Modulex SL-B9351D User manual


Thefixtureisforindooruseonlyingeneralconditions.
Cannotbeusedfollowingconditions(Causesoffalling,electrocutionandfire)
●Ambienttemperatureunder0℃andover35℃
●Highhumidity
●Outside
●Onthefloor
●Insulatedinsideofceiling
●Vibratedorshockedareas
●Areasgetdirectsunlight
●Inclined,unevensurface
●
Ceilingwhichcanʼtholdthefixtureweight
●Onthewall
●
Placesaffectedbywindorair-conditionermachine
●Nearfire
●
Dustyareas,corrosivegasoutbreaksareas
Before
installation
Forelectric
wiring
Atlighting
fixture
installation
Warning
Warning
Warning
Warning: Failuretoinstallthefixtureproperlycouldresultinpersonalinjury.
Failuretoinstallthefixtureproperlycouldresultinpropertydamage.
:Prohibited
:Strictobservance
Caution:
Caution
Caution
Toinstallthefixturesafely《Readcarefullyandfollowalltheinstructionsintheguide》
Pleasefollowthefixturesʼindicationorspecificationforthedistanceofirradiatedarea.
(Causesofchangeinshape,changeincolorofirradiatedobjects)
Pleasecontactifyouarenotabletojudgewhetherinstallation
environmentissuitabletotheplacesornot.
Onlyqualifiedpersonmayworkonelectricwiringandequipment.(Causeofaccidents)
Besurepowersupplyvoltageiswithin±6%mentionedinratingplateortheguide.(Causesofshortlifeoflamps・electrification・fire)
Besureallthewiresandcodesarenotdamaged.(Causesoffalling・damage)
Pleasefollowthefixturesʼinstructionorthisguidetoinstallthefixtureandlamp.(Causesoffalling・electrification・fire)
Switchoffthepowerwheninstallingthelamp.(Causesofelectrification)
Donottouchthefixturewhenswitchisonorjustturnofftheswitchbecauseofhightemperature.
Donotputorcoverthefixturebyanycloths,papers,orinsulators.(Causesofnotlighting・fire)
Donotplaceanymetallicorflammableobjects.(Causeofelectrification・fire・brokenfixture)
Makesuretoinstallallthepartsoffixturesbesidesinstallationandmountingpartswillnottouchwithany
objectsbothinsideandoutsideofceilingsuchaslightingtrack,etc.(Causesoffalling・electrification・fire)
Donotdismountorremodelfixtures.(Causeofelectrification・fire・falling・brokenfixtures)
Donotoperatewithwethands.
Ifyousmellsmoke,seesmoke,orfindanythingunusual,pleaseturntheswitchoffandaskconstruction
companiestorepair.(Causeofelectrification・fire)
Makesuretheconstructionwillnotaffectanyfirepreventionsystemssuchassprinklerbyheatfromthefixture.
(Causesforimproperoperation)
Usealternatingcurrent.Pleasefollowratingplateoffixturesforpowersupplyfrequency.
(Causeofelectrification・fire)(50Hz・60Hzcommonuseforballastsandincandescentlampfixtures)
SL-B9351D/CE/RB
PICKUPDOWNLIGHT
InstallationGuideLightingFixture
InstallationGuide LightingFixture
Lamp LED
inputvoltage
inputcurrent
38.6V
0.7AMAX
Driver
Soldseparately
kg
Weight
0.50
−BLACK
＋RED Pleaseuseconstantcurrentdriver.
20cm〜 10cm〜
Insulator
InsulatorInsulator
10cm〜

LightingFixture
ToinstallModuleXsafety
JIAKARI
SL-B9351D/CE/RB
InstallationGuide
InstallationDetails InstallationDiagram Caution
Cutoutaholeandinstallthe
mountingframe
Mountingframe
1
Installthemountingequipment
forceilingcutout
Slidethemetalfittingsfromupper
side
Onstep2,pleasefixthemetal
fittingfirmlywithyourfingers.
Ifnot,itmaycausefallingoffixtures
Metalfitting
Ceilingcutout
Useascrewdriverandtightenthe
metalfittings
1
2
2
3
a
a b
b3Standardtoscrew
torque1.0〜2.0N・m
Pushtight
Φ100
Makesuretotightenthemetal
fittingssecurelywithascrewdriver.
(torque1.0〜2.0N・m)Ifitisloose,
itmaycausefallingofthefixture
Ceiling
InstallationDetails InstallationDiagram Caution
Installationtoceiling hi
h
Installthefixturetothemounting
frame.
Installthesafetywiretothe
mountingframe.
Makesuretoinstallthesafetywire
tothemountingframesecurely.
Makesurethefixturewillnottouch
anyobjectsinceiling.
1
2
i
Usecleansoftclothtocleanupand
maintaininnersideofthebody.
Safetywire
Mountingframe
Inside
Cleangloves
1
2
Safetywire
Ceiling
Mountingframe
Wiringconnection
Pleaseconnectaccordingto
thedescriptionofapowersupply.
Wiringdiagram
PE
PE
L
L +
+RED
-BLACK
-
N
N
DC700mA MAX
LED
Driver
38.6V
CAUTION！
Donotreversepolarity！
−BLACK
＋RED
Whenconnectingthedriver,
carefulattentionshouldbe
paidtoconnecting＋and−.
Metalpartinacablepoint,
pleasedon'ttouchwithbare
handdirectly.
5/F,LongbowHouse,14-20ChiswellStreet,London,EC1Y4TW,UK
Tel:[phone]
ConcordLighting
（Contact） （Manufacturer）
ModuleXInc.
#21AraiBldg,1-20-6Ebisu-MinamiShibuya-ku,Tokyo
Tel:[phone]
Theluminaireshouldbepositioned
sothatprolongedstaringintothe
luminaireatadistanceclosedthan
3.8misnotexpected.
