MONARCH INSTRUMENT Nova-Pro 100 User manual

Instruction Manual
Nova-Pro® 100
LED Stroboscopes/Laser Tachometers
15 Columbia Drive
Amherst, NH 03031 USA
Phone: [phone] • Fax: [phone]
E-mail: [email protected]
Website: www.monarchinstrument.com
PATENTED
TECHNOLOGY

           
    This product may contain material
which could be hazardous to human health and the environment. DO NOT
DISPOSE of this product as unsorted municipal waste. This product needs to be
RECYCLED in accordance with local regulaons; contact your local authories for
more informaon. This product may be returnable to your distributor for recycling;
contact the distributor for details.
SAFEGUARDS AND PRECAUTIONS
1. Read and follow all instrucons in this manual carefully, and retain this
manual for future reference.
2. Do not use this instrument in any manner inconsistent with these operang
instrucons or under any condions that exceed the environmental
specicaons stated.
3. Certain strobe frequencies can trigger epilepc seizures in those prone to that
type of aack.
4. Users should not stare directly at the light source.
5. Prolonged exposure to the light can cause headaches in some people.
6. Objects viewed with this product may appear to be staonary when in fact
they are moving at high speeds. Always keep a safe distance from moving
machinery and do not touch the target.
7. There are no user serviceable parts in this instrument. Refer service to a
qualied technician.
8. This instrument may not be safe for use in certain hazardous environments,
and serious personal injury or death could occur as a result of improper use.
Please refer to your facility’s safety program for proper precauons.
9. Do not clean this instrument with alcohol or other cleaning solvents as these
may damage the LEDs.
10. Nova-Pro Baery Packs contain Lithium Ion baeries which must be disposed
of in accordance with Federal, State, & Local Regulaons. Do not incinerate.
Baeries should be shipped to a reclamaon facility for recovery of the metal
and plasc components as the proper method of waste management. Contact
distributor for appropriate product return procedures.



Eye injury from beam - Do not look into the direct or reected beam; can cause eye
injury up to 25  (7.5 m) away.
 - Interferes with vision up to 525
 (160 m) away. Can be a distracon up to 1 mile (1.6 km) away. NEVER point any
laser towards aircra or vehicles; it is unsafe and illegal.
Diode Laser
Max. Output Power: 
Wavelength: 
Beam Divergence: <18 milliradian
Output: 
Laser Hazard Classicaon: 
Monarch Instrument’s Limited Warranty applies.
See www.monarchinstrument.com for details.
Warranty Registraon and Extended Warranty Coverage informaon is available
online at www.monarchinstrument.com.
Monarch Instrument holds the following US trademarks and registraons, all rights
reserved: illumiNova®, Nova-Pro®, Nova-Strobe™, DataChart™, Track-It™.
This product is protected by United States Patent No. 10,080,268.

Class 2 lasers are considered safe
for accidental eye exposure. Do
not look or stare into beam. Do
not aim at aircra. This is not a
toy. Always supervise children.

Monarch Instrument
15 Columbia Drive
Amherst, NH 03031 USA
Country of Origin: USA
Contact info: www.monarchinstrument.com

TABLE OF CONTENTS
1.0 INTRODUCTION ........................................................... 1
      
 RTED ....................................................... 5
  
4.0 MODES OF OPERATION .............................................. 6
4.1 STROBE Mode ........................................................ 6
     
          
   (oponal accessory) ............................... 8
       
5.0 MENUS .......................................................................... 10
5.1 Menu Overview ......................................................... 10
 
 
 
 
 
 
6.0 STROBE BRIGHTNESS .................................................... 14
 
 
 

 Y PACK ............................................................. 16
 
 
 
 
10.0 SPECIFIC
 
 
 
 
 
 

1
1.0 INTRODUCTION
The Nova-Pro 100 is a portable handheld LED stroboscope used for
inspecon and to stop moon of rotang objects. The Nova-Pro 100 is
available as baery powered or AC mains powered. An oponal Laser
Module is available which can be used to synchronize the strobe ash to a
remote target or as a laser tachometer to determine the speed of rotang
objects (Tach Mode).
The features of the Nova-Pro 100 are highlighted in Figure 1 and Table 1.
1
2
3
4
5
6
7
Figure 1 Nova-Pro Features

2
Table 1 Nova-Pro 100 Features
1, 2 Bezel and Lens Bezel is removable to add or remove the
oponal Laser Module
3
Laser Module
(oponal
accessory)
Internal laser used to synch the ash to
an external marker on the object under
inspecon; can also be used in Tachometer
Mode (patented technology)
4 Trigger Used to acvate the unit (when power is on)
5 Tripod Mount 1/4-20 tripod mount for hands-free operaon
6 Power Source
Baery Pack—removable; recharged in the
external baery Charger Base
or
AC Power - plug in for connuous use
7 User Interface
• LCD (Liquid Crystal Display)
• Dedicated keypad with “joysck” buon for
adjusng ash rate
• Power and Menu buons

