Monitor Audio WT280 User manual

Custom nsta saies
INSTALLATION GUIDE
GUIDE D'INSTALLATION
GUIDA INSTALLAZIONE
INSTAL LAT I0 N SHAND B U C H
MANUAL DE INSTALACION
GUIA DE INSTALAQAO
HANDLEIDING INSTALLATIE
~~1~~
PyKOBO.QCTBO no ycTaHOBKe

Pri or to Fitt in g the Custom In st all S eri es Sp eaker s
CAUTION: These Custom Install loudspeakers can only be fixed into plasterboaro (dry-lined) or suspended
ceilings/ walls with a thickness of up
to 45mm (1
3 14
"). Solid wall installation will require channeling out and frame
work constructed
to provide a structure for the Tri Grip® dog legs to clamp to . For safety reasons, if you are unsure
of your ability to provide a secure and safe fixing, do not attempt to fix these speakers, please obtain the services
of a competent and qualified trades person.
CAUTION: Ensure that there are no water pipes orelectricity cables running within the wall structure before cutting
the speaker apertures. Work from secure steps and avoid trailing wires.
Ove r lig h ten ing W arni ng
& ATTENTION INSTALLERS:
Do not over-tighten theTri-Grip Dog Leg clamps. Over tightening the clamping mechanism on any in ceiling/ in wall speaker
can result
in damage to the speaker mounting hardware, ceiling/ wall or speaker frame, and/ or deflection in the speaker
frame during installation.
If you notice any
of the above during installation, you have overtightened the Tri Grip dog leg. Back off the mounting screw
until deflection is reduced
to allow the product to sit firmly against the ceiling I wa l l.
& Do not exceed 5Kgf/cm (4.34 lbf/inch.) or 0.5 NM when tightening the Tri Grip dog leg screws.
When are using a cordless screwdriver/ drill to install this product ensure the clutch is set to it's lowest setting to avoid from
over-tightening and damaging the mounting hardware.
x®
Pa i nting the Grilles
& NOTE: If choosing to paint the grille, we recommend you follow these simple steps:
1. Remove the membrane scrimfrom the inside of the grille.
2. Paint
all grilles required for the installation with the same batch of paint (if they are to be the same colour). Spray paint
is easier to apply or use a stippling action when brushing to avoid blocking the holes of the grille.
3. When
dry, attach the spare membrane scrim (supplied) into the inside ofthe grille.
4.
Fit the grille to the speaker (s) .

Fi tting the Custom Instal l Loudspeakers
0
Draw around template and mark
cen tr e l ines if necessary
I
0 ~C?~If<?~ . ~~~~C! ·
CUSTOM INS T A~LATION SERIES
i
I
i
i
m
·- · ~ J Wl - ,~
CT280-IOC,CT380-IDC.CT380-FX CT180,CT18<l-T2,<=n80
8 Connect speaker cables by pushing
down on the terminals and clamping
the bare wire in the through hole.
8 11gh t en 3 Tr i- Gr ip sc r ews on the
in ceil in g models or the 6 Tr i-Grip
sc re ws on th e in wa ll mode ls .
See ove r
& t ig ht~ning
warn 1n g.
f) Cut around marked li ne
0 Gu i de speake r into cu t out
G Fit gri l les. They are he ld in pl ace
magnetically and should 'snap' into
p lace.
•
-

Monitor Audio Ltd.
24 Brook Road
Rayleigh, Essex
SS6 7XJ
England
Tel :[phone]
Fax : [phone]
Email : info@monitoraudio . co . uk
Designed and Engineered in the United Kingdom
© Monitor Audio.
Vers i on 1 201 2

MONITOR
AUDIO
®
monitoraudio.com
CUSTOM
INSTALLATION
SERIES
Tri-Grip x 6
=
5Kgf/cm; 4.34 lbf/inch; 0.5 NM
------------------t-------------------
234mm
(9
3116
")
1
93mm
(3
11
116
")
WT180, WT280, WT280-IDC
97.5mm
(3
13116
")
WT380-IDC
I
I
387mm
(15
114
")

