Moduspace MAX140 Plus User manual

Version 3.0
Bespoke Showcase Engineers
MAX140 Plus Assembly Guide

Back Frame
Vertical Bar x 2
Back Frame
Middle Vertical Bar
Back Frame
Horizontal Bar x 2
Front Frame
Vertical Bar x 2
Side Frame
Horizontal Bar x 4
Front Frame Bottom
Horizontal Bar x1
Conduits x 2
Front Frame Top
Horizontal Bar x1
Front Frame Bottom
Horizontal Bar x1
Vertical C-Channel x 4
Horizontal C-Channel x 4
Middle Bottom
Horizontal Bars x 2
BarsMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
1

M5-Long Screw x 44 M5 Washer x 44
M5 T-Handle
Allen Key x 1
Front Panel
Safety Screw x 1
M4 Allen
Key x 1
Foot Pad x 4
M5-Short Screw x 8M4 Stacking Screw x 8
Stacking Bracket x 4
M5 Nuts x 8
Horizontal Bracket x 4
Accessories for connecting display cases
Attention: If you are connecting multiple display cases, please refer to
“Connecting Display Cases” assembly guide before commencing.
Bespoke Showcase Engineers
2
ToolkitMAX140 Plus Assembly Guide

Back Panel x 2
Top Panel x 2 Laminate Base x 1
Plexiglass Side Panel x 2 Plexiglass Front Panel x 1
Bespoke Showcase Engineers
3
PanelsMAX140 Plus Assembly Guide

Plexiglass
Side Panel
Plexiglass
Side Panel
Magnet
Safety Pilot Hole
Back Panel Back Panel
Top Panel Top Panel
Plexiglass Front Panel
Back Frame Horizontal Bar
Back Frame
Vertical Bar
Front Frame
Vertical Bar
Side Frame Horizontal Bar
Front Frame Horizontal Bar
Front Frame Horizontal Bar
Middle Top Horizontal Bar
Front Frame
Vertical Bar
Back Frame
Vertical Bar
Bespoke Showcase Engineers
4
Overview
Middle Bottom Horizontal Bar
Side Frame
Horizontal Bar
Side Frame
Horizontal Bar
MAX140 Plus Assembly Guide
Laminate Base

Bespoke Showcase Engineers
5
Preparation WorkMAX140 Plus Assembly Guide
You will need
• M5-Long Screw x 44
• M5-Washer x 44
• Side Frame Horizontal Bar x 4
• Middle Top Horizontal Bar x 1
• Middle Bottom Horizontal Bar x 2
• Back Frame Middle Vertical Bar x 1
• Back Frame Horizontal Bar x 2
• Front Frame Top Horizontal Bar x 1
• Front Frame Bottom Horizontal Bar x 1
M5 Washer
M5 Washer
Steps to insert M5-Long Screw
Step 1. Insert the M5-Long Screw fully into the M5-Washer.
Step 2. Position the screw with washer into the pilot hole on
the left side of the bar. Turn clockwise to tighten the
screw. Leave a 15mm gap between the washer and bar.
Step 3. Repeat steps 1-2 for the other side of the bar.
Step 4. Repeat steps 1-3 for
• Side Frame Horizontal Bar x 4
• Middle Top Horizontal Bar x 1
• Middle Bottom Horizontal Bar x 2
• Back Frame Middle Vertical Bar x 1
• Back Frame Horizontal Bar x 2
• Front Frame Top Horizontal Bar x 1
• Front Frame Bottom Horizontal Bar x 1
You will need
• Side Frame Horizontal Bar x 4
• Back Frame Vertical Bar x 2
• Front Frame Vertical Bar x 2
• Horizontal C-Channel x 4
• Vertical C-Channel x 4
Side Frame Horizontal Bar
Position the bar on any side. Install a Horizontal
C-Channel into the top slit of the bar. Repeat for all bars.
Front Frame Vertical Bar
Place a bar with the magnets facing down.
Install a Vertical C-Channel into the top slit.
Repeat for all bars.
Back Frame Vertical Bar
Position the bar with the pilot holes facing the
flat surface. Install a Vertical C-Channel into
the top slit of the bar. Repeat for all bars.
If you are joining the display cases
horizontally, do not insert the C-Channel
on the connecting bar.
If you are joining the display cases
horizontally, do not insert the C-Channel
on the connecting bar.
Please make sure the C-channel
does not cover the pilot hole.
Please make sure the C-channel
does not cover the pilot hole.
Steps to install C-Channel
Step 1. Flatten one end of the C-Channel by
pressing the open edges together.
Step 2. Push the compressed tip into the slit
of the bar.
Step 3. Press down the rest of the C-Channel.
15mm
M5 Washer
C-Channel
Pilot Hole
15mm
M5 Washer

