Mitsubishi Heavy Industries FDT100VNVF1 User manual

(Split system, air to air heat pump type)
Manual No. '13 • PAC-T-198
Single type
FDEN100VNVF1
100VSVF1
125VNVF
125VSVF
140VNVF
140VSVF
Twin type
FDEN100VNPVF
100VSPVF
125VNPVF
125VSPVF
140VNPVF1
140VSPVF1
200VSPVF1
250VSPVF
DUCT CONNECTED-LOW/MIDDLE STATIC PRESSURE TYPE CEILING SUSPENDED TYPE
Single type
FDUM100VNVF1
100VSVF1
125VNVF
125VSVF
140VNVF
140VSVF
Twin type
FDUM100VNPVF
100VSPVF
125VNPVF
125VSPVF
140VNPVF1
140VSPVF1
200VSPVF1
250VSPVF
Triple type
FDUM140VNTVF
140VSTVF
200VSTVF1
CEILING CASSETTE-4WAY COMPACT TYPE
Twin type
FDTC100VNPVF
100VSPVF
125VNPVF
125VSPVF
Single type
FDT100VNVF1
100VSVF1
125VNVF
125VSVF
140VNVF
140VSVF
CEILING CASSETTE-4WAY TYPE
Twin type
FDT100VNPVF
100VSPVF
125VNPVF
125VSPVF
140VNPVF1
140VSPVF1
200VSPVF1
250VSPVF1
Triple type
FDT140VNTVF
140VSTVF
200VSTVF1
Double twin type
FDT200VSDVF
250VSDVF
Triple type
FDEN140VNTVF
140VSTVF
200VSTVF1
Double twin type
FDEN200VSDVF
250VSDVF
Triple type
FDTC140VNTVF
140VSTVF
Double twin type
FDTC200VSDVF
250VSDVF
MICRO INVERTER PACKAGED AIR-CONDITIONERS 
WALL MOUNTED TYPE
Twin type
SRK100VNPZMX
100VSPZMX
125VNPZMX
125VSPZMX
Triple type
SRK140VNTZMX
140VSTZMX
(OUTDOOR UNIT)
FDC100VN
100VS
125VN
125VS
140VN
140VS
200VS
250VS
(INDOOR UNIT)
FDT50VF
60VF
71VF1
100VF1
125VF
FDEN50VF
60VF
71VF1
100VF1
125VF
DUCT CONNECTED-
HIGH STATIC PRESSURE
TYPE
Single type
FDU100VNVF1
100VSVF1
125VNVF
125VSVF
140VNVF
140VSVF
200VSVF
250VSVF
FLOOR STANDING TYPE
Single type
FDF100VNVD1
100VSVD1
125VNVD
125VSVD
140VNVD
140VSVD
Twin type
FDF140VNPVD1
140VSPVD1
200VSPVD1
250VSPVD
V Multi System
updated November 27, 2014
Service code
blank→A： to expand operation temperature
range down to -20℃in heating
A→B：
to expand diameter of half punched hole
for pipes to be drawn in from behind
C→L： to comply with amended safety
standard for LVD
B→C： to replace with new compressor and
PCB, comply with Lot10
Outdoor unit ChangesHistory of service code
FDC100VN blank A B C L
FDC125VN
blank A B C L
FDC140VN
blank A B C L
FDC100VS
blank A B C L
FDC125VS
blank A B C L
FDC140VS
blank A B C L
Page
Service code Exterior Dimensions
blank ~C P107
L
P552

-
1
-
'13 • PAC-T-198
TABLE OF CONTENTS
1. MICRO INVERTER PACKAGED AIR-CONDITIONERS ....................................... 2
2. V MULTI SYSTEM .................................................................................................490
3. OPTION PARTS .....................................................................................................514
4. OUTDOOR UNIT(Service code L)........................................................................552
#

