Mobi-click compact User manual

COMPACT
User manual
www.mobi-click.com

The easiest Mobi-Click Compact works nearly like a usual mobile phone, just much more easier!
mobile phone... You can receive any calls and dial three pre-programmed phone numbers directly.
for seniors:
Mobi-Click Compact is suitable as an emergency system for elder and handicapped persons.
ith these three numbers you can call for example your doctor, your daughter or the
emergency call service directly.
for children (and anxious parents):
ith the three coloured buttons, Mobi-Click is also the perfect mobile phone for children
because parents can always contact their children.
and alarm system: As an alarm system Mobi-Click protects you in different situations:
Car theft and bur lary:
ith Mobi-Click Compact you can protect your vehicle against theft or your flat, your house
or your office against burglary.
Baby phone:
As a Baby phone Mobi-Click alarms you immediately if your child is crying or climbing out of
bed.
In case of an alarm you are going to receive up to three SMS or phone calls on your three
pre-programmed numbers. You have the possibility to contact undetected Mobi-Click from
any phone and so listen in the room quietly.
You can protect your Mobi-Click with a PIN-code, so that only you or any allowed person
can communicate with Mobi-Click quietly.
Product description: What is Mobi-Click "Compact"?
3
More security in all situations!
Product description: hat is Mobi-Click "Compact"? 3
Important information 4
At first: change the PIN-code! 6
Switch on/ off Mobi-Click Compact 8
Mobile phone, emergency and alarm system at the same time! 10
How do I save the 3 phone numbers? 12
My first phone call with Mobi-Click Compact 14
Switch on the alarm standby with another mobile phone 16
hat should I do in case of an alarm? 18
How will I be informed per SMS in case of an alarm? 20
How do I choose the right alarm instruction? 28
Can I change the sensitivity of the sensors? 29
hether everything is set correctly? Test! 30
hat is the meaning of the SMS messages? 31
Eavesdrop in? Yes, but pay attention...! 32
PIN-Code – How to protect against outside access? 33
Can I write personal alarm messages? 34
How can I test if the text is correct? 36
Individual SMS-instructions 37
Security zone and localization of persons or objects 38
How can I connect extern devices? 39
Declaration of Conformity 40
Technical data 41
2
Mobi-Click at home 24-25
Mobi-Click for the car 22-23
Mobi-Click in the child’s room 26-27
Car theftCar theft Bur laryBur lary Baby phoneBaby phone

Important information
1. First steps before usin the Mobi-Click Compact
Mobi-Click Compact possesses an integrated circuit for the protection of the battery from over and under
charging as well as from short-circuit. This protective circuit is activated with a small slide switch (see design).
In order to avoid damage during transport, this slide switch is set to the OFF position at the factory. Before
first use the protective circuit must be activated by moving the slide switch from the OFF to the ON position.
(View of the Compact from the rear)
To set the Compact in operation
.Open the rear cover
.Open the SIM-card caddy
.Using a pointed tool, move the slide switch to the ON position
.Insert SIM-card
.Close the SIM-card caddy
.Close the rear cover
.Connect the battery charger
.A peep signals indicates that the Compact has successfully started
Important information
.
1. Leave the Compact connected to the battery charger for a minimum of 40 Minutes to ensure that the battery is fully
charged.
2. 2. Before switching on the Compact (with the ON/OFF key) the battery charger must be
disconnected. Once Compact is switched on, the battery charger can be connected or disconnected as
required, or be permanently connected. This way, a temporally unlimited working time of
Compact can be guaranteed (e.g. monitoring during a vacation).
3. 3. Compact allows the user a variety of programming options and adjustments of the device
functions to suit individual requirements of the user. If during the programming something does not
really work, you can reprogram the device, reset the Compact by moving the reset switch (located
under the rear cover) to the OFF position for a minimum of 5 seconds and then ON again. This
does not erase previous settings, but sets the Compact ready to receive new instructions.
Restart the Compact after resetting.
54

PIN
At first: chan e the PIN-code!
As Mobi-Click Compact has only 3 buttons and a ON/OFF power button some settings have to be done on a second "normal"
mobile phone at the first use.
These settin s have to be done just once!
Chan in of the PIN-code
For the use of Mobi-Click Compact you also need a SIM-card which is like the SIM-cards you need for other mobile phones.
It does not matter which SIM-card you choose, a prepaid-card or a SIM-card with subscription with an operator. Put the SIM-
card, which you are going to use for Mobi-Click Compact later, in a "normal" mobile phone first.
Every SIM-card has a PIN-code. Since Mobi-Click utilises it own PIN system to guard against unauthorised access by SMS.
Therefore the original PIN-code of the SIM card must be changed (see your mobile phone handbook for changing PIN
instructions). For changing PIN you can use any mobile telephone.
Place the SIM card intended for use in the Mobi-Click into any mobile phone. Using the mobile phone’s menu, navigate to the
changing PIN code option (see your mobile phone handbook for changing PIN instruction) and change the PIN-code as
follows:
new PIN-Code: 1513.
In case of any problems read the instructions of your operator or the instructions of your mobile phone manufacturer.
After changing the PIN-code of your SIM-card, remove the SIM-card from your mobile phone and place it into Mobi-Click
Compact. Open the small cover at the bottom of Mobi-Click Compact and place the SIM-card into the SIM caddy. Carefully
replace the cover.
Ready to start!
Put the new SIM-card into the
"normal" mobile phone 
SIM-
card
Place SIM-card with the changed
PIN into Mobi-Click Compact
SIM-
card



