TECHNICAL MANUAL
(1) Regarding the outdoor unit KXZ series, refer to the No.'14 • KX-T-223, No.'15 • KX-T-227 and
•Note:
No.'17 • KX-T-265.
(INDOOR UNIT)
Ceiling cassette - 4 way compact type
KXZ series
VRF INVERTER MULTI-SYSTEM AIR-CONDITIONERS
FDTC15KXZE1
FDTC22KXZE1
FDTC28KXZE1
FDTC36KXZE1
FDTC45KXZE1
FDTC56KXZE1
Manual No.'18•KX-T-281
updated December 14, 2018

–1–
'18 • KX-T-281
CONTENTS
2. SPECIFICATIONS
3. EXTERIOR DIMENSIONS
(1) Indoor units
(2) Remote control (Option parts)
8. APPLICATION DATA
8.1 Installation of indoor unit
4. ELECTRICAL WIRING
5. NOISE LEVEL
6. TEMPERATURE AND VELOCITY DISTRIBUTION
8.2 Electric wiring work instruction
8.3 Installation of wired remote control (Option parts)
9. OUTLINE OF OPERATION CONTROL BY MYCROCOMPUTER
9.1 Remote control (Option parts)
9.2 Operation control function by the wired remote control
(1) Model RC-EX3A
(2) Model RC-E5
7. CAPACITY TABLES
9.3 Operation control function by the indoor control
10. SYSTEM TROUBLESHOOTING PROCEDURE
10.1 Basics of troubleshooting
10.2 Contents of troubleshooting
10.3 Instruction of how to replace PCB
10.4 Indoor PCB setting
11. OPTION PARTS
11.1 Wireless kit (RCN-TC-5AW-E2)
11.2 Simple wired remote control (RCH-E3)
................................................................................
..............................................................................................................
.. .......................................................... ..............
.................................................................................................
...........................................................................................
................................................................................
..............................................
...................
...........................................
............. ................
.....................................
............... ....................................... .......................................
......
..... ......... ............. . ......................... .......................................
..................................................
..............................................
..........................................................................................
......................................................................................
...........................................................................
............................................................................................
.....................................................................................
.........................................
...........................................................................................................
.........................................................................................
......................................................................................................
..............................................................................
.................................................................
................................................................................................
.............................................................................
4
4
5
21
21
29
33
45
45
48
33
40
51
69
69
70
102
21. INFORMATION .................................................................................................
3
10
9
15
103
104
112
104
8
118
11.3 Motion sensor kit (LB-TC-5W-E)
11.4 OA spacer (FDTC series)
.........................................................................................
............................................................................................
122
126
11.5 Duct joint (FDTC series)

–2–
'18 • KX-T-281
1. INFORMATION
1.1 1.5kW-indoor units connection
(1) 1.5kW-Indoor unit
Model
FDTC15KXZE1
(2) Connectable outdoor units
(a) Connectable
.KXZ series (KXZ, KXZX, KXZPE1, KXZR) are connectable.
.FDC224-335KXE6 (service code A and there after) and FDC400-1360KXE6 (service code F and there after) are
connectable.
(b) Non-Connecctable
.FDC112-155KXE6, KXR and refresh KX series are not connectable.
.In case of connection with not the connectable outdoor units, error display (E22) will be appeared on the remote control.
(3) Installation limitation on 1.5kW-indoor unit connection
(a) Connectable KX6 outdoor units
(i) KX6 outdoor unit must have total indoor unit connection capacity ratio of 100% or more.
<Example>
FDC680KXE6 / service code F connecting with one or more 1.5kW-indoor units must have total indoor unit
capacity 680 or more.
(ii) Total piping length between outdoor unit and indoor units must be 150m or more, including both main and branch piping.
(iii) When one or more 1.5kW-indoor units are in the system, outdoor temperature condition in the cooling operation must
be 10°C or more. Without 1.5kW-indoor units connection in the system, the outdoor lowest temperature for FDC112-
335KXE6 is -15°C and that for FDC400-1360KXE6 is -5°C.
(b) KXZ outdoor units
.KXZ series (KXZ, KXZX, KXZR) does not have installation limitation on 1.5kW-indoor unit connection.
1.2 How to read the model name
■How to read the model name
Example: FDTC 22 E
Series No.
Application power source...See the specifications
Multi KXZ series
Nominal capacity (Nominal cooling capacity : 2.2kW)
Model name〔Ceiling cassette-4 way compact type 〕
KXZ 1

–3–
2. SPECIFICATIONS
Models FDTC15KXZE1, 22KXZE1, 28KXZE1, 36KXZE1, 45KXZE1, 56KXZE1
Model FDTC15KXZE1 FDTC22KXZE1 FDTC28KXZE1 FDTC36KXZE1 FDTC45KXZE1 FDTC56KXZE1
Panel model (Option)
Standard: TC-PSA-5AW-E Draft prevention: TC-PSAE-5AW-E
Standard: TC-PSA-5AW-E Draft prevention: TC-PSAE-5AW-E
Standard: TC-PSA-5AW-E Draft prevention: TC-PSAE-5AW-E
Standard: TC-PSA-5AW-E Draft prevention: TC-PSAE-5AW-E
Standard: TC-PSA-5AW-E Draft prevention: TC-PSAE-5AW-E
Standard: TC-PSA-5AW-E Draft prevention: TC-PSAE-5AW-E
Nominal cooling capacity*1 kW 1.5 2.2 2.8 3.6 4.5 5.6
Nominal heating capacity*2 1.7 2.5 3.2 4.0 5.0 6.3
Power source 220-240V 50Hz / 220V 60Hz 220-240V 50Hz / 220V 60Hz 220-240V 50Hz / 220V 60Hz 220-240V 50Hz / 220V 60Hz 220-240V 50Hz / 220V 60Hz 220-240V 50Hz / 220V 60Hz
Power consumption
Cooling
kW 0.03 - 0.03 / 0.03 0.03 - 0.03 / 0.03 0.03 - 0.03 / 0.03 0.04 - 0.04 / 0.04 0.05 - 0.05 / 0.05 0.06 - 0.06 / 0.06
Heating
0.03 - 0.03 / 0.03 0.03 - 0.03 / 0.03 0.03 - 0.03 / 0.03 0.04 - 0.04 / 0.04 0.05 - 0.05 / 0.05 0.06 - 0.06 / 0.06
Running current
Cooling
A0.25 - 0.22 / 0.25 0.25 - 0.22 / 0.25 0.25 - 0.22 / 0.25 0.38 - 0.35 / 038 0.43 - 0.40 / 0.43 0.54 - 0.50 / 0.54
Heating
0.25 - 0.22 / 0.25 0.25 - 0.22 / 0.25 0.25 - 0.22 / 0.25 0.38 - 0.35 / 038 0.43 - 0.40 / 0.43 0.54 - 0.50 / 0.54
Sound Pressure Level
Cooling
dB(A)
P-Hi: 33 Hi: 30 Me: 28 Lo: 25 P-Hi: 35 Hi: 32 Me: 29 Lo: 25 P-Hi: 35 Hi: 32 Me: 29 Lo: 25 P-Hi: 39 Hi: 36 Me: 31 Lo: 26 P-Hi: 43 Hi: 39 Me: 36 Lo: 28 P-Hi: 47 Hi: 43 Me: 39 Lo: 31
Heating
P-Hi: 33 Hi: 30 Me: 26 Lo: 22 P-Hi: 35 Hi: 32 Me: 29 Lo: 25 P-Hi: 35 Hi: 32 Me: 29 Lo: 25 P-Hi: 39 Hi: 36 Me: 31 Lo: 26 P-Hi: 43 Hi: 39 Me: 36 Lo: 28 P-Hi: 47 Hi: 43 Me: 39 Lo: 31
Sound Power Level
Cooling
47 49 49 54 58 60
Heating
46 49 49 53 57 60
Exterior dimensions Height x Width x Depth mm Unit: 248 × 570 × 570
Panel: 10 × 620 × 620
Unit: 248 × 570 × 570
Panel: 10 × 620 × 620
Unit: 248 × 570 × 570
Panel: 10 × 620 × 620
Unit: 248 × 570 × 570
Panel: 10 × 620 × 620
Unit: 248 × 570 × 570
Panel: 10 × 620 × 620
Unit: 248 × 570 × 570
Panel: 10 × 620 × 620
Exterior appearance ( Munsell color ) ( RAL color )
Fine snow
( 8.0Y9.3/0.1 )near equivalent
( RAL 9001 )near equivalent
Fine snow
( 8.0Y9.3/0.1 )near equivalent
( RAL 9001 )near equivalent
Fine snow
( 8.0Y9.3/0.1 )near equivalent
( RAL 9001 )near equivalent
Fine snow
( 8.0Y9.3/0.1 )near equivalent
( RAL 9001 )near equivalent
Fine snow
( 8.0Y9.3/0.1 )near equivalent
( RAL 9001 )near equivalent
Fine snow
( 8.0Y9.3/0.1 )near equivalent
( RAL 9001 )near equivalent
Net weight*3 kg Unit: 12.5 Standard panel: 2.5 Unit: 13 Standard panel: 2.5 Unit: 13 Standard panel: 2.5 Unit: 14 Standard panel: 2.5 Unit: 14 Standard panel: 2.5 Unit: 14 Standard panel: 2.5
Refrigerant equipment Heat exchanger
Louver n & inner grooved tubing
Electronic Expansion Valve
Louver n & inner grooved tubing
Electronic Expansion Valve
Louver n & inner grooved tubing
Electronic Expansion Valve
Louver n & inner grooved tubing
Electronic Expansion Valve
Louver n & inner grooved tubing
Electronic Expansion Valve
Louver n & inner grooved tubing
Electronic Expansion Valve
Refrigerant control
Air handling equipment Fan type & Q'ty
Turbo fan ×1 Turbo fan ×1 Turbo fan ×1 Turbo fan ×1 Turbo fan ×1 Turbo fan ×1
Motor W50 50 50 50 50 50 Starting method Direct line start Direct line start Direct line start Direct line start Direct line start Direct line start
Air ow(Standard)
Cooling
CMM
P-Hi: 8 Hi: 7 Me: 6 Lo: 5 P-Hi: 9 Hi: 8 Me: 7 Lo: 6 P-Hi: 9 Hi: 8 Me: 7 Lo: 6 P-Hi: 10 Hi: 9 Me: 8 Lo: 6 P-Hi: 12 Hi: 10 Me: 9 Lo: 7 P-Hi: 14 Hi: 12 Me: 10 Lo: 8
Heating
P-Hi: 8 Hi: 7 Me: 6 Lo: 5 P-Hi: 9 Hi: 8 Me: 7 Lo: 6 P-Hi: 9 Hi: 8 Me: 7 Lo: 6 P-Hi: 10 Hi: 9 Me: 8 Lo: 6 P-Hi: 12 Hi: 10 Me: 9 Lo: 7 P-Hi: 14 Hi: 12 Me: 10 Lo: 8
Available static pressure Pa 000000
Outdoor air intake Possible Possible Possible Possible Possible Possible
Air lter, Q'ty Pocket plastic net ×1(Washable) Pocket plastic net ×1(Washable) Pocket plastic net ×1(Washable) Pocket plastic net ×1(Washable) Pocket plastic net ×1(Washable) Pocket plastic net ×1(Washable)
Shock & vibration absorber Rubber sleeve(for fan motor) Rubber sleeve(for fan motor) Rubber sleeve(for fan motor) Rubber sleeve(for fan motor) Rubber sleeve(for fan motor) Rubber sleeve(for fan motor)
Insulation (noise & heat) Polyurethane form Polyurethane form Polyurethane form Polyurethane form Polyurethane form Polyurethane form
Operation control Remote control switch ( option )
Wired : RC-E5, RC-EX3A, RCH-E3
Wireless : RCN-TC-5AW-E2
Wired : RC-E5, RC-EX3A, RCH-E3
Wireless : RCN-TC-5AW-E2
Wired : RC-E5, RC-EX3A, RCH-E3
Wireless : RCN-TC-5AW-E2
Wired : RC-E5, RC-EX3A, RCH-E3
Wireless : RCN-TC-5AW-E2
Wired : RC-E5, RC-EX3A, RCH-E3
Wireless : RCN-TC-5AW-E2
Wired : RC-E5, RC-EX3A, RCH-E3
Wireless : RCN-TC-5AW-E2
Room temperature control Thermostat by electronics Thermostat by electronics Thermostat by electronics Thermostat by electronics Thermostat by electronics Thermostat by electronics
Safety equipment
Overload protection for fan motor
Frost protection thermostat
Overload protection for fan motor
Frost protection thermostat
Overload protection for fan motor
Frost protection thermostat
Overload protection for fan motor
Frost protection thermostat
Overload protection for fan motor
Frost protection thermostat
Overload protection for fan motor
Frost protection thermostat
Installation data Refrigerant piping size
Liquid line: φ6.35 (1/4")
Gas line: φ9.52 (3/8")
Liquid line: φ6.35 (1/4")
Gas line: φ9.52 (3/8")
Liquid line: φ6.35 (1/4")
Gas line: φ9.52 (3/8")
Liquid line: φ6.35 (1/4")
Gas line: φ12.7 (1/2 ")
Liquid line: φ6.35 (1/4")
Gas line: φ12.7 (1/2 ")
Liquid line: φ6.35 (1/4")
Gas line: φ12.7 (1/2 ")
Connecting method Flare piping Flare piping Flare piping Flare piping Flare piping Flare piping
Refrigerant R410A R410A R410A R410A R410A R410A
Drain pump Built-in Drain pump Built-in Drain pump Built-in Drain pump Built-in Drain pump Built-in Drain pump Built-in Drain pump Drain hose Connectable with VP25 Connectable with VP25 Connectable with VP25 Connectable with VP25 Connectable with VP25 Connectable with VP25
Insulation for piping
Necessary(both Liquid & Gas line) Necessary(both Liquid & Gas line) Necessary(both Liquid & Gas line) Necessary(both Liquid & Gas line) Necessary(both Liquid & Gas line) Necessary(both Liquid & Gas line)
Accessories Mounting kit,Drain hose Mounting kit,Drain hose Mounting kit,Drain hose Mounting kit,Drain hose Mounting kit,Drain hose Mounting kit,Drain hose
Exterior dimensions PJF000Z501 PJF000Z501 PJF000Z501 PJF000Z501 PJF000Z501 PJF000Z501
Electrical wiring PJF000Z504 PJF000Z504 PJF000Z504 PJF000Z504 PJF000Z504 PJF000Z504
Notes (1) The data are measured at the following conditions.
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 "UNITARY AIR-CONDITIONERS"
(3) Draft prevention panel weight*3 : 3.0kg (4) Option : Motion sensor kit (LB-TC-5W-E)
Adapted to RoHS directive
Item Indoor air temperature Outdoor air temperature Standards
Operation DB WB DB WB
Cooling*1 27℃19℃35℃24℃ISO-T1
Heating*2 20℃7℃6℃
'18 • KX-T-281
PJF000Z498