-
2
-
'13 • PAC-T-198
CONTENTS
1.1 SPECIFICATIONS ........................................................................................... 6
(1) Ceiling cassette-4way type (FDT) ................................................................ 6
(3) Ceiling suspended type (FDEN) .................................................................. 33
(6) Floor standing type (FDF) ........................................................................... 77
(7) Wall mounted type (SRK) ............................................................................ 87
(7) Wall mounted type (SRK) ............................................................................201
(4) Duct connected-High static pressure type (FDU) ........................................ 52
1.2 EXTERIOR DIMENSIONS ............................................................................... 93
(1) Indoor units .................................................................................................. 93
(2) Outdoor units ...............................................................................................107
1.4 NOISE LEVEL
1.5 CHARACTERISTICS OF FAN
1.7 PIPING SYSTEM
1.6 TEMPERATURE AND VELOCITY DISTRIBUTION
1.3 ELECTRICAL WIRING ....................................................................................113
1.8 RANGE OF USAGE & LIMITATIONS
(1) Indoor units ..................................................................................................113
(2) Outdoor units ...............................................................................................125
(3) Remote control (Option parts) ....................................................................110
1.9 SELECTION CHART
1.9.1 Capacity tables
1.9.2
Correction of cooling and heating capacity in relation to air flow rate control (fan speed)
(2) Ceiling cassette-4way compact type (FDTC) ............................................... 25
(5) Duct connected-Low/Middle static pressure type (FDUM) .......................... 60
(1) Ceiling cassette-4way type (FDT) ................................................................159
(3) Ceiling suspended type (FDEN) ..................................................................173
(6) Floor standing type (FDF) ...........................................................................196
(4) Duct connected-High static pressure type (FDU) ........................................183
(2) Ceiling cassette-4way compact type (FDTC) ...............................................169
(5) Duct connected-Low/Middle static pressure type (FDUM) ..........................187
1.9.3
Correction of cooling and heating capacity in relation to one way length of refrigerant piping
1.9.4 Height difference between the indoor unit and outdoor unit
1.10 APPLICATION DATA
1.10.1 Installation of indoor unit .....................................................................209
...................................................................................209
........................................................................................159
(1) Ceiling cassette-4way type (FDT) ................................................................209
(3) Ceiling suspended type (FDEN) ..................................................................222
(4) Duct connected-High static pressure type (FDU) ........................................226
(2) Ceiling cassette-4way compact type (FDTC) ...............................................216
..........207
.....207
..............207
.................................................................................................128
........................................................................133
........................................141
.............................................................................................150
............................................................155
.......................................................................................159
1. MICRO INVERTER PACKAGED AIR-CONDITIONERS

-
3
-
'13 • PAC-T-198
(6) Floor standing type (FDF) ...........................................................................242
(5) Duct connected-Low/Middle static pressure type (FDUM) ..........................236
1.10.4 Installation of outdoor unit ...................................................................277
(1) Models FDC100 - 140VN, 100 - 140VS .....................................................277
(2) Models FDC200, 250VS ............................................................................286
(3) Method for connecting the accessory pipe (Models FDC200, 250) ..........295
(1) FDT, FDTC, FDEN, FDU200·250, FDUM series .......................................251
(2) FDU100 - 140 series ..................................................................................255
(3) FDF series .................................................................................................259
1.10.2 Electric wiring work installation ...........................................................251
1.10.5 Instructions for branching pipe set (DIS-WA1,WB1,TA1,TB1) ..........297
1.10.3 Installation of wired remote control (option) .....................................263
1.11 OUTLINE OF OPERATION CONTROL BY MICROCOMPUTER ................300
1.11.1 Remote control ....................................................................................300
1.11.2 Operation control function by the wired remote control
1.11.3 Operation control function by the indoor control ............................306
(Ⅰ) FDT, FDTC, FDEN, FDU, FDUM, FDF series ...........................................306
.................303
(1) Auto operation ...........................................................................................306
(2) Operations of functional items during cooling/heating ..............................307
(4) Timer operation .........................................................................................308
(5) Remote control display during the operation stop ....................................309
(6) Hot start (Cold draft prevention at heating) ..............................................309
(7) Hot keep ....................................................................................................309
..........................................................................313
(9) Thermostat operation ................................................................................311
(8) Auto swing control (FDT, FDTC, FDEN, FDF only) ..................................310
...................................................................................................312
....................................................312
(13) Drain motor (DM) control
(11) Compressor inching prevention control
(12) Drain pump control ...................................................................................313
......................................................................314
.............................313
(16) Heating overload protection
(14) Operation check/drain pump test run operation mode
(15) Cooling, dehumidifying frost protection .....................................................314
...................................................................................315
...............................................................................315
(19) High ceiling control
(17) Anomalous fan motor
(18)
Plural unit control - Control of 16 units group by one remote control ...................315
.........316
(21) External input/output control (CnT or CnTA)
(20)
Abnormal temperature thermistor (retun air/indoor heat exchanger) wire/short-circuit detection
............................................316
(3) Dehumidifying operation ...........................................................................307
(8) Effective range of cool/hot wind (Reference) ..............................................250
(7) Wall mounted type (SRK) ............................................................................246
(10) Filter sign

