Moduspace DF60 User manual

Version 3.0
Bespoke Showcase Engineers
DF60 45° Corner Assembly

Middle
Horizontal
Bar x 2
Back Frame
Left Horizontal
Bar x 2
Back
Enhancement
Bar x 2
Back Frame
Right Horizontal
Bar x 2
Front
Enhancement
Bar x 1
Side Frame
Horizontal Bar x 4
Back Frame Middle
Vertical Bar x 2
Side Frame Back
Vertical Bar x 2
Back Frame
Vertical Bar x 1
Side Frame Front
Vertical Bar x 2
Front Frame
Horizontal Bar x 2
Front Frame
Vertical Bar x 2
Conduit x 1Vertical C Channel x 4
Horizontal C Channel x 4
BarsDF60 45° Corner Assembly Guide
Bespoke Showcase Engineers
1

Bespoke Showcase Engineers
2
M5-Long
Screw x30
M5-Short
Screw x 36
M4 Stacking
Screw x 28
M5 Washer
x 30
M5 Nuts
x 30
Back Frame Foot Pad x 5
Extrusion
Angle Brackets x 6
Angle Brackets
x 4
Front Frame Foot Pad x 2
Stacking Bracket x 5
Horizontal Bracket x 8
Front Panel
Safety Screw x 1
M5 T-Handle
Allen Key x 1
Angle Inner
Bracket x 4 M4 Allen Key x 1
M5 Allen Key x 1
ToolkitDF60 45° Corner Assembly Guide

Left Small Back Panel Right Small Back Panel Right Large Back PanelLeft Large Back Panel Large Top Panel
Small Top Panel Small Base Large Base Front Panel Side Panel
Bespoke Showcase Engineers
3
PanelsDF60 45° Corner Assembly Guide

Back Frame
Right Horizontal Bar
Front Frame Horizontal Bar
Front Frame Horizontal Bar
Side Frame Horizontal Bar
Middle Horizontal Bar
Back Frame Vertical Bar
Back Frame Left Horizontal Bar
Front Frame
Horizontal Bar
Side Frame
Front Vertical Bar
Side Frame Horizontal Bar
Side Frame Horizontal Bar
Front Frame
Vertical Bar
Front Frame
Vertical Bar
Side Frame Horizontal Bar
Middle Horizontal Bar
Front Enhancement Bar
Back Enhancement Bar
Back Frame
Left Horizontal Bar
Front Frame
Horizontal Bar
Back Frame
Right Horizontal Bar
Side Frame
Front Vertical Bar
Back Enhancement Bar
Bespoke Showcase Engineers
4
OverviewDF60 45° Corner Assembly Guide

Bespoke Showcase Engineers
5
Preparation WorkDF60 45° Corner Assembly Guide
You will need
• M5-Long Screw x 44
• M5-Washer x 44
• Back Frame Right Horizontal Bar x 2
• Back Frame Left Horizontal Bar x 2
• Back Frame Middle Vertical Bar x 2
• Middle Horizontal Bar x 2
• Side Frame Back Vertical Bar x 2
• Side Frame Front Vertical Bar x 2
• Side Frame Horizontal Bar x 4
15mm
15mm
M5 Washer
M5 Washer
M5 Washer
M5 Washer
Steps to insert M5-Long Screw
Step 1. Insert the M5-Long Screw fully into the M5-Washer.
Step 2. Position the screw with washer into the pilot hole on
the left side of the bar. Turn clockwise to tighten the
screw. Leave a 15mm gap between the washer and bar.
Step 3. Repeat steps 1-2 for the other side of the bar.
Step 4. Repeat steps 1-3 for
• Back Frame Right Horizontal Bar x 2
• Back Frame Left Horizontal Bar x 2
• Back Frame Middle Vertical Bar x 2
• Middle Horizontal Bar x 2
• Side Frame Back Vertical Bar x 2
• Side Frame Front Vertical Bar x 2
• Side Frame Horizontal Bar x 4
You will need
• Side Frame Back Vertical Bar x 2
• Side Frame Front Vertical Bar x 2
• Side Frame Horizontal Bar x 4
• Horizontal C-Channel x 4
• Vertical C-Channel x 4
Side Frame Horizontal Bar
Position the bar on any side. Install a Horizontal
C-Channel into the top slit of the bar. Repeat for all bars.
Side Frame Front Vertical Bar
Place a bar with the magnets facing down.
Install a Vertical C-Channel into the top slit.
Repeat for all bars.
Side Frame Back Vertical Bar
Position the bar with the pilot holes facing the
flat surface. Install a Vertical C-Channel into
the top slit of the bar. Repeat for all bars.
C-Channel
Pilot Hole
If you are joining the display cases
horizontally, do not insert the C-Channel
on the connecting bar.
If you are joining the display cases
horizontally, do not insert the C-Channel
on the connecting bar.
Please make sure the C-channel
does not cover the pilot hole.
Please make sure the C-channel
does not cover the pilot hole.
Steps to install C-Channel
Step 1. Flatten one end of the C-Channel by
pressing the open edges together.
Step 2. Push the compressed tip into the slit
of the bar.
Step 3. Press down the rest of the C-Channel
along the slit of the bar.