–4–
Unit：mm
A
Content
Gas piping
B
Liquid piping
C
Drain piping
VP25（O.D.32）
D１
Power source connection
F
Suspension bolts
（M10 or M8）
G
Space for installation and service
Obstacle
Make a space of 4000 or more between
H
φ125（Knock out）
Symbol
for ducting
Outside air opening
for ducting
Air outlet opening
or more
or more
the units when installing more than one.
（Knock out）
Notes（1）
The model name label is attached to the control box lid.
（2）
This unit is designed for 2x2 grid ceiling.
If it is installed on a ceiling other than 2x2 grid ceiling,
provide an inspection opening on the control box side.
（3）Draft prevention function（※）is provided on the panel TC-PSAE-5AW-E only.
Model
36,45,56
φ6.35（1／4"）（ Flare）
Hanger plate for
box
suspension bolt
（Accessory）
（Installed on site）
Drain hose piece
Draft prevention function（※）
Decorative panel
Air supply
Air return grille
Hole
Hole
6-φ4
Holes for tapping screws
4-φ4
Holes for tapping screws
D２
Remote control code and signal wiring connection
Control
φ9.52（3／8"）
（Flare）
φ12.7（1／2"）
（Flare）
15,22,28
J
Inspection opening
450X450
H
H
H
B
ACF
G
D2
D1
H
G
D1
Control box
J
Inspection opening（Refer to note（2））
1000
1000
530
530
□570
248
130
190
10
210
130
288
110
50
467
225
175
185
354
325
73
184 63
Suspension bolts pitch
Suspension bolts pitch
（ ）
（ ）
89
60
140
140
88
77
89
100
100
158
Max. Drain lift （ ）
or less
-245
215
850
or more
□400 □620
□576-600
□576-610
Ceiling hole size
（）
System ceiling hole size
（）
φ100
150-200
3. EXTERIOR DIMENSIONS
(1) Indoor units
All models
'18 • KX-T-281
A
PJF000Z501

–5–
'18 • KX-T-281
PJZ000Z333
Installation space
30mm
30mm
30mm
120mm
配線
30mm 30mm
30mm
120mm
Wiring
R/C temperature sensor
Secure minimum spaces for disassembling the case.
Upper left and Upper right sides
……30mm or more
Bottom side…120mm or more
If using L-shaped screwdriver, 50mm or more is
available.
Dimensions (Viewed from front)
37 23 23
固定穴
18.383.5
120
19
120
37 23 23 19
120
Fixing holes
83.5
120
18.3
≦200 m 0.5 mm2x 2 cores
≦300m 0.75 mm2x 2 cores
≦400m 1.25 mm2x 2 cores
≦600m 2.0 mm2x 2 cores
● Do not install the remote control at following places.
(1) It could cause break-down or deformation of remote control.
・Where it is exposed to direct sunlight
・Where the ambient temperature becomes 0 °C or below, or 40 °C or above
・Where the surface is not flat
・Where the strength of installation area is insufficient
(2) Moisture may be attached to internal parts of the remote control, resulting in a display failure.
・Place with high humidity where condensation occurs on the remote control
・Where the remote control gets wet
(3) Accurate room temperature may not be detected using the temperature sensor of the remote
control.
・Where the average room temperature cannot be detected
・Place near the equipment to generate heat
・Place affected by outside air in opening/closing the door
・Place exposed to direct sunlight or wind from air-conditioner
・Where the difference between wall and room temperature is large
(4) When you are using the automatic grille up and down panel in the IU, you may not be able to
confirm the up and down motion.
・Where the IU cannot be visually confirmed
● When installing the unit at a hospital, telecommunication facility, etc., take
measures to
suppress electric noises.
It could cause malfunction or break-down due to hazardous effects on the inverter, private power
generator, high frequency medical equipment, radio communication equipment, etc.
The influences transmitted from the remote control to medical or communication equipment could
disrupt medical activities, video broadcasting or cause noise interference.
R/C cable:0.3mm2x2 cores
When the cable length is longer than 100 m,
the max size for wires used in the R/C case
is 0.5 mm2. Connect them to wires of larger
size near the outside of R/C. When wires are
connected, take measures to prevent water,
etc. from entering inside.
Adapted RoHS directive
(2) Remote control (Option parts)
(a) Wired remote control
(e) Model RC-EX3A

– 6–
'18 • KX-T-281
Model RC-E5
TEMP ON/OFF
48
ڧ120
L C D
Wall surface
Wiring
Electrical box
䠄Not included䠅
19
Wiring specifications
Exposed mounting
23
46
11.5 11
Remote
control
outline
120
45
83.5
42
120
Remote control installation dimensions
Wiring oulet
Installation hole
12×7 slot hole
9.5×5 slot hole䠄4places䠅
䠄1䠅Installation screw for remote control
M4 screw (2 pieces)
44
(1) If the prolongation is over 100m, change to the size below.
But, wiring in the remote control case should be under 0.5mm2. Change the wire size outside of
the case according to wire connecting. Waterproof treatment is necessary at the wire connecting
section. Be careful about contact failure.
Length Wiring thickness
100 to 200m 0.5mm2×2 cores
0.75mm2×2 cores
1.25mm2×2 cores
2.0mm2×2 cores
Under 300m
Under 400m
Under 600m
Upper part
Lower part
Lower case
Sheath
Upper cace
Board
Wiring
Upper
Lower
XY
Sheath
Upper cace
Board
Wiring
Upper
Lower
YX
Tighten the screws after
cutting off the thin part of
screw mounting part.
Embedded mounting
The peeling-off length of sheath
The peeling-off length
of sheath
In case of pulling out from
upper left
In case of pulling out
from upper left
In case of pulling out
from upper left
X wiring : 170mm
Y wiring : 190mm
Pulling out from center
X wiring : 215mm
Y wiring : 195mm
Pulling out from upper left
In case of pulling out from center
In case of pulling out
from center
In case of pulling out
from center
Wiring outlet
Cut off the upper thin part of remote control lower case with a nipper or knife,
and grind burrs with a file etc.
0.3mm2×2 cores
X, Y Terminal block
Attach M3 screw
with washer
Unit:mm
Exterior appearance
(Munsell color)
Pearl white
(N8.5) near equivalent
PJZ000Z295

– 7–
'18 • KX-T-281
(b) Wireless remote control (RCN-E2)
Unit: mm
60 24
167

–8–
'18 • KX-T-281
CNTA
BL
12
Thi-A
CNI
BL
CNJ1
WH
6
5
4
3 2
1
CNN
YE
Thi-R3 Thi-R2
Thi-R1
t° t° t°
2
1
CNC
WH
CNH
BK
12
t°
DM
12
CNR
WH
M
2
1
RD RD
RD RD
YE
BK BK
YE
FS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
+12+12
YE／GN BKBK
RDWH
LM4LM1 LM2 LM3
MM
1
M M
BK
2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
BK BK BK BK BK BK BK BK BK RD RD RD RD RD RD RD RD RD RD
E1
CNL
BK
3
1
2
BK BK BK
Option
（volt-free contact）
HS
BK BK
Remote operation input
BK BK BK BK BK BK BK BK BK BK RD RD RD RD RD RD RD RD RD RD
CNJ3
WH
PIS
3
1
2
t°
Remote control
Thc
M
CNA
RD CNJ2
GY
AM4AM1 AM2 AM3
CNM1
WH
F2
CNB
BK
CNK1
WH
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
SM
WHYE
OR
BL
RD
XR1
XR5
CNT
BL
For heat recovery 3-pipe systems
（20S）
（SVH）
（SVG）
（SVE）
XB1
Prepare on site
XB2
XB3
XB4
XR2
XR3
XR4
1
2 3
4
5
6
CNT2
RD
1
2 3
4
5
X
Y A
B
X
Y
TB2
WH
BK
BL
RD
L
N
Power source line
TB1
Connector for branching control
of heat recovery 3-pipe systems
CNU
BL
WH
RD
Earth
YE／GN
1 2 3 4 5 6
+12 +12
（2.0A）
※１
MM
1
M M
2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
WH WH WH WH WH WH WH WH WH WHBL BL BL BL BLBL BL BL BL BL
F1
CNWO
WH 135
YE／GN
RD
（3.15A）
WH
Power circuit
Indoor unit PCB
1
2
1
2
（Operation）
（Heating）
（Thermo ON）
（Inspection）
Remote operation input
（volt-free contact）
220-240V 50Hz 220V 60Hz
Power source
1Phase
Signal line
between indoor units
Signal line
（Shielded cord）
Power source line between indoor units
CNJ4
WH
WH WH WH WH WH WH WH WH WH WHBL BL BL BL BL
BL BL BL BL BL
FMi
M
1 4 5 6 7
BLRD BR OR WH
CNM2
WH
BLRD BR OR WH
Operation check,drain motor test run Thermistor（Remote control） Model capacity setting
SW6,SW7-2
Terminal block（Power source）（ □ mark）
TB1 TB2
Stepping motor（For electronic expansion valve）
SM SW1 SW2
Indoor unit address:tens place Indoor unit address:ones place
SW3 SW4
Automatic adjustment ／Fixed previous
SW5-1 SW5-2 SW7-1 Thi-A Thi-R1,2,3 Thc
Outdoor unit address:tens place Outdoor unit address:ones place Indoor unit address:hundreds place Terminal block（Signal line）（ □ mark） Thermistor（Return air） Thermistor（Heat exchanger） version of superlink protocol Drain motor Fan motor
DM
FuseF1,2 ConnectorCNA-Z
FMi
DescriptionItem
Draft prevention function motorAM1-4 Louver motor Float switch
LM1-4 FS
Indication lamp（Red-Inspection）
LED・2
Indication lamp（Green-Nomal operation）
LED・3 JSL1 Spare Superlink connector change PIS Motion sensor
Color marks
Meaning of marks
Mark Color
Blue
BK
BL
Brown
Orange
BR
OR
Red
RD
Black
Mark Color
Yellow
WH
YE
Gray
Yellow／Green
GY
YE／GN
White
Humidity sensor
HS
SW2SW1
SW4SW3
SW6SW7
CNK2
Superlink（spare）
JSL1
BK
LED・3LED・2
SW5
Prepare on site
1. indicates wiring on site.
2.Use twin core shielded cord（0.75-1.25mm ）at signal line between
2
indoor unit and outdoor unit, and signal line between indoor units.
3.Use twin core cord（0.3mm ）at remote control line.
2
See spec sheet of remote control in case that the total length is more than 100m.
4.Do not put signal line and remote control line alongside power source line.
Notes
5.Draft prevention function（※１）is provided on the panel TC-PSAE-5AW-E only.
4. ELECTRICAL WIRING
All models
PJF000Z504
4. NOISE LEVEL
Note (1) The data are based on the following conditions.
Ambient air tempetature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB
(2) The data in the chart are measuted in an unechonic room.
Measured based on JIS B 8616
Mike position as right
1.5m
Mike (Center & low points)
FDTC15KXZE1
63 125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
FDTC45KXZE1
63 63
125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
FDTC56KXZE1
125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Noise level 33dB(A) at P-Hi Noise level 35dB(A) at P-Hi Noise level 39dB(A) at P-Hi
Noise level 43dB(A) at P-Hi Noise level 47dB(A) at P-Hi
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Mid octave band frequency (Hz) Mid octave band frequency (Hz)
FDTC22,28KXZE1 FDTC36KXZE1
Mid octave band frequency (Hz) Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
63 125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
63 125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60

