Hand Crimp Tool
Krimptite 
Application Tooling
Specification Sheet
Order No. 64003-1100
Eng. No. RHT 1751
FEATURES
A full cycle ratcheting hand tool ensures complete crimps
Long handles for comfortable crimping with reduced crimping force
A precision user-friendly terminal locator wire stop holds terminals in the proper crimping position
2-nested tool eliminates the need for additional tools
SCOPE
Products: KrimptiteFemale Non-Insulated Quick Disconnects, Piggybacks and Bullet Receptacles 14–22 AWG.
Testing
Mechanical
The tensile test or pull test is a means of evaluating the mechanical properties of the crimped connections. The
following chart shows the UL specifications for various wire sizes. The tensile strength is shown in pounds and
indicates the minimum acceptable force to break or separate the terminal from the conductor.
Wire Size (AWG)
*UL - 310
22
8
20
13
18
20
16
30
14
50
*UL –310 –Quick Disconnects
The following is a partial list of the product part numbers and their specifications that this tool is designed to run.
We will be adding to this list and an up to date copy is available on www.molex.com.
Wire Size: 18 –22 AWG 0.80 –0.35 mm²
Terminal No.
Terminal
Eng No. (REF)
LOCATOR
Wire Strip Length
Insulation Diameter Maximum
In.
mm
In.
mm
19016-0001
AA-1131
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0003
AA-1134
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0005
AA-1137
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0006
AA-1137-032
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0009
AA-1140
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0110
AA-1190
TAB (64007-1175)
0.25
6.35
N/A
N/A
19037-0002
AA-1121
LOOP (64003-1275)
0.25
6.35
N/A
N/A
19037-0010
AAZ-1125
LOOP (64003-1275)
0.25
6.35
N/A
N/A
19037-0011
AAZ-1126
LOOP (64003-1275)
0.25
6.35
N/A
N/A
19037-0015
AA-1120
LOOP (64003-1275)
0.25
6.35
N/A
N/A
19273-0007
AA-1140-LIF
TAB (64007-1175)
0.25
6.35
N/A
N/A
19010-0027
AA-1301
TAB (64007-1175)
0.25
6.35
N/A
N/A

RHT 1751 Hand Crimp Tool
Doc No: ATS-640031100 Release Date: 08-27-04 UNCONTROLLED COPY Page 2 of 7
Revision: D Revision Date: 02-09-15
WIRE
TERMINAL
Figure 2
Figure 3
2ND AND 3rd TAB
LOCATOR
WIRE
TERMINAL
BARREL
CONDUCTOR
ANVIL
TERMINAL
LOCATOR
CONDUCTOR
PUNCH
1ST TAB
LOCATOR
WIRE STOP BUILT
INTO TERMINAL
Wire Size: 14 –16 AWG 2.00 –1.30 mm²
Terminal No.
Terminal
Eng No. (REF)
LOCATOR
Wire Strip Length
Insulation Diameter Maximum
In.
mm
In
mm
19037-0004
BB-1122
LOOP (64003-1275)
0.25
6.35
N/A
N/A
19037-0006
BB-1123
LOOP (64003-1275)
0.25
6.35
N/A
N/A
19016-0035
BB-1132
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0037
BB-1135
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0039
BB-1138
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0040
BB-1138-032
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0045
BB-1191
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0046
BB-1191-032
TAB (64007-1175)
0.25
6.35
N/A
N/A
19016-0111
BB-1141
TAB (64007-1175)
0.25
6.35
N/A
N/A
19203-0373
19203-0373
TAB (64007-1175)
0.205
5.20
N/A
N/A
19203-0390
19203-0390
TAB (64007-1175)
0.205
5.20
N/A
N/A
19273-0008
BB-1141-LIF
TAB (64007-1175)
0.25
6.35
N/A
N/A
19010-0028
BB-1302
TAB (64007-1175)
0.25
6.35
N/A
N/A
OPERATION
Open the tool by first closing the jaws sufficiently for the ratchet
mechanism to release.
Crimping Female Quick Disconnects Terminals
1. There are 3 tab locator blades supplied with the tool. One is for
.187 and .250 tabs; another is for .205 tabs and .110 Tabs and
another for LIF terminals. Make sure the proper blade is installed
on the top of the locator and the others are stored on the bottom of
the locator. For proper orientation of the locator blade see Figure 1.
2. Push the terminal onto the tab locator all the way to the stop in the
proper color-coded nest. The barrel of the terminal should be up
3. Partially close the tool to hold the terminal in place. See Figure 2.
4. Insert the properly stripped wire into the terminal barrel. See Figure 2 and 3. The wires end should butt against
the wire stop stamped into each terminal. Cycle the tool.
Crimping Piggyback Quick Disconnect Terminals
Follow the procedure described above but the terminal
must be loaded with the male tab up and the barrel down.
LOCATOR
JAWS OPEN
TAB LOCATOR
(64007-1175)
Figure 1
TERMINAL