Enter the original PIN-code
code
Change the PIN-code
(as per page 6)
Take the SIM-card out
of the mobile phone again

Bottom
Compact
6 7
ATTENTION!
Mobi-Click Compact works only when you delete all messa es you have in the "inbox" of your SIM-card.

Start
Switch on Mobi-Click Compact
The yellow LED comes on
Ready for use
8 9




The green LED begins
to flash and the yellow
LED turns off
Switch on Press the ON/OFF-button for
about 5 seconds
Automatic GSM network
search (ca. 20 sec.)

A dual tone indicates that
telephone mode has started Mobi-Click
Compact
works only
if...
…it is switched on and
the accumulator
is loaded.
…the PIN-code of the
SIM-card has been
changed.
…the SIM-card is put in
correctly.
…a perfect GSM
reception is given.
Mobi-Click
Compact
works only
if...
…it is switched on and
the accumulator
is loaded.
…the PIN-code of the
SIM-card has been
changed.
…the SIM-card is put in
correctly.
…a perfect GSM
reception is given.
Press until you hear "peep".
(During this time the red LED
flashes)
Mobi-Click Compact was produced by keeping to the strict
manufacturing and quality controls. Thus your device works correctly
and to prevent that the guarantee expires there has to be considered
the following security councils:
1 Mobi-Click Compact
1 SIM-card
1 mobile phone for changing the PIN-code of the SIM-card and
to program the three phone numbers
You need
Connect Mobi-Click
Ensure the Mobi-Click is turned OFF and connect the battery charger
to ensure that the battery is fully charged.You will hear a short peep
tone when the charging cycle begins
Orange LED is blinking: the battery is not charged
Switch on your device as described on the left page. You should
NOT turn on the Mobi-Click with the charger connected. An
integrated protection circuit is built into the Mobi-Click to ensure
that the battery delivers optimal supply to the Mobi-Click.
What to do if...
…there is no dual tone and the green LED does not light?
Is the device switched on?
Does the battery have enough power?
Is the PIN-code changed, and is the SIM-card inserted correctly?
Attention! General Reset (s. pa es 35)
Security advise
Take care of your Mobi-Click Compact.
Mobi-Click is full of electronics and sensitive sensors. Therefore
do not drop Mobi-Click, do not expose Mobi-Click any hard hit as
the electronic printed circuit board could get any defect because
of this.
Moisture, heat or cold could influence the perfect work of the
device strongly and lead to damages.
Do not try to open the Mobi-Click device. Thus you damage the
housing and you loose the guarantee service.
ATTENTION!
Should the green LED not start flashing, turn off the Mobi-Click using the ON/OFF-button and
check to ensure the SIM-card has been inserted correctly. Also ensure that you are in a good
mobile phone reception area.
For switchin off the device,
also press the power ON/OFF
key (the yellow and the green LED
will flash during this operation).

Activate as mobile phone Activate as emer ency system
RED
GREY
Keep the two
buttons pressed
when switching on
until you hear a
signal tone!
Press when switching
on (power ON/OFF).
Set up connection If it is rin in Durin phone call
Emer ency mode:
The call will be answered
automatically after 1 ring.
Emer ency mode:
Hear the call automatically
loudly (free speaker).
Dial the 1st number
Dial the 2nd number
Dial the 3rd number
Reject call
Answer the call
loudly
Answer the call
normally
Switch to mute
Hear loudly
(free speaker)
Hang up
Activate as alarm system Activate test mode
GREEN
Press the two
buttons when
switching on until
you hear a signal
tone!
Switch on alarm standby
AUTO Car monitoring
HOME Protection against burglary
BABY Baby phone
BLUE
Press the two
buttons when
switching on until
you hear a signal
tone!
Press the button until the countdown starts
(peep...peep...). You now have 15 seconds
to leave of the room.
To switch off: press the button again.
In the test mode
In case of an alarm the three SMS or phone
numbers will be informed. See page 20 and
21.
Switch on: press the same buttons as
described on the left. ith the test mode you
can test the different sensors. In case of an
alarm you hear a siren. Switch off: Press the
chosen number again.
In an emer ency case:
Multifunctions
Mobile phone, emer ency and alarm system at the same time!
10 11
+ + +
ON/OFF ON/OFFON/OFF
(GREEN)
(RED)
(BLUE)