-
4
-
'13 • PAC-T-198
(33) The operation judgment is executed every 5 minutes (RC-EX1 only)
.................................319(23) Selection of cooling/heating external input function
................................................321(28) Energy-saving operation (RC-EX1A only)
..........................................................321(29) Warm-up control (RC-EX1A only)
...................................................................320(24) Fan control at heating startup
......................................................320(26) Return air temperature compensation
.....................................................320(27) High power operation (RC-EX1A only)
(25)
Room temperature detection temperature compensation during heating ............320
.....................................................321(34) Auto fan speed control (RC-EX1 only)
..........................................................321(35) IU overload alarm (RC-EX1A only)
1.11.4 Operation control function by the outdoor control .........................328
(1) Determination of comressor speed (frequency) .......................................328
(2) Compressor start control ..........................................................................328
(3) Compressor soft start control ...................................................................329
(4) Outdoor unit fan control ............................................................................330
(5) Defrosting .................................................................................................332
(6)
Protective control/anomalous stop control by compressor,s number of revolutions ..........333
(7) Silent mode ..............................................................................................336
(8) Test run .....................................................................................................336
(9) Pump-down control ...................................................................................337
...........................................337(10) Base heater ON/OFF output control (option)
................................................................................................322
..........................................................321(30) Home leave mode (RC-EX1A only)
.................................................321(32) Fan circulator operation (RC-EX1A only)
.......321
(31)
Auto temp. setting (RC-EX1A only) .............................................................321
(Ⅱ) SRK Seris
(4) Timer operation .......................................................................................323
(5) Remote control display during the operation stop ...................................324
(6) Outline of heating or cooling operation ...................................................324
(12) Frost prevention control ..........................................................................326
................................................................326
(7) Indoor fan motor protection .....................................................................325
(8) Serial signal transmission error protection ..............................................325
................325
(11) Outline of automatic operation
(14) Outline of dry (dehumidifying) operation ..................................................327
........................................................................327(13) Dew prevention controlⅡ
(9)
Plural unit control - Control of 16 units group by one remote control
(10) Filter sign ................................................................................................326
(1) Unit ON/OFF button ................................................................................322
(2) Auto restart function ................................................................................322
(3) Auto swing control ...................................................................................322
..............................................................318(22) Operation permission/prohibition

-
5
-
'13 • PAC-T-198
How to read the model name
FDT : Ceiling cassette-4way type
FDF : Floor standing type
SRK : Wall mounted type
FDTC : Ceiling cassette-4way compact type
FDEN : Ceiling suspended type
FDU : Duct connected-High static pressure type
FDUM : Duct connected-Low/Middle static pressure type
Example: FDT 100 VN P VF
Series code
P : Twin type
: Single type
T : Triple type
D : Double-Twin type
Applicable power source...See the specification
Product capacity
Model name
FDC : Outdoor unit
(blank)
..........................................................................373
(1) List of troubles ...........................................................................................373
(2) Troubleshooting ........................................................................................375
1.12.2 Troubleshooting flow
(1) Selfdiagnosis function ...............................................................................338
(2) Troubleshooting procedure .......................................................................343
(3) Troubleshooting at the indoor unit .............................................................343
(4) Troubleshooting at the outdoor unit ..........................................................359
(5) Check of anomalous operation data with the remote control ....................366
(6)
Power transistor module (including the driver PCB) inspection procedure ...........368
(7) Inverter checker for diagnosis of inverter output ......................................369
(8) Outdoor unit control failure diagnosis circuit diagram ...............................370
1.12 MAINTENANCE DATA ...............................................................................338
1.12.1 Diagnosing of microcomputer circuit ...............................................338
1.13 TECHNICAL INFORMATION ...................................................................470
(1) Ceiling cassette-4way type (FDT) ................................................................470
(3) Ceiling suspended type (FDEN) ..................................................................476
(6) Floor standing type (FDF) ...........................................................................486
(7) Wall mounted type (SRK) ............................................................................488
(4) Duct connected-High static pressure type (FDU) ........................................480
(2) Ceiling cassette-4way compact type (FDTC) ...............................................474
(5) Duct connected-Low/Middle static pressure type (FDUM) ..........................482