–9–
'18 • KX-T-281
CNTA
BL
12
Thi-A
CNI
BL
CNJ1
WH
6
5
4
3 2
1
CNN
YE
Thi-R3 Thi-R2
Thi-R1
t° t° t°
2
1
CNC
WH
CNH
BK
12
t°
DM
12
CNR
WH
M
2
1
RD RD
RD RD
YE
BK BK
YE
FS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
+12+12
YE／GN BKBK
RDWH
LM4LM1 LM2 LM3
MM
1
M M
BK
2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
BK BK BK BK BK BK BK BK BK RD RD RD RD RD RD RD RD RD RD
E1
CNL
BK
3
1
2
BK BK BK
Option
（volt-free contact）
HS
BK BK
Remote operation input
BK BK BK BK BK BK BK BK BK BK RD RD RD RD RD RD RD RD RD RD
CNJ3
WH
PIS
3
1
2
t°
Remote control
Thc
M
CNA
RD CNJ2
GY
AM4AM1 AM2 AM3
CNM1
WH
F2
CNB
BK
CNK1
WH
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
SM
WHYE
OR
BL
RD
XR1
XR5
CNT
BL
For heat recovery 3-pipe systems
（20S）
（SVH）
（SVG）
（SVE）
XB1
Prepare on site
XB2
XB3
XB4
XR2
XR3
XR4
1
2 3
4
5
6
CNT2
RD
1
2 3
4
5
X
Y A
B
X
Y
TB2
WH
BK
BL
RD
L
N
Power source line
TB1
Connector for branching control
of heat recovery 3-pipe systems
CNU
BL
WH
RD
Earth
YE／GN
1 2 3 4 5 6
+12 +12
（2.0A）
※１
MM
1
M M
2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
WH WH WH WH WH WH WH WH WH WHBL BL BL BL BLBL BL BL BL BL
F1
CNWO
WH 135
YE／GN
RD
（3.15A）
WH
Power circuit
Indoor unit PCB
1
2
1
2
（Operation）
（Heating）
（Thermo ON）
（Inspection）
Remote operation input
（volt-free contact）
220-240V 50Hz 220V 60Hz
Power source
1Phase
Signal line
between indoor units
Signal line
（Shielded cord）
Power source line between indoor units
CNJ4
WH
WH WH WH WH WH WH WH WH WH WHBL BL BL BL BL
BL BL BL BL BL
FMi
M
1 4 5 6 7
BLRD BR OR WH
CNM2
WH
BLRD BR OR WH
Operation check,drain motor test run Thermistor（Remote control） Model capacity setting
SW6,SW7-2
Terminal block（Power source）（ □ mark）
TB1 TB2
Stepping motor（For electronic expansion valve）
SM SW1 SW2
Indoor unit address:tens place Indoor unit address:ones place
SW3 SW4
Automatic adjustment ／Fixed previous
SW5-1 SW5-2 SW7-1 Thi-A Thi-R1,2,3 Thc
Outdoor unit address:tens place Outdoor unit address:ones place Indoor unit address:hundreds place Terminal block（Signal line）（ □ mark） Thermistor（Return air） Thermistor（Heat exchanger） version of superlink protocol Drain motor Fan motor
DM
FuseF1,2 ConnectorCNA-Z
FMi
DescriptionItem
Draft prevention function motorAM1-4 Louver motor Float switch
LM1-4 FS
Indication lamp（Red-Inspection）
LED・2
Indication lamp（Green-Nomal operation）
LED・3 JSL1 Spare Superlink connector change PIS Motion sensor
Color marks
Meaning of marks
Mark Color
Blue
BK
BL
Brown
Orange
BR
OR
Red
RD
Black
Mark Color
Yellow
WH
YE
Gray
Yellow／Green
GY
YE／GN
White
Humidity sensor
HS
SW2SW1
SW4SW3
SW6SW7
CNK2
Superlink（spare）
JSL1
BK
LED・3LED・2
SW5
Prepare on site
1. indicates wiring on site.
2.Use twin core shielded cord（0.75-1.25mm ）at signal line between
2
indoor unit and outdoor unit, and signal line between indoor units.
3.Use twin core cord（0.3mm ）at remote control line.
2
See spec sheet of remote control in case that the total length is more than 100m.
4.Do not put signal line and remote control line alongside power source line.
Notes
5.Draft prevention function（※１）is provided on the panel TC-PSAE-5AW-E only.
5. NOISE LEVEL
Notes (1) The data are based on the following conditions.
Ambient air tempetature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB
(2) The data in the chart are measuted in an unechonic room.
(3) The noise levels measured in the eld are usually higher than the data because of reection.
4. NOISE LEVEL
Note (1) The data are based on the following conditions.
Ambient air tempetature: Indoor unit 27˚C DB, 19˚C WB. Outdoor unit 35˚C DB
(2) The data in the chart are measuted in an unechonic room.
Measured based on JIS B 8616
Mike position as right
1.5m
Mike (Center & low points)
FDTC15KXZE1
63 125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
FDTC45KXZE1
63 63
125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
FDTC56KXZE1
125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Noise level 33dB(A) at P-Hi Noise level 35dB(A) at P-Hi Noise level 39dB(A) at P-Hi
Noise level 43dB(A) at P-Hi Noise level 47dB(A) at P-Hi
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Mid octave band frequency (Hz) Mid octave band frequency (Hz)
FDTC22,28KXZE1 FDTC36KXZE1
Mid octave band frequency (Hz) Mid octave band frequency (Hz)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
Sound pressure level (dB)
(Standard 2×10-5 Pa)
63 125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60
63 125 250 500 1000 2000 4000 8000
20
10
30
40
50
60
20
10
30
40
50
60
N30
N40
N20
N50
N60

–10 –
'18 • KX-T-281
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Louver position
Louver position
Velocity distribution
(℃)
Temperature distribution
Heating Air flow: P-Hi
Cooling Air flow: P-Hi
FDTC15KXZE1
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
(m/sec)
2525
23
23 15
15
19
19
25
25
23
23
15
15 19
19
0.30.3
0.5
0.5
1.0
1.0
0.3
0.3
0.5
0.5
1.0
1.0
2222
23
23
32
32
35
35
25
25
22
22
23
23
32
32
35
35
25
25
0.30.3
0.5
0.5
0.8
0.8
0.3
0.3
0.5
0.5
0.8
0.8
6. TEMPERATURE AND VELOCITY DISTRIBUTION
Indoor temperature
Cooling 27°CDB/19°CWB, Heating 20°CDB
〔Note〕
These gures represent the typical main range of temperature and velocity distribution at the center of air outlet within the published conditions.
In the actual installation, they may differ from the typical gures under the inuence of air temperature conditions, ceiling height, operation conditions and obstacles.
Model FDTC15KXZE1
Louver position
Louver position
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
Cooling Air flow: P-Hi
FDTC22,28 KXZE1
Heating Air flow: P-Hi
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2424
21
21
15
15
18
18
24
24
21
21
15
15 18
18
0.30.3
0.6
0.6 0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
2323
32
32
3535
29
29
26
26
23
23
32
32
3535
29
29
26
26

–11 –
'18 • KX-T-281
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Louver position
Louver position
Velocity distribution
(℃)
Temperature distribution
Heating Air flow: P-Hi
Cooling Air flow: P-Hi
FDTC15KXZE1
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
(m/sec)
2525
23
23 15
15
19
19
25
25
23
23
15
15 19
19
0.30.3
0.5
0.5
1.0
1.0
0.3
0.3
0.5
0.5
1.0
1.0
2222
23
23
32
32
35
35
25
25
22
22
23
23
32
32
35
35
25
25
0.30.3
0.5
0.5
0.8
0.8
0.3
0.3
0.5
0.5
0.8
0.8
Louver position
Louver position
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
Cooling Air flow: P-Hi
FDTC22,28 KXZE1
Heating Air flow: P-Hi
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2424
21
21
15
15
18
18
24
24
21
21
15
15 18
18
0.30.3
0.6
0.6 0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
2323
32
32
3535
29
29
26
26
23
23
32
32
3535
29
29
26
26
Models FDTC22, 28KXZE1

– 12 –
'18 • KX-T-281
FDTC36KXZE1
Louver position
Louver position
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
Cooling Air flow: P-Hi
Heating Air flow: P-Hi
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2424
21
21
24
24
21
21
0.30.3
0.6
0.6
0.9
0.9
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
23
23
32
32
3535
29
29
26
26
15
15
18
18 15
15 18
18
0.3
0.3
0.6
0.6
0.9
0.9
23
23
32
32
3535
29
29
26
26
23232323
32
32
3535
29
29
26
26
Model FDTC36KXZE1
FDTC45KXZE1
Louver position
Louver position
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
Heating Air flow: P-Hi
Cooling Air flow: P-Hi
2424
21
21
0.30.3
0.6
0.6 0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
15
15
18
18
24
24
21
21
15
15 18
18
3232
23
23
26
26
35
35
29
29
32
32
23
23
26
26
35
35
29
29

–13 –
'18 • KX-T-281
FDTC36KXZE1
Louver position
Louver position
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
Cooling Air flow: P-Hi
Heating Air flow: P-Hi
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2424
21
21
24
24
21
21
0.30.3
0.6
0.6
0.9
0.9
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
23
23
32
32
3535
29
29
26
26
15
15
18
18 15
15 18
18
0.3
0.3
0.6
0.6
0.9
0.9
23
23
32
32
3535
29
29
26
26
23232323
32
32
3535
29
29
26
26
FDTC45KXZE1
Louver position
Louver position
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
Heating Air flow: P-Hi
Cooling Air flow: P-Hi
2424
21
21
0.30.3
0.6
0.6 0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
15
15
18
18
24
24
21
21
15
15 18
18
3232
23
23
26
26
35
35
29
29
32
32
23
23
26
26
35
35
29
29
Model FDTC45KXZE1

– 14 –
'18 • KX-T-281
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
FDTC56KXZE1
Louver position
Louver position
Heating Air flow: P-Hi
Cooling Air flow: P-Hi
2424 2424
21
21
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
15
15
18
18
21
21
15
15 18
18
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
23
23
32
32
35
35
29
29
26
26 2323
32
32
35
35
29
29
26
26
Model FDTC56KXZE1

