momit Smart Thermostat User manual

User guide

momit Smart Thermostat User Guide
Contents
First connection
1. Welcome to momitST
2. Language
3. Loading
4. User conditions
5. Country
6. Postcode
7. Date/time
8. Unit of measurement
9. User account
10. Email
11. User password
12. Detected networks
13. Network name
14. DHCP IP - Fixed IP
15. Enter password
16. Check connection
17. momit Designs
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
13
Main menu
1. Home
2. Main menu
3. Minimum requirements
a. Raise/lower temperature
b. Use
c. Calendar
c.1 Programming
c.2 Holidays
d. Set-up
d.1 General set-up
d.2 Parameters
d.2.1 Safety temperature
d.2.2 Calibration
d.2.3 Hysteresis
d.3 Advanced
d.3.1 Smart
d.3.2 Presence
d.3.3 Ambient
d.3.4 Standby
d.4 Technical
d.4.1 Technical information
d.4.2 Last connection
d.4.3 Network
d.4.4 MAC
d.4.5 Reset
16
16
17
17
18
18
19
19
20
20
21
21
21
22
22
22
22
23
24
24
24
25
25
25
26

momit Smart Thermostat User Guide
3
The rst time you connect your momit Smart
Thermostat, a series of screens will appear,
which will take you through the initial device
set-up.
First connection

momit Smart Thermostat User Guide
4
Welcome to momit Smart Thermostat,
the intelligent WIFI thermostat.
Welcome
1
Language
Start by selecting your desired lan-
guage, a mandatory step before you
can proceed.
2
SET-UP
Language
Deutsch
English
Español
Français
Italiano
Portugués
delete accept

momit Smart Thermostat User Guide
5
You may consult the user conditions
on our website
www.greenmomit.com
You must accept these in order to
continue.
Loading
3
User conditions
4
Now the interface set-up will start,
a process that takes no more than
3 minutes.
SET-UP
User Conditions
By accepting, you are
agreeing to comply with the user conditions
when using the momit Smart Thermostat.
Before continuing, you may consult the user
conditions at www.greenmomit.com
I do not accept accept

momit Smart Thermostat User Guide
6
To conduct a proper study of the en-
ergy consumption, you must select a
destination country.
Country
5
By entering the postcode, more de-
tailed information of the environmen-
tal situation may be produced and a
study of energy consumption in each
geographical area may thus be per-
formed.
Postcode
6
SET-UP
Country
delete accept
1
SET-UP
Postcode
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
A B C D E F
G H I J K L
M N O P Q R
S T U V Y Z

momit Smart Thermostat User Guide
7
Select the current date and time to
start programming the thermostat.
momit Smart Thermostat will auto-
matically update the time when ap-
propriate.
Date/time
7
Unit of measurement
8
Select the unit of temperature meas-
urement you want to use.
1
SET-UP
Date/Time
1 2 3 4 5 6 7 8 9 0
DD/MM
am
MM/DD
pm
delete accept
1
SET-UP
°F/°C
°F
°C
delete accept
DD/MM/YY
HHMM

momit Smart Thermostat User Guide
8
Email
10
User account
9
If you have already created an ac-
count, select the corresponding eld.
If, on the other hand, you have not
done so, click on 'create account' and
follow the steps that appear on the
screen.
Enter the email address you want to
use to access your momit Smart Ther-
mostat.
1
SET-UP
User Account
Create user account
delete accept
I already have an account
1
SET-UP
E-mail
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE

momit Smart Thermostat User Guide
9
User password
11
Create a personal password in order
to control your thermostat. It must
contain at least 6 characters.
Detected networks
12
1
SET-UP
User Password
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
Please enter your user password
The networks to which the device may
be connected appear on the screen.
The network name may also be en-
tered manually.
1
SET-UP
Detected Networks - SSID
delete accept
Manual entry of WiFi network
Network 1
Network 2
Network 3

momit Smart Thermostat User Guide
10
Network name
13
Enter the name of the WiFi you want
to connect to.
1
SET-UP
Network
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
WiFi network name
If you select DHCP IP, a dynamic IP
will be assigned to the thermostat.
Enter the password of the selected
WiFi network.
If you want to assign a xed IP, you
must select this option. Then enter the
Gateway, the IP you want to assign to
the thermostat and the netmask.
SET-UP
DHCP IP
Fixed IP
delete accept
DHCP IP - Fixed IP
14

