Mobatime TPHP LAN User manual

© MOBATIME BE-801181.00
User manual
TPHP LAN
Intelligent Ethernet sensor for temperature, humidity and dew point
Temperature and humidity sensor connected to DC and DSC digital clock and to the DP and DO
text display panels via the Ethernet.
Measures temperature within the range of -40 to +123.8 °C
Measures relative humidity within the range of 0 % to 100 %
Possibility of temperature and humidity display on more than
one device at the same time
Data transfer via TCP/IP protocols (10/100 Ethernet).
WEB based Configuration.
Sensor “SD TPH”, IP 54
Sensor is connected by a silicon cable with high temperature
resistance.
Powered from 5 V to 30 V (Wall-plug adaptor included).
Mounting onto DIN 35 mm rail on request.
Engineering data
TP LAN
Scope of measured temperatures
- 40°C to +123,8°C
Measuring accuracy
±0.5 °C within the range of -10 °C to +85 °C;
otherwise ±2 °C
Power supply
4 –6 VDC (max. 230mA)
Operating temperature
-40 .to.. +85°C
Humidity range
0 % to 100 %
Resolution
1% RH
Protection degree
IP 54
Dimensions
46 x 16 x 10 mm
Weight
approx. 80 g (without sensor)
Sensor connection cable
3m length, (up to 20 meters upon request), silicon
Connectors
RJ45, Tbase 10/100 Ethernet
coaxial 3.8 x 1.3 mm, powering (+ pole in the middle)
Indication
green LED –power supply
yellow LED –indicates established TCP/IP connection.
Link LED, Activity LED on the RJ45 connector
Default parameters of the network
IP address 192.168.1.254
mask: 255.255.255.0
gateway: 0.0.0.0

© MOBATIME BE-801181.00
Change to the thermometer IP address:
setting is carried out using the Ethernet Configurator software (Downloads
http://www.papouch.com/cz/shop/product/tme-ethernetovy-teplomer/ethernetconfigurator.zip)
following the start all thermometers connected to the LAN local network and the respective
IP addresses are displayed in the upper window
choose the IP of the thermometer you want to set and depress the Set Device button
edit the IP address or other contingent parameters in the bottom window
by depressing the Set button send away the actual setting data to the thermometer.
Reset of thermometer:
Reset is carried out using the following procedure:
disconnect power supply from the device
open the electronic box by screwing off screws on the sides
insert the shortcircuiting jumper in the inside of the device and keep it short-circuited
switch the power supply on and wait for 10 seconds
the process of resetting is now finished
Set communication mode to TCP Server:
after setting the TPHP LAN’s IP address, you can connect to it by any WEB browser. WEB
interface is the primary means to configure the thermometer. (For example by entering
http://192.168.1.254/ - for default IP address.)
to enter settings, push “Settings” button in upper right corner of TPHP LAN main WEB
set communication mode to TCPServer
factory device default set

© MOBATIME BE-801181.00
Setting the DC or DSC digital clock:
the digital clock has to have its own IP address set manually or using DHCP
enter the clock main MENU and move to SW version, hold long both push-buttons placed on
the frame or button DISP on the IR controller - service menu will be entered
set the C5 item of the service menu to 7 and open the submenu
set gradually the 4 octets of the thermometer IP address in the submenu and confirm the setting
close the service menu
within approx. 3 minutes the digital clock should start displaying the measured temperature
for both temperature sensors can be set the correction of measured temperature in range
-9 ÷ +9°C (°F) in the submenu of the P12 main menu item
enter the submenu by pushing the SET button on the IR remote controller or by long push of the
left button on the clock frame when the P12 item is displayed
the c1: 0 is displayed, correction value for temperature 1 s blinking, the value can be changed
using +- buttons on the IR controller or by pushing the right button on the frame
after pushing the right arrow button on the IR controller or left button on the frame the c2: 0 is
displayed, correction value for temperature 2 is displayed, value can be changed the same way
as in previous point
saving the correction values and return to the main menu item P12 is done be pushing the OK
button on the IR controller or by long push of the left button on the frame
Notice:
For detailed information visit the manufacturer's website www.papouch.com
Warranty and repair
device meets the following standards:
IEC 60950-1 ed. 2 - with respect to electrical safety
EN 55022 class B, EN 55024 - with respect to EMC
The warranty does not apply to defects caused by
- Improper handling or intervention
- Chemical effects
- Mechanical damage
- The intervention of external events (natural disaster, etc.)
