Moduspace MAX70 User manual

Version 3.0
Bespoke Showcase Engineers
MAX70 Assembly Guide

Back Frame
Vertical Bar x 2
Back Frame
Horizontal Bar x2
Front Frame
Vertical Bar x 2
Front Frame
Horizontal Bar x 2
Side Frame
Horizontal Bar x 4
Vertical
C-Channel x 4
Horizontal
C-Channel x 4 Conduits x 2
BarsMAX70 Assembly Guide
Bespoke Showcase Engineers
1

M5-Long Screw x 32 M5-Short Screw x 8M4 Stacking Screw x 8
Stacking Bracket x 4
M5 Washer x 32
M5 Nuts x 8
M5 T-Handle
Allen Key x 1
Front Panel
Safety Screw x 1
Bespoke Showcase Engineers
2
Horizontal Bracket x 4
Accessories for connecting display cases
M4 Allen Key x 1
ToolkitMAX70 Assembly Guide
Foot Pad x 4
Attention: If you are connecting multiple display cases, please refer to
“Connecting Display Cases” assembly guide before commencing.

Back Panel x 1
Top Panel x 1 Laminate Base x 1
Plexiglass Side Panel x 2 Plexiglass Front Panel x 1
Bespoke Showcase Engineers
3
PanelsMAX70 Assembly Guide

Magnet Magnet
Magnet
Magnet
Magnet
Magnet
Safety Pilot Hole
Back Frame
Vertical Bar
Side Frame
Horizontal Bar
Front Frame
Vertical Bar
Front Frame
Vertical Bar
Front Frame
Horizontal Bar
Side Frame
Horizontal Bar
Bespoke Showcase Engineers
4
Attention: If you have a floor that could easily
scratched or damaged, please ensure you
cover the surface with a protective cover.
Attention: Please ensure you have all the
parts before commencing assembly. Please
read all of the instructions before commencing.
Attention: If you have purchased optional accessories,
please refer to the Optional Accessories assembly
instructions which are supplied separately.
OverviewMAX70 Assembly Guide
Plexiglass
Front Panel
Plexiglass
Side Panel
Back Panel
Laminate
Base
Plexiglass
Side Panel
Back Frame
Horizontal Bar
Top Panel
Back Frame
Horizontal Bar Side Frame
Horizontal Bar Front Frame
Horizontal Bar
Back Frame
Vertical Bar
Side Frame
Horizontal Bar

Bespoke Showcase Engineers
5
Preparation WorkMAX70 Assembly Guide
You will need
• Side Frame Horizontal Bar x 4
• Back Frame Vertical Bar x 2
• Front Frame Vertical Bar x 2
• Horizontal C-Channel x 4
• Vertical C-Channel x 4
You will need
• M5-Long Screw x 32
• M5-Washer x 32
• Side Frame Horizontal Bar x 4
• Back Frame Horizontal Bar x 2
• Front Frame Horizontal Bar x 2
Side Frame Horizontal Bar
Position the bar on any side. Install a Horizontal
C-Channel into the top slit of the bar. Repeat for all bars.
Front Frame Vertical Bar
Place a bar with the magnets facing down.
Install a Vertical C-Channel into the top slit.
Repeat for all bars.
Back Frame Vertical Bar
Position the bar with the pilot holes facing the
flat surface. Install a Vertical C-Channel into
the top slit of the bar. Repeat for all bars.
If you are joining the display cases
horizontally, do not insert the C-Channel
on the connecting bar.
If you are joining the display cases
horizontally, do not insert the C-Channel
on the connecting bar.
15mm
M5 Washer
M5 Washer
M5 Washer
Steps to insert M5-Long Screw
Step 1. Insert the M5-Long Screw fully into
the M5-Washer.
Step 2. Position 2 screws with washer into
the pilot holes on the left side of the
bar. Turn clockwise to tighten the
screw. Leave a 15mm gap between
the washer and bar.
Step 3. Repeat steps 1-2 for the other side
of the bar.
Step 4. Repeat steps 1-3 for
• Side Frame Horizontal Bar x 4
• Front Frame Horizontal Bar x 2
• Back Frame Horizontal Bar x 2
C-Channel
Pilot Hole
Please make sure the C-channel
does not cover the pilot hole.
Please make sure the C-channel
does not cover the pilot hole.
Steps to install C-Channel
Step 1. Flatten one end of the C-Channel by
pressing the open edges together.
Step 2. Push the compressed tip into the slit
of the bar.
Step 3. Press down the rest of the C-Channel.