–15 –
'18 • KX-T-281
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
(℃)
Temperature distribution
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
1m0m 2m 3m 4m 5m
5m 4m 3m 2m 1m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
2.7m
2m
1m
0m
Velocity distribution (m/sec)
FDTC56KXZE1
Louver position
Louver position
Heating Air flow: P-Hi
Cooling Air flow: P-Hi
2424 2424
21
21
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
15
15
18
18
21
21
15
15 18
18
0.30.3
0.6
0.6
0.9
0.9
0.3
0.3
0.6
0.6
0.9
0.9
23
23
32
32
35
35
29
29
26
26 2323
32
32
35
35
29
29
26
26
Model FDTC15KXZE1
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.69 1.62 1.89 1.81 1.97 1.89
-19.8 -20 0.99 0.99 0.99 0.99 0.99
12 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.69 1.62 1.89 1.81 1.96 1.88
-17.8 -18 1.05 1.05 1.05 1.05 1.05
14 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.69 1.62 1.88 1.80 1.95 1.87
-15.7 -16 1.11 1.11 1.11 1.11 1.11
16 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.68 1.61 1.87 1.80 1.94 1.86
-13.7 -14 1.18 1.18 1.18 1.18 1.18
18 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.68 1.61 1.87 1.80 1.93 1.85
-11.7 -12 1.24 1.24 1.24 1.24 1.24
P-Hi 20 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.68 1.61 1.86 1.79 1.93 1.85
P-Hi -9.6 -10 1.30 1.30 1.30 1.30 1.30
22 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.67 1.60 1.84 1.77 1.90 1.82
-7.5 -8 1.38 1.38 1.38 1.38 1.38
8 24 0.00 #####1.23 1.18 1.47 1.41 1.59 1.53 1.66 1.59 1.81 1.74 1.87 1.80
8 -5.5 -6 1.46 1.46 1.46 1.46 1.46
(m3/min) 26 0.00 #####1.23 1.18 1.46 1.40 1.58 1.52 1.64 1.57 1.78 1.71 1.84 1.77
(m3/min) -3.4 -4 1.51 1.51 1.51 1.49 1.48
28 1.11 1.07 1.22 1.17 1.46 1.40 1.56 1.50 1.63 1.56 1.76 1.69 1.81 1.74
-1.3 -2 1.56 1.56 1.56 1.53 1.50
30 1.11 1.07 1.22 1.17 1.44 1.38 1.55 1.49 1.61 1.55 1.73 1.66 1.79 1.72
0.8 0 1.65 1.63 1.60 1.54 1.49
0.0506932 1.11 1.07 1.22 1.17 1.43 1.37 1.53 1.47 1.59 1.53 1.70 1.63 1.76 1.69
3.9 3 1.79 1.73 1.66 1.57 1.47
34 1.11 1.07 1.21 1.16 1.43 1.37 1.51 1.45 1.56 1.50 1.67 1.60 1.72 1.65
7.0 6 1.96 1.83 1.70 1.58 1.46
0.96 35 1.11 1.07 1.21 1.16 1.43 1.37 1.50 1.44 1.55 1.49 1.65 1.58 1.71 1.64
10.1 9 1.94 1.82 1.69 1.57 1.45
36 1.11 1.07 1.21 1.16 1.41 1.35 1.49 1.43 1.53 1.47 1.62 1.56 1.67 1.60
13.2 12 1.93 1.81 1.68 1.56 1.44
38 1.11 1.07 1.21 1.16 1.39 1.33 1.48 1.42 1.51 1.45 1.56 1.50 1.61 1.55
16.9 15.5 1.91 1.79 1.67 1.54 1.42
39 1.11 1.07 1.21 1.16 1.38 1.32 1.47 1.41 1.49 1.43 1.53 1.47 1.57 1.51
41 1.11 1.07 1.20 1.15 1.34 1.29 1.41 1.35 1.43 1.37 1.46 1.40 1.50 1.44
43 1.11 1.07 1.20 1.15 1.30 1.25 1.35 1.30 1.36 1.31 1.39 1.33 1.43 1.37
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.14 1.09 1.36 1.31 1.47 1.41 1.56 1.50 1.75 1.68 1.82 1.70
-19.8 -20 0.90 0.90 0.90 0.90 0.90
12 0.00 #####1.14 1.09 1.36 1.31 1.47 1.41 1.56 1.50 1.74 1.67 1.81 1.70
-17.8 -18 0.96 0.96 0.96 0.96 0.96
14 0.00 #####1.14 1.09 1.36 1.31 1.47 1.41 1.56 1.50 1.74 1.67 1.80 1.69
-15.7 -16 1.01 1.01 1.01 1.01 1.01
16 0.00 #####1.14 1.09 1.36 1.31 1.47 1.41 1.56 1.50 1.73 1.66 1.79 1.69
-13.7 -14 1.07 1.07 1.07 1.07 1.07
18 0.00 #####1.14 1.09 1.36 1.31 1.47 1.41 1.55 1.49 1.72 1.65 1.79 1.69
-11.7 -12 1.13 1.13 1.13 1.13 1.13
Hi 20 0.00 #####1.14 1.09 1.36 1.31 1.47 1.41 1.55 1.49 1.72 1.65 1.78 1.69
Hi -9.6 -10 1.19 1.19 1.19 1.19 1.19
22 0.00 #####1.13 1.08 1.36 1.31 1.47 1.41 1.54 1.48 1.70 1.63 1.75 1.68
-7.5 -8 1.26 1.26 1.26 1.26 1.26
7 24 0.00 #####1.13 1.08 1.36 1.31 1.47 1.41 1.54 1.48 1.67 1.60 1.73 1.66
7 -5.5 -6 1.33 1.33 1.33 1.33 1.33
(m3/min) 26 0.00 #####1.13 1.08 1.35 1.30 1.45 1.39 1.52 1.46 1.65 1.58 1.70 1.63
(m3/min) -3.4 -4 1.38 1.37 1.37 1.36 1.35
28 1.02 0.98 1.13 1.08 1.34 1.29 1.44 1.38 1.50 1.44 1.62 1.56 1.68 1.61
-1.3 -2 1.42 1.42 1.42 1.39 1.36
30 1.02 0.98 1.13 1.08 1.33 1.28 1.43 1.37 1.48 1.42 1.60 1.54 1.65 1.58
0.8 0 1.50 1.48 1.46 1.41 1.35
0.0395332 1.02 0.98 1.12 1.08 1.32 1.27 1.41 1.35 1.47 1.41 1.57 1.51 1.63 1.56
3.9 3 1.63 1.57 1.51 1.43 1.34
34 1.02 0.98 1.12 1.08 1.32 1.27 1.39 1.33 1.44 1.38 1.54 1.48 1.59 1.53
7.0 6 1.78 1.66 1.55 1.44 1.33
0.9602235 1.02 0.98 1.12 1.08 1.32 1.27 1.39 1.33 1.43 1.37 1.52 1.46 1.58 1.52
10.1 9 1.77 1.65 1.54 1.43 1.32
36 1.02 0.98 1.12 1.08 1.31 1.26 1.38 1.32 1.42 1.36 1.50 1.44 1.54 1.48
13.2 12 1.76 1.64 1.53 1.42 1.31
38 1.02 0.98 1.12 1.08 1.29 1.24 1.36 1.31 1.39 1.33 1.44 1.38 1.48 1.42
16.9 15.5 1.74 1.63 1.52 1.41 1.29
39 1.02 0.98 1.11 1.07 1.28 1.23 1.36 1.31 1.38 1.32 1.41 1.35 1.45 1.39
41 1.02 0.98 1.11 1.07 1.24 1.19 1.30 1.25 1.32 1.27 1.35 1.30 1.38 1.32
43 1.02 0.98 1.11 1.07 1.20 1.15 1.25 1.20 1.26 1.21 1.29 1.24 1.32 1.27
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.41 1.35 1.58 1.51 1.64 1.49
-19.8 -20 0.80 0.80 0.80 0.80 0.80
12 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.41 1.35 1.58 1.51 1.64 1.49
-17.8 -18 0.85 0.85 0.85 0.85 0.85
14 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.41 1.35 1.57 1.51 1.63 1.48
-15.7 -16 0.90 0.90 0.90 0.90 0.90
16 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.41 1.35 1.57 1.51 1.62 1.48
-13.7 -14 0.95 0.95 0.95 0.95 0.95
18 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.41 1.35 1.56 1.50 1.62 1.48
-11.7 -12 1.01 1.01 1.01 1.01 1.01
Me 20 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.40 1.34 1.56 1.50 1.61 1.48
Me -9.6 -10 1.06 1.06 1.06 1.06 1.06
22 0.00 #####1.03 0.99 1.23 1.18 1.33 1.28 1.40 1.34 1.54 1.48 1.59 1.47
-7.5 -8 1.12 1.12 1.12 1.12 1.12
6 24 0.00 #####1.02 0.98 1.23 1.18 1.33 1.28 1.39 1.33 1.52 1.46 1.57 1.47
6 -5.5 -6 1.19 1.19 1.19 1.19 1.19
(m3/min) 26 0.00 #####1.02 0.98 1.22 1.17 1.32 1.27 1.37 1.32 1.49 1.43 1.54 1.46
(m3/min) -3.4 -4 1.23 1.23 1.22 1.21 1.20
28 0.93 0.89 1.02 0.98 1.22 1.17 1.30 1.25 1.36 1.31 1.47 1.41 1.52 1.45
-1.3 -2 1.27 1.27 1.26 1.24 1.21
30 0.93 0.89 1.02 0.98 1.21 1.16 1.29 1.24 1.34 1.29 1.45 1.39 1.49 1.43
0.8 0 1.34 1.32 1.30 1.25 1.21
0.030932 0.93 0.89 1.02 0.98 1.20 1.15 1.28 1.23 1.33 1.28 1.42 1.36 1.47 1.41
0.11 3.9 3 1.45 1.40 1.35 1.27 1.20
34 0.93 0.89 1.01 0.97 1.19 1.14 1.26 1.21 1.31 1.26 1.39 1.33 1.44 1.38
7.0 6 1.59 1.48 1.38 1.28 1.19
0.96 35 0.93 0.89 1.01 0.97 1.19 1.14 1.25 1.20 1.30 1.25 1.38 1.32 1.43 1.37
10.1 9 1.58 1.48 1.37 1.28 1.18
36 0.93 0.89 1.01 0.97 1.18 1.13 1.25 1.20 1.28 1.23 1.35 1.30 1.40 1.34
13.2 12 1.57 1.47 1.37 1.27 1.17
38 0.93 0.89 1.01 0.97 1.16 1.11 1.23 1.18 1.26 1.21 1.30 1.25 1.34 1.29
16.9 15.5 1.55 1.45 1.35 1.25 1.15
39 0.93 0.89 1.01 0.97 1.16 1.11 1.23 1.18 1.25 1.20 1.28 1.23 1.32 1.27
41 0.93 0.89 1.00 0.96 1.12 1.08 1.18 1.13 1.19 1.14 1.22 1.17 1.25 1.20
43 0.93 0.89 1.00 0.96 1.09 1.05 1.13 1.08 1.14 1.09 1.17 1.12 1.19 1.14
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.24 1.19 1.39 1.29 1.45 1.27
-19.8 -20 0.69 0.69 0.69 0.69 0.69
12 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.24 1.19 1.39 1.29 1.44 1.26
-17.8 -18 0.74 0.74 0.74 0.74 0.74
14 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.24 1.19 1.38 1.29 1.43 1.26
-15.7 -16 0.78 0.78 0.78 0.78 0.78
16 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.24 1.19 1.38 1.29 1.43 1.26
-13.7 -14 0.83 0.83 0.83 0.83 0.83
18 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.24 1.19 1.37 1.28 1.42 1.26
-11.7 -12 0.87 0.87 0.87 0.87 0.87
Lo 20 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.24 1.19 1.37 1.28 1.42 1.26
-9.6 -10 0.92 0.92 0.92 0.92 0.92
22 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.23 1.18 1.35 1.28 1.40 1.25
-7.5 -8 0.97 0.97 0.97 0.97 0.97
5 24 0.00 #####0.90 0.86 1.08 1.04 1.17 1.12 1.22 1.17 1.33 1.27 1.38 1.25
5 -5.5 -6 1.03 1.03 1.03 1.03 1.03
(m3/min) 26 0.00 #####0.90 0.86 1.07 1.03 1.16 1.11 1.21 1.16 1.31 1.26 1.36 1.24
(m3/min) -3.4 -4 1.06 1.06 1.06 1.05 1.04
28 0.82 0.79 0.90 0.86 1.07 1.03 1.15 1.10 1.19 1.14 1.29 1.24 1.33 1.23
-1.3 -2 1.10 1.10 1.09 1.07 1.05
30 0.82 0.79 0.90 0.86 1.06 1.02 1.14 1.09 1.18 1.13 1.27 1.22 1.31 1.22
0.8 0 1.16 1.14 1.13 1.09 1.05
0.0219532 0.82 0.79 0.90 0.86 1.05 1.01 1.12 1.08 1.17 1.12 1.25 1.20 1.29 1.22
3.9 3 1.26 1.21 1.17 1.10 1.04
34 0.82 0.79 0.89 0.85 1.05 1.01 1.11 1.07 1.15 1.10 1.23 1.18 1.27 1.21
7.0 6 1.38 1.29 1.20 1.11 1.03
0.9612335 0.82 0.79 0.89 0.85 1.05 1.01 1.10 1.06 1.14 1.09 1.21 1.16 1.25 1.20
10.1 9 1.37 1.28 1.19 1.11 1.02
36 0.82 0.79 0.89 0.85 1.04 1.00 1.10 1.06 1.13 1.08 1.19 1.14 1.23 1.18
13.2 12 1.36 1.27 1.18 1.10 1.01
38 0.82 0.79 0.89 0.85 1.02 0.98 1.09 1.05 1.11 1.07 1.15 1.10 1.18 1.13
16.9 15.5 1.35 1.26 1.17 1.09 1.00
39 0.82 0.79 0.89 0.85 1.02 0.98 1.08 1.04 1.10 1.06 1.13 1.08 1.16 1.11
41 0.82 0.79 0.88 0.84 0.99 0.95 1.04 1.00 1.05 1.01 1.08 1.04 1.10 1.06
43 0.82 0.79 0.88 0.84 0.96 0.92 0.99 0.95 1.00 0.96 1.03 0.99 1.05 1.01
Notes(1) This data shows average statuses out of those possible to occur in the system control.
(Depending on controls, there may be ranges where the operation is not conducted continuously.）
(2) Symbols are as follows
TC :Total cooling capacity(kW)
SHC :Sensible heat capacity(kW)
Lo
Cooling mode Heating mode (kW)(kW)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
7. CAPACITY TABLES
Caution: In case that the cooling operation during low outdoor air temperature below -5°C is expected, install the outdoor unit
where it is not influenced by natural wind. Otherwise protection control by low pressure will be activated much more
frequently and it will cause insufficient capacity or breakdown of the compressor in worst case.
PJF000Z513

