Modena Preciso Series Owner's manual

User
Manual Book
Vacuum Cleaner
Preciso Series
VC 2025, VC 2125
Latore Series
VC 2071 S, VC 3071 S
Nettare Series
VC 3143

1
Thank you for your trust in choosing MODENA products for your household
needs. With your satisfaction as our priority, we constantly aim to deliver stylishly
designed products equipped with state-of-the-art technology to assist you in
your daily activities.
This is your guidebook containing everything you need to know about our
product. Please reach out to us if you need further assistance or other
information via our Customer Care or our official website www.modena.com.

2
CONTENTS PAGE.
• Introduction 1
• Part 1 : Name of Parts 3
•Part 2 : Installation 5
• Part 3 : How to Use 8
• Part 4 : Maintenance 9
• Part 5 : Precaution Action 10
• Part 6 : Problem & Solution 11
• Part 7 : Specification 12

3
VC 3071 S & VC 2071 S
VC 3143
Part 1: Name of Parts
Handle
Switch
Blowing Door
Suction Inlet
Top Cover
Supply Cord
Power Plug
Look Button
Dust Barrel
Handle
Hose
Tool Cover
Pipe
Floor Brush
Hose Connector
Dustbin
Dust Indicator
Power Switch
Cable rewind button
Speed Controller

4
VC 2125
VC 2025
Handle
Hose
Floor Brush
Pipe
Wind-force
adjuster
Hose
Connector
Power Switch
Cable
Rewind
Button
Dust
Indicator
Dustbin
Speed
Control
Handle
Hose
Floor Brush
Pipe
Wind-force
adjuster
Hose Connector
Dustbin
Power Switch
Cable Rewind Button
Dust Indicator

5
NOZZLE:
1.Floor /Carpet
2. Gap
3. Small brush
-Extend / deploy the
brush to clean the
hard floor surface.
-Pull /retract the
brush to clean
the carpet.
-Used for radiator,
gap, corner and gap
between the sofa
cushions.
-Used to clean the
curtain, books, shelf,
lamp shade and other
similar objects.
* Features depend on the type of product.
Important:
1. Read this manual thoroughly before starting operations.
2. Check whether the voltage specified on the unit fits with the one in your house. If not contact
MODENA Call Center for further inquiries.
3. Unit must be connected with a properly grounded 10A electrical outlet.
4. Always unplug the power cord before installing / detaching accessories, disassembling the unit,
when the unit is not to be used for a long time, or before cleaning and repairing.
5. Do not use solvent substances (methylated spirits) to clean the unit
6. Do not use the unit on wet surface.
7. When the unit is activated, do not leave it without supervision. Make sure to keep it away from
children or incompetent people.
8. The unit is meant for house hold usage. Use it according to the instructions provided in the manual.
9. Do not activate the unit if the unit is damaged.
10. Contact the dealer or call center for repairs and after sales service.
11. If the power cord is damaged, contact MODENA call center for replacement.
12. This unit is not meant to be used by children, mentally or physically challenged, or those who lack
the experience and knowledge regarding the unit. For safety precautions, provide serious
instructions and guidance when they attempt to do operations.
13. Keep the unit away from children’s reach.
14. If you wish to unplug the power cord from the socket, pull the plug, not the cord. If the power cord
is damaged, both cord and the plug must be repaired by a qualified technician.
15. If the dust indicator light turns red, immediately replace or clean the dust container.
16. Replace or clean the dust container on a regular basis to prolong the product’s age.
17. Make sure the front cover is always attached.
Part 2: Installation

6
CONNECTING THE VACUUM CLEANER
Remove flexible pipe
Remove the cord plug from the socket before releasing the flexible
pipe from the air inlet.
VC 3071 S & VC 2071 S
Push and rotate the flexible tube towards the lock position to insert
the hose.
Pull and rotate the flexible tube towards open to remove.
VC 3143, VC 2125, VC 2025
Press the button at the end of the flexible pipe and pull it to release.
Installing and connecting additional pipes and accessories
-Install additional pipes on
the handle.
-Connect additional
pipes.
-Install accessories to the
additional pipe.
Emptying and replacing the dust bag
VC 3071 S & VC 2071 S
1. Release the lock and lift the top cover.
2. Take out the whole top cover including the filter bag.
Filter Bag

