momit Smart Thermostat User manual

Designed for your comfort

Index
First connection
1. Welcome to momit Smart
Thermostat
2. Language
3. Smart Registration
4. Date/Time
5. Unit of measurement
6. Network detection
7. User Registration
8. Display Design
8
8
9
12
12
13
14
15
Main menu
Main menu
a. Raise/lower temperature
b. Use
c. Schedule
c.1 Programming
c.2 Holidays
d.1 General setup
d.1.1 Hysteresis
d.1.2 Calibration
d.1.3 Screen Lock
d.2 Advanced
d.2.1 Smart
d.2.2 Presence
d.2.3 Ambient
d.2.4 Standby
d.3 Technical
d.3.1 Technical Information
d.3.2 Network
d.3.3 Reset
Minimum Requirements
17
18
18
19
19
20
21
22
22
22
23
23
23
23
24
25
25
25
26
27
Installation Guide…………...................……… 3

3
Installation Guide
1For safety, make sure to turn the
power supply o in the installation area.
2Remove your current thermostat to
be able to see the wiring. Locate the C
(also known as COM) and W (also known
as NO) wires, these are the control wires.
You will need these wires for momit
Smart Thermostat to work. If you don’t
have these wires, you will have to install
them. Once you have done this, proceed
with the installation.

4
3Open momit Smart Thermostat. To do
so, insert the tip of a flathead screwdriver
into the openings found at the bottom.
4Gently press the openings while
prying. Make a hinge movement to finish
opening the thermostat case without
forcing the connection pins.
5Remove the back plate, you will see
several openings in which the fixings of
the thermostat to the wall will go.

5
6Position the back plate on the wall.
Make sure that none of the labels fall out
when attaching the wall plate. Insert the
screws and tighten them up. Now you
can begin to connect the wires.
7Below you can find the wiring
diagram for heat and cooling systems.
The heating system diagram shows the
connection between thermostat and
heating system (C and W to T1 and T2).
The cooling system diagram shows the
connection between cooling system,
Dry Contact and thermostat. The
thermostat and Dry Contact connect
through the C2 and Y terminals, while
the Dry Contact connects to the cooling
system through the cables that were
connected to your previous thermostat.
This will vary depending on the cooling
system brand.
Both systems connect to the power
supply through L and N.

6
8Introduce the existing wires through
the hole in the center of the back plate.
9Using a screwdriver put the wires
in proper position, taking the marks
inside the plate into consideration. It is
important that the exposed wires are
pushed back close to the wall opening
and are as tight as possible.
10 Now you can close momit Smart
Thermostat. To close the plates properly,
place the top and bottom parts and
then press gently until the tabs at the
bottom of the plates make a
clicking sound. This means it has been
wedged in properly.
11Now you can turn the power supply
back on and continue with the momit
Smart Thermostat setup.

7
The first time you connect your momit Smart
Thermostat, a series of screens will appear,
which will take you through the initial device
setup.
First time connection
Welcome to momit Smart
Thermostat, the smart WiFi
thermostat.
Welcome
1
m

8
Language
Start by selecting the desired
language, it is a mandatory field
to advance to the next step. After
selecting the language four “m’s”
will appear, this means that the
thermostat is loading; it may take a
few minutes.
2
SETTINGS
Language
Deutsch
English
Español
Français
Italiano
Portugués
delete accept
Smart Registration
3
When registering your momit
Smart Thermostat you must check
whether your device has the Smart
Registration option or not. You’ll
know because a screen appears
informing you if you are enabled for
Smart Registration.
If yes, proceed to step 4. Later you
will be provided with a registration
code you must enter in the momit
Smart Thermostat App.
SETTINGS
This device is enabled for
Smart Registration option
continue>>

9
SET-UP
User Conditions
By accepting, you are
agreeing to comply with the user conditions
when using the momit Smart Thermostat.
Before continuing, you may consult the user
conditions at www.momit.com
I do not accept accept
SET-UP
Country
delete accept
A B C D E F
G H I J K L
M N O P Q R
S T U V Y Z
1
SET-UP
Postcode
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
If not, the following screen will appear.
In this case, your thermostat will be
updated automatically once you have
registered manually. This update can
take up to 24 hours. After performing
steps 4 and 5, the registration screens
that will appear on the left.

