Modena Puro Series Owner's manual

User
Manual Book
Vacuum Cleaner
Puro Series
VC 1518 Y

1
Thank you for your trust in choosing MODENA products for your household needs. With
your satisfaction as our priority, we constantly aim to deliver stylishly designed products
equipped with state-of-the-art technology to assist you in your daily activities.
This is your guidebook containing everything you need to know about our product.
Please reach out to us if you need further assistance or other information via our
Customer Care or our official website www.modena.com.

2
CONTENTS PAGE.
• Introduction 1
• Part 1 : Name of Parts 3
•Part 2 : Installation 4
• Part 3 : How to Use 5
• Part 4 : Maintenance 7
• Part 5 : Precaution Action 8
• Part 6 : Problem & Solution 8
• Part 7 : Specification 9

3
VC 1518 Y
NOZZLE:
1. Floor
2. Gap
3. Small brush
-Extend / deploy the
brush to clean the
hard floor surface.
-Pull /retract the
brush to clean
the carpet.
-Used for radiator,
gap, corner and gap
between the sofa
cushions.
-Used to clean the
curtain, books, shelf,
lamp shade and other
similar objects.
Part 1: Name of Parts

4
Important:
1. Read this manual thoroughly before starting the operations.
2. Check whether the voltage specified on the unit fits with the one in your house. If not, contact the
MODENA Call Center for further inquiries.
3. The unit must be connected with a properly grounded 10A electrical outlet.
4. Always unplug the power cord before installing/detaching accessories, disassembling the unit,
when the unit is not to be used for a long time, or before cleaning and repairing.
5. Do not use solvent substances (methylated spirits) to clean the unit
6. Do not use the unit on wet surface.
7. When the unit is activated, do not leave it without supervision. Make sure to keep it away from
children or incompetent people.
8. The unit is meant for household usage. Use it according to the instructions provided in
the manual.
9. Do not activate the unit if the unit is damaged.
10. Contact the dealer or call center for repairs and aftersales service.
11. If the power cord is damaged, contact MODENA call center for replacement.
12. This unit is not meant to be used by children, mentally or physically challenged, or those who lack
the experience and knowledge regarding the unit. For safety precautions, provide serious
instructions and guidance when they attempt to do operations.
13. Keep the unit away from children’s reach.
14. If you wish to unplug the power cord from the socket, pull the plug, not the cord. If the power cord
is damaged, both cord and the plug must be repaired by a qualified technician.
15. Clean the filter on a regular basis to prolong the product’s age.
CONNECTING THE VACUUM CLEANER
Remove flexible pipe
Remove the plug from the socket before releasing the flexible pipe
from the air inlet. Press both button at the end of the flexible pipe and
pull to release it.
Installing and connecting additional pipes and accessories
-Installing additional pipes on
the handle by rotating the metal pipe
-Connecting additional
Pipes by rotating one of the
metal pipes
-Installing accessories to the
additional pipe by rotating the
metal pipe
Part 2: Installation

5
Emptying the dust
After removing the flexible pipe, open the cover by pulling the two locks upward.
VC 1518 Y
1. Hold and lift the filter (upper dust collector) to release the dust collector.
2. Remove the filter from the dust bag
3. Clean the dust bag and reinstall it to the unit.
1. Before usage, pull / detangle the power cord as needed and connect the plug to the wall socket
2. Press the On/Off button to activate or turn on the unit. Set the vacuum power to OFF before
Part 3: How to Use
1
2
3
Position to remove the
dust

6
activating the unit.
3. The vacuum power can be adjusted according to the needs by sliding the vacuum power
button.
4. Nozzle brush usage.
-Floor/Carpet
Extend/release the brush to clean the hard floor surface.
Retract/pull the brush to clean the carpet.
-Small brush
Used to clean the dust on the curtain, book, shelf, lampshade and other objects.
-Gap
Used to clean the gap, corner, radiator and the gap between the sofas.

