Moen LEVEL POSI-TEMP T2701BN User manual

Specifications
CRITICAL DIMENSIONS
(DO NOT SCALE)
THIN WALL APPLICATION
THICK WALL APPLICATION
FOR MORE INFORMATION CALL: 1-800-465-6130
www.moen.com
ADA
7" (178mm)
ESCUTCHEON
DIAMETER
2" CC (51mm)
1 7/8" IPS (48mm)
MAX WALL
HOT
INLET
COLD
INLET
FINISHED WALL LINE
FACE OF STUD
4-1/2" (114mm)
WALL OPENING
FLOOR
45" (1143mm)/
48" (1219mm)-SHOWER
7-1/2"
(191mm)
MIN
TUB RIM
L
C
1-3/8" (35mm)
2-1/2" MAX. (63mm)
1/2" MIN. CC (13mm)
5/8" MIN. IPS (16mm)
FLOOR LINE
1-3/8"
(35mm)
1-1/2"
(38mm)
3/16" (typ) (5mm)
PLASTER GROUND
3-1/2" (89mm) MAX.
2-1/4" (57mm) MIN.
DIAMETER
WALL
OPENING
PLASTIC
TUB/SHOWER
SURROUND
L
C
LEVEL™POSI-TEMP®
Single-Handle Shower
(Valve Trim Only)
Models: T2701, T2701BN
FAUCET DESCRIPTION
• Metal construction with chrome plated or LifeShine®
brushed nickel finish
OPERATION
• Handle operates counterclockwise through a 270˚ arc
with off at 6 o’clock and maximum hot at the 9 o’clock
position. Shut off in clockwise direction
• Adjustable temperature limit stop to control maximum
hot water temperature
• Pressure balancing mechanism maintains selected
discharge temperature to ± 3°
CARTRIDGE
• 1222 cartridge design
• Nonmetallic/nonferrous and stainless steel materials
• Accommodates back to back installations
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B-125.1,
ICC A117.1 and all applicable requirements
referenced therein
WARRANTY
• Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