10
In case of having previously created
an account, you must select the
appropriate field. However if you have
not done so yet, click Create Account
and follow the steps on the screen.
Enter the email address you will use to
access your momit Smart Thermostat.
Create a personal password to be able
to control your thermostat. It must
have at least 6 characters.
You can now proceed to step 6 for
Internet settings. Some of the screens
will be dierent but they will be
updated within 24 hours.
1
SET-UP
User Account
Create user account
delete accept
I already have an account
1
SET-UP
E-mail
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
1
SET-UP
User Password
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
Please enter your user password

11
Select the unit of temperature
measurement you want to use.
Unit of Measurement
5
Date/Time
4
Select the current date and time to
start programming the thermostat.
momit Smart Thermostat will
automatically update the time when
appropriate.
1
°F/°C
°F
°C
delete accept
SETTINGS
1
SETTINGS
Date/Time
1 2 3 4 5 6 7 8 9 0
DD/MM
am
MM/DD
pm
DD/MM/YY
HHMM
delete accept
12H 24H

12
The networks to which the device may
be connected appears on the screen.
The network name may also be entered
manually.
If you select DHCP IP, a dynamic IP will
be assigned to the thermostat. Enter
the password of the selected WiFi
network. If you want to assign a
fixed IP, you must select this option.
Then enter the Gateway, the IP you
want to assign to the thermostat and
the net mask.
Enter the password for the network you
selected. Then, you will be able to verify
that the internet connection process
has been performed correctly. If the
following situation shows up on the
screen, it means that the thermostat has
not been able to connect to the server.
If after 30 seconds it does not say “OK”,
you should retry the WiFi connection.
In this case, you must check if the WiFi
settings are correct.
Network Detection
6
1
SETTINGS
Networks - SSID found
delete accept
Manual entry of WiFi network
Network 1
Network 2
Network 3
1
Network
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
Wireless Network Name
SETTINGS
SETTINGS
DHCP IP
Static IP
delete accept

13
The code you need for Smart
Registration will show up. Enter
it and follow the instructions on
the App. If you do not have Smart
Registration, proceed with step 8.
User Registration
7
SETTINGS
accept
User Register
FF0033DD66EE
Download the APP and register
your device with next code

14
Display Design
8
Using the side buttons, you may
browse through the designs and
select the one you want by clicking
in the centre of the screen.
6display modes:
Elegant
Elegant
Maya Minimalist
Retro
SimpleStandard
1 4
2 5
3 6
1
4
2
5
3
6

15
The tens and units are
shown in the bottom left.
The tens are represented
by hollow circles, while
the units are represented
by solid circles.
Tens
Units
Temperature reading
Maya
Minimalist
In this case, 3bars appear:
the middle one represents
the units (the highest), the
left one represents the tens
and the one on the right
represents the decimals
(smallest).
The solid dots represent
each unit and the hollow
dot represents the
number5.
5 -
1 -
5 6 7 8 90 1 2 3 4
5 6 7 8 90 1 2 3 4
1 -
0

16
Main menu
Once the initial setup has been completed
upon first connecting your momit Smart
Thermostat, every subsequent time that
the device is turned on, you will be taken
directly to the main menu.
If you do not have Smart Registration, your
thermostat must have been updated before
you can view the current functions.
The following options appear on the
main menu:
a.Raise/Lower Temperature This op-
tion will appear if you give the screen
a single tap.
b. Use
c. Schedule
d. Setup
e. momit Design
USE
m
CALENDAR
SET-UP
MOMIT DESIGN

17
a. Raise/Lower Temperature
b. Use
With a single tap on the screen, the
“+” and “–” symbols will appear.
Use these symbols to select the
desired temperature, and once
selected, click OK.
Allows you to select the heating,
cooling or O function.
Ok
m
1
SETTINGS
Use
What you do you want to enable?
delete accept
Heating
A/C
Off
21.4°

18
c. Schedule
c.1 Programming
c.1 Programming
c.2 Holidays
This section shows the Schedule.
The colour red indicates heating,
and blue indicates cooling. Hours
appear at the top and days on the
left.
There are two options in Schedule:
To programme the schedule, select
the temperature, start time and
end time. Then choose the days on
which you would like this to repeat.
Once configured, tap accept. The
following screen shows the new
configuration.
1
Schedule
Temperature
delete accept
Start time
End time
Repeat on
Mon Tue Wed Thurs Fri Sat Sun
Programming
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
0.00 1.00 2.00 3.00 4.00 5.00
22ºC
19ºC

19
c.2 Holidays
When a holiday period is configured,
momit Smart Thermostat will turn o
the heating or cooling systems until
the return date.
CALENDAR
Activate
I am Leaving
I am Back
Holidays
General
Advanced
Technical
SETTINGS
When in Holidays mode, the
following icon will appear on the
screen:
By clicking on it, the Holiday
Settings screen will open, where
you will have the option of editing
or disabling the settings.
d. Setup
d.1 General setup
d.2 Advanced
d.3 Technical

20
d.1 General Setup
Allows you to access:
- Language
- Date/Time
- F/C
- Calibration
- Screen Lock
Language
Date/Time
F/C
Calibration
Lock
GENERAL SETTINGS
