modway MOD-6305 User manual

Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 35 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Hardware:
Component:
A. HEADBOARD
C. SIDE RAIL (L/R)
D.
E.
F.
CENTER RAIL SUPPORT
BED SLAT
BED LEG
01 of 04
MOD - 6305
x 1
B. FOOTBOARD x 1
E
A
B
C
F
D
1
2WOOD SCREW M4 x 25mm 12 PCS
3
4
JCBB BOLT M8 x 30mm 4 PCS
5M8 SPRING WASHER
4 PCS
6
M8 FLAT WASHER
4 PCS
BED SLAT CENTER FITTER
7
24 PCS
WOOD SCREW M3.5 x 16mm 4 PCS
M5 ALLEN KEY (BALL SHAPE) 1 PC
x 2
x 1
x 12
x 4

STEP 1
02 of 04
1.1 Insert and secure the Bed Leg (F) to the Headboard (A) and Footboard (B) using hardware
parts Wood Screw (2), Bolt (3), Flat Washer (4), Spring Washer (5) and Allen Key (7).
STEP 2
A
B
MOD - 6305
2.1 Loosen the pre-inserted bolt on the Headboard (A) & Footboard (B) using hardware part
Allen Key (7).
7
7. M5 ALLEN KEY (BALL SHAPE) x 1pcs
STEP 1.1
STEP 1.2
F
4537
2
2. WOOD SCREW M4 x 25mm x 12pcs 3. JCBB BOLT M8 x 30mm x 4pcs 4. M8 FLAT WASHER x 4pcs
5. M8 SPRING WASHER x 4pcs 7. M5 ALLEN KEY (BALL SHAPE) x 1pcs
Screw Driver

STEP 3
03 of 04
1. WOOD SCREW M3.5 x 16mm x 4pcs
STEP 4
A
C
3.1 Attach the Side Rails (C) to the Headboard (A) & Footboard (B) using hardware part
Allen Key (7).
C
A
B
Screw Driver
MOD - 6305
D
C
1
4.1 Insert and secure the Center Rail Support (D) to the Side Rail (C) using hardware parts Screw
(1).
D
C
A
B
7
7. M5 ALLEN KEY (BALL SHAPE) x 1pcs

STEP 5
04 of 04
6.1 Carefully position the assembled bed to the desired location by four adults.
6. BED SLAT SIDE FITTER x 24pcs
MOD - 6305
5.1 Insert the Slats (E) into the end Slat Cap (6) and fix it to the corresponding holes on
the Side Rail (C). 6
E
STEP 6
Assembly is complete. The bed is ready to use now!
NOTE: Hardware may loosen over time. Periodically check that all connections are tight.