12 13
Start
How do I save the 3 phone numbers?
COMPACT 42
31.03.2004 10:11
COMPACT 42
Tel1 = call
004191123456
Write a SMS
(messa e) on a
normal mobile phone
and send it to
Mobi-Click!
Write a SMS
(messa e) on a
normal mobile phone
and send it to
Mobi-Click!
Please consider the space bars between single words / numbers: Set(space
bar)TEL2(space bar)+41...
Always include intl. prefixes for intl. phone numbers (e.g. 0041 or +41 for
Switzerland).
Use capital or small letters or both.
Every new SMS-order deletes the old one!
You can store all three numbers at one time by sending the instruction set key
followed by the three numbers you wish to send to the Mobi-Click Compact. This acts
the same as the instruction for only one number (e.g. set TEL/SMS1). (Note! The
spaces between the three numbers must be inserted!)
Enterin on a normal mobile phone Activate Mobi-Click Compact in the alarm mode (see page 11)
As easy as SMS...
The number is saved:
button 1 (red)
You receive confirmation
(SMS)
Set TEL1 [phone] red button: 1. receiver
e.g.:
triple tone
Confirmation of
the SMS instruction
messa e
(SMS)
ith Mobi-Click Compact you can dial three different
numbers, without the tiring typing of the phone numbers:
just press one of the three coloured buttons and you are
connected directly to the number you have chosen!
Before you can profit from this short dialling, you have to
save those three numbers first. (You can change them easily
at any time). Therefore you need a normal mobile phone.
At first you have to choose a number for every coloured
button.
Start Mobi-Click Compact in the alarm mode!
Press and hold the blue button at the same time as pressing
the ON/FF button (see page 11)
For every single number you have to create an SMS on a
normal mobile phone and send it to Mobi-Click Compact. You
can also send and save all three number simultaneously using
the set key command (see page 13).
After the numbers have been saved, switch off the
Mobi-Click and restart Mobi-Click in mobile phone
mode.
ATTENTION!
Even if you have one or more of these three numbers set as
SMS in alarm mode – in telephone mode always this number
will be called independently of the alarm set-up.
rite a SMS instruction:
Next number:
continue with 
TEL1 ... red button
TEL2 ... green button
TEL3 ... blue button
Send SMS instruction
to Mobi-Click Compact
Set TEL[phone]...
Set TEL3 +4152765...
e.g.:
e.g:
+


Activate as alarm
system (page 11)
+







Start
My first phone call with Mobi-Click Compact
14 15
Dial the number
Keep one of the three coloured buttons
pressed at minimum for 3 seconds!
1 2 3
The chosen connection will be made
During the
connection Switch to mute
Loudspeaker (free speaker)
Hang up
If it‘s ringing... Reject call
Answer the call loudly
Answer the call normally Answer a call automatically:
Elderly and handicapped person
are often living alone. Especially
this group of people is often
exposed to dangerous
situations: a fall or an
unexpected collapse could have
bad consequences.
hen the call is answered
automatically you can contact
your beloved person directly
whenever you want: Mobi-Click
Compact answers automatically
and put the hear- and speaking
settings to "loud" (free
speaker), thus the person do
not have to pick up the
telephone.
Answer a call automatically:
Elderly and handicapped person
are often living alone. Especially
this group of people is often
exposed to dangerous
situations: a fall or an
unexpected collapse could have
bad consequences.
hen the call is answered
automatically you can contact
your beloved person directly
whenever you want: Mobi-Click
Compact answers automatically
and put the hear- and speaking
settings to "loud" (free
speaker), thus the person do
not have to pick up the
telephone.
GREENRED BLUE
(GREEN)
(RED)
(BLUE)
(GREEN)
(RED)
(BLUE)
Answer a call automatically – more security for people who live alone or
handicapped persons:
Mobi-Click Compact answers automatically after 1 ring.
Acoustic
confirmation (peep)
During the phone
connection:
Activate as mobile phone
(see also page 10)
+Activate as
emer ency system
(see page 10)
+
or or
Keypad lock
KEYPAD LOCK:
Switch on Mobi-Click: Press ON/OFF-
button, until you hear the dual tone. ait
until the network is present (green LED is
blinking). Press again the ON/OFF-button
and press immediately button 1.
If you hear a triple tone, all buttons,
except the ON/OFF, are locked.
KEYPAD UNLOCK:
Press the ON/OFF-button, until you hear
a clicking signal, then press immediately
button 3. If you hear a triple tone again
now, the keypad is unlocked.
In the normal speech mode the green LED flashes. In
the free speech mode the green and the red LED flash
alternately. The orange light is continuously lit during
the call. After hanging up, a peep will be heard, which
can be understood as confirmation for terminated call.