0 MONITOR AUDIO LTD
24 BROOK ROAD
RAYLEIGH
ESSEX SS6 7XL
·ENGLAND
PLEASE AFFIX
STAMP HERE

t
Q)
c:
~
c:
0
"0
0
u..
"0
c:
co
Q)
~
Q)
:I:
c:
5
(/)
·c;
~
.MONITOR
AUDIO Limited Warranty/Registration card
To
validate
your
warranty
please
fill
in
this
card
(using
block
capitals)
and
tick
boxes
where
applicable.
Alternatively,
you
can
register
on
line
at
www.monitoraudio.co.uk
Should you
wish
not
to
be contacted
by
us
either
by
post, e-mail
or
phone, please
tick
this
box.
0
Personal
Details
Title
M-.
0
Mrs.
0
Ms
0
Other
..............................................................................................
..
First Name
....................................
..................................
Last name
...................................................................................
.
Ad~ress
.......................................................................................................................................................................................
.
Town
...............................................................................
State/County
..............................................................................
.
Zip/
Post Code
...............................................................
Country
Product
details
~
..........................................................................
,
........
~al
Number
............................................................................
.
Date
of
Purchase
.........................................
Shopwhere purchased
.........................................
:
..............................
.
Which
related
magazines
do
you
read?
.........................................................................................................................
..
·
What
is
the
intended
use
of
the
speakers?
Music
Is
the
purchase?
Replacement/ Additional purchase
What
made
you
pur~hase
Monitor
Audio?
Existing owner
Dealer
recommendation
0
0
Movies 0 Both
0 Your
first
purchase
0
Magazine review
0
·0
0
Ottler please specify
....................................................................................................................................................................
..
What
music
do
you
like
listening
to?.
Jazz
Ocountry
Oclassical
.0
Rock/Pop
0
Your age is?
16-25
0
26-35
0
36-55
0
55+0
_
Your
amp/receiver
is?
.................................................................................................................................................................
..
Your CD/DVD
player
is?
...............................................................................................................................................................
..
Thank you
for
your
time.
If
you have any
further
comments
about
our
products
please use
the
space below.
Moisten Here
t