RHT 1751 Hand Crimp Tool
Doc No: ATS-640031100 Release Date: 08-27-04 UNCONTROLLED COPY Page 3 of 7
Revision: D Revision Date: 02-09-15
PUSH TO LOAD/
REMOVE TERMINAL
Figure 4
TERMINAL
JAWS
OPEN
LOOP
LOCATOR
(64003-1275)
Figure 5
CONDUCTOR
ANVIL
TERMINAL WITH WIRE
STOP BUILT IN
LOCATOR
BLADE
CONDUCTOR
PUNCH
TERMINAL
BARREL
WIRE
Note: The tamper proof ratchet action will not release the tool until it has been fully closed.
1. Remove the crimp and inspect for proper crimp location. Molex offers a Crimp Inspection Handbook for
closed barrel industrial product. See our website or contact your Sales Engineer.
Note: Whenever crimping without the locator, make sure the seam of the terminal is oriented up or down in
the tool if using unbrazed product, as this will provide higher pull force values.
Crimping Bullet Terminals
1. Adjust the locator up or down until the bullet terminal being crimped sits flat and straight into the tool.
2. Push up on the locator blade and insert the terminal in the proper nest with the barrel up and against the
locator blade. Release the locator blade to hold the terminal in position. See Figure 4. Locator may be
raised or lowered so terminal sits flat and straight in the tool.
3. Partially close the tool to hold the terminal in place.
4. Insert the properly stripped wire into the terminal barrel. See Figure 5. The wires end should stop against
the locator blade. Cycle the tool.
Note: The tamper proof ratchet action will not release the tool until it has been fully closed.
5. Push the locator blade to remove the crimp and inspect for proper crimp location. Locator is adjustable up
and down to keep terminals straight after crimping. See Figure 4. Molex offers a Crimp Inspection Handbook
for closed barrel industrial product. See our website or contact your sales engineer.
Note: Whenever crimping without the locator, make sure the seam of the terminal is oriented up or down in
the tool if using unbrazed product, as this will provide higher pull force values.
Maintenance
It is recommended that each operator of the tool be made aware of, and responsible for, the following maintenance
steps:
1. Remove dust, moisture, and other contaminants with a clean brush, or soft, lint free cloth.
2. Do not use any abrasive materials that could damage the tool.

RHT 1751 Hand Crimp Tool
Doc No: ATS-640031100 Release Date: 08-27-04 UNCONTROLLED COPY Page 4 of 7
Revision: D Revision Date: 02-09-15
3. Make certain all pins; pivot points and bearing
surfaces are protected with a thin coat of high
quality machine oil. Do not oil excessively. This
tool was engineered for durability, but like any fine
piece of equipment it needs cleaning and
lubrication for a maximum service life of trouble-
free crimping. A light oil, such as 30 weight
automotive oil used at the oil points shown in
Figure 6, every 5,000 crimps or 3 months will
significantly enhance the tool life and ensure a
stable calibration.
4. When tool is not in use, keep the handles closed to
prevent objects from becoming lodged in the
crimping dies, and store the tool in a clean, dry
area.
Miscrimps or Jams
Should this tool ever become stuck or jammed in a partially closed position, Do Not force the handles open or
closed. The tool will open easily by pressing the ratchet release lever. See Figure 7.
How to Adjust Tool Preload (See Figure 7)
Over the life of the tool, it may be necessary
to adjust tool handle preload force. Listed
below are the steps required to adjust the
crimping force of the hand tool to obtain
proper crimp conditions:
1. Remove the screw and plastic cover
washer. Note the setting wheel
position.
2. Lift the setting wheel off the axle. Turn
the eccentric axle with a screwdriver.
3. Turning the eccentric axle counter-
clockwise will increase handle force.
4. Replace the setting wheel to the axle,
aligning the nearest notch in the setting wheel to the dowel pin.
5. Replace the plastic cover washer and screw.
6. Check the crimp specifications after tool crimp force is adjusted.
Tool Calibration
A Certificate of Calibration (See Last Page) was supplied with the tool. To recalibrate this Tool, a soft metal slug
or solder should be crimped in the conductor nest and the “X” Dimension measured in each conductor nest and
compared to this chart. The tool should be lubricated prior to recalibration to ensure consistent measurements.
Handle preload is factory set to 25-45 LBS. See How to Adjust Tool Preload (See Figure 7) to recalibrate.
Figure 6
LUBRICATION POINTS (BOTH SIDES)
LIGHT OIL (EVERY 3 MONTHS
OR 5,000 CRIMPS)
Figure 7
1.00
1.00
PRELOAD
TEST POINT
PRELOAD
TEST POINT
PRELOAD
ADJUSTMENT
LOCKING SCREW
RATCHET
RELEASE LEVER
PUSH UP