16 17
Switch on alarm standby
Switch on the alarm standby with another mobile phone
Alarm standby is
activated
rite the SMS instruction
Confirmation of the SMS
instruction
e.g.:
e.g.:
set auto: Protection a ainst vehicle theft
Vibration-sensor and locating activated.
set home: Protection a ainst bur lary
Motion-sensor activated.
set baby: Baby phone
Motion- and acoustic- sensor/
microphone activated.
examples:
Test Auto test monitoring vehicles
(no alarm calls, on the Mobi-Click an
alarm tone is heard)
Reset Home monitoring rooms switched off
Set Baby Baby phone switched on
Mobi-Click Compact can be set per SMS
instructions with every normal mobile phone.
Therefore you should be able to write and send
SMS messages on your mobile phone, then you
are also able to serve Mobi-Click. All settings of
Mobi-Click are made by a simple principle:
rite a SMS on your mobile phone.
Send this SMS to the Mobi-Click Compact
SMS instructions consist of 2 words:
1. word: what do I want to do?
Set = switch on
Reset = switch off
Test = test
2. word: determine situation or sensors
Auto = vehicle monitoring
Home = room monitoring
Baby = baby phone
Always space bar between the
words.
Use capital / small letters or both.
Every new instruction deletes the
old one!
ith the instruction set alarm
you can activate the Mobi-Click in
alarm mode.
Alarm is ready!
Activate Compact as alarm system On your own mobile phone
Send the SMS instruction
to Mobi-Click Compact
Set auto
Set home
Set baby
e.g.:
As easy as a SMS… hat is the meaning of the SMS?
You receive short
message (SMS)
on your mobile phone



+

Activate as alarm
system (page 11)
+
31.03.2003 10:11
COMPACT 42
Command:
SET AUTO
Message:
Command OK
> End of Report

18 19
In case of alarm
What should I do in case of an alarm?
31.03-2004 10:11
COMPACT 42
Messa e: An alarm
was released!
AREA : off
VIBRA : off mid
MOVE : ALARM mid
VOICE : ALARM mid
saved ALL the numbers that you
Always your mobile
phone...
Please ensure that you have
saved ALL the numbers that you
wish Mobi-Click to alarm in event of an alarm
(see page 12-13)
Alarm is caused
rite SMS instruction and send to Mobi-Click Compact:
Mobi-Click calls you back
automatically
If you pick up you can
listen quietly in the room
Alarm standby is
switched off
or
Home
Baby
Auto
All
...
A Mobi-Click alarm message has always to be
taken serious! Keep cool in any case and consider
your next steps exactly:
hich persons were be alarmed?
Control: send instruction "Test SMS" to
Mobi-Click.
If you were alarmed per SMS:
Send the instruction "Hear" to Mobi-Click.
Mobi-Click calls you back quietly immediately.
If you were called:
Do not hang up! Now you can listen in the
monitored room/place quietly. After about 2
minutes the connection will be disconnected
by Mobi-Click, but before it will be hanged
up, you will hear peep tone twice (so you
know you were connected to Mobi-Click).
If the alarm standby is not switched off then
there will be sent a new alarm message after
5 minutes if necessary.
(example of an alarm SMS)



Reset ...
Do you want to be called if
there is an alarm?
By switching on the alarm
standby add the word "Call" to
the instruction.
Example:
Set baby (normal)
Confirmation and alarm message
per SMS.
Set baby call
Confirmation of Set Baby will be
received by a call on your mobile
phone. In the event of an alarm
there will be a call or SMS to your
mobile phone depending on your
saved settings.
Activate Compact as alarm system On your own mobile phone
SMS
alarm message
Hear

You receive a short
message (SMS)
on your mobile phone:

Keep cool!

Alarm messa es
How will I be informed per SMS in case of an alarm?
20 21
In case of an alarm Mobi-Click Compact can call
3 alarm numbers altogether and therefore send
up to three different persons a SMS or make a
phone call to them. (see also information by e-
mail, page 37).
If the alarm message
should be sent per SMS:
If the alarm message
should be made per call:
Send SMS to Mobi-Click
Compact
Set SMS1 +4179123… Number of the 1st receiver
rite an SMS instruction:
e.g.:
Set SMS2 00417911… Number of the 2nd receiver
Set SMS3 +4152765… Number of the 3rd receiver
e.g.:
Next number:
(repeat process)
e.g.:
rite SMS instruction:
e.g.:
(will be informed per SMS) (will be informed per telephone call)
Set TEL1 +4179123... Number of the 1st receiver
Examples:
You want to monitor a holiday house. In case of
an alarm Mobi-Click should
send 1 SMS to your mobile phone (after it 3
min. pause)
send 1 SMS to the mobile phone of your wife
(after it 3 min. pause)
make 1 call to a fix net number (max. call
length 3 min.)
The notify process can be interrupted only by
pressing any button on Mobi-Click Compact.
The settin looks like:
Set SMS1 [phone]
(Your personal mobile phone number)
Set SMS2 0041791112233
(Mobile phone number of your wife)
Set TEL3 [phone]
(Number of your fix net telephone)
For professionals:
Test SMS
You receive a short message with a list
of all alarm numbers.
control:
e.g. Reset SMS2 (leave empty)
Number 2 will be deactivated.
switch off:
e.g. Set SMS2 (leave empty)
The old number 2 will be reactivated.
restart:
Reset SMS (leave empty)
All numbers (SMS/TEL) switched off
except number 1.
switch off all:
e.g. Set SMS2 004179555…
Old number 2 will be overwritten.
chan e:
Alarm number…
(Send all instructions from your mobile
phone to Mobi-Click Compact):





Triple security!
On your own mobile phone
SMS only in alarm mode!
You can save 3 numbers altogether with
Mobi-Click Compact.
If you use Mobi-Click Compact as a mobile phone you can
dial these three numbers directly with the three coloured
buttons.
The same numbers are used to make an alarm call or to
send a SMS (message) like described here, if alarm standby
is activated.

