modway QUEEN BED FRAME MOD-5432 User manual

Customer Service 908-368-1025︱www.modwayfurniture.com Page 1 of 3
MOD-5432 QUEEN BED FRAME
Thank you for purchasing the MODWAY QUEEN BED FRAME！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed frame, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Component:
1 Short Board x2
1
1
2
2
3
3
3
3
6
2 Long Board x2 3 Leg x4
6 Slat x26
Hardware:
D
Side Plastic Cover x26
A Blot M8x20mm x28
B Blot M6x35mm x4
Nut M6 x4
F Allen Wrench x1
G Open Wrench x1
Center Plastic Cover x13
H
J
4
5
4 Center Rail x1 5 Support Leg x2
C Metal Support x4
E Flat Washer x8

Customer Service 908-368-1025︱www.modwayfurniture.com Page 2 of 3
MOD-5432 QUEEN BED FRAME
Ax16 Fx1
STEP 1:
Please put Short Boards (1),Long Boards (2) upside down on a carpeted or padded area.
Attach 1 piece of Metal Support (C) to one corner of Short Boards (1) and Long Boards (2) by using 2 pieces of
Bolt (A) as shown.
Repeat the same steps for the remaining 3 pieces of Metal Support (C).
Use Allen Wrench (F) to tighten Bolts (A) clockwise until secure.
STEP 2:
Attach 1 piece of Leg (3) to one corner of Short Boards (1) and Long Boards (2) by using 4 pieces of Bolt (A) as shown.
Repeat the same steps for the remaining 3 pieces of Leg (3).
Use Allen Wrench (F) to tighten Bolts (A) clockwise until secure.
Hardware & Tool required
Ax8 Cx4 Fx1Hardware & Tool required
1
1
2
2
1
2
C
A
F
A
A
C
1
2
21
3
3
3
3
A
F
A
AA
3
C
A
A
21
A
A
A

Customer Service 908-368-1025︱www.modwayfurniture.com Page 3 of 3
MOD-5432 QUEEN BED FRAME
Hx26 Jx13
STEP 3:
Hardware & Tool required
1
6
6
2
Assembly is complete. Your bed frame is ready to be used now!
1
2
H
H
Insert 2 piece of Side Plastic Cover (H) into each end of 2 pieces of Slat (6) as shown.
Insert the other end of the Slats (6) into 1 piece of Center Plastic Cover (J) as shown.
Insert the assembled Side Plastic Covers (H) into the corresponding holes on LongBoard (2),and the assembled Center
Plastic Cover (J) into the corresponding holes on Center Rail (4) as shown.
Repeat the same steps for the remaining 24 pieces Slat (6).
J
STEP 4:
Ax4 Bx4 Dx4 Ex8 Gx1 Fx1Hardware & Tool required
Place Stretcher (4) to the assembled Long Board (2).
Secure each end of Stretcher (4) by using 2 pieces of Bolt (A) and 2 pieces of Flat Washer (E) as shown.
Tighten Bolts (A) by using Allen Wrench (F) clockwise until secure.
Place 2 pieces of Support Leg (5) under the assembled Stretcher (4).
Secure each Support Leg (5) by using 2 piece of Bolt (B), 2 pieces of Flat Washer (E) and 2 pieces of Nut (D) as show.
Tighten Bolts (B) and Nuts (D) by using Allen Wrench (F) and Open Wrench (G) until secure.
4
5
5
1
1
2
2
3
3
3
3
1
4
4
AE
AE
F
F
B
B
EE
G
DD
4