–16 –
'18 • KX-T-281
PJF000Z513
Model FDTC22KXZE1
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.80 1.73 2.16 2.07 2.33 2.18 2.48 2.20 2.78 2.39 2.89 2.34
-19.8 -20 1.45 1.45 1.45 1.45 1.45
12 0.00 #####1.80 1.73 2.16 2.07 2.33 2.18 2.48 2.20 2.77 2.39 2.87 2.34
-17.8 -18 1.54 1.54 1.54 1.54 1.54
14 0.00 #####1.80 1.73 2.16 2.07 2.33 2.18 2.47 2.19 2.76 2.38 2.86 2.33
-15.7 -16 1.64 1.64 1.64 1.64 1.64
16 0.00 #####1.80 1.73 2.16 2.07 2.33 2.18 2.47 2.19 2.75 2.38 2.85 2.33
-13.7 -14 1.73 1.73 1.73 1.73 1.73
18 0.00 #####1.80 1.73 2.16 2.07 2.33 2.18 2.47 2.19 2.74 2.38 2.84 2.33
-11.7 -12 1.82 1.82 1.82 1.82 1.82
P-Hi 20 0.00 #####1.80 1.73 2.16 2.07 2.33 2.18 2.46 2.19 2.73 2.37 2.82 2.32
P-Hi -9.6 -10 1.92 1.92 1.92 1.92 1.92
22 0.00 #####1.80 1.73 2.15 2.06 2.33 2.18 2.45 2.19 2.69 2.36 2.78 2.31
-7.5 -8 2.03 2.03 2.03 2.03 2.03
9 24 0.00 #####1.80 1.73 2.15 2.06 2.33 2.18 2.44 2.18 2.66 2.35 2.75 2.30
9 -5.5 -6 2.15 2.15 2.15 2.15 2.15
(m3/min) 26 0.00 #####1.80 1.73 2.14 2.05 2.31 2.17 2.41 2.17 2.62 2.34 2.70 2.29
(m3/min) -3.4 -4 2.23 2.22 2.22 2.20 2.18
28 1.63 1.56 1.80 1.73 2.13 2.04 2.29 2.17 2.38 2.16 2.58 2.32 2.66 2.27
-1.3 -2 2.30 2.29 2.29 2.24 2.20
30 1.63 1.56 1.79 1.72 2.12 2.04 2.27 2.16 2.36 2.16 2.54 2.31 2.62 2.26
0.8 0 2.43 2.39 2.36 2.27 2.19
0.0432532 1.63 1.56 1.79 1.72 2.10 2.02 2.24 2.15 2.33 2.14 2.50 2.30 2.58 2.25
3.9 3 2.63 2.54 2.44 2.31 2.17
34 1.63 1.56 1.78 1.71 2.09 2.01 2.21 2.12 2.29 2.13 2.44 2.28 2.53 2.24
7.0 6 2.88 2.69 2.50 2.33 2.15
0.96 35 1.63 1.56 1.78 1.71 2.09 2.01 2.20 2.11 2.27 2.12 2.42 2.27 2.50 2.23
10.1 9 2.86 2.67 2.49 2.31 2.13
36 1.63 1.56 1.78 1.71 2.07 1.99 2.19 2.10 2.25 2.12 2.37 2.26 2.45 2.21
13.2 12 2.84 2.66 2.48 2.29 2.11
38 1.63 1.56 1.77 1.70 2.04 1.96 2.17 2.08 2.21 2.10 2.29 2.20 2.36 2.19
16.9 15.5 2.82 2.63 2.45 2.27 2.09
39 1.63 1.56 1.77 1.70 2.03 1.95 2.16 2.07 2.19 2.10 2.24 2.15 2.31 2.17
41 1.63 1.56 1.76 1.69 1.97 1.89 2.07 1.99 2.09 2.01 2.14 2.05 2.20 2.11
43 1.63 1.56 1.76 1.69 1.91 1.83 1.98 1.90 2.00 1.92 2.05 1.97 2.09 2.01
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.67 1.60 1.99 1.91 2.16 1.98 2.29 2.00 2.57 2.16 2.67 2.12
-19.8 -20 1.33 1.33 1.33 1.33 1.33
12 0.00 #####1.67 1.60 1.99 1.91 2.16 1.98 2.29 2.00 2.56 2.16 2.66 2.11
-17.8 -18 1.42 1.42 1.42 1.42 1.42
14 0.00 #####1.67 1.60 1.99 1.91 2.16 1.98 2.29 2.00 2.55 2.15 2.64 2.11
-15.7 -16 1.51 1.51 1.51 1.51 1.51
16 0.00 #####1.67 1.60 1.99 1.91 2.16 1.98 2.28 1.99 2.54 2.15 2.63 2.11
-13.7 -14 1.59 1.59 1.59 1.59 1.59
18 0.00 #####1.67 1.60 1.99 1.91 2.16 1.98 2.28 1.99 2.53 2.15 2.62 2.10
-11.7 -12 1.68 1.68 1.68 1.68 1.68
Hi 20 0.00 #####1.67 1.60 1.99 1.91 2.16 1.98 2.28 1.99 2.52 2.14 2.61 2.10
Hi -9.6 -10 1.76 1.76 1.76 1.76 1.76
22 0.00 #####1.66 1.59 1.99 1.91 2.16 1.98 2.27 1.99 2.49 2.13 2.57 2.09
-7.5 -8 1.87 1.87 1.87 1.87 1.87
8 24 0.00 #####1.66 1.59 1.99 1.91 2.16 1.98 2.26 1.99 2.46 2.12 2.54 2.08
8 -5.5 -6 1.98 1.98 1.98 1.98 1.98
(m3/min) 26 0.00 #####1.66 1.59 1.98 1.90 2.14 1.98 2.23 1.97 2.42 2.11 2.50 2.07
(m3/min) -3.4 -4 2.05 2.04 2.04 2.02 2.00
28 1.50 1.44 1.66 1.59 1.97 1.89 2.11 1.96 2.20 1.96 2.38 2.10 2.46 2.05
-1.3 -2 2.12 2.11 2.11 2.07 2.02
30 1.50 1.44 1.66 1.59 1.96 1.88 2.09 1.96 2.18 1.96 2.34 2.09 2.42 2.04
0.8 0 2.23 2.20 2.17 2.09 2.01
0.0342532 1.50 1.44 1.65 1.58 1.94 1.86 2.07 1.95 2.15 1.95 2.31 2.08 2.39 2.03
3.9 3 2.42 2.34 2.25 2.12 2.00
34 1.50 1.44 1.65 1.58 1.94 1.86 2.05 1.94 2.12 1.94 2.26 2.06 2.34 2.02
7.0 6 2.65 2.47 2.30 2.14 1.98
0.9539535 1.50 1.44 1.64 1.57 1.93 1.85 2.03 1.94 2.10 1.93 2.24 2.05 2.31 2.01
10.1 9 2.63 2.46 2.29 2.13 1.96
36 1.50 1.44 1.64 1.57 1.92 1.84 2.02 1.93 2.08 1.92 2.20 2.04 2.27 2.00
13.2 12 2.61 2.44 2.28 2.11 1.94
38 1.50 1.44 1.64 1.57 1.89 1.81 2.00 1.92 2.04 1.91 2.12 2.01 2.18 1.97
16.9 15.5 2.59 2.42 2.26 2.09 1.92
39 1.50 1.44 1.64 1.57 1.87 1.80 1.99 1.91 2.02 1.90 2.07 1.99 2.13 1.96
41 1.50 1.44 1.63 1.56 1.82 1.75 1.91 1.83 1.94 1.86 1.98 1.90 2.03 1.93
43 1.50 1.44 1.62 1.56 1.76 1.69 1.83 1.76 1.85 1.78 1.89 1.81 1.93 1.85
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.52 1.46 1.81 1.74 1.96 1.77 2.09 1.78 2.34 1.94 2.43 1.90
-19.8 -20 1.21 1.21 1.21 1.21 1.21
12 0.00 #####1.52 1.46 1.81 1.74 1.96 1.77 2.08 1.78 2.33 1.93 2.42 1.90
-17.8 -18 1.29 1.29 1.29 1.29 1.29
14 0.00 #####1.52 1.46 1.81 1.74 1.96 1.77 2.08 1.78 2.32 1.93 2.41 1.89
-15.7 -16 1.37 1.37 1.37 1.37 1.37
16 0.00 #####1.52 1.46 1.81 1.74 1.96 1.77 2.08 1.78 2.31 1.93 2.40 1.89
-13.7 -14 1.44 1.44 1.44 1.44 1.44
18 0.00 #####1.52 1.46 1.81 1.74 1.96 1.77 2.08 1.78 2.30 1.92 2.39 1.89
-11.7 -12 1.52 1.52 1.52 1.52 1.52
Me 20 0.00 #####1.52 1.46 1.81 1.74 1.96 1.77 2.07 1.78 2.30 1.92 2.38 1.88
Me -9.6 -10 1.60 1.60 1.60 1.60 1.60
22 0.00 #####1.51 1.45 1.81 1.74 1.96 1.77 2.06 1.77 2.27 1.91 2.34 1.87
-7.5 -8 1.70 1.70 1.70 1.70 1.70
7 24 0.00 #####1.51 1.45 1.81 1.74 1.96 1.77 2.05 1.77 2.24 1.90 2.31 1.86
7 -5.5 -6 1.79 1.79 1.79 1.79 1.79
(m3/min) 26 0.00 #####1.51 1.45 1.80 1.73 1.94 1.76 2.03 1.76 2.20 1.89 2.27 1.85
(m3/min) -3.4 -4 1.86 1.85 1.85 1.83 1.82
28 1.37 1.32 1.51 1.45 1.80 1.73 1.92 1.75 2.01 1.75 2.17 1.88 2.24 1.84
-1.3 -2 1.92 1.91 1.91 1.87 1.84
30 1.37 1.32 1.51 1.45 1.78 1.71 1.91 1.75 1.98 1.74 2.13 1.87 2.21 1.83
0.8 0 2.02 1.99 1.97 1.90 1.83
0.0273232 1.37 1.32 1.50 1.44 1.77 1.70 1.89 1.74 1.96 1.74 2.10 1.86 2.17 1.82
0.11 3.9 3 2.20 2.12 2.04 1.92 1.81
34 1.37 1.32 1.50 1.44 1.76 1.69 1.86 1.73 1.93 1.73 2.06 1.85 2.13 1.81
7.0 6 2.40 2.24 2.09 1.94 1.79
0.93 35 1.37 1.32 1.50 1.44 1.76 1.69 1.85 1.73 1.91 1.72 2.03 1.84 2.11 1.80
10.1 9 2.38 2.23 2.08 1.93 1.78
36 1.37 1.32 1.49 1.43 1.74 1.67 1.84 1.72 1.89 1.71 2.00 1.83 2.06 1.79
13.2 12 2.37 2.22 2.07 1.91 1.76
38 1.37 1.32 1.49 1.43 1.72 1.65 1.82 1.72 1.86 1.70 1.92 1.80 1.98 1.76
16.9 15.5 2.35 2.20 2.05 1.90 1.74
39 1.37 1.32 1.49 1.43 1.71 1.64 1.81 1.71 1.84 1.69 1.89 1.79 1.94 1.75
41 1.37 1.32 1.48 1.42 1.65 1.58 1.74 1.67 1.76 1.67 1.80 1.73 1.85 1.72
43 1.37 1.32 1.48 1.42 1.60 1.54 1.67 1.60 1.68 1.61 1.72 1.65 1.76 1.69
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.86 1.56 2.08 1.69 2.16 1.66
-19.8 -20 1.07 1.07 1.07 1.07 1.07
12 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.86 1.56 2.08 1.69 2.15 1.66
-17.8 -18 1.14 1.14 1.14 1.14 1.14
14 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.85 1.56 2.07 1.69 2.14 1.65
-15.7 -16 1.21 1.21 1.21 1.21 1.21
16 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.85 1.56 2.06 1.69 2.14 1.65
-13.7 -14 1.28 1.28 1.28 1.28 1.28
18 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.85 1.56 2.05 1.68 2.13 1.65
-11.7 -12 1.35 1.35 1.35 1.35 1.35
Lo 20 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.85 1.56 2.05 1.68 2.12 1.65
-9.6 -10 1.42 1.42 1.42 1.42 1.42
22 0.00 #####1.35 1.30 1.62 1.53 1.75 1.55 1.84 1.55 2.02 1.67 2.09 1.64
-7.5 -8 1.51 1.51 1.51 1.51 1.51
6 24 0.00 #####1.35 1.30 1.61 1.52 1.75 1.55 1.83 1.55 1.99 1.66 2.06 1.63
6 -5.5 -6 1.59 1.59 1.59 1.59 1.59
(m3/min) 26 0.00 #####1.35 1.30 1.61 1.52 1.73 1.54 1.81 1.54 1.96 1.65 2.03 1.62
(m3/min) -3.4 -4 1.65 1.65 1.64 1.63 1.61
28 1.22 1.17 1.35 1.30 1.60 1.52 1.72 1.54 1.79 1.54 1.93 1.64 2.00 1.61
-1.3 -2 1.70 1.70 1.70 1.66 1.63
30 1.22 1.17 1.34 1.29 1.59 1.52 1.70 1.53 1.77 1.53 1.90 1.63 1.97 1.60
0.8 0 1.80 1.77 1.75 1.68 1.62
0.0200732 1.22 1.17 1.34 1.29 1.57 1.51 1.68 1.52 1.75 1.52 1.87 1.62 1.94 1.59
3.9 3 1.95 1.88 1.81 1.71 1.61
34 1.22 1.17 1.33 1.28 1.57 1.51 1.66 1.52 1.72 1.51 1.83 1.61 1.90 1.58
7.0 6 2.13 1.99 1.85 1.72 1.59
0.9156235 1.22 1.17 1.33 1.28 1.57 1.51 1.65 1.51 1.70 1.50 1.81 1.60 1.88 1.57
10.1 9 2.12 1.98 1.85 1.71 1.58
36 1.22 1.17 1.33 1.28 1.55 1.49 1.64 1.51 1.69 1.50 1.78 1.59 1.84 1.56
13.2 12 2.10 1.97 1.83 1.70 1.57
38 1.22 1.17 1.33 1.28 1.53 1.47 1.62 1.50 1.65 1.49 1.72 1.57 1.77 1.54
16.9 15.5 2.09 1.95 1.82 1.68 1.55
39 1.22 1.17 1.33 1.28 1.52 1.46 1.62 1.50 1.64 1.48 1.68 1.56 1.73 1.53
41 1.22 1.17 1.32 1.27 1.47 1.41 1.55 1.48 1.57 1.46 1.61 1.54 1.65 1.50
43 1.22 1.17 1.32 1.27 1.43 1.37 1.48 1.42 1.50 1.43 1.53 1.47 1.57 1.48
Notes(1) This data shows average statuses out of those possible to occur in the system control.
(Depending on controls, there may be ranges where the operation is not conducted continuously.）
(2) Symbols are as follows
TC :Total cooling capacity(kW)
SHC :Sensible heat capacity(kW)
Lo
Cooling mode Heating mode (kW)(kW)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature

