modway MOD-6247 User manual

G
A
B
A
C
F
D
MOD-6247
Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
Customer Service 609-256-9000 | www.modway.com 01 of 04
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 40 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Components:
AHEAD / FOOTBOARD PANEL 2 PCS
B
C
SIDE RAIL 2 PCS
D
CENTER RAIL 2 PCS
E
F
BED LEG (L) 2 PCS
G
BED LEG (R) 2 PCS
BED SLATS 1 SET
E
CENTER RAIL LEG 6 PCS

MOD-6247
HARDWARE BED FRAME
Customer Service 609-256-9000 | www.modway.com 02 of 04
1
2
JCBC BOLT M6 x 90mm 22 PCS
3
JCBC BOLT M6 x 40mm 16 PCS
4
JCBC BOLT M6 x 15mm 8 PCS
6
WOOD DOWEL
M10 x 40MM 8 PCS
7
PH SCREW M4 x 32mm 18 PCS
M4 ALLEN KEY 1 PC
STEP 1
5
BARREL NUT 22 PCS
L BRACKET 4 PCS
ADJUSTABLE FOOT 6 PCS
STEP 2
8
9
4
A
F
E
Short Tab of
L Bracket (8)
3
8
7
5
1
7
A

D
9
D
C
4
1
C
D
D
D
F
E
MOD-6247
Customer Service 609-256-9000 | www.modway.com 03 of 04
STEP 3
STEP 4
STEP 5
14
7
3
C
A
7
7
B
B
DC
5

MOD-6247
Customer Service 609-256-9000 | www.modway.com 04 of 04
STEP 6
STEP 7
7.1 Assembly completed.
6
22
G
72
726
C
BG