Set Auto
Mobi-Click for the car
22 23
Activate the alarm system
BLUE
Press the two
buttons when
switching on until
you hear a signal
tone!
Activate alarm standby (auto)
RED
Press red button for about 3 seconds. Countdown
starts (peep... peep...). You have 15 seconds to
leave your car. To turn off: press red button
within 15 seconds.
Start
Activate the alarm system as described above. Mobi-Click Compact is now ready. To activate car monitoring function press
the red button. Now the countdown starts automatically (peep…peep…). Quickly hide Mobi-Click Compact in your car and
leave. After 15 seconds Mobi-Click is ready.
The alarm function can also be activated from another mobile phone: just send the following SMS-command to Mobi-Click
Compact "set auto".
Switch off Mobi-Click Compact:
- hen you enter your vehicle you can switch off your Mobi-Click Compact by pressing the red button.
Remember: you only have 15 seconds time, before the alarm starts!
( hen the alarm is turned off, you hear a triple tone.)
- Or:
send the following SMS-instruction from you mobile phone to Mobi-Click Compact: "reset auto".
The monitoring will be switched off.
ON/OFF
+
ith Mobi-Click Compact you protect your vehicle (car, machine, motorbike, etc.)
reliably and without any problems against thieves and burglars.
The Vibration-sensor reacts on smallest vibrations (shut the car door, drag s.o.
off, etc.) and causes an alarm message immediately per SMS or phone call to up to
3 pre-programmed numbers.
In case of a vehicle theft there will appear constantly the appropriate location
messa e (GSM zone code) on your own mobile phone display where the vehicle is
located at the moment. Mobile phone operators and the police are able to locate
your vehicle because of this information.
To install Mobi-Click is not as expensive as to install an alarm device in a car repair
shop: just hide it in your vehicle (e.g. in the glove compartment, in the trunk or also
under the seat).
Vehicle theft
Right placement

Activate the alarm system
BLUE
Press the two
buttons when
switching on until
you hear a signal
tone!
Activate alarm standby (home)
GREEN
Press green button for about 3 seconds.
Countdown starts (peep... peep...). You have 15
seconds to leave the room. To turn off: press
green button within 15 seconds.
Start
Activate the alarm system as described above. Mobi-Click Compact is now ready. To activate the alarm function in home-
mode press the green button. Now the countdown starts automatically (peep…peep…). Quickly hide Mobi-Click Compact
in the room and leave. After 15 seconds Mobi-Click is ready.
The alarm function can also be activated from another mobile phone: just send the following SMS-command to Mobi-Click
Compact "set home".
Switch off Mobi-Click Compact:
- hen you enter the room you can switch off your Mobi-Click Compact by pressing the green button.
Remember: You only have 15 seconds time, before the alarm starts!
( hen the alarm is turned off, you hear a triple tone.)
- Or:
send the following SMS-instruction from you mobile phone to Mobi-Click Compact: "reset home".
The monitoring will be switched off.
ON/OFF
+
Set Home
Mobi-Click at home
24 25
ith Mobi-Click Compact you can monitor your flat, your house or office reliably: The
Motion-sensor registers persons which move within a distance of 5 meters. If a
stranger enters the room, an alarm will be caused immediately quietly.
You chose who will be informed per SMS or call if there is a break-in. Now you can
listen undetected in the room and make the necessary steps.
Ranges of application: flat, house, holiday house/flat, boat, camper, office, repair
shop, atelier, shop, restaurant, garage, petrol station, etc.
The Mobi-Click has a monitoring radius of approx. 5 meters with a angle of approx.
80°. To ensure best coverage for monitoring, place the Mobi-Click Compact in a
corner.
Do not face the Mobi-Click at a window as movement outside the window can cause a
false alarm. Best placement in the corner of a room (away from window) facing to
the door.
ATTENTION!
In order to ensure the most effective monitoring possible over the greatest area,
position the Mobi Click Compact in a place that allows common access to all rooms.
(e.g. Hallway, stairway etc.)
Burglary
Right placement

