Moduspace Sixth55 User manual

Version 3.0

Bespoke Showcase Engineers

Sixth55 Assembly Guide

Back Frame

Vertical Bar x 2

Back Frame

Horizontal Bar x2

Front Frame

Vertical Bar x 2

Front Frame

Horizontal Bar x 2

Side Frame

Horizontal Bar x 4

Vertical

C-Channel x 4

Horizontal

C-Channel x 4 Conduits x 2

BarsSixth55 Assembly Guide

Bespoke Showcase Engineers

M5-Long Screw x 16 M5-Short Screw x 8M4 Stacking Screw x 8

Stacking Bracket x 4

M5 Washer x 16

M5 Nuts x 8

Back Frame Foot Pad x 2

Front Frame Foot Pad x 2

M5 T-Handle

Allen Key x 1

Front Panel

Safety Screw x 1

Bespoke Showcase Engineers

Horizontal Bracket x 4

Accessories for connecting display cases

M4 Allen Key x 1

ToolkitSixth55 Assembly Guide

Attention: If you are connecting multiple display cases, please refer to

“Connecting Display Cases” assembly guide before commencing.

Back Panel x 1

Top Panel x 1 Laminate Base x 1

Plexiglass Side Panel x 2 Plexiglass Front Panel x 1

Bespoke Showcase Engineers

PanelsSixth55 Assembly Guide

Magnet Magnet

Magnet

Safety Pilot Hole

Back Frame

Vertical Bar

Back Frame

Horizontal Bar

Side Frame

Horizontal Bar

Front Frame

Vertical Bar

Back Frame

Horizontal Bar

Side Frame

Horizontal Bar Front Frame

Horizontal Bar

Back Frame

Vertical Bar

Side Frame

Horizontal Bar

Front Frame

Vertical Bar

Front Frame

Horizontal Bar

Side Frame

Horizontal Bar

Bespoke Showcase Engineers

Attention: If you have a floor that could easily

scratched or damaged, please ensure you

cover the surface with a protective cover.

Attention: Please ensure you have all the

parts before commencing assembly. Please

read all of the instructions before commencing.

Attention: If you have purchased optional accessories,

please refer to the Optional Accessories assembly

instructions which are supplied separately.

OverviewSixth55 Assembly Guide

Bespoke Showcase Engineers

Preparation WorkSixth55 Assembly Guide

You will need

• Side Frame Horizontal Bar x 4

• Back Frame Vertical Bar x 2

• Front Frame Vertical Bar x 2

• Horizontal C-Channel x 4

• Vertical C-Channel x 4

You will need

• M5-Long Screw x 16

• M5-Washer x 16

• Side Frame Horizontal Bar x 4

• Back Frame Horizontal Bar x 2

• Front Frame Horizontal Bar x 2

Side Frame Horizontal Bar

Position the bar on any side. Install a Horizontal

C-Channel into the top slit of the bar. Repeat for all bars.

Front Frame Vertical Bar

Place a bar with the magnets facing down.

Install a Vertical C-Channel into the top slit.

Repeat for all bars.

Back Frame Vertical Bar

Position the bar with the pilot holes facing the

flat surface. Install a Vertical C-Channel into

the top slit of the bar. Repeat for all bars.

If you are joining the display cases

horizontally, do not insert the C-Channel

on the connecting bar.

If you are joining the display cases

horizontally, do not insert the C-Channel

on the connecting bar.

Please make sure the C-channel

does not cover the pilot hole.

Please make sure the C-channel

does not cover the pilot hole.

Steps to insert M5-Long Screw

Step 1. Insert the M5-Long Screw fully into

the M5-Washer.

Step 2. Position the screw with washer into

the pilot hole on the left side of the

bar. Turn clockwise to tighten the

screw. Leave a 15mm gap between

the washer and bar.

Step 3. Repeat steps 1-2 for the other side

of the bar.

