modway Kali MOD-6194 User manual

A
B
JCBC SCREW M6 X 70MM
SPRING WASHER 1/4"
Hardware for DRESSER
Component :
1- DRESSER
Customer Service 908-368-1025 www.modway.com Page 1/3
x8
x8
Thank you for purchasing the MODWAY DRESSER !
Before you start,here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommed that it is assembled by two adults,on a carpeted or
padded area, in the room that it is intended for.Approx assembly time:30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled.Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten.Depending on use, it may be necessary to tighten
the components from time to time,so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
MOD-6194
CFLAT WASHER 1/4" x8
DM4 ALLEN KEY (BALL SHAPE) LONG x1
EHANDLE x6
FHANDLE SCREW M4 x 22mm x12
GPROTECTION PAD x4
2- LEGS
1
2
HWALL SCREW M4 x 18MM x1
IWALL SCREW M4 x 50MM x1
JL- BRACKET x2
KBELT x1

Place
Place
Hardware & Tool required
STEP 1 :
Page 2/3
Customer Service 908-368-1025 www.modway.com
A x 8 B x 8 C x 8 D x 1
D
B
C
A
G x 4
G
x12
F
E
STEP 2 :
Hardware & Tool required
E x 6 F x 12
Place DRESSER (1) and Legs (2) on a carpeted or padded area as shown. Attach Legs (2) into DRESSER (1) by inserting
JCBC SCREW M6 x 70mm(A),Spring Washer 1
4''(B) and Flat washer 1 4'' (C).Tighten with M4 Allen Key (Ball Shape)Long(D). Then,
place the PROTECTION PAD(G) on bottom of Legs(2).
Attach HANDLE (E) with DRESSER (1) together.Then, insert HANDLE SCREW M4 x 22mm (F) through the HANDLE (E).Tighten with
Screw Driver.
MOD-6194

J
H
J
I
K
STEP 3.1
STEP 3.2
Place
Place
Hardware & Tool required
STEP 3 :
Page 3/3
Customer Service 908-368-1025 www.modway.com
J x 2 H x 1 I x 1
Attach one of the L-Bracket(J) to wall by inserting WALL SCREW M4 x 50MM(I). Then attach another L-Bracket(J) to back side center of
Dresser by inserting WALL SCREW M4 x 18MM (H).
Place
STEP 4 :
Attach the two L-BRACKET(J) with the BELT(K).
Hardware & Tool required
K x 1
Assembly is complete,the DRESSER is ready to be enjoyed now!
MOD-6194