–17 –
'18 • KX-T-281
Model FDTC28KXZE1
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.30 2.11 2.74 2.38 2.97 2.42 3.16 2.45 3.54 2.65 3.67 2.59
-19.8 -20 1.86 1.86 1.86 1.86 1.86
12 0.00 #####2.30 2.11 2.74 2.38 2.97 2.42 3.15 2.45 3.52 2.65 3.66 2.59
-17.8 -18 1.98 1.98 1.98 1.98 1.98
14 0.00 #####2.30 2.11 2.74 2.38 2.97 2.42 3.15 2.45 3.51 2.64 3.64 2.58
-15.7 -16 2.09 2.09 2.09 2.09 2.09
16 0.00 #####2.30 2.11 2.74 2.38 2.97 2.42 3.14 2.44 3.50 2.64 3.63 2.58
-13.7 -14 2.21 2.21 2.21 2.21 2.21
18 0.00 #####2.30 2.11 2.74 2.38 2.97 2.42 3.14 2.44 3.49 2.64 3.61 2.57
-11.7 -12 2.33 2.33 2.33 2.33 2.33
P-Hi 20 0.00 #####2.30 2.11 2.74 2.38 2.97 2.42 3.14 2.44 3.47 2.63 3.59 2.57
P-Hi -9.6 -10 2.45 2.45 2.45 2.45 2.45
22 0.00 #####2.29 2.11 2.74 2.38 2.97 2.42 3.12 2.44 3.43 2.62 3.54 2.55
-7.5 -8 2.60 2.60 2.60 2.60 2.60
9 24 0.00 #####2.29 2.11 2.74 2.38 2.97 2.42 3.11 2.43 3.39 2.60 3.50 2.54
9 -5.5 -6 2.75 2.75 2.75 2.75 2.75
(m3/min) 26 0.00 #####2.29 2.11 2.73 2.38 2.94 2.41 3.07 2.42 3.33 2.58 3.44 2.52
(m3/min) -3.4 -4 2.85 2.84 2.84 2.81 2.78
28 2.07 1.99 2.28 2.11 2.72 2.37 2.91 2.40 3.03 2.40 3.28 2.56 3.39 2.50
-1.3 -2 2.94 2.94 2.93 2.87 2.82
30 2.07 1.99 2.28 2.11 2.70 2.37 2.88 2.39 3.00 2.39 3.23 2.54 3.34 2.49
0.8 0 3.10 3.06 3.02 2.91 2.80
0.0432532 2.07 1.99 2.27 2.10 2.67 2.35 2.86 2.38 2.96 2.37 3.18 2.53 3.29 2.47
3.9 3 3.37 3.25 3.13 2.95 2.78
34 2.07 1.99 2.27 2.10 2.66 2.35 2.82 2.37 2.92 2.36 3.11 2.50 3.22 2.45
7.0 6 3.68 3.44 3.20 2.98 2.75
0.84 35 2.07 1.99 2.26 2.10 2.66 2.35 2.80 2.36 2.89 2.35 3.08 2.49 3.18 2.44
10.1 9 3.66 3.42 3.19 2.96 2.73
36 2.07 1.99 2.26 2.10 2.64 2.34 2.79 2.36 2.86 2.34 3.02 2.47 3.12 2.42
13.2 12 3.63 3.40 3.17 2.94 2.70
38 2.07 1.99 2.25 2.09 2.60 2.33 2.76 2.34 2.81 2.32 2.91 2.44 3.00 2.38
16.9 15.5 3.60 3.37 3.14 2.91 2.68
39 2.07 1.99 2.25 2.09 2.58 2.32 2.74 2.34 2.78 2.31 2.86 2.42 2.94 2.36
41 2.07 1.99 2.24 2.09 2.50 2.29 2.63 2.30 2.66 2.27 2.73 2.37 2.80 2.32
43 2.07 1.99 2.24 2.09 2.43 2.26 2.52 2.26 2.55 2.23 2.60 2.33 2.66 2.27
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.92 2.23 3.27 2.42 3.39 2.36
-19.8 -20 1.71 1.71 1.71 1.71 1.71
12 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.91 2.23 3.26 2.41 3.38 2.35
-17.8 -18 1.82 1.82 1.82 1.82 1.82
14 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.91 2.23 3.25 2.41 3.37 2.35
-15.7 -16 1.93 1.93 1.93 1.93 1.93
16 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.91 2.23 3.23 2.40 3.35 2.34
-13.7 -14 2.04 2.04 2.04 2.04 2.04
18 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.90 2.22 3.22 2.40 3.34 2.34
-11.7 -12 2.15 2.15 2.15 2.15 2.15
Hi 20 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.90 2.22 3.21 2.39 3.32 2.33
Hi -9.6 -10 2.26 2.26 2.26 2.26 2.26
22 0.00 #####2.12 1.92 2.54 2.17 2.74 2.21 2.89 2.22 3.17 2.38 3.28 2.32
-7.5 -8 2.40 2.40 2.40 2.40 2.40
8 24 0.00 #####2.12 1.92 2.53 2.17 2.74 2.21 2.87 2.21 3.13 2.36 3.23 2.31
8 -5.5 -6 2.53 2.53 2.53 2.53 2.53
(m3/min) 26 0.00 #####2.11 1.92 2.52 2.16 2.72 2.20 2.84 2.20 3.08 2.35 3.18 2.29
(m3/min) -3.4 -4 2.62 2.62 2.61 2.59 2.56
28 1.92 1.84 2.11 1.92 2.51 2.16 2.69 2.19 2.80 2.19 3.03 2.33 3.13 2.27
-1.3 -2 2.71 2.70 2.69 2.64 2.59
30 1.92 1.84 2.11 1.92 2.49 2.15 2.67 2.18 2.77 2.17 2.98 2.31 3.08 2.26
0.8 0 2.86 2.82 2.78 2.68 2.58
0.0342532 1.92 1.84 2.10 1.91 2.47 2.14 2.64 2.17 2.74 2.16 2.94 2.30 3.04 2.25
3.9 3 3.10 2.99 2.88 2.72 2.56
34 1.92 1.84 2.09 1.91 2.46 2.14 2.61 2.16 2.70 2.15 2.88 2.28 2.98 2.21
7.0 6 3.39 3.17 2.95 2.74 2.53
0.8306735 1.92 1.84 2.09 1.91 2.46 2.14 2.59 2.15 2.67 2.14 2.85 2.27 2.94 2.20
10.1 9 3.36 3.15 2.93 2.72 2.51
36 1.92 1.84 2.09 1.91 2.44 2.13 2.58 2.14 2.65 2.13 2.79 2.23 2.89 2.19
13.2 12 3.34 3.13 2.92 2.70 2.49
38 1.92 1.84 2.08 1.90 2.40 2.11 2.55 2.13 2.60 2.11 2.69 2.20 2.77 2.15
16.9 15.5 3.32 3.10 2.89 2.68 2.46
39 1.92 1.84 2.08 1.90 2.38 2.11 2.54 2.13 2.57 2.10 2.64 2.18 2.72 2.13
41 1.92 1.84 2.07 1.90 2.31 2.08 2.43 2.09 2.46 2.06 2.52 2.14 2.59 2.09
43 1.92 1.84 2.07 1.90 2.24 2.05 2.33 2.05 2.36 2.02 2.41 2.11 2.46 2.05
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.66 1.99 2.98 2.16 3.09 2.11
-19.8 -20 1.55 1.55 1.55 1.55 1.55
12 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.65 1.99 2.96 2.16 3.08 2.11
-17.8 -18 1.65 1.65 1.65 1.65 1.65
14 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.65 1.99 2.95 2.15 3.06 2.10
-15.7 -16 1.75 1.75 1.75 1.75 1.75
16 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.65 1.99 2.94 2.15 3.05 2.10
-13.7 -14 1.85 1.85 1.85 1.85 1.85
18 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.64 1.99 2.93 2.15 3.04 2.10
-11.7 -12 1.95 1.95 1.95 1.95 1.95
Me 20 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.64 1.99 2.92 2.14 3.02 2.09
Me -9.6 -10 2.05 2.05 2.05 2.05 2.05
22 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.63 1.98 2.88 2.13 2.98 2.08
-7.5 -8 2.17 2.17 2.17 2.17 2.17
7 24 0.00 #####1.93 1.72 2.31 1.94 2.50 1.97 2.61 1.98 2.85 2.12 2.94 2.06
7 -5.5 -6 2.30 2.30 2.30 2.30 2.30
(m3/min) 26 0.00 #####1.92 1.71 2.30 1.93 2.47 1.96 2.58 1.96 2.80 2.10 2.90 2.05
(m3/min) -3.4 -4 2.38 2.37 2.37 2.35 2.32
28 1.74 1.67 1.92 1.71 2.28 1.93 2.45 1.95 2.55 1.95 2.76 2.09 2.85 2.03
-1.3 -2 2.46 2.45 2.44 2.40 2.35
30 1.74 1.67 1.92 1.71 2.27 1.92 2.43 1.95 2.52 1.94 2.72 2.07 2.81 2.02
0.8 0 2.59 2.55 2.52 2.43 2.34
0.0273232 1.74 1.67 1.91 1.71 2.25 1.91 2.40 1.93 2.49 1.93 2.67 2.05 2.76 2.01
0.11 3.9 3 2.81 2.71 2.61 2.46 2.32
34 1.74 1.67 1.91 1.71 2.24 1.91 2.37 1.92 2.45 1.92 2.62 2.04 2.71 1.99
7.0 6 3.07 2.87 2.67 2.48 2.30
0.82 35 1.74 1.67 1.90 1.70 2.24 1.91 2.36 1.92 2.43 1.91 2.59 2.03 2.68 1.98
10.1 9 3.05 2.86 2.66 2.47 2.28
36 1.74 1.67 1.90 1.70 2.22 1.90 2.34 1.91 2.41 1.90 2.54 2.01 2.63 1.96
13.2 12 3.03 2.84 2.64 2.45 2.26
38 1.74 1.67 1.90 1.70 2.19 1.89 2.32 1.90 2.36 1.88 2.45 1.98 2.52 1.93
16.9 15.5 3.01 2.81 2.62 2.43 2.23
39 1.74 1.67 1.89 1.70 2.17 1.88 2.31 1.90 2.34 1.87 2.40 1.96 2.47 1.91
41 1.74 1.67 1.89 1.70 2.11 1.86 2.21 1.86 2.24 1.84 2.30 1.92 2.36 1.88
43 1.74 1.67 1.88 1.70 2.04 1.83 2.12 1.83 2.14 1.80 2.19 1.89 2.24 1.84
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.37 1.76 2.65 1.90 2.75 1.85
-19.8 -20 1.38 1.38 1.38 1.38 1.38
12 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.36 1.75 2.64 1.89 2.74 1.85
-17.8 -18 1.46 1.46 1.46 1.46 1.46
14 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.36 1.75 2.63 1.89 2.73 1.84
-15.7 -16 1.55 1.55 1.55 1.55 1.55
16 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.36 1.75 2.62 1.89 2.72 1.84
-13.7 -14 1.64 1.64 1.64 1.64 1.64
18 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.35 1.75 2.61 1.88 2.71 1.84
-11.7 -12 1.73 1.73 1.73 1.73 1.73
Lo 20 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.35 1.75 2.60 1.88 2.69 1.83
-9.6 -10 1.82 1.82 1.82 1.82 1.82
22 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.34 1.74 2.57 1.87 2.66 1.82
-7.5 -8 1.93 1.93 1.93 1.93 1.93
6 24 0.00 #####1.72 1.51 2.06 1.70 2.22 1.73 2.33 1.74 2.54 1.86 2.62 1.81
6 -5.5 -6 2.04 2.04 2.04 2.04 2.04
(m3/min) 26 0.00 #####1.71 1.50 2.05 1.70 2.20 1.73 2.30 1.73 2.50 1.84 2.58 1.80
(m3/min) -3.4 -4 2.11 2.11 2.10 2.08 2.06
28 1.55 1.49 1.71 1.50 2.04 1.69 2.18 1.72 2.27 1.72 2.46 1.83 2.54 1.78
-1.3 -2 2.18 2.18 2.17 2.13 2.09
30 1.55 1.49 1.71 1.50 2.02 1.69 2.16 1.71 2.25 1.71 2.42 1.81 2.50 1.77
0.8 0 2.30 2.27 2.24 2.16 2.08
0.0200732 1.55 1.49 1.70 1.50 2.00 1.68 2.14 1.70 2.22 1.70 2.38 1.80 2.46 1.76
3.9 3 2.50 2.41 2.32 2.19 2.06
34 1.55 1.49 1.70 1.50 2.00 1.68 2.11 1.69 2.19 1.69 2.33 1.78 2.41 1.74
7.0 6 2.73 2.55 2.37 2.21 2.04
0.8004135 1.55 1.49 1.70 1.50 1.99 1.67 2.10 1.68 2.17 1.68 2.31 1.78 2.39 1.73
10.1 9 2.71 2.54 2.36 2.19 2.02
36 1.55 1.49 1.69 1.49 1.98 1.67 2.09 1.68 2.15 1.67 2.27 1.76 2.34 1.72
13.2 12 2.69 2.52 2.35 2.18 2.00
38 1.55 1.49 1.69 1.49 1.95 1.66 2.07 1.67 2.11 1.65 2.18 1.73 2.25 1.69
16.9 15.5 2.67 2.50 2.33 2.16 1.98
39 1.55 1.49 1.69 1.49 1.93 1.65 2.06 1.67 2.09 1.65 2.14 1.71 2.20 1.67
41 1.55 1.49 1.68 1.49 1.88 1.63 1.97 1.63 2.00 1.61 2.05 1.68 2.10 1.64
43 1.55 1.49 1.68 1.49 1.82 1.61 1.89 1.60 1.91 1.58 1.95 1.65 2.00 1.61
Notes(1) This data shows average statuses out of those possible to occur in the system control.
(Depending on controls, there may be ranges where the operation is not conducted continuously.）
(2) Symbols are as follows
TC :Total cooling capacity(kW)
SHC :Sensible heat capacity(kW)
i
Lo
Cooling mode Heating mode (kW)(kW)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
PJF000Z513