Step 4. Repeat steps 1-3 for

• Side Frame Horizontal Bar x 4

• Front Frame Horizontal Bar x 2

• Back Frame Horizontal Bar x 2

Steps to install C-Channel

Step 1. Flatten one end of the C-Channel by pressing

the open edges together.

Step 2. Push the compressed tip into the slit of the bar.

Step 3. Press down the rest of the C-Channel

DORQJWKHVOLWRIWKHEDU C-Channel

Pilot Hole

15mm

M5 Washer

Side Frame

Horizontal Bar

Back Frame

Vertical Bar

Step 1.

Connect Back Frame Vertical Bar to Side

Frame Horizontal Bar. Tighten the connecting

screw using the T-Allen Key.

Back Frame

Vertical Bar

Front Frame

Vertical Bar

Side Frame

Horizontal Bar

Side Frame

Horizontal Bar

Step 2.

Slide in the Plexiglass Side Panel

diagonally into the C-Channels of

the bars.

Step 4.

Press down the Side Frame Horizontal

Bar into the Plexiglass Side Panel.

Tighten the connecting screw using the

T-Allen Key.

Plexiglass Side Panel Plexiglass Side Panel

C-Channel

Left Side PanelSixth55 Assembly Guide

Bespoke Showcase Engineers

Check that the pilot holes

are facing outwards.

15mm

M5 Washer

15mm

M5 Washer

Step 3.

Connect Front Frame Vertical

Bar to Side Frame Horizontal

Bar (Refer to Step 1). Tighten

the connecting screw using

the T-Allen Key.

Pilot Hole

C-Channel

Back Frame

Vertical Bar

Front Frame

Vertical Bar

Side Frame

Horizontal Bar

Side Frame

Horizontal Bar

Step 8.

Press down the Side Frame Horizontal Bar

into the Plexiglass Side Panel. Tighten the

connecting screw using the T-Allen Key.

Right Side PanelSixth55 Assembly Guide

Bespoke Showcase Engineers

15mm

M5 Washer

Step 7.

Connect Front Frame Vertical

Bar to Side Frame Horizontal

Bar (Refer to Step 1). Tighten

the connecting screw using the

T-Allen Key.

Plexiglass Side Panel

Side Frame

Horizontal Bar

Back Frame

Vertical Bar

Step 5.

Connect Back Frame Vertical Bar

to Side Frame Horizontal Bar.

Tighten the connecting screw

using the T-Allen Key.

Step 6.

Slide in the Plexiglass Side Panel

diagonally into the C-Channels of

the bars.

C-Channel

Back PanelSixth55 Assembly Guide

Bespoke Showcase Engineers

Step 12.

Press Back Frame Horizontal Bar

into Back Panel.

Step 11.

Slide in the Back Panel.

Step 10.

Connect Back Frame Horizontal

Bar to Left Side Panel.

Step 9.

Connect Front Frame Horizontal Bar

to Left Side Panel.

Magnet

15mm

M5 Washer

Plexiglass

Left Side Panel

Back Panel

Please ensure the longer

notch is at the bottom.

Step 13.

Connect Front Frame Horizontal

Bar to Front Frame Vertical bar.

Top PanelSixth55 Assembly Guide

Bespoke Showcase Engineers

Plexiglass

Left Side Panel

Front Frame

Horizontal Bar

Magnet

Safety Pilot Hole

Back Panel

Top Panel

Back Panel

Step 14.

Slide in the Top Panel

between the bars.

Step 15.

Slide in the Right Side Panel.

Please ensure the Front Frame

Vertical Bar Lip is on the right side

of the panel before sliding it down.

Please ensure the longer notch

is facing the Back Panel.

15mm

M5 Washer

15mm

M5 Washer

Step 17.

Attach the Plexiglass

Front Panel and insert

the Safety Screw.

Step 16.

Tilt and insert the

Laminate Base.

Laminate Base

Back Panel

Magnet

Safety Pilot Hole

Plexiglass

Front Panel

Front PanelSixth55 Assembly Guide

Bespoke Showcase Engineers