-
6
-
'13 • PAC-T-198
1.1 SPECIFICATIONS
(1) Ceiling cassette-4way type (FDT)
(a) Single type
Model
Item
FDT100VNVF1
Indoor unit FDT100VF1 Outdoor unit FDC100VN
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 4.0(Min.)
~ 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 4.0(Min.)
~ 12.5(Max.)]
Power Cooling
kW
2.76
consumption Heating 2.74
Max power consumption 3.86
Running Cooling
A
12.1 / 12.7
current Heating 12.0 / 12.6
Inrush current, max current 5, 24
Power factor Cooling %99
Heating 99
EER Cooling 3.62
COP Heating 4.09
Sound power level Cooling
dB(A)
65 70
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 40 Me : 37 Lo : 35 49
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 81
Compressor type & Q'ty — RMT5126MDE2×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg in outdoor unit (incl. the amount for the piping of : 30m)
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 27 Me : 24 Lo : 20 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: φ15.88 (5/8") φ15.88 (5/8")×1.0 φ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V50Hz or 220V60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 46
#
Addition

-
7
-
'13 • PAC-T-198
Model
Item
FDT100VSVF1
Indoor unit FDT100VF1 Outdoor unit FDC100VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 4.0(Min.)
~ 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 4.0(Min.)
~ 12.5(Max.)]
Power Cooling
kW
2.76
consumption Heating 2.74
Max power consumption 3.86
Running Cooling
A
4.2 / 4.4
current Heating 4.2 / 4.4
Inrush current, max current 5, 15
Power factor Cooling %95 / 91
Heating 94 / 95
EER Cooling 3.62
COP Heating 4.09
Sound power level Cooling
dB(A)
65 70
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 40 Me : 37 Lo : 35 49
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 83
Compressor type & Q'ty — RMT5126MDE3×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg in outdoor unit (incl. the amount for the piping of : 30m)
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 27 Me : 24 Lo : 20 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: φ15.88 (5/8") φ15.88 (5/8")×1.0 φ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 46
#

-
8
-
'13 • PAC-T-198
Model
Item
FDT125VNVF
Indoor unit FDT125VF Outdoor unit FDC125VN
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 12.5 [ 5.0(Min.)
~ 14.0(Max.)]
Nominal heating capacity (range) kW 14.0 [ 4.0(Min.)
~ 16.0(Max.)]
Power Cooling
kW
4.05
consumption Heating 3.77
Max power consumption 5.27
Running Cooling
A
17.7 / 18.6
current Heating 16.6 / 17.3
Inrush current, max current 5, 24
Power factor Cooling %99
Heating 99
EER Cooling 3.09
COP Heating 3.71
Sound power level Cooling
dB(A)
68 72
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 42 Me : 40 Lo : 37 50
Heating 51
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 81
Compressor type & Q'ty — RMT5126MDE2×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg in outdoor unit (incl. the amount for the piping of : 30m)
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 30 Me : 27 Lo : 23 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: φ15.88 (5/8") φ15.88 (5/8")×1.0 φ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V50Hz or 220V60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 48
#

