MLis MLB-G1102 User manual

MLB-G1102
Quad Band GSM/GPRS
Terminal
USER MANUAL

MLB-G1102 Wireless Terminal User Manual 2 Rev 1.1
Information provided by Schmidt & Co., (HK) Ltd, (herein known as ‘the company’), is believed to be
accurate and reliable. However, the company assumes no responsibility for its use, nor any
infringement of patents or other rights of third parties, which may result from its use. No license is
granted by implication or otherwise under any patent rights of the company other than for circuitry
embodied in the company’s products. The company reserves the right to change the circuitry and
specifications at any time without notice. This document is subject to change without notice.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including but not limited to photocopying, recording, transmitting via fax and/or modem
devices, scanning, and/or information storage and retrieval systems for any purpose without the
expressed written consent of the company.
WARNING: The MLiS GSM wireless terminal is a RF product intended for interfacing and operating
with a host device. Local relevant RF regulations such as allowed frequencies and usage in commercial
flights must be observed. Safety instructions must be included in the manuals of the host device.
Schmidt & Co., (HK) Ltd assumes NO liability for customers, who fail to comply with these precautions.
Service and Support
[e-mail]
Download Information
http://www.schmidtm2m.com/en/support_download.php

MLB-G1102 Wireless Terminal User Manual 3 Rev 1.1
CONTENTS
1INTRODUCTION............................................................................................................................ 5
1.1 Description............................................................................................................................. 5
1.2 Highlights ...............................................................................................................................5
1.3 Functional Block diagram.......................................................................................................7
1.4 Main Features and Services................................................................................................... 8
1.4.1 Wireless Terminal Features and Electrical Specifications...................................................8
1.5 Precautions............................................................................................................................ 9
2MECHANICAL DESCRIPTION..................................................................................................... 10
2.1 Overview.............................................................................................................................. 10
2.2 Dimensions .......................................................................................................................... 10
3ELECTRICAL INTERFACE DESCRIPTIONS............................................................................... 11
3.1 Right side view (DB9 connector) .......................................................................................... 11
3.2 Left side view (DC Jack & Industry connector)...................................................................... 12
3.3 Frond view (Antenna & LED)................................................................................................ 13
3.4 SIM card holder.................................................................................................................... 14
3.5 Getting Started..................................................................................................................... 15
4OPERATING NOTE...................................................................................................................... 27
4.1 Power on the Modem ........................................................................................................... 27
4.2 Reset to default.................................................................................................................... 27
4.3 External input x2................................................................................................................... 27
4.4 External Relay x1................................................................................................................. 27
4.5 DB9 Connector..................................................................................................................... 27
4.6 Install SIM card..................................................................................................................... 27
5MLiS Cellular Control Protocol (MCCP)........................................................................................ 28
SALES CONTACT............................................................................................................................... 37

MLB-G1102 Wireless Terminal User Manual 4 Rev 1.1
6ORDERING INFORMATION......................................................................................................... 38
List of Figures
Figure 1: Functional Block Diagram for MLB-G1102..............................................................................7
Figure 2: Chassis Dimension for MLB-G1102...................................................................................... 10
Figure 3:RS232/RS422/RS485 for MLB-G1102................................................................................... 11
Figure 4: DC and Industry connector for MLB-G1102 .......................................................................... 12
Figure 5: Antenna Connector for MLB-G1102...................................................................................... 13
Figure 6: SIM Card Holder for MLB-G1102.......................................................................................... 14
List of Tables
Table 1: Operating Modes ..................................................................................... 錯誤! 尚未定義書籤。
Table 2: Features and Specifications.....................................................................................................8
Table 3: Chassis Dimensions and Mechanical Description for MLB-G1102......................................... 10
Table 4: DB9 pins define for MLB-G1102............................................................................................. 11
Table 5: Interfaces and Indicators Description of MLB-G1102 ............................................................. 12
Table 6: LED functions of MLB-G1102................................................................................................. 13