momit Smart Thermostat User Guide
11
Enter password
15
Enter the WiFi network password.
Once 3 minutes of set-up have passed,
the results of the user registration
and connection process will appear.
If successful, you will receive an
email in your registered email
account to validate your username.
Once validated, which takes less
than 2 minutes, you may access the
application to nish setting up your
account data and remotely manage
your momit Smart Thermostat.
1
SET-UP
Network
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
?123 space DONE
Password
In this screen, we receive conrmation
as to whether the user registration
and internet connection process were
performed correctly.
TECHNICAL
LAN
WWW
accept
Check connection
16
momit server
OK
OK
OK

momit Smart Thermostat User Guide
12
If the error status shown in the image
appears on your screen, this means that
the thermostat was unable to connect to
the server. If it does not switch to the “OK”
status after 30 seconds, you must try again
to connect to the WiFi.
In this case, you must check whether the
WiFi set-up is correct.
TECHNICAL
LAN
WWW
accept
momit server
Check SSID and Pom
Check SSID and Pom
ERROR
TECHNICAL
LAN
WWW
accept
momit server
OK
OK
ERROR

momit Smart Thermostat User Guide
13
momit Designs
17
Using the side buttons, you may
browse through the designs and
select the one you want by clicking in
the centre of the screen.
6 display modes:
Elegant
Elegant
Maya Minimalist
Retro
SimpleStandard
1 4
2 5
3 6
1
4
2
5
3
6

momit Smart Thermostat User Guide
14
The tens and units are
shown in the bottom left.
The tens are represented
by hollow circles, while the
units are represented by
solid circles.
Units
Tens
Decimals
5 6 7 8 90 1 2 3 4
Temperature reading
MAYA
MINIMALIST
Units
Tens
In this case, 3 bars appear:
the middle one represents
the units (the highest), the
left one represents the tens
and the one on the right
represents the decimals
(smallest).
The solid dots represent
each unit and the hollow dot
represents the number 5.
5 6 7 8 90 1 2 3 4
Decimals

momit Smart Thermostat User Guide
15
Main menu
Once the initial set-up has been completed
upon rst connecting your momit Smart
Thermostat, every subsequent time that
the device is turned on, you will be taken
directly to the main menu.

momit Smart Thermostat User Guide
16
Welcome to momit Smart Thermostat,
the intelligent WIFI thermostat.
Home
1
Main menu
2
The following options appear in the
main menu:
a. RAISE/LOWER TEMPERATURE
This option will appear if you give the
screen a single tap.
b. USE
c. CALENDAR
d. SET-UP
e. MOMIT DESIGN
USE
m
CALENDAR
SET-UP
MOMIT DESIGN

momit Smart Thermostat User Guide
17
a. RAISE/LOWER TEMPERATURE
b. USE
With a single tap on the screen, the
“+” and “–” symbols will appear.
Use these symbols to select the
desired temperature, and once
selected, click OK.
Allows you to select the Heating,
A/C or Off function.
Ok
m
1
SET-UP
Use
What you do you want to enable?
delete accept
Heating
A/C
Off
21.4°

momit Smart Thermostat User Guide
18
c. CALENDAR
c.1 PROGRAMMING
c.1 PROGRAMMING
c.2 HOLIDAYS
This section shows the calendar pro-
gramme. The colour red indicates
heating, and the blue A/C.
The hours appear at the top and the
days on the left.
There are two options in the Calen-
dar:
To programme the calendar, select
the temperature, start time and end
time. Then choose the days on which
you would like this to repeat.
Once congured, click accept. The
above screen shows the new con-
guration.
1
Programming
Temperature
delete accept
Start time
End time
Repeat on
Mon Tue Wed Thurs Fri Sat Sun

momit Smart Thermostat User Guide
19
c.2 HOLIDAYS
When a holiday period is cong-
ured, momit Smart Thermostat will
turn off the air-conditioning systems
until the return date.
CALENDAR
Disable
Going
Coming back
Holidays
d. SET-UP
d.1 GENERAL SET-UP
d.2 PARAMETERS
d.3 ADVANCED
d.4 TECHNICAL
General
Parameters
Advanced
Technical
SET-UP
When in Holidays mode,
the following icon will
appear in the screen:
By clicking on this, the Holiday Set-
tings screen will open, where you
will have the option of editing or
disabling the settings.

momit Smart Thermostat User Guide
20
d.1 GENERAL SET-UP
Allows you to access:
- Language
- Country
- Postcode
- Date/time
- Email
Language
Country
Postcode
Date/Time
Email
GENERAL SET-UP
d.2 PARAMETERS
d.2.1 Safety temperature
d.2.2 Calibration
d.2.3 °F / °C
Safety temperature
Calibration
°F/°C
Parameters