Activate the alarm system
BLUE
Press the two
buttons when
switching on until
you hear a signal
tone!
Activate alarm standby (baby)
BLUE
Press blue button for about 3 seconds.
Countdown starts (peep... peep...). You have 15
seconds to leave the room. To turn off: press
blue button within 15 seconds.
Start
Activate the alarm system as described above. Mobi-Click Compact is now ready. To activate the alarm function as
babyphone press the blue button. Now the countdown starts automatically (peep…peep…). Quickly hide Mobi-Click
Compact in the child’s room and leave. After 15 seconds Mobi-Click is ready. (The baby should be sleeping this time!)
The Mobi-Click baby sensor is set to MID as default. This can be adjusted by setting the sensitivity to LO , MID or HIGH
when you send the Set Baby command.
The baby phone alarm function can also be activated from another mobile phone: just send the following SMS-command
to Mobi-Click Compact "set baby".
Switch off Mobi-Click Compact:
- hen you enter your child's room you can switch off your Mobi-Click Compact by pressing the blue button.
Remember: You only have 15 seconds time, before the alarm starts!
( hen the alarm is turned off, you hear a triple tone.)
- Or:
send the following SMS-instruction from you mobile phone to Mobi-Click Compact: "reset baby".
The monitoring will be switched off.
ON/OFF
+
Set Baby
Mobi-Click in the child's room
26 27
Mobi-Click Compact reacts because of the integrated acoustic-sensor/
microphone not only when your child is crying, but also when it climbs out of bed
silently (motion-sensor). You can listen quietly in the child’s room at every time
just to make sure everything is alright.
Range of application: at home, with relatives and friends, especially on holidays in
hotel rooms, camping, etc.
The best is you test the acoustic-sensor by starting the Mobi-Click in test mode
(see page 11)
Parents often leave the child’s room while the child is still awake. For avoiding wrong
alarms, switch on Mobi-Click Compact not until your child is silent or send the
instruction "set baby call" from your mobile phone to Mobi-Click. Mobi-Click will be
switched on and calls you back immediately for confirmation. ith the instruction
"hear" you can also listen in your child’s room later (see on p. 32).
Put the Mobi-Click in the direction of the child’s bed or the door of the room. If the
child is climbing out of bed the alarm will be caused immediately.
Important: The acoustic-sensor/microphone is set as it reacts not until the child is
really awake and makes sounds 3 times within 30 seconds. (e.g. coughing only one
time does not cause an alarm). The best is you test it. ("Test baby"). To increase
sensitivity generally: "set baby hi h".
Baby phone
Right time / placement

29
Set ...
How do I choose the ri ht alarm instruction?
Low/Mid/Hi h
Can I chan e the sensitivity of the sensors?
28
Set Auto
Set Home
Set Baby
Set Vibra
Set Area
Set Move
Set Voice
Set All
Protect your vehicle (car, machine, motorbike etc.) reliably against thieves or
burglars! Vibration-sensor and locatin are activated.
Protect your home (flat, house, holiday house, bureau, etc.) reliably against
burglary or unauthorized entering! Motion-sensor is activated.
The ideal Baby phone! Reacts not only when your child cries but also when it climbs
out of bed! Motion-sensor and acoustic-sensor are activated.
Vibration-sensor: Reacts on smallest vibrations and is suitable for monitoring of
vehicles of each kind.
Locatin : For protecting individuals and localizing children and elder people but
also for transporting values or demonstration-cars etc.
Motion-sensor (PIR): Registers every move within a distance of about 5 meters.
Put your Mobi-Click with the sensor in direction of the corridor or the door but never
in direction of the window.
Acoustic-sensor (microphone): The hyper-sensitive microphone reacts on voices
or sounds in the monitored room.
All sensors are activated at the same time.
A combination of the sensors is also possible, e. . "set vibra move".
Set sensors directly
Choose the right situation
Low
Mid
Hi h
Action:
e.g.:
Instruction Sensor Sensitivity
Set Vibra mid
Set Voice Move hi h
vibration sensor: mid sensitivity
acoustic and motion sensor: high sensitivity
Set All low all sensors: low sensitivity
All integrated sensors of Mobi-Click are set in the factory optimal for the appropriate monitoring
situation. The sensitivity can be adjusted with a simple instruction and so can be set to be more
or less sensitive.
Choose a sensor and complete this sensor with a further instruction which influence the
sensitivity:
In set baby you can adjust the sensitivity as required:
Set baby hi h