MLB-G1102 Wireless Terminal User Manual 5 Rev 1.1
1 INTRODUCTION
1.1 Description
The MLiS MLB-G1102 is a Dual Band 2G wireless terminal designed for RS232/RS422/RS485
communication over TCP/IP via any readily available 2G carrier network. Overall, it is more cost and
time effective to use remote solutions to combine Machine to Machine over diverse locations without
having first to establish and invest in a huge complex network.
The MLB-G1102 wireless terminal uses the DB9 Connector to provide data communication interface
and the DC jack to provide power input. LEDs are used to indicate the status of the wireless terminal.
The MLB-G1102 wireless terminal can be used to provide a wireless communication link to many
applications, including metering, fleet and asset management, vending, security and alarm monitoring,
e-maintenance and other telemetry applications.
1.2 Highlights
Interface
DC jack Connector for power
DB9 connector(Female)
SMA Female Connector (GSM antenna connector)
SIM card reader
1 * relay
2 * I/O pins
General Features
•Frequency Range : GSM / GPRS：Quad band GSM 850 / 900 / 1800 / 1900 MHz
•Protocol Stack : TCP/UDP
•Power Supply Input : 5 to 32 VDC
•Relative Humidity : 90% MAX.
•Operation Temperature : -40°C ~75°C
•Switch Off Protection : +90°C
•Dimensions (L) x (W) x (H) : 119.5 x 89 x 26.9 mm (excluding connectors)
•Weight : 200g
•Casing Material : Metal

MLB-G1102 Wireless Terminal User Manual 6 Rev 1.1
Data Transmission
•GPRS : Multi-slot Class 12, Mobile Station Class B.
•EDGE : Multi-slot Class 12
•CSD : -9.6kbps, non-transparent, V.110
•SMS : MT, MO, Cell Broadcast, Text and PDU mode.
•Serial Parameter :
–Data Bits : 5, 6, 7, 8
–Stop Bits : 1, 1.5, 2
–Parity : None, Even, Odd, Space, Mark
–Flow Control : RTS/CTS, DTR/DSR
–Baud-rate : 1200~230400 selectable
–Serial signals : TxD, RxD, RTS, CTS, DTR, DSR, DCD, RST(reset circuit), GND
•Relay : 1 output with current carrying capacity of 2A @ 40 VDC
•Digital Inputs : 2 electrically isolated inputs:
–+13 to 30V for state “1”(On)
–+3 to -30V for state “0”(Off)
•ESD Protection : 15KV
•Data Buffering : 1M
•Data Delimiter : Yes
•Data Length Packing : Yes
•MCCP/MCCU : Yes
–API : MLiS Cellular Control Protocol (=MCCP)
–Utility : MLiS Cellular Control Utility (=MCCU)

MLB-G1102 Wireless Terminal User Manual 7 Rev 1.1
1.3 Functional Block Diagram
Figure 1: Functional Block Diagram for MLB-G1102
The MLB-G1102 consists of a fully certified (CE approved) GSM/GPRS engine, SIM card holder and
power regulator.
The wireless terminal is supplied with power via the DC jack. The remaining DB9 connector is used for
data communications.
The SMA female connector provides the air interface to an external 50 ohm antenna specified for the
correct frequency band.
DB9

MLB-G1102 Wireless Terminal User Manual 8 Rev 1.1
1.4 Main Features and Services
The MLB-G1102 performs a set of telecom services (TS) according to GSM standard phase 2+, ETSI
and ITU-T. The services and functions of the MLB-G1102 are implemented by issuing customized
applications embedded on the device, or by AT commands issued internally, or over the RJ45 to
RS232 serial interface.
1.4.1 Wireless Terminal Features and Electrical Specifications
S/N
Feature
Specifications
1
Frequency Bands
GSM/GPRS: Quad band GSM 850/900/1800/1900 MHz
2
RF Output Power
Class 4 (+33dBm ±2dB) for EGSM850 (quad band only)
Class 4 (+33dBm ±2dB) for EGSM900
Class 1 (+30dBm ±2dB) for GSM1800
Class 1 (+30dBm ±2dB) for GSM1900 (quad band only)
3
GSM Phase
Release 99
4
Power Supply
5~32VDC
5
Power Consumption
Idle Mode
0.18W(9V@20mA)
Operation Mode
0.36W(9V@40mA)
6
Operating Temperature
Normal operation: -40°C ~+75°C
7
Data Transfer
GPRS
•Multislot Class 8 (dual band) or 10 (quad band)
•Full PBCCH support
•Mobile Station Class B
•Coding Scheme 1 –4
CSD
•V.110, RLP, non-transparent
•2.4, 4.8, 9.6, 14.4kbps
•USSD
PPP-stack for GPRS data transfer
8
SMS
Point-to-Point MT and MO
Cell Broadcast
Text and PDU Mode
Storage: SIM Card plus 25 SMS locations in mobile equipment
Transmission of SMS alternatively over CSD or GPRS. Preferred
mode can be user defined.
9
AT Commands
AT-Hayes 3GPP TS 27.007, TS 27.005
10
TCP/IP Stack
Access by AT Commands
Internet Services include TCP, UDP,