Left Side PanelMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
6
Side Frame
Horizontal Bar
Back Frame
Vertical Bar
Step 1.
Connect Back Frame Vertical Bar to
Side Frame Horizontal Bar. Tighten the
connecting screw using the T-Allen Key.
Back Frame
Vertical Bar
Front Frame
Vertical Bar
Side Frame
Horizontal Bar
Side Frame
Horizontal Bar
Step 2.
Slide in the Plexiglass Side Panel
diagonally into the C-Channels of
the bars.
Plexiglass Side Panel Plexiglass Side Panel
C-Channel
C-Channel
Check that the pilot holes
are facing outwards.
15mm
M5 Washer
15mm
M5 Washer
Step 3.
Connect Front Frame Vertical
Bar to Side Frame Horizontal
Bar (Refer to Step 1). Tighten
the connecting screw using
the T-Allen Key.
Pilot Hole
C-Channel
C-Channel
Step 4.
Press down the Side Frame Horizontal Bar
into the Plexiglass Side Panel. Tighten the
connecting screw using the T-Allen Key.

Right Side PanelMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
7
Back Frame
Vertical Bar
Front Frame
Vertical Bar
Side Frame
Horizontal Bar
Side Frame
Horizontal Bar
Step 8.
Press down the Side Frame Horizontal Bar
into the Plexiglass Side Panel. Tighten the
connecting screw using the T-Allen Key.
Step 7.
Connect Front Frame Vertical
Bar to Side Frame Horizontal
Bar (Refer to Step 1). Tighten
the connecting screw using
the T-Allen Key.
Plexiglass Side Panel
Plexiglass Side Panel
Side Frame
Horizontal Bar
Back Frame
Vertical Bar
Step 5.
Connect Back Frame Vertical Bar
to Side Frame Horizontal Bar.
Tighten the connecting screw
using the T-Allen Key.
Step 6.
Slide in the Plexiglass Side Panel
diagonally into the C-Channels of
the bars.
C-Channel
C-Channel
15mm
M5 Washer

Base FrameMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
7
Step 10.
Connect Back Frame Horizontal
Bar to Left Side Panel.
15mm
M5 Washer
Plexiglass
Left Side
Panel
Step 11.
Connect Back Frame Horizontal Bar
to Left Side Panel.
Step 9.
Connect Front Frame Horizontal Bar
to Left Side Panel.

Back PanelMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
8
Step 15.
Slide in Middle Bottom Horizontal
Bar and position it to the left of Back
Frame Middle Vertical Bar. Tighten
the connecting screws using the
T-Allen Key.
Back Panel Back Panel
Step 13.
Slide in Back Frame Middle
Vertical Bar and position it to the
pilot hole. Tighten the connecting
screw using the T-Allen Key.
Step 12.
Slide in one Back Panel
between the bars.
Step 14.
Slide in one Back Panel
between the bars.
Magnet
Plexiglass
Left Side Panel
Please ensure the longer
notch is at the bottom.

Plexiglass
Side Panel
Top PanelMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
9
Step 16.
Connect Front Frame Horizontal Bar
to Front Frame Vertical bar.
Step 17.
Slide in a Top Panel
between the bars.
Step 19.
Slide in a Top Panel
between the bars.
Step 18.
Slide in a Middle Top Horizontal
Bar between the bars and
position it to align with Back
Frame Middle Vertical Bar
Safety Pilot Hole
Back Panel
Top Panel
Top Panel
Back Panel
Please ensure the longer notch
is facing the Back Panel.

Top PanelMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
10
Magnet Safety Pilot Hole
Magnet
Magnet
Step 20.
Slide in the Right Side Panel.
Please ensure the Front Frame
Vertical Bar Lip is on the right side
of the panel before sliding it down.
15mm
M5 Washer
15mm
M5 Washer

Step 22.
Attach the Plexiglass
Front Panel and insert
the Safety Screw.
Step 21.
Tilt and insert the
Laminate Base.
Magnet
Magnet
Magnet
Magnet
Safety Pilot Hole
Laminate Base
Front PanelMAX140 Plus Assembly Guide
Bespoke Showcase Engineers
11