Left Side PanelMAX70 Assembly Guide
Bespoke Showcase Engineers
6
Side Frame
Horizontal Bar
Back Frame
Vertical Bar
Step 1.
Connect Back Frame Vertical Bar to
Side Frame Horizontal Bar. Tighten the
connecting screw using the T-Allen Key.
Back Frame
Vertical Bar
Front Frame
Vertical Bar
Side Frame
Horizontal Bar
Side Frame
Horizontal Bar
Step 2.
Slide in the Plexiglass Side Panel
diagonally into the C-Channels of
the bars.
Plexiglass Side Panel Plexiglass Side Panel
C-Channel
C-Channel
Check that the pilot holes
are facing outwards.
15mm
M5 Washer
15mm
M5 Washer
Step 3.
Connect Front Frame Vertical
Bar to Side Frame Horizontal
Bar (Refer to Step 1). Tighten
the connecting screw using
the T-Allen Key.
Pilot Hole
C-Channel
C-Channel
Step 4.
Press down the Side Frame Horizontal Bar
into the Plexiglass Side Panel. Tighten the
connecting screw using the T-Allen Key.

Right Side PanelMAX70 Assembly Guide
Bespoke Showcase Engineers
7
Back Frame
Vertical Bar
Front Frame
Vertical Bar
Side Frame
Horizontal Bar
Side Frame
Horizontal Bar
Step 8.
Press down the Side Frame Horizontal Bar
into the Plexiglass Side Panel. Tighten the
connecting screw using the T-Allen Key.
Step 7.
Connect Front Frame Vertical
Bar to Side Frame Horizontal
Bar (Refer to Step 1). Tighten
the connecting screw using
the T-Allen Key.
Plexiglass Side Panel
Plexiglass Side Panel
Side Frame
Horizontal Bar
Back Frame
Vertical Bar
Step 5.
Connect Back Frame Vertical Bar
to Side Frame Horizontal Bar.
Tighten the connecting screw
using the T-Allen Key.
Step 6.
Slide in the Plexiglass Side Panel
diagonally into the C-Channels of
the bars.
C-Channel
C-Channel
15mm
M5 Washer

Back PanelMAX70 Assembly Guide
Bespoke Showcase Engineers
8
Magnet
15mm
M5 Washer
Back Panel
Step 12.
Press Back Frame Horizontal Bar
into Back Panel.
Step 11.
Slide in the Back Panel.
Step 10.
Connect Back Frame Horizontal
Bar to Left Side Panel.
Step 9.
Connect Front Frame Horizontal Bar
to Left Side Panel.
Plexiglass
Left Side
Panel
Please ensure the
longer notch is at
the bottom.

Step 13.
Connect Front Frame Horizontal
Bar to Front Frame Vertical bar.
Top PanelMAX70 Assembly Guide
Bespoke Showcase Engineers
9
Plexiglass
Left Side Panel
Front Frame
Horizontal Bar
Magnet
Magnet
Magnet
Magnet
Safety Pilot Hole
Back Panel
Top Panel
Back Panel
Step 14.
Slide in the Top Panel
between the bars.
Step 15.
Slide in the Right Side Panel.
Please ensure the Front Frame
Vertical Bar Lip is on the right side
of the panel before sliding it down.
Please ensure the longer notch
is facing the Back Panel.
15mm
M5 Washer
15mm
M5 Washer

Step 17.
Attach the Plexiglass
Front Panel and insert
the Safety Screw.
Magnet
Plexiglass
Front Panel
Front PanelMAX70 Assembly Guide
Bespoke Showcase Engineers
10
Back Panel
Magnet
Magnet
Magnet
Safety Pilot Hole
Step 16.
Tilt and insert the
Laminate Base. Laminate Base