MLB-G1102 Wireless Terminal User Manual 9 Rev 1.1
Table 1: Features and Specifications
1.5 Precautions
The MLB-G1102 wireless terminal is designed for indoor use only. For outdoor use it has to be
integrated into a weatherproof enclosure. Do not exceed the environmental and electrical limits as
specified in the user manual.
11
Serial Interface
DB9 connector
8-wire Modem Interface with status and control lines, unbalanced,
asynchronous
Fixed bit rate: 1,200bps to 230,400bps
Flow Control: Hardware RTS0/CTS0 and Software XON/OFF
Multiplex ability according to GSM 07.10 Multiplexer Protocol
12
SIM Interface
SIM Card Slot
Supports SIM Cards: +3V and +1.8V
13
Antenna
50 ohms via External SMA Connector
14
Software Reset
Orderly shutdown and Reset by AT Command (AT^SMSO)
15
RoHs
All hardware components are fully compliant with the EU RoHs
directive 2002/95/EC
Exception: MLB55IN

MLB-G1102 Wireless Terminal User Manual 10 Rev 1.1
2 MECHANICAL DESCRIPTION
2.1 Overview
The pictures below show the mechanical design of the wireless terminal along with the positions of the
different connectors.
2.2 Dimensions
Figure 2: Chassis Dimension for MLB-G1102
S/N
Parameter
Value
1
Height (H)
26.9mm
2
Length (L)
119.5mm
3
Width (W)
89.0mm
4
Weight
200g
5
Chassis Material
Metal
Table 2: Chassis Dimensions and Mechanical Description for MLB-G1102

MLB-G1102 Wireless Terminal User Manual 11 Rev 1.1
3 ELECTRICAL INTERFACE DESCRIPTIONS
3.1 Right side view (DB9 connector)
Figure 3:RS232/RS422/RS485 for MLB-G1102
The table below defines the RS232/RS422/RS485 pin configuration on the wireless terminal.
Table 3: DB9 pins define for MLB-G1102

MLB-G1102 Wireless Terminal User Manual 12 Rev 1.1
3.2 Left side view (DC Jack & Industry connector)
Figure 4: DC and Industry connector for MLB-G1102
The interfaces and indicators for MLB-G1102 are as follows:
Name
Description
Function
DC
DC
Input Power:+5V~+32V
Terminal
Block
PWR(V+,V-)
•Input Power:+5V~+32V
•Pin #1 is V+
•Pin #2 is V-
•When use DC for input, the output power of TB is same as input
power
Do Not use DC & PWR to be the input power at the same time, it
may cause damage to the equipment.
Relay
External Relay:max+40V
DI1(I1,COM_1)
Pin #5 is +
Pin #6 is -
•I1:external signal +12V~+48V
•COM_1:common grand
•Pin #5 is +
•Pin #6 is -
DI2(I2,COM_2)
Pin #7 is +
Pin #8 is -
•I2:external signal,+12V~+48V
•COM_2:comman grand
•Pin #7 is +
•Pin #8 is -
Reset
Reset
•1-click to reboot MLB-G1102.
•Double click to set MLB-G1102 into configuration mode.
•Long press over 5 seconds to reset MLB-G1102 to default.
Table 4: Interfaces and Indicators Description of MLB-G1102

MLB-G1102 Wireless Terminal User Manual 13 Rev 1.1
3.3 Frond view (Antenna & LED)
Figure 5: Antenna Connector for MLB-G1102
For optimum RF performance, the MLiS wireless terminal has to be connected to an external RF
antenna matched to 50ohms. Please use a SMA Male connection for the wireless terminal.
The functions of LED are indicated on the table below.
Item
Description
Function
1
Power
Power on indication
2
2G
2G status indication
3
Ready
Function working indication
4
Fault
Occur error
5
Net
Builds connection
6
SIMerr
SIM card error indication
7
Tx
UART transmit indication
8
Rx
UART Receive indication
Table 5: LED Functions of MLB-G1102

MLB-G1102 Wireless Terminal User Manual 14 Rev 1.1
3.4 SIM card holder
In the bottom, The MLB-G1102 wireless terminal is provided with a SIM card reader designed for 1.8V
and 3V SIM cards. It is the flip-up type which can be locked. It can be accessed through removing the
battery cover as shown below.
Figure 6: SIM Card Holder for MLB-G1102
Be sure to power off the modem when user replaces the SIM card. Otherwise it may cause
damage to the equipment.
The MLB-G1102 fully operates when inserting a SIM card. Some MLB-G1102 functionality may be lost
if user try to operate the wireless terminal without a SIM card.

