220-240V ~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 4.0 [ 1.8 (Min.) ~ 4.7 (Max.)] 4.5 [ 2.0 (Min.) ~ 5.4 (Max.)]
Power consumption kW 1.04 1.10
Running current A 4.6 / 4.8 4.9 / 5.2
Power factor % 98 / 99 97
Inrush current A 5 < Max.running current 12 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 47
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 640 × 800 × 290
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 43
Refrigerant equipment
Compressor type & Q'ty — 5CS130XG04 × 1
Starting method — Direct line start
Refrigerant oil — 0.48 RB68A
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 45 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 40
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — —
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line: I/Uφ6.35 (1/4") Pipeφ6.35 (1/4") x 0.8 O/Uφ6.35 (1/4")
Gas line :
φ12.7 (1/2") φ12.7 (1/2") x 0.8 φ12.7 (1/2")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.30m
Vertical height difference between
outdoor unit and indoor unit
Max.20m (Outdoor unit is higher) 1.See page 154
Max.20m (Outdoor unit is lower)
Refrigerant Quantity R410A 1.4kg in outdoor unit (incl. the amount for the piping of : 15m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 x 5pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Drain elbow, Drain hole grommet
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375 A

-
5
-
'10 • PAC-DB-142
Model
Item
FDTC50ZIXVD
Indoor unit FDTC50VD Outdoor unit SRC50ZIX-S
Panel TC-PSA-25W-E
Power source 220-240V ~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 5.0 [ 2.2 (Min.) ~ 5.6 (Max.)] 5.4 [ 2.5 (Min.) ~ 6.3 (Max.)]
Power consumption kW 1.56 1.45
Running current A 6.9 / 7.2 6.4 / 6.7
Power factor % 99 / 98 99
Inrush current A 5 < Max.running current 14 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 47
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 640 × 800 × 290
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 43
Refrigerant equipment
Compressor type & Q'ty — 5CS130XG04 × 1
Starting method — Direct line start
Refrigerant oil — 0.48 RB68A
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 45 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 40
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — —
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line: I/Uφ6.35 (1/4") Pipeφ6.35 (1/4") x 0.8 O/Uφ6.35 (1/4")
Gas line : φ12.7 (1/2") φ12.7(1/2") x 0.8
φ12.7 (1/2")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.30m
Vertical height difference between
outdoor unit and indoor unit
Max.20m (Outdoor unit is higher) 1.See page 154
Max.20m (Outdoor unit is lower)
Refrigerant Quantity R410A 1.4kg in outdoor unit (incl. the amount for the piping of : 15m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 x 5pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Drain elbow, Drain hole grommet
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375 A

-
6
-
'10 • PAC-DB-142
Model
Item
FDTC60ZIXVD
Indoor unit FDTC60VD Outdoor unit SRC60ZIX-S
Panel TC-PSA-25W-E
Power source 220-240V ~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 5.6 [ 2.8(Min.) ~ 6.3(Max.)] 6.7 [ 3.1(Min.) ~ 6.7(Max.)]
Power consumption kW 1.99 2.08
Running current A 8.3 / 8.7 8.7 / 9.1
Power factor % 96 96
Inrush current A 5 < Max.running current 14 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 46 Me : 39 Lo : 30
Heating P-Hi : 47 Hi : 46 Me : 39 Lo : 32 48
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 640 × 800 × 290
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 43
Refrigerant equipment
Compressor type & Q'ty — 5CS130XG04 × 1
Starting method — Direct line start
Refrigerant oil — 0.48 RB68A
Heat exchanger Louver fin & inner grooved tubing M shape fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 45 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 7
Heating P-Hi : 13.5 Hi : 13.5 Me : 10 Lo : 8 40
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — —
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") Pipeφ6.35 (1/4") x 0.8 O/Uφ6.35 (1/4")
Gas line :
φ12.7 (1/2")
φ12.7(1/2") x 0.8 φ12.7 (1/2")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.30m
Vertical height difference between
outdoor unit and indoor unit
Max.20m (Outdoor unit is higher) 1.See page 154
Max.20m (Outdoor unit is lower)
Refrigerant Quantity R410A 1.4kg in outdoor unit (incl. the amount for the piping of : 15m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 x 5pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Drain elbow, Drain hole grommet
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375 A

-
7
-
'10 • PAC-DB-142
(b) Twin type
Model
Item
FDTC71VNPVD
Indoor unit FDTC40VD (2 units) Outdoor unit FDC71VN
Panel TC-PSA-25W-E
Power source 220-240V ~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 7.1 [ 3.2 (Min.) ~ 8.0 (Max.)] 8.0 [ 3.6 (Min.) ~ 9.0 (Max.)]
Power consumption kW 1.91 2.08
Running current A 8.3 / 8.8 9.0 / 9.6
Power factor % 99 99 / 98
Inrush current A 5 < Max.running current 17 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 48
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 750 × 968 × 340
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 60
Refrigerant equipment
Compressor type & Q'ty — 2YC45DXD × 1
Starting method — Direct line start
Refrigerant oil — 0.65 FVC50K
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 Cooling : 60, Heating : 50
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor)
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") x 0.8 ①φ9.52 (3/8") x 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2") ②φ12.7 (1/2") x 0.8 ①φ15.88 (5/8") x 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 154
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 2.95kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes sizeφ20 x 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose —
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-TA1"×1(option). ① : Pipe of O/U
~ Branch, ② : Pipe of Branch ~ I/U
(7) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375 A