– 18 –
'18 • KX-T-281
Model FDTC36KXZE1
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.06 2.97 4.55 3.22 4.72 3.14
-19.8 -20 2.32 2.32 2.32 2.32 2.32
12 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.05 2.97 4.53 3.21 4.70 3.13
-17.8 -18 2.47 2.47 2.47 2.47 2.47
14 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.05 2.97 4.51 3.20 4.68 3.13
-15.7 -16 2.62 2.62 2.62 2.62 2.62
16 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.04 2.96 4.50 3.20 4.66 3.12
-13.7 -14 2.77 2.77 2.77 2.77 2.77
18 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.04 2.96 4.48 3.19 4.64 3.11
-11.7 -12 2.92 2.92 2.92 2.92 2.92
P-Hi 20 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.03 2.96 4.47 3.19 4.62 3.11
P-Hi -9.6 -10 3.07 3.07 3.07 3.07 3.07
22 0.00 #####2.95 2.55 3.53 2.88 3.82 2.94 4.01 2.95 4.41 3.17 4.56 3.09
-7.5 -8 3.25 3.25 3.25 3.25 3.25
10 24 0.00 #####2.94 2.55 3.52 2.88 3.82 2.94 3.99 2.94 4.35 3.15 4.49 3.06
-5.5 -6 3.44 3.44 3.44 3.44 3.44
(m3/min) 26 0.00 #####2.94 2.55 3.51 2.87 3.78 2.92 3.95 2.93 4.28 3.12 4.43 3.04
(m3/min) -3.4 -4 3.56 3.56 3.55 3.52 3.48
28 2.66 2.52 2.94 2.55 3.49 2.86 3.74 2.91 3.90 2.91 4.22 3.10 4.36 3.02
-1.3 -2 3.68 3.67 3.66 3.59 3.52
30 2.66 2.52 2.93 2.55 3.47 2.86 3.71 2.89 3.86 2.89 4.15 3.07 4.29 3.00
0.8 0 3.88 3.83 3.77 3.64 3.50
0.0133332 2.66 2.52 2.92 2.54 3.44 2.84 3.67 2.88 3.81 2.87 4.09 3.05 4.23 2.98
3.9 3 4.21 4.06 3.91 3.69 3.47
34 2.66 2.52 2.91 2.54 3.43 2.84 3.62 2.86 3.75 2.85 4.00 3.02 4.14 2.95
7.0 6 4.60 4.30 4.00 3.72 3.44
0.79 35 2.66 2.52 2.91 2.54 3.42 2.84 3.60 2.85 3.72 2.84 3.96 3.01 4.09 2.93
10.1 9 4.57 4.28 3.99 3.70 3.41
36 2.66 2.52 2.91 2.54 3.39 2.82 3.58 2.84 3.68 2.82 3.89 2.98 4.02 2.91
13.2 12 4.54 4.25 3.96 3.67 3.38
38 2.66 2.52 2.90 2.53 3.34 2.80 3.55 2.83 3.61 2.80 3.74 2.93 3.86 2.86
16.9 15.5 4.51 4.22 3.93 3.64 3.35
39 2.66 2.52 2.89 2.53 3.32 2.80 3.53 2.82 3.58 2.79 3.67 2.91 3.78 2.83
41 2.66 2.52 2.88 2.52 3.22 2.76 3.38 2.76 3.43 2.73 3.51 2.85 3.60 2.78
43 2.66 2.52 2.87 2.52 3.12 2.71 3.24 2.71 3.28 2.67 3.35 2.80 3.42 2.72
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.72 2.33 3.25 2.63 3.51 2.68 3.74 2.72 4.19 2.93 4.35 2.86
-19.8 -20 2.11 2.11 2.11 2.11 2.11
12 0.00 #####2.72 2.33 3.25 2.63 3.51 2.68 3.73 2.71 4.17 2.92 4.33 2.85
-17.8 -18 2.25 2.25 2.25 2.25 2.25
14 0.00 #####2.72 2.33 3.25 2.63 3.51 2.68 3.73 2.71 4.15 2.91 4.31 2.84
-15.7 -16 2.39 2.39 2.39 2.39 2.39
16 0.00 #####2.72 2.33 3.25 2.63 3.51 2.68 3.72 2.71 4.14 2.91 4.29 2.83
-13.7 -14 2.52 2.52 2.52 2.52 2.52
18 0.00 #####2.72 2.33 3.25 2.63 3.51 2.68 3.72 2.71 4.12 2.90 4.27 2.83
-11.7 -12 2.66 2.66 2.66 2.66 2.66
Hi 20 0.00 #####2.72 2.33 3.25 2.63 3.51 2.68 3.71 2.71 4.11 2.90 4.25 2.82
Hi -9.6 -10 2.79 2.79 2.79 2.79 2.79
22 0.00 #####2.71 2.32 3.25 2.63 3.51 2.68 3.69 2.70 4.06 2.88 4.19 2.80
-7.5 -8 2.96 2.96 2.96 2.96 2.96
9 24 0.00 #####2.71 2.32 3.24 2.63 3.51 2.68 3.68 2.69 4.01 2.86 4.14 2.78
9 -5.5 -6 3.13 3.13 3.13 3.13 3.13
(m3/min) 26 0.00 #####2.71 2.32 3.23 2.63 3.48 2.67 3.63 2.67 3.94 2.84 4.07 2.76
(m3/min) -3.4 -4 3.24 3.24 3.23 3.20 3.17
28 2.45 2.30 2.70 2.32 3.21 2.62 3.45 2.66 3.59 2.66 3.88 2.81 4.01 2.74
-1.3 -2 3.35 3.34 3.33 3.27 3.21
30 2.45 2.30 2.70 2.32 3.19 2.61 3.41 2.64 3.55 2.64 3.82 2.79 3.95 2.72
0.8 0 3.53 3.48 3.43 3.31 3.19
0.0116432 2.45 2.30 2.69 2.32 3.16 2.60 3.38 2.63 3.51 2.63 3.76 2.77 3.89 2.70
3.9 3 3.84 3.70 3.56 3.36 3.16
34 2.45 2.30 2.68 2.31 3.15 2.59 3.34 2.62 3.45 2.60 3.68 2.74 3.81 2.68
7.0 6 4.19 3.92 3.64 3.39 3.13
0.7847935 2.45 2.30 2.68 2.31 3.15 2.59 3.31 2.60 3.42 2.59 3.64 2.73 3.77 2.66
10.1 9 4.16 3.90 3.63 3.37 3.11
36 2.45 2.30 2.67 2.31 3.12 2.58 3.30 2.60 3.39 2.58 3.58 2.71 3.70 2.64
13.2 12 4.14 3.87 3.61 3.34 3.08
38 2.45 2.30 2.67 2.31 3.08 2.56 3.26 2.58 3.32 2.55 3.45 2.66 3.55 2.59
16.9 15.5 4.10 3.84 3.58 3.31 3.05
39 2.45 2.30 2.66 2.30 3.05 2.55 3.25 2.58 3.29 2.54 3.38 2.64 3.48 2.57
41 2.45 2.30 2.65 2.30 2.96 2.51 3.11 2.52 3.15 2.49 3.23 2.58 3.31 2.52
43 2.45 2.30 2.64 2.29 2.87 2.47 2.98 2.47 3.01 2.43 3.08 2.53 3.15 2.47
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.47 2.10 2.95 2.36 3.19 2.41 3.39 2.44 3.80 2.64 3.95 2.56
-19.8 -20 1.90 1.90 1.90 1.90 1.90
12 0.00 #####2.47 2.10 2.95 2.36 3.19 2.41 3.39 2.44 3.79 2.63 3.93 2.56
-17.8 -18 2.02 2.02 2.02 2.02 2.02
14 0.00 #####2.47 2.10 2.95 2.36 3.19 2.41 3.39 2.44 3.77 2.63 3.91 2.55
-15.7 -16 2.14 2.14 2.14 2.14 2.14
16 0.00 #####2.47 2.10 2.95 2.36 3.19 2.41 3.38 2.44 3.76 2.62 3.90 2.55
-13.7 -14 2.27 2.27 2.27 2.27 2.27
18 0.00 #####2.47 2.10 2.95 2.36 3.19 2.41 3.38 2.44 3.75 2.62 3.88 2.54
-11.7 -12 2.39 2.39 2.39 2.39 2.39
Me 20 0.00 #####2.47 2.10 2.95 2.36 3.19 2.41 3.37 2.43 3.73 2.61 3.86 2.53
Me -9.6 -10 2.51 2.51 2.51 2.51 2.51
22 0.00 #####2.46 2.09 2.95 2.36 3.19 2.41 3.36 2.43 3.69 2.59 3.81 2.52
-7.5 -8 2.66 2.66 2.66 2.66 2.66
8 24 0.00 #####2.46 2.09 2.95 2.36 3.19 2.41 3.34 2.42 3.64 2.57 3.76 2.50
8 -5.5 -6 2.82 2.82 2.82 2.82 2.82
(m3/min) 26 0.00 #####2.46 2.09 2.93 2.36 3.16 2.40 3.30 2.40 3.58 2.55 3.70 2.48
(m3/min) -3.4 -4 2.92 2.91 2.91 2.88 2.85
28 2.23 2.07 2.46 2.09 2.92 2.35 3.13 2.39 3.26 2.39 3.52 2.53 3.64 2.46
-1.3 -2 3.01 3.01 3.00 2.94 2.88
30 2.23 2.07 2.45 2.09 2.90 2.34 3.10 2.38 3.22 2.37 3.47 2.51 3.59 2.44
0.8 0 3.18 3.13 3.09 2.98 2.87
0.011132 2.23 2.07 2.44 2.08 2.87 2.33 3.07 2.36 3.19 2.36 3.42 2.49 3.53 2.42
3.9 3 3.45 3.32 3.20 3.02 2.84
34 2.23 2.07 2.44 2.08 2.86 2.33 3.03 2.35 3.13 2.34 3.34 2.46 3.46 2.40
7.0 6 3.77 3.52 3.28 3.05 2.82
0.78 35 2.23 2.07 2.43 2.08 2.86 2.33 3.01 2.34 3.11 2.33 3.31 2.45 3.42 2.39
10.1 9 3.74 3.50 3.26 3.03 2.79
36 2.23 2.07 2.43 2.08 2.84 2.32 2.99 2.33 3.08 2.32 3.25 2.43 3.36 2.37
13.2 12 3.72 3.48 3.24 3.01 2.77
38 2.23 2.07 2.42 2.07 2.79 2.30 2.96 2.32 3.02 2.30 3.13 2.39 3.22 2.32
16.9 15.5 3.69 3.45 3.21 2.98 2.74
39 2.23 2.07 2.42 2.07 2.77 2.29 2.95 2.32 2.99 2.28 3.07 2.37 3.16 2.30
41 2.23 2.07 2.41 2.07 2.69 2.26 2.83 2.27 2.86 2.24 2.93 2.32 3.01 2.26
43 2.23 2.07 2.40 2.06 2.61 2.23 2.71 2.22 2.74 2.19 2.80 2.27 2.86 2.21
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####1.93 1.61 2.30 1.81 2.49 1.85 2.65 1.87 2.97 2.03 3.08 1.98
-19.8 -20 1.45 1.45 1.45 1.45 1.45
12 0.00 #####1.93 1.61 2.30 1.81 2.49 1.85 2.65 1.87 2.96 2.02 3.07 1.97
-17.8 -18 1.55 1.55 1.55 1.55 1.55
14 0.00 #####1.93 1.61 2.30 1.81 2.49 1.85 2.64 1.87 2.95 2.02 3.06 1.97
-15.7 -16 1.64 1.64 1.64 1.64 1.64
16 0.00 #####1.93 1.61 2.30 1.81 2.49 1.85 2.64 1.87 2.94 2.01 3.04 1.96
-13.7 -14 1.73 1.73 1.73 1.73 1.73
18 0.00 #####1.93 1.61 2.30 1.81 2.49 1.85 2.64 1.87 2.93 2.01 3.03 1.96
-11.7 -12 1.83 1.83 1.83 1.83 1.83
Lo 20 0.00 #####1.93 1.61 2.30 1.81 2.49 1.85 2.63 1.87 2.92 2.01 3.02 1.95
-9.6 -10 1.92 1.92 1.92 1.92 1.92
22 0.00 #####1.92 1.60 2.30 1.81 2.49 1.85 2.62 1.86 2.88 1.99 2.98 1.94
-7.5 -8 2.04 2.04 2.04 2.04 2.04
6 24 0.00 #####1.92 1.60 2.30 1.81 2.49 1.85 2.61 1.86 2.84 1.98 2.94 1.92
6 -5.5 -6 2.15 2.15 2.15 2.15 2.15
(m3/min) 26 0.00 #####1.92 1.60 2.29 1.81 2.47 1.84 2.58 1.85 2.80 1.96 2.89 1.91
(m3/min) -3.4 -4 2.23 2.23 2.22 2.20 2.18
28 1.74 1.58 1.92 1.60 2.28 1.80 2.45 1.83 2.55 1.83 2.75 1.94 2.85 1.89
-1.3 -2 2.30 2.30 2.29 2.25 2.20
30 1.74 1.58 1.91 1.60 2.26 1.80 2.42 1.82 2.52 1.82 2.71 1.93 2.80 1.88
0.8 0 2.43 2.39 2.36 2.28 2.19
0.0099132 1.74 1.58 1.91 1.60 2.25 1.79 2.40 1.81 2.49 1.81 2.67 1.91 2.76 1.86
3.9 3 2.64 2.54 2.45 2.31 2.17
34 1.74 1.58 1.90 1.59 2.24 1.79 2.37 1.80 2.45 1.80 2.61 1.89 2.70 1.84
7.0 6 2.88 2.69 2.50 2.33 2.15
0.7612135 1.74 1.58 1.90 1.59 2.23 1.78 2.35 1.79 2.43 1.79 2.58 1.88 2.67 1.83
10.1 9 2.86 2.68 2.49 2.31 2.13
36 1.74 1.58 1.90 1.59 2.22 1.78 2.34 1.79 2.41 1.78 2.54 1.87 2.62 1.82
13.2 12 2.84 2.66 2.48 2.30 2.12
38 1.74 1.58 1.89 1.59 2.18 1.76 2.32 1.78 2.36 1.76 2.45 1.83 2.52 1.78
16.9 15.5 2.82 2.64 2.46 2.28 2.09
39 1.74 1.58 1.89 1.59 2.17 1.76 2.30 1.77 2.34 1.75 2.40 1.82 2.47 1.77
41 1.74 1.58 1.88 1.59 2.10 1.73 2.21 1.74 2.24 1.71 2.29 1.78 2.35 1.73
43 1.74 1.58 1.88 1.59 2.04 1.70 2.12 1.70 2.14 1.68 2.19 1.74 2.24 1.70
This data shows average statuses out of those possible to occur in the system control.
(Depending on controls, there may be ranges where the operation is not conducted continuously.）
Symbols are as follows
TC :Total cooling capacity(kW)
SHC :Sensible heat capacity(kW)
Lo
10
Notes(1)
(2)
Cooling mode Heating mode (kW)(kW)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
PJF000Z513