MLB-G1102 Wireless Terminal User Manual 15 Rev 1.1
3.5 Getting Started
HW Installation
Step 1: Please insert a SIM card into SIM card holder as follows.
Be sure to power off the modem when user replaces the SIM card. Otherwise it may cause
damage to the equipment.
Step 2: Please connect to device through serial port as following Pinouts.

MLB-G1102 Wireless Terminal User Manual 16 Rev 1.1
Step 3: Please connect power supplier with 5~32 VDC, then boot up. The LED will light up when MLB-
G1102 ready.
Step 4：After plug-in power adapter. The wireless terminal is usually fully operational within 30
seconds, after powering it up. Depending on the signal strength of the network in the area, logging into
a network may take longer and is outside the control of the wireless terminal.
The device is ready after LED of signal is lighted. Then user can operate it.
Step 5: When user use the MCCU (MLiS Cellular Configuration Utility) to
configure MLB-G1102, please refer the connection as below:

MLB-G1102 Wireless Terminal User Manual 17 Rev 1.1
SW Installation
Preliminary work: Power on MLB-G1102 and use USB-to-RS232 cable to connect to MLB-G1102 & PC.
Step 1：Open MCCU (MLiS Cellular Configuration Utility).
Step 2：The main window of MCCU launch.
Figure 1: MLB-G1102 Configuration Utility

MLB-G1102 Wireless Terminal User Manual 18 Rev 1.1
Basic Information
The Basic Information page summarizes the current settings of MLB-G1102.
Item
Model
Shows the model user connected.
FW Version
Current firmware version.
SIM Card
The status of SIM Card.
Operator
Telecoms
Get Info
Click it to reload the basic information.

MLB-G1102 WIRELESS TERMINAL User Guide 19 Rev 1.1
SMS Configuration
MLB-G1102 support events alert through SMS.
Item
Phone no. format
SMS Admin
Set the phone no. to be the Admin. Then user
uses this phone to send SMS to modify the
settings of MLB-G1102. The SMS content follow
the MCCP.
Input phone no. with country
code.
For example: [phone]
Reboot event
Tick the check box then input the phone number.
When the reboot event occurred, MLB-G1102
will send SMS to the phone number user set.
Input phone no. with country
code
For example: [phone].
GPRS off-line
Tick the check box then input the phone number.
When the GPRS off-line event occurred, MLB-
G1102 will send SMS to the phone number user
set.
Input phone no. with country
code.
For example: [phone].
DIO1 changed
Tick the check box then input the phone number.
When the DIO1 event occurred, MLB-G1102 will
send SMS to the phone number user set. (Make
sure your setting is “Send to SMS”when event
occurred)
Input phone no. with country
code.
For example: [phone].
DIO2 changed
Tick the check box then input the phone number.
When the DIO2 event occurred, MLB-G1102 will
send SMS to the phone number user set (Make
sure your setting is “Send to SMS”when event
occurred).
Input phone no. with country
code.
For example: [phone].
Relay
changed
Tick the check box then input the phone number.
When the relay event occurred, MLB-G1102 will
send SMS to the phone number user set (Make
sure your setting is “Send to SMS”when event
occurred).
Input phone no. with country
code.
For example: [phone].

MLB-G1102 WIRELESS TERMINAL User Guide 20 Rev 1.1
System
Set system variables in System tab.
Item
APN
Input the APN (Please confirm with carriers.)
User Name
Input user name of APN
Password
Input password of APN
Device ID
Set ID.(It supports up to 15 characters)
Retry Time
Set the retry times when connection interrupts.
Time Interval
The interval between two retries.
Heartbeat
Set the frequency of heartbeat.
Ex. If user sets 60 seconds, the heartbeat will be send every 60
seconds.
Heartbeat String
Set the string of heartbeat.
Send to Main/Send to all
Select the Heartbeat receiver. (Main server only or all)