3
 
The Nova-Pro 100 user interface consists of a large display, dedicated keys
on the user interface panel, and a trigger to acvate the unit when the
power is on. The user interface is described in Figure 2 and Table 2.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Figure 2 Nova-Pro 100 User Interface

4

16-digit display used to display ash rate and other numeric values
2Lock icon—acve when the device is locked on
3On-Target indicator—acve when the input/laser is locked on to a target;
also used to indicate current selecon in the menus
4Laser icon—indicates that the laser is armed (ashing) or on (solid)
5EXT icon— not used; available on the Nova-Pro 300 and 500 models
6Baery icon—acve when the baery is low
7TACH icon—acve when Tachometer Mode is selected
8PHASE icon — not used; available on the Nova-Pro 500 model
9x2, ÷2 and arrows—used to indicate joysck (11) funcon
10  buon—turns the unit on/o; used as escape/back buon in
menus and trigger lock
11 Joysck—adjusts ash rate; also used for menu navigaon
12 Trigger—used to acvate the unit when the power is on
13 MENU buon—allows access to the menus; also used to conrm selecons
14 Temperature icon—acve when the system is overheated; see secon 10.1
15 TIME icon — not used; available on the Nova-Pro 500 model
16 AUTO icon— not used; available on the Nova-Pro 500 model
17 CAL icon — acve if the unit requires calibraon
18 5-digit alphanumeric display used for general messaging
19 Engineering units — for brightness sengs
MENU buon POWER buon On-Target indicator Joysck arrows

5
 
 
The baery-powered Nova-Pro has a removable
Baery Pack that should be charged before use
(see secon 7.0 BATTERY PACK). The Baery Pack
is keyed to ensure correct inseron into the Nova-
Pro and Baery Charger. Make sure to remove the
tape protecng the baery terminals and charge the
baery before use.
The AC-powered Nova-Pro has an external power
adapter that must be plugged into an AC outlet
(100-240 Vac) using the appropriate connector.
Interchangeable plugs allow for operaon in most
countries (see secon 8.0 AC POWER OPTION).
With the power source (baery or AC) inserted into the Nova-Pro,
turn the unit on by pressing and holding the POWER buon unl the
display illuminates, then release the buon. To operate the unit, pull
the trigger.
The unit can be locked in connuous operaon by pressing the POWER
buon while squeezing the trigger, then holding the POWER buon as
you release the trigger so the Lock icon will show on the display.
To remove the lock, simply pull the trigger.
To turn the unit o, press and hold the POWER buon unl the
display shows OFF and then release. The unit will automacally power
o aer 3 minutes.
MENU buon POWER buon On-Target indicator Joysck arrows

6
4.0 MODES OF OPERATION
The Nova-Pro 100 has a single mode of operaon (, UNLESS the
oponal Laser Module is installed in the unit. This adds two addional
modes:
LASER—uses the laser beam to trigger the stroboscope so that the ashes
may be synchronized to an external target such as a keyway in a sha or a
piece of reecve tape on a fan blade.
TACH (Tachometer)—uses the laser to measure the speed of a rotang or
reciprocang target using reecons from a keyway in a sha or a piece of
reecve tape on a fan blade.
The mode of operaon is selected in the MODE menu (see secon 5.2
MODE Menu).
4.1 STROBE Mode
In this mode, the strobe generates the ash rate set by the user. The
strobe will not ash unl the trigger is depressed. The user can set the
ash rate as follows:
 
Pressing any buon on the joysck will cause a digit on the display
to start blinking—this is the digit that will be edited. There is a
rollover eect when the digit is changed—if incremenng the
units, digit 99 will roll over to 100. If the user does not increment or
decrement a digit within 5 seconds, the edit mode will be canceled.
MENU buon POWER buon On-Target indicator Joysck arrows
MENU buon POWER buon On-Target indicator Joysck arrows

7
Press ◄or ►to change
the digit that blinks.
Press ▲or ▼ to increase
or decrease the value of
the blinking digit. Hold
for auto increment or
decrement.
To conrm that the strobe is ashing at the same rate that the
target is moving and that the RPM/RPS reading is accurate, use the
x2 buon unl you see a double or mulple image, then use the
÷2 buon unl you see a single image. This will now be the correct
speed (see Figure 3).
Press the MENU buon.
Use the joysck to x2 or ÷2.
 