-
9
-
'13 • PAC-T-198
Model
Item
FDT125VSVF
Indoor unit FDT125VF Outdoor unit FDC125VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 12.5 [ 5.0(Min.)
~ 14.0(Max.)]
Nominal heating capacity (range) kW 14.0 [ 4.0(Min.)
~ 16.0(Max.)]
Power Cooling
kW
4.05
consumption Heating 3.77
Max power consumption 5.27
Running Cooling
A
5.9 / 6.3
current Heating 5.5 / 5.9
Inrush current, max current 5, 15
Power factor Cooling %99 / 98
Heating 99 / 97
EER Cooling 3.09
COP Heating 3.71
Sound power level Cooling
dB(A)
68 72
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 42 Me : 40 Lo : 37 50
Heating 51
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 83
Compressor type & Q'ty — RMT5126MDE3×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg in outdoor unit (incl. the amount for the piping of : 30m)
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 30 Me : 27 Lo : 23 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: φ15.88 (5/8") φ15.88 (5/8")×1.0 φ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 48
#

-
10
-
'13 • PAC-T-198
Model
Item
FDT140VNVF
Indoor unit FDT140VF Outdoor unit FDC140VN
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 14.0 [ 5.0(Min.)
~ 14.5(Max.)]
Nominal heating capacity (range) kW 16.0 [ 4.0(Min.)
~ 16.5(Max.)]
Power Cooling
kW
4.98
consumption Heating 4.57
Max power consumption 6.47
Running Cooling
A
22.0 / 23.0
current Heating 20.2 / 21.2
Inrush current, max current 5, 24
Power factor Cooling %98
Heating 98
EER Cooling 2.81
COP Heating 3.5
Sound power level Cooling
dB(A)
68 73
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 43 Me : 41 Lo : 38 51
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 81
Compressor type & Q'ty — RMT5126MDE2×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg in outdoor unit (incl. the amount for the piping of : 30m)
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 30 Me : 27 Lo : 23 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: φ15.88 (5/8") φ15.88 (5/8")×1.0 φ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V50Hz or 220V60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 47 / Heating : 50
#

-
11
-
'13 • PAC-T-198
Model
Item
FDT140VSVF
Indoor unit FDT140VF Outdoor unit FDC140VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 14.0 [ 5.0(Min.)
~ 14.5(Max.)]
Nominal heating capacity (range) kW 16.0 [ 4.0(Min.)
~ 16.5(Max.)]
Power Cooling
kW
4.98
consumption Heating 4.57
Max power consumption 6.47
Running Cooling
A
7.4 / 7.8
current Heating 6.7 / 7.4
Inrush current, max current 5, 15
Power factor Cooling %97
Heating 98 / 94
EER Cooling 2.81
COP Heating 3.5
Sound power level Cooling
dB(A)
68 73
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 43 Me : 41 Lo : 38 51
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 83
Compressor type & Q'ty — RMT5126MDE3×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg in outdoor unit (incl. the amount for the piping of : 30m)
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 140 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 30 Me : 27 Lo : 23 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") Pipeφ9.52(3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: φ15.88 (5/8") φ15.88 (5/8")×1.0 φ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 47 / Heating : 50
#

-
12
-
'13 • PAC-T-198
Model
Item
FDT100VNPVF
Indoor unit FDT50VF (2 units) Outdoor unit FDC100VN
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 4.0(Min.)
~ 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 4.0(Min.)
~ 12.5(Max.)]
Power Cooling
kW
2.94
consumption Heating 3.09
Max power consumption 4.33
Running Cooling
A
12.9 / 13.7
current Heating 13.6 / 14.2
Inrush current, max current 5, 24
Power factor Cooling %99 / 98
Heating 99
EER Cooling 3.40
COP Heating 3.62
Sound power level Cooling
dB(A)
55 70
Heating
Sound pressure level Cooling P-Hi : 39 Hi : 33 Me : 31 Lo : 30 49
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 246 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 22 PANEL 5.5 81
Compressor type & Q'ty — RMT5126MDE2×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 50 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 20 Hi : 18 Me : 16 Lo : 14 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ6.35 (1/4") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ12.7 (1/2") ②φ12.7 (1/2")×0.8 ①φ15.88 (5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicates when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(7) Indoor unit specification for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
(b) Twin type
Cooling : 46 / Heating : 46
#