m
MONITOR
AUDIO®
design
for
sound
IMPORTANT SAFETY INSTRUCTIONS
GB -SAFETY INSTRUCTIONS
FR-
CONSIGNES DE SECURITE
IT-
ISTRUZIONI PER LASICUREZZA
DE -SICHERHEITSANWEISUNGEN
ES -INSTRUCCIONES DE SEGURIDAD
PT-
INSTRU<;OES DE SEGURAN<;A
NL-
VEILIGHEIDSINSTRUCTIES
CH-
~~~B~
RU -
lllHCTPYKL\111111
no
TEXHII1KE 6E30nACHOCTII1
RU -YCnOBV1fl
rAPAHTV1111
SPEAKERS

IMPORTANT SAFETY INSTRUCTIONS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Please read these instructions.
Please keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus with water.
Clean only with a dry cloth. Great care and attention has gone into the
materials chosen to produce your Monitor Audio loudspeakers. A gentle
wipe with a
dry, clean cloth is all that is required to remove any dust. Treat
them as you would a fine piece offurniture because that
is howthey have
been designed.
To clean the high gloss finishes use our "Lacquer Polish"
that has been developed alongside Auto Glym.
It can only be purchased
from the online shop at www.monitoraudio.com (UK customers only).
Do not install near any heat source, such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Only use attachments/ accessories specified by Monitor Audio.
Use only with the cart, stand, tripod, bracket, or table <I
specified by monitorAudio or sold with the apparatus. When
a cart
is used, use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
Refer all servicing
to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power supply cord or plug
is damaged, liquid has been spilled or objects
have fallen onto the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally or has been dropped.
This apparatus shall not
be exposed to dripping or splashing
water and that no object filled with liquids such as vases shall be placed
on the apparatus.
This exclamation point within an equilateral triangle &
is intended to alert the user to the presence of important f
maintenance (servicing) instructions in the literature •
accompanying the appliance.
No naked flame sources, such as lighted candles, should be placed.
on the apparatus.
RE-CYCLING
Correct Disposal ofWaste Electrical and Electronic Equipment (WEEE) by User
in Private Households in the EU.
This symbol on the product or accessories indicat~s
that they must not be disposed of with your household
wastes throughout the
EU. To prevent possible harm to
the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable
reuse of material resources. Instead it
is your responsibility
to dispose of your waste equipment by handing it over
to a designated
WEEE collection point for recycling. The
separate collection and recycling of your waste equipment
will help conserve natural resources and ensure that it
is
recycled in a manner that protects human health and the environment.
For more specific information about where you can take your equipment for
recycling please contact your local city/council office, your local waste disposal
service or the outlet where you purchased your Monitor Audio product.
ROHS DECLARATION OF CONFORMI1Y
· Directive 2011/65/EU of the European Parliament and of
the Council on the reduction ofthe use ofcertain hazardous
substances
in electrical and electronic equipment, June
2011.
Background
RoHS2
COMPLIANT
2011/65/EU
The RoHS directive restricts the use ofLead
(Pb), Cadmium (Cd), Mercury (Hg),
hexavalent Chromium (CrVI), polybrominated biphenyl (PBB) compounds, and
polybrominated diphenyl ether
(PBDE) compounds in electrical and electronic
equipment sold
in the European Union.
monitoraudio.com 1

GUARANTEE
AND
SERVICE
To
validate your warranty please visit www.monitoraudio.com within 30 days of
purchase.
When you register online you'll gain free entry to our monthly prize draw!
What's more you'
II
be the first to hear about the great things happening at
Monitor Audio, including new products and events!
This equipment has been fully tested prior to dispatch from the factory.
Both the craftsmanship and the performance of this product
is
guaranteed
against manufacturing defects for the period of
five years
from the date of
purchase
(see
conditions below), provided that the product was supplied by
an
authorised Monitor Audio retailer under the consumer sale agreement.
(The
words 'consumer sale' shall be construed
in
accordance with section 15 of
the supply of goods act 1973). Monitor Audio accepts no responsibility for
defects arising from accident, misuse, abuse, wear and
tear,
modification or
operation outside of that specified within this instruction manual. Neither
will
responsibility be accepted for damage or loss occurring during transit to or
from the parties claiming under this guarantee.
This guarantee covers both labour and parts. The liability of Monitor Audio
is
limited to the cost of repair or replacement of the defective parts
(at
the discretion of Monitor Audio) and under no circumstances extends to
consequential losses or damage.
CLAIMS
UNDER
THIS
GUARANTEE
The equipment should be returned
in
its original packaging to the original
supplier where possible, or to any other authorised Monitor Audio
dealer.
If
it
is
not possible to return the equipment by hand, then
it
should be sent
carriage prepaid via a reputable
carrier.
If
the original packing
is
not available
replacement packaging can be purchased from Monitor Audio.
If
you have any difficulties complying with these requirements please contact
us
at the following address:
Customer Service
Monitor Audio Ltd.
24 Brook Road
Rayleigh
Essex, SS6
7XJ
England
Tel:
[phone]
Fax:
[phone]
40589
Internet: www.monitoraudio.com
Email:
[email protected].uk
Th1s
guarantee does not affect the statutory rights of the consumer under UK
law.
DATA
PROTECTION
We
at MonitorAudio
are
committed to respecting the wishes and privacy ofour
customers. Ahy information you provide will be held
in
the strictest confidence
and only used within the Monitor Audio organisation for the provision of
services such
as
warranty claims or spare parts.
We
may wish to contact you
in
the future to ensure you are happy with the
products and standards ofservice we provide and to keep you up-to-date with
the latest products and promotions we have to
offer.
Should you wish not to be contacted by us either by post, e-mail or phone,
please tick the box on the warranty form on the web site. Alternatively you can
request not to be contacted
in
futu.re
by writing to Customer Service, at the
address above.
2 Important Safety Instructions

EC Declaration of Conformity
We, Monitor Audio Ltd.
24 Brook Road
Rayleigh
Essex
SS6 7XJ
England 12
Declare in own responsibility, that the Monitor Audio products
described
in this manual is in compliance with Technical Standards/
Council Directives:
(LVD) 2006/95/EC Low Voltage Directive
EN60065: 2002+A1: 2006 Safety requirements for mains operated
electronic and related apparatus for household and similar use.
(EMC) 89/336/EEC Electro Magnetic Compatibility
EN55013: 08.90+A12:08.94+A13:12.96 Limits and methods
of
measurement of radio disturbance characteristics of broadcast
receivers and associated equipment.
EN55020: 12.94+A11:12.96 Electro magnetic immunity of
broadcast receivers and associated equipment.
EN61000-3-2: 04.95+A1:1998+A2:1998 Electro magnetic
compatibility
(EMC)- Part 3: Limits- Section 2: Limits for harmonic
current emissions (equipment input current up to and including 16
Ampere per phase).
EN6100-3-3: 01.95 Electro magnetic compatibility (EMC)- Part 3:
Limits -Section 3: Limits of voltage fluctuations and flicker in low-
voltage supply systems for equipment with rated current up and
including 16 Ampere per phase.
Signedby: ~
Name: D.S. Hartley
Position: Technical Director
Company: Monitor Audio Ltd
monitoraudio.com 3

m
MONITOR
AUDIO®
monitoraudio.com
Monitor Audio Ltd.
24 Brook Road
Rayleigh, Essex
886
7XJ
England
Tel:
[phone]
40580
Fax:
+44
(0)1268 740589
Email: [email protected]
Web: www.monitoraudio.com
Designed
in
the United Kingdom
©
2012. Version 3