-
8
-
'10 • PAC-DB-142
Model
Item
FDTC100VNPVD
Indoor unit FDTC50VD (2 units) Outdoor unit FDC100VN
Panel TC-PSA-25W-E
Power source 220-240V ~ 50Hz / 220V ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 10.0 [ 4.0 (Min.) ~ 11.2 (Max.)] 11.2 [ 4.0 (Min.) ~ 12.5 (Max.)]
Power consumption kW 2.84 3.08
Running current A 12.4 / 13.0 13.5 / 14.1
Power factor % 99 99
Inrush current A 5 < Max.running current 24 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 HI : 42 Me : 36 Lo : 32 49
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 845 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 81
Refrigerant equipment
Compressor type & Q'ty — RMT5126MDE2×1
Starting method — Direct line start
Refrigerant oil — 0.9 M-MA68
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 Cooling : 75, Heating : 73
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") x 0.8 ①φ9.52 (3/8") x 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2")
②φ12.7 (1/2") x 0.8 ①φ15.88 (5/8") x 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 154
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes sizeφ20 x 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ①: Pipe of O/U
~ Branch, ②: Pipe of Branch ~ I/U
(7) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375 A

-
9
-
'10 • PAC-DB-142
Model
Item
FDTC100VSPVD
Indoor unit FDTC50VD (2 units) Outdoor unit FDC100VS
Panel TC-PSA-25W-E
Power source 380-415V 3N ~ 50Hz / 380V 3N ~ 60Hz
Operation data Cooling Heating
Nominal capacity kW 10.0 [ 4.0 (Min.) ~ 11.2 (Max.)] 11.2 [ 4.0 (Min.) ~ 12.5 (Max.)]
Power consumption kW 2.84 3.08
Running current A 4.2 / 4.4 4.5 / 4.8
Power factor % 98 99 / 97
Inrush current A 5 < Max.running current 15 >
Sound Pressure Level dB(A) Cooling P-Hi : 47 Hi : 42 Me : 36 Lo : 30
Heating P-Hi : 47 Hi : 42 Me : 36 Lo : 32 49
Exterior dimensions
Height x Width x Depth mm Unit 248 × 570 × 570 Panel 35 × 700 × 700 845 × 970 × 370
Exterior appearance
(Munsell color)
Plaster White
(6.8Y8.9/0.2) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 15 PANEL 3.5 83
Refrigerant equipment
Compressor type & Q'ty — RMT5126MDE3 × 1
Starting method — Direct line start
Refrigerant oil — 0.9 M-MA68
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control — Electronic expansion valve
Air handling equipment
Fan type & Q'ty Turbo fan × 1 Propeller fan × 1
Motor <Starting method> W 33 < Direct line start > 86 < Direct line start >
Air flow (Standard) CMM Cooling P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 7
Heating P-Hi : 13.5 Hi : 11.5 Me : 9 Lo : 8 Cooling : 75, Heating : 73
Available static pressure Pa 0 —
Outdoor air intake Not possible —
Air filter, Q'ty Pocket plastic net × 1 (Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for Compressor )
Insulation (noise & heat) Polyurethane form —
Electric heater W — 20 (Crank case heater)
Remote controller wired : RC-E4 (option) wireless : RCN-TC-24W-ER (option)
Room temperature control Thermostat by electronics —
Safety equipment Overload protection for fan motor
Frost protection thermostat
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size mm Liquid line : I/Uφ6.35 (1/4") ②φ9.52 (3/8") x 0.8 ①φ9.52 (3/8") x 0.8 O/Uφ9.52 (3/8")
Gas line : I/Uφ12.7 (1/2") ②φ12.7 (1/2") x 0.8 ①φ15.88 (5/8") x 1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Refrigerant line (one way) length Max.50m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher) 1.See page 154
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Drain pump Built-in Drain pump —
Drain Hose Connectable with VP20 Holes size φ20 x 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
Standard Accessories Mounting kit, Drain hose Edging
Adapted to RoHS directive
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
Notes (1) The data are measured at the following conditions.
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber.
During operation these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(5) Indoor unit specifications for one unit. Capacity and operation data is two indoor units are combined and run together.
(6) Branching pipe set "DIS-WA1"×1(option). ①: Pipe of O/U
~ Branch, ②: Pipe of Branch ~ I/U
(7) When wireless remote controller is used, fan is 3 speed setting (Hi-Me-Lo) only.
PJA003Z375 A