-
13
-
'13 • PAC-T-198
Model
Item
FDT100VSPVF
Indoor unit FDT50VF (2 units) Outdoor unit FDC100VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 10.0 [ 4.0(Min.)
~ 11.2(Max.)]
Nominal heating capacity (range) kW 11.2 [ 4.0(Min.)
~ 12.5(Max.)]
Power Cooling
kW
2.94
consumption Heating 3.09
Max power consumption 4.33
Running Cooling
A
4.3 / 4.6
current Heating 4.5 / 4.8
Inrush current, max current 5, 15
Power factor Cooling %99 / 97
Heating 99 / 98
EER Cooling 3.4
COP Heating 3.62
Sound power level Cooling
dB(A)
55 70
Heating
Sound pressure level Cooling P-Hi : 39 Hi : 33 Me : 31 Lo : 30 49
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 246 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 22 PANEL 5.5 83
Compressor type & Q'ty — RMT5126MDE3×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 50 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 20 Hi : 18 Me : 16 Lo : 14 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ6.35 (1/4") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ12.7 (1/2") ②φ12.7 (1/2")×0.8 ①φ15.88 (5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 46
#

-
14
-
'13 • PAC-T-198
Model
Item
FDT125VNPVF
Indoor unit FDT60VF (2 units) Outdoor unit FDC125VN
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 12.5 [ 5.0(Min.)
~ 14.0(Max.)]
Nominal heating capacity (range) kW 14.0 [ 4.0(Min.)
~ 16.0(Max.)]
Power Cooling
kW
3.95
consumption Heating 3.70
Max power consumption 5.14
Running Cooling
A
17.7 / 18.5
current Heating 16.6 / 17.3
Inrush current, max current 5, 24
Power factor Cooling %97
Heating 97
EER Cooling 3.16
COP Heating 3.78
Sound power level Cooling
dB(A)
60 72
Heating
Sound pressure level Cooling P-Hi : 46 Hi : 33 Me : 31 Lo : 30 50
Heating 51
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 246 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 24 PANEL 5.5 81
Compressor type & Q'ty — RMT5126MDE2×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 50 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 28 Hi : 18 Me : 16 Lo : 14 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ6.35 (1/4") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ12.7 (1/2") ②φ12.7 (1/2")×0.8 ①φ15.88 (5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 48
#

-
15
-
'13 • PAC-T-198
Model
Item
FDT125VSPVF
Indoor unit FDT60VF (2 units) Outdoor unit FDC125VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 12.5 [ 5.0(Min.)
~ 14.0(Max.)]
Nominal heating capacity (range) kW 14.0 [ 4.0(Min.)
~ 16.0(Max.)]
Power Cooling
kW
3.95
consumption Heating 3.70
Max power consumption 5.14
Running Cooling
A
5.9 / 6.2
current Heating 5.5 / 5.8
Inrush current, max current 5, 15
Power factor Cooling %97
Heating 97
EER Cooling 3.16
COP Heating 3.78
Sound power level Cooling
dB(A)
60 72
Heating
Sound pressure level Cooling P-Hi : 46 Hi : 33 Me : 31 Lo : 30 50
Heating 51
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 246 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 24 PANEL 5.5 83
Compressor type & Q'ty — RMT5126MDE3×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 50 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 28 Hi : 18 Me : 16 Lo : 14 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ6.35 (1/4") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ12.7 (1/2") ②φ12.7 (1/2")×0.8 ①φ15.88 (5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 46 / Heating : 48
#

-
16
-
'13 • PAC-T-198
Model
Item
FDT140VNPVF1
Indoor unit FDT71VF1 (2 units) Outdoor unit FDC140VN
Power source 1 Phase 220-240V 50Hz / 220V 60Hz
Operation
data
Nominal cooling capacity (range) kW 14.0 [ 5.0(Min.)
~ 14.5(Max.)]
Nominal heating capacity (range) kW 16.0 [ 4.0(Min.)
~ 16.5(Max.)]
Power Cooling
kW
4.51
consumption Heating 4.58
Max power consumption 5.95
Running Cooling
A
19.8 / 20.7
current Heating 20.1 / 21.0
Inrush current, max current 5, 24
Power factor Cooling %99
Heating 99
EER Cooling 3.1
COP Heating 3.49
Sound power level Cooling
dB(A)
64 73
Heating
Sound pressure level Cooling P-Hi : 46 Hi : 35 Me : 36 Lo : 31 51
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 246 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 24 PANEL 5.5 81
Compressor type & Q'ty — RMT5126MDE2×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 50 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 28 Hi : 21 Me : 19 Lo : 17 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") ②φ15.88 (5/8")×1.0 ①φ15.88 (5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) (2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 230V50Hz or 220V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 47 / Heating : 50
#