RHT 1751 Hand Crimp Tool
Doc No: ATS-640031100 Release Date: 08-27-04 UNCONTROLLED COPY Page 5 of 7
Revision: D Revision Date: 02-09-15
Nest Color Code
Wire Range
“X” Dimension
Conductor Crimp
Awg
mm²
Mean
Go
No Go
Red
22 - 18
0.35 - 0.80
.052
.049
.060
Blue
16 - 14
1.30 - 2.00
.061
.058
.069
CAUTION: Repetitive use of this tool should be avoided.
Warranty
This tool is for electrical terminal crimping purposes only. This tool is made of the best quality materials. All vital
components are long life tested. All tools are warranted to be free of manufacturing defects for a period of 30
days. Should such a defect occur, we will repair or exchange the tool free of charge. This repair or exchange will
not be applicable to altered, misused or damaged tools. This tool is designed for hand use only. Any clamping,
fixturing, or use of handle extensions voids this warranty.
Hand held crimping tools are intended for low volume, prototyping, or repair requirements only.
CAUTION: Molex crimp specifications are valid only when used with Molex terminals, applicators and tooling.
“ X ”
NOT POSSIBLE TO PIN GAUGE, MEASURE A
CRIMPED UNINSULATED TERMINAL OR SLUG*
*SOLDER, LEAD OR
SIMILAR SOFT METAL

RHT 1751 Hand Crimp Tool
Doc No: ATS-640031100 Release Date: 08-27-04 UNCONTROLLED COPY Page 6 of 7
Revision: D Revision Date: 02-09-15
(64007-1175)
M4 X 12LG
PAN HEAD SCREW
FOR SPRING
ACCESS SWING
OPEN COVER
7
SCREW AND PLASTIC
COVER FOR HANDTOOL
PRELOAD ADJUSTMENT
RATCHET
RELEASE LEVER
3
1
2
M4 X 25LG (64003-1175)
M4 X 30LG (64003-1275)
PAN HEAD SCREW
M4 FLAT WASHER
6
5
REPAIR KIT. ALL PARTS REQUIRED FOR
REPAIR. (ONLY MAIN SPRING SHOWN)
4
M4 FLAT
WASHER
M4 LOCKNUT W/
HEX NYLON INSERT
M4 WING NUT
Figure 6
(64003-1275)
PARTS LIST
Item
Order No
Description
Quantity
64003-1100
Hand Crimp Tool
Figure 6
1
64000-0076
Repair Kit (Springs, Pins and E-Rings)
1
2
63810-0000
Handle
1
3
64007-1175
Locator Assembly
1
4
64003-1275
Locator Assembly
1
5
64003-1170
Tooling Kit
1
Tooling Kit Only
6
64003-1101
Conductor Punch
1
7
64003-1102
Conductor Anvil
1

RHT 1751 Hand Crimp Tool
Doc No: ATS-640031100 Release Date: 08-27-04 UNCONTROLLED COPY Page 7 of 7
Revision: D Revision Date: 02-09-15
Hand Crimp Tool
Krimptite 
Certificate of Calibration
Order No. 64003-1100
Tool Order Number __________________
Tool Eng. Number ___________________
Tool Revision ___________________
Serial Number ___________________
Date of Manufacture__________________
Handle Load Range at 1 inch from the Tips =______________
Actual =_____________
Pin Gauge of Conductor Nest/Nests or Slug height if the nest is the “F” Crimp style.
Range Conductor Nest # 1 = ____________-- Actual = ______________
Range Conductor Nest # 2 = ____________-- Actual = ______________
Range Conductor Nest # 3 = ____________-- Actual = ______________
Technician ______________
Date of Calibration ______________
Calibration should be done every 5,000 cycles or 3 months.
Tools should be lubricated during this operation.
Visit our Web site at http://www.molex.com