7
3. Remove the filter bag and clean the dust in the barrel
4. Put the bag and the top cover back to its place.
VC3143, VC2125, VC2025
After removing the flexible pipe, open the cover by pressing the lock button and pull it upwards. Remove
the dust bag.
VC 3143
1. Open the front cover by pressing the button and pulling it upwards.
2. Clean the dust bag and reinstall it to the unit.
VC 2125
1. Open the front cover by pressing the button and pulling it upwards.
2. Clean the dust bag and reinstall it to the unit.
VC 2025
1. Open the front cover by pressing the button and pulling it upwards.
2. Clean the dust bag and reinstall it to the unit.
a. Type of cloth dust

8
1. Cloth
To remove the dust from the cloth dust bag, remove the pins
on the bottom of the bag to release the dirt inside the bag,
clean the bag and pin the bottom part again.
2. Paper
If you use a dust bag made from paper, throw away the bag
after usage.
1. Before usage, pull / detangle the power cord as necessary and connect the power cord head
to the socket. Red represents the maximum efficient length of cord. Do not pull the cord beyond
the red mark. To roll the power cord, press the cord roller button with one hand and detangle
the cord with one other hand.
2. Press the On/Off button to activate / turn on the unit. Set the vacuum power to MIN before
activating the unit.
3. The vacuum power can be adjusted according to the needs by turning the vacuum power
button.
4. Nozzle brush usage.
-Floor/Carpet
Extend / release the brush to clean the hard floor surface.
Retract / pull the brush to clean the carpet.
-Small brush
Used to clean the dust on the curtain, book, shelf, lampshade and other objects.
-Gap
Part 3: How to Use

9
Used to clean the gap, corner, radiator and the gap between the sofas.
5. When it`s used to suck water,please take out the filter bag.
For Model: VC 2071 S & VC 3071 S
6. After usage, turn off the vacuum cleaner by pressing the ON/OFF and reroll the power cord.
7. For certain models, do not move the vacuum cleaner when the cleaning pipe is not hooked
perpendicularly to the hole / hook on the unit. This may cause the floor to get scratched from the
brush nozzle.
.
Always remove the plug from the socket before performing maintenance on the vacuum cleaner.
1. Clean the unit using dry cloth. Do not use shining powder, detergent, gasoline, acid, thinner, oil or
hot water to clean any part of the unit.
2. Remove the inlet and outlet air filter, clean the filter by submerging it in warm water, and dry it inside
out. After it’s dried, reinstall it to the vacuum.
If the unit is not going to be used for a long time, store it in a dry place with good circulation. Keep away
from children.
DISPOSAL
Environmental Preservation
Electronic waste should not be disposed of with household waste. Dispose
property at an electronic dump site. Ask for advice from the retailer or the local
authorities on how to perform proper disposal and recycle.
Part 4: Maintenance
−Make sure the filter is dry when reinstalled on the vacuum cleaner.
−Make sure it is placed in its proper place.
−
−