-
17
-
'13 • PAC-T-198
Model
Item
FDT140VSPVF1
Indoor unit FDT71VF1 (2 units) Outdoor unit FDC140VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 14.0 [ 5.0(Min.)
~ 14.5(Max.)]
Nominal heating capacity (range) kW 16.0 [ 4.0(Min.)
~ 16.5(Max.)]
Power Cooling
kW
4.51
consumption Heating 4.58
Max power consumption 5.95
Running Cooling
A
6.7 / 7.1
current Heating 6.7 / 7.1
Inrush current, max current 5, 15
Power factor Cooling %97
Heating 99 / 98
EER Cooling 3.1
COP Heating 3.49
Sound power level Cooling
dB(A)
64 73
Heating
Sound pressure level Cooling P-Hi : 46 Hi : 35 Me : 33 Lo : 31 51
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 246 × 840 × 840
Panel 35 × 950 × 950 845×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 24 PANEL 5.5 83
Compressor type & Q'ty — RMT5126MDE3×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 0.9 M-MA68
Refrigerant (Type, amount, pre-charge length) kg R410A 3.8kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×1
Fan motor (Starting method) W 50 < Direct line start > 86 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 28 Hi : 21 Me : 19 Lo : 17 75
Heating 73
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 20 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") ②φ15.88 (5/8")×1.0 ①φ15.88 (5/8")×1.0 O/Uφ15.88 (5/8")
Connecting method Flare piping Flare piping
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.50m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 47 / Heating : 50
#

-
18
-
'13 • PAC-T-198
Model
Item
FDT200VSPVF1
Indoor unit FDT100VF1 (2 units) Outdoor unit FDC200VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 20.0 [ 7.0(Min.)
~ 22.4(Max.)]
Nominal heating capacity (range) kW 22.4 [ 7.6(Min.)
~ 25.0(Max.)]
Power Cooling
kW
6.58
consumption Heating 6.02
Max power consumption 8.36
Running Cooling
A
9.9 / 10.6
current Heating 9.1 / 9.8
Inrush current, max current 5, 19
Power factor Cooling %96 / 94
Heating 95 / 93
EER Cooling 3.04
COP Heating 3.72
Sound power level Cooling
dB(A)
65 74
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 40 Me : 37 Lo : 35 57
Heating
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 1,300×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 122
Compressor type & Q'ty — GTC5150ND70K×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 1.45 M-MA32R
Refrigerant (Type, amount, pre-charge length) kg R410A 5.4kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×2
Fan motor (Starting method) W 140 < Direct line start > 86 x 2 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 27 Me : 24 Lo : 20 150
Heating 145
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 33 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") ②φ9.52 (3/8")×0.8 ①φ9.52 (3/8")×0.8 O/Uφ9.52 (3/8")
Gas line: I/Uφ15.88 (5/8") ②φ15.88 (5/8")×1.0 ①φ22.22 (7/8")×1.6 O/Uφ22.22 (7/8")
Connecting method Flare piping Liquid : Flare / Gas : Brazing
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.70m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Connecting pipe, Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 56 / Heating : 56
#