Press the MENU buon and the display will show the x2 and ÷2
icons. Use the le ◄and right ► buons on the joysck to double
or halve the ash rate. Press the POWER buon to exit this mode.
MENU buon POWER buon On-Target indicator Joysck arrows

8
Figure 3 Object rotang at 3000 RPM
If doubling or halving the ash rate causes the strobe to
exceed its range, the display ash rate will remain at the
current ash value.
 (oponal accessory)

installed. This mode uses the LASER to trigger the strobe ash.
Laser icon will blink when Laser Mode is enabled and be on
solid when trigger is pulled and laser is on.
By pulling the trigger and aiming the laser at a reecve target on the
rotang or reciprocang machine, the strobe will ash each me a
reecon is received allowing the user to virtually “stop moon”. On-
Target indicator will show on the display when target is detected by
laser.
The ash rate (speed) will be displayed in the selected units (see
Figure 4).

MENU buon POWER buon On-Target indicator Joysck arrows
MENU buon POWER buon On-Target indicator Joysck arrows

9
Figure 4 Using the Laser Module
 
                                                          
is installed. This mode uses the laser to measure rotaonal speed.
Tachometer icon will show on the display when the Nova-
Pro is in TACH Mode.
Unit will NOT FLASH in Tachometer Mode.
Laser icon will blink when Laser Mode is enabled, and will be
on solid when trigger is pulled, acvang the laser.
Pull the trigger and aim the laser at a reecve
target on a rotang or reciprocang machinery. The
speed will be displayed in the selected units.
On-Target icon will show on the display when the
target is detected.
Refer to Figure 4 Using the Laser Module and associated warnings.
TACH
TACH
RPM
3600
MENU buon POWER buon On-Target indicator Joysck arrows
TACH
RPM
3600
CAUTION
• AVOID EXPOSURE—LASER RADIATION IS EMITTED FROM
THIS APERTURE
• 
• DO NOT AIM AT AIRCRAFT

10
5.0 MENUS
5.1 Menu Overview
The menu that shows is dependent on the current operang mode of
the unit and whether the Laser Module is installed.
To enter the menus, press the MENU buon once or twice depending
on the current mode (see overview above) unl the word SEtUP
appears on the top line of the display. To enter StrobE, LASEr or tACH
 , press the MENU buon again, then the down
arrow ▼, and MENU buon, to enter that mode. Not all items will be
available in the menu; it depends if the Laser Module is installed.
Once in the opons menu, use the ▲ and ▼ arrows on the joysck to
scroll through the dierent available menu opons.
MENU buon POWER buon On-Target indicator Joysck arrows
MENU buon POWER buon On-Target indicator Joysck arrows
RPM

11
Press the MENU buon to enter menu opons and make selecons.
Press the POWER buon to escape or back out of the menus.
On-Target icon will show which menu opon is selected.
The following secons describe the individual menu opons.
 

MODE choices are: tACH (Tachometer), StrobE or LASEr. The modes
are described in secon 4.0 MODES OF OPERATION.
Press the MENU buon to enter the MODE menu. The top line
will show the mode and the On-Target indicator will be on for the
currently selected mode.
Use the ▲and ▼ arrows on the joysck to select the desired mode.
Press the MENU buon to select the desired mode. This will change
the mode and exit the menu.
Press the POWER buon to escape without changing the mode.
 
Refer to 6.0 STROBE BRIGHTNESS for details on brightness and ash
duraon before using this feature.
The Brightness (BRITE) menu opon sets the ash duraon which
aects the brightness. Flash duraon can be adjusted in degrees of
rotaon (proporonal ash duraon—changes with ash rate) or me
in milliseconds (msec—xed ash duraon). The ash duraon will be
set by the last ash duraon value adjusted. If you adjusted degrees,
the strobe will have a ash duraon in degrees proporonal to the
MENU buon POWER buon On-Target indicator Joysck arrows

12
ash rate. If the adjustment was in me, the strobe will have a xed
duraon irrespecve of the ash rate.
This is a live adjustment—if the trigger is depressed, the eect of
changing the brightness can be seen immediately.
 
Press the MENU buon to enter the BRITE menu. The current ash
duraon will be shown in degrees.
Use the arrows on the joysck to adjust the ash duraon
in degrees - refer to 4.1.1 Joysck. Degrees can be set from 0.1°
to 14°.
Press the MENU buon followed by the POWER buon to save the
degree seng.
 
To set the ash duraon in me instead of degrees, press the MENU
buon again (skip the DEG menu).
Use the arrows on the joysck to adjust to the me value. Time can
be set from 0.001 msec to 2.000 msec.
Press the MENU buon followed by the POWER buon to save the
me seng.
 