Front Frame
Horizontal Bar
Angle Inner
Front Frame
Vertical Bar
Front Frame AssemblyDF60 45° Corner Assembly Guide
Bespoke Showcase Engineers
6
Step 1.
Connect Front Frame Horizontal Bar to
Front Frame Vertical Bar. Tighten the
connecting screw using the M4 Allen Key.
Put the Angle Inner to Front
Frame Horizontal Bar.
Put the Angle Inner other side
to Front Frame Vertical Bar.
Tighten the connecting screw
using the M4 Allen Key.
Tighten the connecting screw
using the M4 Allen Key.
Front Frame x 1

Bespoke Showcase Engineers
6
Step 2.
Slide in one Back Frame
Vertical Bar between the bars.
Back Frame Right Horizontal Bar
(3 holes)
Back Frame Vertical Bar
Back Frame Left Horizontal Bar
(2 holes)
Connect Back Frame Vertical Bar to Back
Frame Right Horizontal Bar and Back Frame
Left Horizontal Bar. Tighten the connecting
screw using the T-Allen Key.
DF60 45° Corner Assembly Guide
Check that the pilot holes
are facing outwards.
Pilot Hole

Bespoke Showcase Engineers
7
Step 3.
Slide the Back Frame Left
Horizontal Bar and Back Frame
Right Horizontal Bar to the Back
Frame Vertical Bar.
DF60 45° Corner Assembly Guide
Back Frame Right Horizontal Bar
(2 holes)
Back Frame
Left Horizontal Bar
(3 holes)
Connect Back Frame Left Horizontal Bar and
Back Frame Right Horizontal Bar to the Back
Frame Vertical Bar. Tighten the connecting
screw using the T-Allen Key.
Check that the pilot holes
are facing outwards.
Pilot Hole
Back Frame Vertical Bar

Bespoke Showcase Engineers
8
DF60 45° Corner Assembly Guide
Back Frame
Middle Vertical Bar
Back Frame
Middle Vertical Bar
Step 6.
Slide in one Right
Large Back Panel
between the bars.
Step 7.
Slide in Back Frame
Middle Vertical Bar
between the bars.
Step 4.
Slide in one Left Large
Back Panel between
the bars.
Step 5.
Slide in Back Frame
Middle Vertical Bar
between the bars.
Please ensure the longer
notch is at the bottom.

Bespoke Showcase Engineers
9
DF60 45° Corner Assembly Guide
Step 11.
Slide in Middle Horizontal
Bar between the bars.
Please ensure the longer
notch is at the bottom.
Step 8.
Slide in one Right Small
Back Panel between
the bars.
Step 10.
Slide in Middle Horizontal
Bar between the bars.
Step 9.
Slide in one Left Small
Back Panel between
the bars.

Bespoke Showcase Engineers
10
DF60 45° Corner Assembly Guide
M5-Short
Screw
M5 Nuts
Angle Brackets
Back Enhancement Bar
Step 12.
Prepare the Back Enhancement Bar
Put the M5 Nuts into Back
Enhancement Bar
Put the Angle Brackets,
tighten the connecting screw
using the M5 Allen Key.
35cm
35cm

Bespoke Showcase Engineers
11
DF60 45° Corner Assembly Guide
Please ensure the longer
notch is at left side.
Put the M5 Nuts into Bar
Slide the M5 nuts to align with the
holes in the brackets
Tighten the connecting screw
using the M5 Allen Key.
Step 12.
Connecting Back Enhancement Bar
between the bars.
35cm
35cm
Back Enhancement Bar
Step 13.
Slide in one Large
Top Panel between
the bars.

Bespoke Showcase Engineers
12
Step 14.
Slide in the Plexiglass Side Panel
diagonally into the C-Channels of
the bars.
DF60 45° Corner Assembly Guide
Plexiglass Side PanelPlexiglass Side Panel
Side Frame Horizontal Bar
with c-channel if there is
side panel
Side Frame Back Vertical
Bar with c-channel if there
is side panel
Side Frame Horizontal Bar
with c-channel if there is
side panel
Side Frame Horizontal Bar
with c-channel if there is
side panel
Side Frame Back Vertical
Bar with c-channel if there
is side panel
Side Frame Back Vertical
Bar with c-channel if there
is side panel
Plexiglass Side Panel

Bespoke Showcase Engineers
13
DF60 45° Corner Assembly Guide
Step 14.
Side Frame Front Vertical Bar with
C-channel if there is side panel.

Bespoke Showcase Engineers
14
DF60 45° Corner Assembly Guide
Put the M5 Nuts into Bar
Slide the M5 nuts to align with the
holes in the brackets
tighten the connecting screw
using the M5 Allen Key.
Step 14.
Connecting Back Enhancement Bar
between the bars.
Step 15.
Slide in one Small Top Panel
between the bars.

M5-Short Screw
Horizontal Bracket
Bespoke Showcase Engineers
15
Put the M5 Nuts into Bar
Tighten the connecting screw using
the T-Allen Key.
Inner Conect
Tighten the connecting
screw using the T-Allen Key.
Step 16.
Front frame assembly
inner connect.
Inner Conect
Tighten the connecting
screw using the T-Allen Key.
Inner Conect
Tighten the connecting
screw using the T-Allen Key.
Inner Conect
Tighten the connecting
screw using the T-Allen Key.
DF60 45° Corner Assembly Guide
Front frame assembly
M5-Short Screw
Horizontal Bracket
Put the M5 Nuts into Bar
Tighten the connecting screw using
the T-Allen Key.

Bespoke Showcase Engineers
16
DF60 45° Corner Assembly Guide
Step 17.
Tilt and insert the
Large Base.
Step 18.
Tilt and insert the
Small Base.

Bespoke Showcase Engineers
17
Plexiglass
Front Panel
Plexiglass
Front Panel
DF60 45° Corner Assembly Guide
Front Panel
Step 19.
Attach the Plexiglass Front Panel
and insert the Safety Screw.