-
19
-
'13 • PAC-T-198
Model
Item
FDT250VSPVF
Indoor unit FDT125VF (2 units) Outdoor unit FDC250VS
Power source 3 Phase 380-415V 50Hz / 380V 60Hz
Operation
data
Nominal cooling capacity (range) kW 25.0 [ 10.0(Min.)
~ 28.0(Max.)]
Nominal heating capacity (range) kW 28.0 [ 9.5(Min.)
~ 31.5(Max.)]
Power Cooling
kW
8.30
consumption Heating 7.75
Max power consumption 9.96
Running Cooling
A
12.4 / 13.0
current Heating 11.8 / 12.3
Inrush current, max current 5, 22
Power factor Cooling %97
Heating 95 / 96
EER Cooling 3.01
COP Heating 3.61
Sound power level Cooling
dB(A)
68 74
Heating
Sound pressure level Cooling P-Hi : 51 Hi : 42 Me : 40 Lo : 37 57
Heating 58
Silent mode sound pressure level — —
Exterior dimensions (Height × Width × Depth) mm Unit 298 × 840 × 840
Panel 35 × 950 × 950 1,505×970×370
Exterior appearance
( Munsell color )
Plaster White
(6.8Y8.9/0.2 ) near equivalent
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg UNIT 27 PANEL 5.5 140
Compressor type & Q'ty — GTC5150ND70K×1
Compressor motor (Starting method) kW — Direct line start
Refrigerant oil (Amount, type) — 1.45 M-MA32R
Refrigerant (Type, amount, pre-charge length) kg R410A 7.2kg (Pre-charged up to the piping length of 30m) Outdoor unit
Heat exchanger Louver fin & inner grooved tubing Straight fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Fan type & Q'ty Turbo fan ×1 Propeller fan ×2
Fan motor (Starting method) W 140 < Direct line start > 86 x 2 < Direct line start >
Air flow Cooling
m
3
/min P-Hi : 37 Hi : 30 Me : 27 Lo : 23 150
Heating 145
Available external static pressure Pa 0 —
Outside air intake Possible —
Air filter, Quality / Quantity Pocket plastic net ×1(Washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for compressor)
Electric heater W — 33 (Crank case heater)
Operation
control
Remote control (option) wired : RC-EX1A, RC-E5, RCH-E3 wireless : RCN-T-36W-E
Room temperature control Thermostat by electronics
Operation display —
Safety equipments
Overload protection for fan motor.
Frost protection thermostat.
Internal thermostat for fan motor.
Abnormal discharge temperature protection.
Installation
data
Refrigerant piping size ( O.D. ) mm Liquid line: I/Uφ9.52 (3/8") ②φ9.52 (3/8")×0.8 ①φ12.7 (1/2")×0.8 O/Uφ12.7 (1/2")
Gas line: I/Uφ15.88 (5/8") ②φ15.88 (5/8")×1.0 ①φ22.22 (7/8")×1.6 O/Uφ22.22 (7/8")
Connecting method Flare piping Liquid : Flare / Gas : Brazing
Attached length of piping m — —
Insulation for piping Necessary (both Liquid & Gas lines)
Refrigerant line (one way) length m Max.70m
Vertical height diff. between O.U. and I.U. m Max.30m (Outdoor unit is higher) Max.15m (Outdoor unit is lower)
Drain hose Hose connectable with VP25 (O.D.32) Holes size φ20 × 3pcs
Drain pump, max lift height mm Built-in Drain pump, 700 —
Recommended breaker size A —
L.R.A. (Locked rotor ampere) A 5.0
Interconnecting wires Size × Core number φ1.6mm×3 cores (including earth cable) / Termainal block (Screw fixing type)
IP number IPX0 IP24
Standard accessories Mounting kit, Drain hose Connecting pipe, Edging
Option parts —
Note (1) The data are measured at the following conditions. The pipe length is 7.5m.
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) When wireless remote control is used, fan is 3 speed setting (Hi-Me-Lo) only.
(6) The operation data indicate when the air-conditioner is operated at 400V50Hz or 380V60Hz.
(7) Indoor unit specifications for one unit. Capacity and operation data are two indoor units are combined and run together.
(8) Branching pipe set "DIS-WA1"×1(option). ① : Pipe of O/U
~
Branch, ② : Pipe of Branch
~
I/U
Item
Operation
Indoor air temperature Outdoor air temperature Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C ISO5151-T1
Heating 20˚C —7˚C 6˚C
C
PJF000Z314
Cooling : 56 / Heating : 57
#