– 19 –
'18 • KX-T-281
PJF000Z513
Model FDTC45KXZE1
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####3.69 3.13 4.41 3.53 4.77 3.60 5.07 3.64 5.68 3.94 5.90 3.85
-19.8 -20 2.90 2.90 2.90 2.90 2.90
12 0.00 #####3.69 3.13 4.41 3.53 4.77 3.60 5.07 3.64 5.66 3.93 5.88 3.84
-17.8 -18 3.09 3.09 3.09 3.09 3.09
14 0.00 #####3.69 3.13 4.41 3.53 4.77 3.60 5.06 3.64 5.64 3.93 5.85 3.83
-15.7 -16 3.27 3.27 3.27 3.27 3.27
16 0.00 #####3.69 3.13 4.41 3.53 4.77 3.60 5.05 3.64 5.62 3.92 5.83 3.82
-13.7 -14 3.46 3.46 3.46 3.46 3.46
18 0.00 #####3.69 3.13 4.41 3.53 4.77 3.60 5.05 3.64 5.60 3.91 5.80 3.81
-11.7 -12 3.65 3.65 3.65 3.65 3.65
P-Hi 20 0.00 #####3.69 3.13 4.41 3.53 4.77 3.60 5.04 3.63 5.58 3.90 5.78 3.81
P-Hi -9.6 -10 3.83 3.83 3.83 3.83 3.83
22 0.00 #####3.68 3.12 4.41 3.53 4.77 3.60 5.02 3.63 5.51 3.88 5.70 3.78
-7.5 -8 4.07 4.07 4.07 4.07 4.07
12 24 0.00 #####3.68 3.12 4.41 3.53 4.77 3.60 4.99 3.61 5.44 3.85 5.62 3.75
-5.5 -6 4.30 4.30 4.30 4.30 4.30
(m3/min) 26 0.00 #####3.68 3.12 4.39 3.52 4.73 3.59 4.93 3.59 5.35 3.82 5.53 3.72
(m3/min) -3.4 -4 4.45 4.44 4.44 4.39 4.35
28 3.33 3.09 3.67 3.12 4.37 3.52 4.68 3.57 4.88 3.57 5.27 3.79 5.44 3.69
-1.3 -2 4.60 4.59 4.58 4.49 4.40
30 3.33 3.09 3.66 3.11 4.33 3.50 4.64 3.55 4.82 3.55 5.19 3.76 5.36 3.66
0.8 0 4.85 4.78 4.71 4.54 4.38
0.0171832 3.33 3.09 3.65 3.11 4.30 3.49 4.59 3.53 4.76 3.52 5.11 3.73 5.28 3.63
3.9 3 5.26 5.08 4.89 4.61 4.34
34 3.33 3.09 3.64 3.10 4.28 3.48 4.53 3.51 4.69 3.50 5.00 3.69 5.17 3.60
7.0 6 5.75 5.38 5.00 4.65 4.30
0.78 35 3.33 3.09 3.64 3.10 4.28 3.48 4.50 3.50 4.65 3.48 4.95 3.67 5.12 3.58
10.1 9 5.71 5.35 4.98 4.62 4.26
36 3.33 3.09 3.63 3.10 4.24 3.46 4.48 3.49 4.60 3.46 4.86 3.64 5.02 3.55
13.2 12 5.68 5.31 4.95 4.59 4.23
38 3.33 3.09 3.62 3.10 4.18 3.44 4.43 3.47 4.52 3.43 4.68 3.58 4.82 3.48
16.9 15.5 5.63 5.27 4.91 4.54 4.18
39 3.33 3.09 3.62 3.10 4.15 3.43 4.41 3.46 4.47 3.41 4.59 3.54 4.72 3.45
41 3.33 3.09 3.61 3.09 4.02 3.37 4.23 3.39 4.28 3.34 4.39 3.48 4.50 3.38
43 3.33 3.09 3.59 3.08 3.90 3.32 4.05 3.31 4.09 3.26 4.18 3.40 4.28 3.31
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.43 3.12 4.96 3.37 5.15 3.29
-19.8 -20 2.48 2.48 2.48 2.48 2.48
12 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.42 3.11 4.94 3.36 5.13 3.28
-17.8 -18 2.64 2.64 2.64 2.64 2.64
14 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.42 3.11 4.93 3.36 5.11 3.27
-15.7 -16 2.80 2.80 2.80 2.80 2.80
16 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.41 3.11 4.91 3.35 5.09 3.26
-13.7 -14 2.96 2.96 2.96 2.96 2.96
18 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.41 3.11 4.89 3.34 5.06 3.25
-11.7 -12 3.12 3.12 3.12 3.12 3.12
Hi 20 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.40 3.10 4.87 3.34 5.04 3.25
Hi -9.6 -10 3.28 3.28 3.28 3.28 3.28
22 0.00 #####3.22 2.67 3.85 3.01 4.16 3.08 4.38 3.10 4.81 3.31 4.97 3.22
-7.5 -8 3.48 3.48 3.48 3.48 3.48
10 24 0.00 #####3.21 2.67 3.85 3.01 4.16 3.08 4.36 3.09 4.75 3.29 4.90 3.20
-5.5 -6 3.68 3.68 3.68 3.68 3.68
(m3/min) 26 0.00 #####3.21 2.67 3.83 3.01 4.12 3.06 4.31 3.07 4.67 3.26 4.83 3.18
(m3/min) -3.4 -4 3.81 3.80 3.79 3.76 3.72
28 2.91 2.64 3.21 2.67 3.81 3.00 4.08 3.04 4.26 3.05 4.60 3.24 4.75 3.15
-1.3 -2 3.93 3.92 3.91 3.84 3.76
30 2.91 2.64 3.20 2.66 3.78 2.98 4.05 3.03 4.21 3.03 4.53 3.21 4.68 3.13
0.8 0 4.15 4.09 4.03 3.89 3.74
0.0133332 2.91 2.64 3.19 2.66 3.75 2.97 4.01 3.02 4.16 3.01 4.46 3.19 4.61 3.10
3.9 3 4.50 4.34 4.18 3.94 3.71
34 2.91 2.64 3.18 2.65 3.74 2.97 3.95 2.99 4.09 2.98 4.36 3.15 4.52 3.07
7.0 6 4.92 4.60 4.28 3.98 3.68
0.758735 2.91 2.64 3.17 2.65 3.73 2.96 3.93 2.98 4.06 2.97 4.32 3.13 4.47 3.06
10.1 9 4.89 4.57 4.26 3.95 3.65
36 2.91 2.64 3.17 2.65 3.70 2.95 3.91 2.97 4.02 2.95 4.24 3.11 4.38 3.03
13.2 12 4.85 4.54 4.23 3.92 3.61
38 2.91 2.64 3.16 2.64 3.65 2.93 3.87 2.96 3.94 2.92 4.08 3.05 4.21 2.97
16.9 15.5 4.82 4.51 4.20 3.89 3.58
39 2.91 2.64 3.16 2.64 3.62 2.92 3.85 2.95 3.90 2.91 4.01 3.02 4.12 2.94
41 2.91 2.64 3.15 2.64 3.51 2.87 3.69 2.89 3.74 2.85 3.83 2.96 3.93 2.88
43 2.91 2.64 3.14 2.64 3.40 2.83 3.53 2.82 3.57 2.78 3.65 2.90 3.73 2.82
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.08 2.85 4.57 3.07 4.74 2.99
-19.8 -20 2.26 2.26 2.26 2.26 2.26
12 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.07 2.85 4.55 3.06 4.72 2.98
-17.8 -18 2.40 2.40 2.40 2.40 2.40
14 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.07 2.85 4.53 3.05 4.70 2.98
-15.7 -16 2.55 2.55 2.55 2.55 2.55
16 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.06 2.84 4.52 3.05 4.68 2.97
-13.7 -14 2.70 2.70 2.70 2.70 2.70
18 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.05 2.84 4.50 3.04 4.66 2.96
-11.7 -12 2.84 2.84 2.84 2.84 2.84
Me 20 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.05 2.84 4.48 3.04 4.64 2.95
Me -9.6 -10 2.99 2.99 2.99 2.99 2.99
22 0.00 #####2.96 2.44 3.54 2.75 3.83 2.81 4.03 2.83 4.43 3.02 4.58 2.93
-7.5 -8 3.17 3.17 3.17 3.17 3.17
9 24 0.00 #####2.95 2.43 3.54 2.75 3.83 2.81 4.01 2.82 4.37 2.99 4.51 2.91
9 -5.5 -6 3.35 3.35 3.35 3.35 3.35
(m3/min) 26 0.00 #####2.95 2.43 3.52 2.75 3.80 2.80 3.96 2.80 4.30 2.97 4.44 2.89
(m3/min) -3.4 -4 3.47 3.46 3.46 3.42 3.39
28 2.67 2.40 2.95 2.43 3.51 2.74 3.76 2.79 3.92 2.79 4.23 2.94 4.37 2.86
-1.3 -2 3.58 3.57 3.56 3.50 3.43
30 2.67 2.40 2.94 2.43 3.48 2.73 3.72 2.77 3.87 2.77 4.17 2.92 4.31 2.84
0.8 0 3.78 3.72 3.67 3.54 3.41
0.0116432 2.67 2.40 2.94 2.43 3.45 2.72 3.69 2.76 3.83 2.75 4.10 2.89 4.24 2.82
0.11 3.9 3 4.10 3.95 3.81 3.59 3.38
34 2.67 2.40 2.93 2.42 3.44 2.71 3.64 2.74 3.76 2.72 4.02 2.86 4.16 2.79
7.0 6 4.48 4.19 3.90 3.62 3.35
0.76 35 2.67 2.40 2.92 2.42 3.43 2.71 3.61 2.73 3.73 2.71 3.97 2.85 4.11 2.77
10.1 9 4.45 4.17 3.88 3.60 3.32
36 2.67 2.40 2.92 2.42 3.41 2.70 3.60 2.72 3.70 2.70 3.90 2.82 4.03 2.75
13.2 12 4.42 4.14 3.86 3.57 3.29
38 2.67 2.40 2.91 2.41 3.36 2.68 3.56 2.70 3.63 2.67 3.76 2.77 3.87 2.70
16.9 15.5 4.39 4.10 3.82 3.54 3.26
39 2.67 2.40 2.91 2.41 3.33 2.67 3.54 2.70 3.59 2.66 3.69 2.75 3.79 2.67
41 2.67 2.40 2.90 2.41 3.23 2.63 3.40 2.64 3.44 2.60 3.52 2.69 3.61 2.61
43 2.67 2.40 2.89 2.40 3.13 2.58 3.25 2.58 3.29 2.54 3.36 2.63 3.44 2.56
Indoor air temperature
℃DB 23 ℃DB 26 ℃DB 27 ℃DB 28 ℃DB 31 ℃DB 33 ℃DB
Air flow 14 ℃WB 16 ℃WB 18 ℃WB 19 ℃WB 20 ℃WB 22 ℃WB 24 ℃WB
Air flow
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
DB WB 16 ℃DB 18 ℃DB 20 ℃DB 22 ℃DB 24 ℃DB
10 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.31 2.28 3.71 2.46 3.85 2.39
-19.8 -20 1.80 1.80 1.80 1.80 1.80
12 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.30 2.27 3.69 2.45 3.83 2.39
-17.8 -18 1.91 1.91 1.91 1.91 1.91
14 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.30 2.27 3.68 2.45 3.81 2.38
-15.7 -16 2.03 2.03 2.03 2.03 2.03
16 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.30 2.27 3.67 2.44 3.80 2.38
-13.7 -14 2.14 2.14 2.14 2.14 2.14
18 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.29 2.27 3.65 2.44 3.78 2.37
-11.7 -12 2.26 2.26 2.26 2.26 2.26
Lo 20 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.29 2.27 3.64 2.43 3.77 2.37
-9.6 -10 2.37 2.37 2.37 2.37 2.37
22 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.27 2.26 3.59 2.41 3.71 2.35
-7.5 -8 2.52 2.52 2.52 2.52 2.52
7 24 0.00 #####2.40 1.94 2.87 2.19 3.11 2.25 3.26 2.25 3.55 2.39 3.66 2.32
7 -5.5 -6 2.66 2.66 2.66 2.66 2.66
(m3/min) 26 0.00 #####2.40 1.94 2.86 2.19 3.08 2.23 3.22 2.24 3.49 2.37 3.61 2.31
(m3/min) -3.4 -4 2.75 2.75 2.75 2.72 2.69
28 2.17 1.91 2.39 1.94 2.85 2.18 3.05 2.22 3.18 2.22 3.44 2.35 3.55 2.29
-1.3 -2 2.85 2.84 2.83 2.78 2.72
30 2.17 1.91 2.39 1.94 2.82 2.17 3.02 2.21 3.14 2.21 3.38 2.33 3.50 2.27
0.8 0 3.00 2.96 2.92 2.81 2.71
0.0100632 2.17 1.91 2.38 1.93 2.80 2.16 2.99 2.20 3.11 2.19 3.33 2.31 3.44 2.25
3.9 3 3.26 3.14 3.03 2.85 2.68
34 2.17 1.91 2.37 1.93 2.79 2.16 2.95 2.18 3.06 2.17 3.26 2.29 3.37 2.22
7.0 6 3.56 3.33 3.09 2.88 2.66
0.7396735 2.17 1.91 2.37 1.93 2.79 2.16 2.93 2.17 3.03 2.16 3.22 2.27 3.34 2.21
10.1 9 3.54 3.31 3.08 2.86 2.64
36 2.17 1.91 2.37 1.93 2.77 2.15 2.92 2.17 3.00 2.15 3.17 2.25 3.27 2.19
13.2 12 3.51 3.29 3.06 2.84 2.62
38 2.17 1.91 2.36 1.92 2.72 2.13 2.89 2.15 2.94 2.13 3.05 2.21 3.14 2.15
16.9 15.5 3.49 3.26 3.04 2.81 2.59
39 2.17 1.91 2.36 1.92 2.70 2.12 2.88 2.15 2.91 2.11 2.99 2.19 3.08 2.13
41 2.17 1.91 2.35 1.92 2.62 2.09 2.76 2.10 2.79 2.07 2.86 2.14 2.93 2.08
43 2.17 1.91 2.34 1.91 2.54 2.05 2.64 2.05 2.67 2.02 2.73 2.09 2.79 2.03
This data shows average statuses out of those possible to occur in the system control.
(Depending on controls, there may be ranges where the operation is not conducted continuously.）
Symbols are as follows
TC :Total cooling capacity(kW)
SHC :Sensible heat capacity(kW)
12
Lo
10
Notes(1)
(2)
Cooling mode Heating mode (kW)(kW)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
air
temperature
(℃DB)
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
Outdoor
temperature Indoor temperature
