ModuLaro AIGLE GH202020 User manual

WOODEN GREENHOUSE AIGLE
2,1X4,15X2,59M
24-05-2022

Assembly instruction
Greenhouse Aigle
IMPORTANT !
TOOLS
B
A

Assembly instruction
Greenhouse Aigle
page 1/14
2005 mm.
2005 mm.
2100 mm.
2005 mm.
2005 mm.
pos. 2
pos. 1
pos. 2 pos. 1
pos. 2
pos. 2
40x40x40
4,5 x 80
120x60
4,5 x 80
4,5 x 806
40x40x404
120x602
3,5 x 4040
pos. 3
pos. 3
40x40x40
4,5 x 80
4,5 x 8018
40x40x4018
3,5 x 40108
480 mm
435 mm
435 mm
480 mm

Assembly instruction
Greenhouse Aigle
page 2/14
pos. 4
pos. 4a
pos. 4
pos. 4a
pos. 4b
pos. 4b
pos. 4a
pos. 4
pos. 4b
pos. 4a
pos. 4
pos. 4b
4,5 x 80
fix with 4,5 x 80
fix with
4,5 x 80 52 4,5 x 80
4,5 x 80
15 40 x 40 x 4015 40 x 40 x 4015 40 x 40 x 40
90 x 90 x 40 / 135
4,5 x 80
18
15 40 x 40 x 4015 40 x 40 x 4015 40 x 40 x 40
50 x 50 x 40
9
3,5 x 40
144
9
pos.5a
pos.5a
pos.5b
angle 50x50x40
screws 3,5x40 - 8 pcs.
angle 90x90x40 135
screws 3,5x40 - 8 pcs.
per connection

Assembly instruction
Greenhouse Aigle
page 3/14
please tape the ends of the
polycarbonate elements before
installation!
TAPE
28 mm.
pos. 5
pos. 5
18 4,5 x 80
18 90x90x40
180 3,5 x 40
4,5 x 80
90x90x40

pos. 7
Assembly instruction
Greenhouse Aigle
page 4/14
pos. 7
view from inside
26 3,5 x 40
pos. 6
pos. 6a
pos. 6b
4,5 x 80
40x40x40
4,5 x 80
84,5 x 80
440x40x40
24 3,5 x 40
pos. 7
pos. 7
pos. 6
pos. 6a
pos. 6b
480 mm
435 mm
480 mm
435 mm

Assembly instruction
Greenhouse Aigle
page 5/14
2 40x40x40
12 3,5 x 40
pos. 8
478 mm
40x40x40
22 mm
4 x 35 special
3+3
pos.11

Assembly instruction
Greenhouse Aigle
page 6/14
2 mm 15 40 x 40 x 4015 40 x 40 x 4015 40 x 40 x 40
4 x 35 special
3+3
40 x 40 x 4040 x 40 x 4040 x 40 x 40
30 3,5 x 50
pos.11
pos.22
15 mm

Assembly instruction
Greenhouse Aigle
page 7/14
22 mm
40 x 40 x 4040 x 40 x 4040 x 40 x 40
12+12 4 x 35 special
40 x 40 x 4040 x 40 x 4040 x 40 x 40
18 4,8 x 28
pos.12
pos.12
pos.12
pos.21
pos.21

Assembly instruction
Greenhouse Aigle
page 8/14
20 mm
20 mm
4,2 x 28
pos. 9
pos. 13
polycarbonate must be mounted on the hinges
15 40 x 40 x 4015 40 x 40 x 4015 40 x 40 x 40
4,2 x 28 special
16
40 x 40 x 4040 x 40 x 4040 x 40 x 40
15+15 3,5 x 50
pos.23
pos.23
pos.23

Assembly instruction
Greenhouse Aigle
page 9/14
206 mm
63,5 x 40
40 x 40 x 4040 x 40 x 4040 x 40 x 40
4 x 3,5 special
pos.14
pos.15
pos.16
pos.9+13

Assembly instruction
Greenhouse Aigle
page 10/14
40 x 40 x 4040 x 40 x 4040 x 40 x 40
pos. 20
20 mm
20 mm
pos. 10
4,2 x 28
84 x 35 special
6 3,5 x 50
4 x 35 special
pos.14
pos.15
pos.18
pos.19
pos.19

Assembly instruction
Greenhouse Aigle
page 11/14
pos.16
pos.17
63,5 x 40
4 x 35 special (pos.16)
7
3,5 x 50 (pos.17)
8
pos.10+20

Assembly instruction
Greenhouse Aigle
page 12/14
pos. 29
ca. 1250
ca. 1250
pos. 27
63,5 x 40

Assembly instruction
Greenhouse Aigle
page 13/14
pos. 25
pos. 25
pos. 28
3,5 x 40
3,5 x 40
63,5 x 40
63,5 x 40

Assembly instruction
Greenhouse Aigle
page 14/14
pos. 24
3 x 30
pos. 26
18 3 x 30

For more information please visit: www.dancovershop.com