The Decimal Point menu adjusts the resoluon of the ash/tach rate
displayed. Up to three places aer the decimal point can be shown.
The number of decimal places is limited by the 6-digits available and
the unit will auto range to show the maximum number of digits aer
the decimal point selected by the user. The choices are NONE, 1, 2, 3.
MENU buon POWER buon On-Target indicator Joysck arrows
MENU buon POWER buon On-Target indicator Joysck arrows

13
A value of 600 will be displayed as 600, 600.0, 600.00, 600.000
depending on the seng.
Press the MENU buon to enter the DECPT menu. The current value
is shown on the top line with DECPT on the lower line. The On-Target
indicator will be on for the currently selected value.
Use the arrows on the joysck to select the desired value.
Press the MENU buon followed by the POWER buon to save the
decimal point seng.
To exit without seng the units, press the POWER buon.
5.5 UNITS Menu
This menu opon selects the Engineering Units used to display the
ash rate or speed. The choices are:
FPM Flashes per Minute (not available in TACH Mode)
FPS Flashes per Second (same as Hz, not available in TACH Mode)
RPM Revoluons per Minute
RPS Revoluons per Second (same as Hz)
Press the MENU buon to enter the UNITS menu. Unit is shown on the
top line with the current engineering unit on the lower line. The On-
Target indicator will be on for the currently selected value.
Use the arrows on the joysck to select the desired value.
Press the MENU buon followed by the POWER buon to save
the value.
To exit without seng the units, press the POWER buon.
MENU buon POWER buon On-Target indicator Joysck arrows

14
6.0 STROBE BRIGHTNESS
The strobe’s brightness depends on how wide the strobe’s ash pulse is;
the wider the pulse, the brighter the ash from the LEDs appears to be.
There is however, a downside to the wider pulses. All strobes work by
giving short bursts of light (the pulse width) at a rapid repeon rate (the
ash rate). Strobes rely on the persistence of the human eye (the ability to
remember an image) and its response to bright light to give an apparent
stop moon image. Imagine a sha rotang at 6000 RPM or one rotaon
every 1/100 of a second (10 msec). If the strobe ashes once every 10 msec
for a brief moment, the user sees the ash at the same spot in the rotaon
of the sha and the persistence of the eye remembers this unl the next
ash making the sha appeared to be stopped. As the target is rotang,
there is some movement evident during the strobe ash. The longer the
ash duraon, the more obvious the rotaon is and this increases the blur.
 
Blur can be calculated–if the sha is turning at 6000 RPM, it takes 10
msec to complete one revoluon. If the strobe ash duraon is 100
µsec (1/100 of a millisecond), the sha will turn:
(ash duraon/me per rotaon) x 360°, which is
(.0001/.01) x 360 = 3.6°. So you will see the sha
appear to move 3.6°.
As the ash pulse widens you will see greater
degrees of rotaon which results in more blur
and a brighter perceived illuminaon (the LEDs
are on longer so the average light the eyes see is
greater). The trade o is blur versus brightness.
The further away the rotang point is from the
center axis the faster the tangenal velocity and
the worse the blur appears to be.
MENU buon POWER buon On-Target indicator Joysck arrows
MENU buon POWER buon On-Target indicator Joysck arrows

15
When seng the pulse duraon in degrees, what you set is what you
get. Refer to the image on the right for the dierence between a 1° and
5° (of rotaon) ash duraon.
There are two methods of adjusng the ash pulse width and hence
the brightness and consequently the blur. For seng Brightness see
secon 5.3 Brightness (BRITE) Menu.
 
Brightness can be set from 0.2 to 14° out of 360. The higher the seng,
the brighter the strobe appears to be but the more blurred the target is.
Opmal seng to stop moon is 1.8 to 3.6°. The number of degrees is
a proporonal amount and remains constant as the ash rate increases
or decreases. The strobe automacally calculates how wide the pulse
width should be at dierent ash rates to keep the blur constant—the
faster the ash rate, the narrower the pulse width. The pulse width
equals (seng in degrees/360) x (1/ash rate in Hz).
 
Brightness can also be set to a xed duraon pulse in milliseconds. The
ash rate remains constant irrespecve of the ash rate, thus as the
ash rate increases, the image will get brighter and more blurred.
There are two limits maintained by the strobe—the ash pulse
width can never be greater than 2.0 msec (milliseconds) nor can
it exceed 14° of rotaon.
The strobe automacally adjusts the pulse width and rotaon values
as the ash rate is increased or decreased to maintain the limits at all
mes. For example, a ash rate of 600 ashes per minute (10 Hz), 14°
of rotaon represents a ash pulse width of 3.8 msec. The strobe will
limit this value to 2.0 msec or 7.3° of rotaon (blur).