10
Perform the following preventive measures before operating the vacuum cleaner:
−Read all instructions thoroughly and pay attention to the pictures before operating the vacuum
cleaners.
−Check the voltage specifications on the vacuum cleaner whether it matches with the voltage in
your house. If it doesn’t match, contact the MODENA Call Center for further information.
−Do not leave the vacuum cleaner while it is still connected to the socket. Always unplug the
power cord from the socket if the vacuum cleaner is not used.
−To avoid electric shock, do not use the vacuum cleaner outside the house or out in the open
area and do not put or submerge the power cord or plug in the water or liquid substance.
−Tight supervision is required if vacuum cleaner is used around the children.
−Do not operate the vacuum cleaner if the power cord or the plug is damaged, dysfunctional,
taking fall damage, or broken. Take it to our Call Center for inspection & testing, rearrangement
of electrical or mechanical functions, and necessary repairs.
−Usage of additional equipment/tools without recommendations and not supplied by the
manufacture may result in fire, electric shock / shortage and damage to the vacuum cleaner.
−Special attention is required for usage on stairs.
−If the air inlet, pipe nozzle or telescopic pipe is obstructed, immediately deactivate the vacuum
cleaner and clear the obstruction before restarting it.
−Make sure you plug the power cord to the socket with dry hands.
−Remove large or sharp objects on the floor before using the vacuum cleaner to avoid damages
to the filter.
−If you wish to unplug the power cord from the socket, pull the plug, not the cord. The damaged
cord and plug must be repaired by a qualified technician.
Do not operate vacuum
cleaner near heat sources
such as stove, cigarette buds,
etc.
Do not use the unit on top of
the power cord. Make sure the
power cord is not pinned or
stepped on when the unit is
operating.
Do not use the unit to vacuum /
clean lighted match, lighted
cigarette or hot dust.
Do not use the unit on wet
surface.
Do not obstruct the air inlet or the
drainage.
Do not use the unit to
vacuum / clean threads,
sharp objects, nails, pins,
etc.
Part 5: Precaution Action

11
In the event of operational issues, check the following problems and solutions below before contacting
our Call Center:
Problem
Cause
Solution
Weak Suction Power
-Dust bag and the cylindrical
filter are obstructed.
-Brush or nozzle are
obstructed.
-Flexible pipe is obstructed.
-Replace or clean the dust bag
and the cylindrical filter.
-Clean the brush and nozzle
from dust.
-Clean the flexible pipe
The motor cannot rotate /
vacuum
-Is the cord plugged to the
socket?
-Has the ON button been
pressed yet?
-Reconnect the power cord
with the socket.
-Press the ON Button
Part 6: Problem & Solution

12
VACUUM CLEANER
VC 3071 S
VC 2071 S
VC 3143
Type
Wet & Dry
Wet & Dry
Dry
Color
Stainless
Stainless
Blue
Nozzle material
Fiber
Fiber
Fiber
Main Feature
Blower function
Yes
Yes
No
Cloth filter
Yes
Yes
Yes
Cloth paper
No
No
No
Filter for motor / cylinder
Yes
Yes
Yes
Filter for blower
Yes
Yes
No
Overload safety / Motor
Yes
Yes
Yes
Wheel
Yes
Yes
Yes
Suction controller
No
No
Yes
Accessoris
Nozzles
3
3
3
Flexible hose
1
1
1
Pipe
1
1
1
Exhaust filter
1
1
1
Technical Features
Capacity (liter)
30
20
4
Cable length (meter)
4.5
4.5
4.5
Noise level (dbA)
< 83
< 81
< 78
Suction power (kPa)
21
21
26
Power Consumption (watt)
1200
1000
1200
Product Dimension
Depth(mm)
390
390
471
Width(mm)
370
370
316
Height (mm)
632
497
250
Gross Weight (Kg)
7.7
7.3
5.8
Part 7: Specification

13
VACUUM CLEANER
VC 2125
VC 2025
Type
Dry(cyclone)
Dry(cyclone)
Color
Red
Blue
Nozzle material
Fiber
Fiber
Main Feature
Blower function
No
No
Cloth filter
No
No
Cloth paper
No
No
Filter for motor / cylinder
Yes
Yes
Filter for blower
No
No
Overload safety / Motor
Yes
Yes
Wheel
Yes
Yes
Suction controller
Yes
Yes
Accessoris
Nozzles
3
3
Flexible hose
1
1
Pipe
1
1
Exhaust filter
1
1
Technical Features
Capacity (liter)
2
2
Cable length (meter)
4.5
4.5
Noise level (dbA)
< 82
< 82
Suction power (kPa)
23
23
Power Consumption (watt)
1200
1200
Product Dimension
Depth(mm)
408
383
Width(mm)
295
285
Height (mm)
270
275
Gross Weight (Kg)
5.1
5.1
S = Stainless W = White V = Silver G = Grey L = Black Y = Yellow U= Blue N = Green
Design and specifications are subject to change at any time without prior notice.

11/20