7
-Wet floor
Used to clean wet floors
5. After usage, turn off the vacuum cleaner by pressing the ON/OFF and roll the power cord.
.
Always remove the plug from the socket before performing maintenance on the vacuum cleaner.
1. Clean the unit using dry cloth. Do not use shining powder, detergent, gasoline, acid, thinner, oil or
hot water to clean any part of the unit.
2. Remove the inlet and outlet air filter, clean the filter by submerging it in warm water, dry it with the
inside part out. After it is dried, reinstall the vacuum.
If the unit is not going to be used for a long time, store it in a dry place with good circulation. Keep it
away from children.
DISPOSAL
Environmental Preservation
Electronic waste should not be disposed of with household waste. Dispose
property at an electronic dump site. Ask for advice from the retailer or the local
authorities on how to perform proper disposal and recycle.
Part 4: Maintenance
Make sure the filter is dry when being reinstalled to the vacuum cleaner.
Make sure it is placed in its proper place.

8
Perform the following preventive measures before operating the vacuum cleaner:
−Read all instructions thoroughly and pay attention to the pictures before operating the vacuum
cleaners.
−Check the voltage specifications on the vacuum cleaner whether it matches with the voltage in your
house. If it doesn’t match, contact the MODENA Call Center for further information.
−Do not leave the vacuum cleaner while it is still connected to the socket. Always unplug the power
cord from the socket if the vacuum cleaner is not used.
−To avoid electric shock, do not use the vacuum cleaner outside the house or out in the open area
and do not put or submerge the power cord or plug in the water or liquid substance.
−Tight supervision is required if vacuum cleaner is used around the children.
−Do not operate the vacuum cleaner if the power cord or the plug is damaged, dysfunctional, taking
fall damage, or broken. Take it to our Call Center for inspection & testing, rearrangement of
electrical or mechanical functions, and necessary repairs.
−Usage of additional equipment/tools without recommendations and not supplied by the manufacture
may result in fire, electric shock / shortage and damage to the vacuum cleaner.
−Special attention is required for usage on stairs.
−If the air inlet, pipe nozzle or telescopic pipe is obstructed, immediately deactivate the vacuum
cleaner and clear the obstruction before restarting it.
−Make sure you plug the power cord to the socket with dry hands.
−Remove large or sharp objects on the floor before using the vacuum cleaner to avoid damages to
the filter.
−If you wish to unplug the power cord from the socket, pull the plug, not the cord. The damaged cord
and plug must be repaired by a qualified technician.
In the event of operational issues, check the following problems and solutions below before contacting
our Call Center:
Problem
Cause
Solution
Weak Suction Power
-Filter are obstructed.
-Brush or nozzle are
obstructed.
-Flexible pipe is obstructed.
-Clean filter.
-Clean the brush and nozzle
from dust.
-Clean the flexible pipe
The motor cannot rotate /
vacuum
-Is the cord plugged to the
socket?
-Has the ON button been
pressed?
-Reconnect the power cord
with the socket.
-Press the ON Button
Part 5: Precaution Action
Part 6: Problem & Solution

9
VACUUM CLEANER
VC 1518 Y
Type
Wet & Dry (mullticyclone)
Color
Yellow
Capacity (liter)
15 liter
Filter :
-Motor
-Multicyclone filter
Yes
Yes
Pipe
-Material
Stainless Steel Tube
Motor safety mechanism
Yes
Nozzle :
-Floor/Carpet
-Wet floor
-Gap
-Dust/Furniture
Yes
Yes
Yes
Yes
Brush nozzle
Plastic
Cord length (meter)
2.3
Wheels
Yes
Noise level (dbA)
≤ 85
Suction power (kPa)
17 Kpa
Voltage (Volt)
220
Electrical frequency (Hz)
50
Power(watt)
1100
Dimension (L x W x H) mm
310 x 350 x 540
Weight (kg)
7.7
S = Stainless W = White V = Silver G = Grey L = Black Y = Yellow U= Blue N = Green
Design and specifications are subject to change at any time without prior notice.
Part 7: Specification