3130
Test
Whether everythin is set correctly? Test!
List of saved
SMS and telephone
numbers.
31.03.2004 10:11
MOBI-CLICK
Alarm 1 = SMS
0049222333444
Alarm 2 = TEL
0049333444555
Alarm 3 = off
[phone]
Test SMS
System and mobile
phone values.
31.03.2004 10:11
COMPACT 42
Battery : 5
Signal : 5
Zone : 2C57
PIN : 1234
AREA: : off
VIBRA : off mid
MOVE : on high
VOICE : on low
Test Status
Practice alarm.
Mobi-Click informs
all saved numbers
per SMS or call.
31.03.2004 10:11
HOLIDAY HOUSE
Message: An alarm
was released!
AREA : off
VIBRA : off mid
MOVE : ALARM low
VOICE : ALARM high
Test Alarm
Mobi-Click calls all
saved alarm
numbers with "Tel
1-3" in succession.
To save costs: do
not pick up the
phone.
Test Tel
31.03.2004 10:11
COMPACT 42
Tel1 = SMS
[phone]
Tel2 = call
0041791112233
Tel3 = off
[phone]
Status messa e
31.03.2004 10:11
COMPACT 42
Battery : 5
Signal : 5
Zone : 2C57
PIN : 1234
AREA: : off
VIBRA : off mid
MOVE : on high
VOICE : on low
SMS and telephone alarm numbers
Date / time
Name and software version
Information per SMS
Telephone number 1
Information per call
Telephone number 2
Informed. Switched off
Telephone number 3
Date / time
Name and software version
Battery strength (0...5)
Signal strength (0...5)
Actual location (GSM zone)
4-digit PIN-Code (or "off")
Sensors
Alarm status (on /off)
sensitivity (low/mid/high)
31.03.2004 10:11
HOLIDAY HOUSE
Command:
SET NAME
HOLIDAY HOUSE
Messa e:
Command OK
> End of Report
Confirmation of the instruction:
Date / time
chan ed name
"Echo" of the sent instruction
(control for the sender)
Messa e: instruction received
& operated correctly
End of the report
Problem messa e:
31.03.2004 10:11
HOLYDAY HOUSE
Messa e:
BATTERY LOW
AREA : off
VIBRA : off mid
MOVE : ALARM low
VOICE : ALARM low
Date / time
changed name
Messa e:
Battery/Accumulator low
Control for the receiver if all
sensors are still working
regularly and have the right
status despite low battery
voltage
What is the meanin of the SMS messa es?
31.03.2004 10:11
COMPACT 42
Tel1 = SMS
[phone]
Tel2 = call
0041791112233
Tel3 = off
[phone]

32 33
The instruction "Hear Tel2" or "Hear Tel3" is useful if, for example, your fix net telephone does not have the
possibility of writing a SMS but you want to be called back on the fix net nevertheless.
Protection of the private sphere is in the constitution of
many countries. It should not and is not allowed to abuse
Mobi-Click for unauthorized monitorin purposes!
e.g.
Instruction Add-on
Hear
Hear Tel2 Mobi-Click calls back the pre-programmed telephone alarm number 2
Hear Tel3 Mobi-Click calls back the pre-programmed telephone alarm number 3
The instruction "Hear" causes a soundless call from Mobi-Click to you after
you have received your SMS. Now you can listen in the room or place
without being detected. This is useful if you, for example, use Mobi-Click as
a baby phone and you want to control if everything is OK.
Hear
Eavesdrop in? Yes, but pay attention...!
ith this function Mobi-Click can be protected against outside access. The PIN-code consists of the word "PIN" and a code.
The code is always 4-digit and cannot contain any signs, but just digits (e.g. "1234").
IMPORTANT:
If you have saved your own Mobi-Click text responses, then all instructions which you transmit to Mobi-Click must have the
same text and PIN-code at the end, e.g. "set auto pin 1234". ithout the code the instruction will not be fulfilled. If you
forgot to attach the PIN-code or attached a false PIN, you get a message with "Access denied!". (To save costs, Mobi-Click
sends you this message only once).
Action Instruction
Set code
Designation
1234
Description
write and save PIN-code
Reset code pin 1234 switch off PIN-code temporarily
Set Code / PIN
PIN-Code – How to protect a ainst outside access?
ATTENTION!
Lost PIN-Code? hat to do?
It is possible to do a general reset to factory default settings when you start the Mobi-Click Compact in alarm mode
(see page 11). This will also reset the PIN-Code.
After switching to alarm mode, you will hear 5 peeps, after which you must press and hold the blue button until you hear a
triple tone. Afterwards all settings, including the PIN-Code will be reset to factory default settings.
Action
Mobi-Click calls your mobile phone back

34 35
Set Name / Text
Can I write personal alarm messa es?
Personal texts are used to describe an alarm which had happen more exactly, especially if the alarm message goes
to a third person or if there are several Mobi-Click devices in order.
Set name Maserati rite / save new name (max. 10 signs)
Reset name Name will be deleted (Mobi-Click is called "Mobi-Click")
Set name Maserati Mobi-Click is now called "Maserati"
Reset name Mobi-Click is called "Mobi-Click" again.
Set alarm text Baby phone Nathalie System alarm is called "Baby phone Nathalie" now.
Reset alarm Alarm message is called "system alarm" again.
Set alarm text Babyphone Nathalie (example, max. 21 signs)
Change name of Mobi-Click:
e.g.:
Change name of system alarm:
Reset alarm text
Individual alarm messages: Individual alarm texts:
For every sensor can be assigned a personal text which is allowed to consist of 21 signs.
See the following samples:
Set voice text Baby is cryin !
Set move text Bur lar in the house!
Set vibra text Alfa Romeo stolen!
Set area text Left way to school!
Set voice text Baby is cryin ! hen acoustic sensor / microphone is activated there will be
the alarm message: "Baby is crying!"
Set area text left way to school! hen e.g.your child leaves the way to school you get a
message "left way to school!"
Reset all text No individual messages.
Reset vibra text (example for reset text) e.g.
Reset all text (example for reset all text)
Text returns to factory default
+
BLUE ON/OFF
Reset System:
Keep the two buttons pressed, than you hear 5 times a peep. Stop pressing the ON/OFF-button, you can
hear a triple tone. Keep pressing the blue button, till the yellow LED lights.
Set name Maserati rite / save new name (max. 10 signs)
Reset name Name will be deleted (Mobi-Click is called "Mobi-Click")
Set alarm text Babyphone Nathalie (example, max. 21 signs)
Reset alarm text Text returns to factory default

Test Text
How can I test if the text is correct?
As per page 35 different SMS text can be assigned to different sensors. In order to test please follow
he instructions below:
Send one of the following SMS to Mobi-Click to test the associated sensor:
36
Set E-mail
Individual SMS-instructions
37
How can I use the notification by e-mail?
Action
Set Email aaa
DescriptionInstruction
Save e-mail address (aaa = address, till 23 signs)
Reset Email Notification by e-mail deactivated
Set SMS *bbb Notification by e-mail activated (*bbb = SC-number, till 8 signs)
You can also receive notification by e-mail. In addition you need an e-mail receiver to be informed in the case of
emergency. This is useful if, for example, your daughter is to be informed, however she is in the office all day so a
message is more suitable by e-mail, since she may not use her mobile phone during the day, or does not have her
own one.
This instruction can be deactivated simply with the instruction "Reset Email". In order to determine whether the e-mail
address of the receiver was stored correctly, you send the instruction "Test Text" to Mobi-Click, and you receive a reply,
in which the stored e-mail address is indicated.
You can change this e-mail address also at any time, by again sending a SMS with the instruction "Set Email aaa" and
"Set SMS *bbb" to Mobi-Click Compact. The old stored e-mail address is automatically overwritten.
Attention: The asterisk before the service centre number (SC number) must be always set!
You can get the service centre number from your provider.
Test Text Acknowledgement to the indicated e-mail address
Instruction Action
Test
Test Text The alarm SMS text reply and the e-mail address will be sent.
Test Text1
Text2
Text3
The alarm SMS text reply will be sent.
The area and the vibra SMS text reply will be sent.
The move and the voice SMS text reply will be sent.
Test
Text

Alarm display
Because the contact itself does not own a sole-alarm-display, an identification is given as follows: if the alarm report is given by
SMS or e-mail, then a release of the contact can be determined because even though there was an alarm reported, the sensors
had no sole release.
Sole Monitoring
ith the command SET ALARM Mobi-Click will not only put into the "security-mode". hen a contact is connected it will be
focused automatically. Because all the other sensors will not be activated with this command, solely this contact will be monitored.
Monitoring together with other sensors
hen one of the sensors is switched on, then this contact will be monitored automatically as well
(e.g. SET HOME, SET VIBRA etc.).
Function/Software
The interface of Compact is normally served for the data-communication to and from external system-components. The logical
standby level is in this case LO . If there is a connection, then this stand-by level will logically be pulled up to HIGH. Therewith
Mobi-Click Compact recognises with the next set function (SET XXX) or with the next mode shift (SET ALARM) a standby power
connection and it will begin to monitoring this additional sensor automatically. It is also important to make the connection before
activating the Mobi-Click device via SMS or buttons.
38 39
Set Zone / Area
Security zone and localization of persons or objects
ith Mobi-Click you can define protection zones, e.g. your child’s way to school. If the child leaves this area (e.g.
because it enters a stranger's car) you will be warned immediately per SMS and you can monitor the situation if
necessary.
Set Zone
Set Area Switch on locating monitoring
Set Auto Switch on vehicle monitoring with locating monitoring.
On the way with the car:
It is possible that not all GSM cells can be detected immediately during the security zones learning process
(especially when driving the children's path to school). Some cells may be working to capacity and therefore
they can not be registered by Mobi-Click. That is why it is advisable for urban areas to cross a security zone
slowly or more than once if possible, this allows for every possible GSM cell to be registered by Mobi-Click.
(Security zones can be tested with "Test Area".)
Activate locating
Define security zone
Set Alarm
How can I connect extern devices?
Learning mode is activated. Mobi-Click gives a short peep every 20 seconds. hen finding a new unknown GSM
zone the dual tone signal is heard. Interrupt learning mode: when Mobi-Click is switched off previously learnt
zones remain saved. Reactivate learning mode: "set zone". Mobi-Click can store a maximum of 48 zones. hen
this number is exceeded there will be an error tone (peep) and the LED lights continuously. Zones will remain
saved. Stop learning mode: Switch off Mobi-Click. "Reset zone": Security zones will be deleted.
Mobi-Click can be connected to an external contact. This contact generates an alarm report to the programmed target call number
in the programmed communication forms (SMS, call, e-mail).
Important: Switch your Mobi-Click Compact only on/off when the contact is not connected yet. Else, it can be possible that the
connected hardware will not be interpreted rightly and/or the switching on/off function will not function in proper form.
